GE G005 User manual

GEAppliances.com
Safety Instructions .......... 2,s
Operating Instructions
Appliance Communication ....... 10
Care and Cleaning
of the Washer .................... ii
Features ........................... 7
Loading and Using
the Washer ........................ 8
Operating instructions .......... 4-6
Troubleshooting Tips..... 12-14
Consumer Support
Consumer Support ................ 16
Parts and Accessories ........... 3, 16
Warranty .......................... 15
Printed in the United States
ENERGYSTAR
As an ENERGY STAR @partner,
GEhas determined that this
product meets the ENERGYSTAR@
guidelines for energy efficiency.
Write the model and serial
numbers here:
Model #
Serial #
You can find /'--'--7
them under
the lid of the
washer.
49-90486-105-13GE

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
m
Thisisthe safety alert symbol. Thissymbol alerts to potential hazards that can kill or hurt and others. Allsafety
you you you
messageswill follow the safety alert symbol and the word "DANGER","WARNING",or "CAUTION".Thesewords are defined as:
Indicates a hazardous situation which, if not avoided, will result in death or serious inJury.
Indicates a hazardous situation which, if not avoided, could result in death or serious inJury.
_ Indicates hazardous situation which, if not avoided, could result in minor moderate
aor inJury.
IMPORTANT SAFETYINSTRUCTIONS
To reduce the risk of death, fire, explosion,electric shock,or injury to persons when using your appliance,
follow basic precautions, including the following:
[] Readall instructionsbeforeusingtheappliance.
[] DONOTwash or dry articles that have been previously cleaned in,washed in,soaked in or spotted with gasoline, dry-
cleaning solvents, or other flammable or explosive substances, as they give off vapors that could ignite or explode.
[] DONOTadd gasoline, dry-cleaning solvents, or other flammable or explosive substances to the wash water. These
substances give off vapors that could ignite or explode.
[] Under certain conditions, hydrogen gas may be produced in a hot-water system that has not been used for 2 weeks
or more. HYDROGENGAS ISEXPLOSIVE.If the hot water system has not been used for such a period, before using a
washing machine, turn on all hot-water faucets and let the water flow from each for several minutes. This will release
any accumulated hydrogen gas. As the gas is flammable, DO NOTsmoke or use an open flame during this time.
[] DONOTallow children to play on or in this appliance. Close supervision of children is necessary when this appliance is
used near children. Before the washer is removed from service or discarded, remove the door or lid. Failure to follow
these instructions may result in death or injury to persons.
[] DONOTreach into the appliance if the tub or agitator is moving to prevent accidental entanglement.
[] DONOTinstall or store this appliance where it will be exposed to the weather.
[] DONOTtamper with controls, repair or replace any part of this appliance or attempt any servicing unless specifically
recommended in the user maintenance instructions or in published user repair instructions that you understand and
have the skills to carry out.
[] Keepthe area around your appliance clean and dry to reducethe possibility of slipping.
[] DONOToperate this appliance if it isdamaged, malfunctioning, partially disassembled, or has missingor broken parts
including a damaged cord or plug.
[] Unplug the appliance or turn off the circuit breaker before servicing. Pressingthe Power button DOESNOTdisconnect power.
[] See "Electrical Requirements" located in the Installation Instructions for grounding instructions.
SAVETHESE INSTRUCTIONS
2

GEAppliances.com
PROPERINSTALLATION
This washer must be properly installed and located in accordance with the Installation Instructions before it is used.
If you did not receive an Installation Instructions, you can receive one by visiting GEAppliences.com or by calling
800.GE.CARES(800.432.2737).
[] Ensurethat the hot water hose isconnected to the "H"
(internalred screened)valve and the cold water hose is
connected to the "C"(internal blue screened)valve.
[]
[]
Installor store where it will not be exposed to
temperatures below freezing or exposed to the weather,
which could cause permanent damage and invalidate the
warranty.
Properlyground washer to conform with all
governing codes and ordinances. Follow details
in Installation Instructions.
_ - Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
DO NOT remove ground prong.
DO NOT use an adapter.
DO NOT use an extension cord.
Failure to do so can result in death, fire or electrical
shock.
[] Optional drain hoseextension recommended for
discharging heights from 60" - 96"
[] This washer does not include water supply hoses.
GEstrongly recommends the useof factory specified
parts.A list of factory hoses availablefor purchase are
listed.These hosesare manufactured and tested to meet
GEspecifications.
GEstrongly recommends the useof new water supply
hoses.Hosesdegrade over time and need to be replaced
every 5 years to reduce the risk of hosefailures and water
damage.
Parts end Accessories
Order on-line at GEApplionceports.com today, 24 hoursa
day or by phone at 800.626.2002during normal business
hours.
Port Number
PH!4X!O002
Or
PHI4XIO005
WH49X301
Accessory
4 ft RubberWater Supply Hoses
4 ft BraidedWater Supply Hoses
Drain Hose Extension
WX10X10011
WX7X1
DR07X10005
Tide®Washing Machine Cleaner*
Washer FloorTray
6' Cable
4FUNCTIONALITYCHECK
[] If the lid isopened between cycles(i.e.not pausing and
restarting the current cycle, changing cycles after it
started, etc.)pushingthe Start button will cause the
washer to turn on the cold water for 5 secondsfollowed
by a 10 second delay before locking the lid and starting
the cycle.
[] If the lid isopened during this !5 second period,the word
PAUSEwill start scrollingacross its display.Youwill have
to pushthe Start button again to restart the cycle.
jWHEN NOT IN USE
[] Turn off water faucets to minimize leakage ifa break or
rupture should occur.Checkthe condition of the fill hoses;
GErecommends changing the hoses every 5 years.
SAVE THESE INSTRUCTIONS
* Tide®is a registered trademark of Procter & Gamble 3

Operating instructions.
Throughout this manual, features and appearance may vary from your model.
Step 1
• Add fabric softener to the fabric
softener dispenser; see page 7.
• Add detergent. GErecommends
the use of High Efficiency
detergents in all Energy
Star-rated washers.
Step 2
• Looselyadd itemsaround infusoff".
Overloading may negatively impact
wash performance. _ee page 8 for
suggested loading examples.
. Close lid.
NOTE:Washer will not fill with lid
open.
Normal
ig_-t co_ors
Stort Whites
Dark ColorsHeavy Duty
Pause
(Unlock Lid} Jeans
Towels /Sheets
BuIky items
Quick Rinse
Drain & Spin
Delicate }ASKETcleon
Step 3 _ O.
CD
CZD
. Select wash cycle.
. Select wash options,
including Fabric
Softener option.
Step 4
. Press Start.
Controls
Power
Pressto "wake up" the display. Ifthe display is active, press to put the washer into idle mode.
NOTE:Pressing POWERdoes not disconnect the appliance from the power supply.
Start and Pause
PressStart to beginthe cycle.NOTE:The lid must be closed for the washer to filland the cycle to start, tf the lid is open, "LID"will scroll across
the display. If the lid isclosed,the lidwill lock, the detergent will be dispensed,and "FILL"will scroll acrossthe display.
PressingStart again will Pause the cycle and the Start indicator light will blink.
Tocontinue the cycle, pressStart again. Ifmachine ispaused more than 24 hours, the cycle will be cancelled. Ifwater remains inthe machine,
selectthe Drain &Spin cycle to drain tub and spinwater out of the washer tub.
Display and Status Lights
Display:
The display shows the approximate time remaining until the end of the cycle.
NOTE:Thecycle time isaffected by how long it takes the washer to fill.This depends on the water pressure in your home. The"smart" timer
"learns"the amount of time it takes to fillyour washer and adjusts the total time accordingly.
In addition, this display will, "scroll" the washer status:
•bALAnCINg Start of rebalancing cycle to redistribute clothes.Stops after rebalancing is complete.
•CYCLEPrEP Sensingdry load size prior to fill (normal).
•dELAY When Delay Wash isinitiated. Replacedwith estimated time when cycle starts.
•End Endof current cycle.
•ES Washer in a delay start (4 hour maximum) awaiting lower energy rates (seethe Energy Smart section).
•FILL Forthe first 45 secondsof afill,the estimated end of cycle time isdisplayed. Forthe rest ofthe fill time, "FILL"isscrolled
until the fill completes.
•H20 SUPPLY Cannot sensewater level (valvespossibly turned off).
•Lid Cyclestopped because lid isopen. Closethe lid.
•LOAdSenSE Sensingwet load size(normal).
•PAUSE Cyclepaused because the Start/Pause button was pressedand the washer was setto Pause. PressStart button again to
restart the cycle.
Cyclestatus lights:
Showswhether the washer is inthe SOAK,WASH,RINSEor SPINcycle.
Feature status lights indicate (seesectionsFand G formore details):
EnergySmart® TheEnergy Smart feature is selected.Seethe About Appfiance Communication section.
Lid Locked Thewasher is locked - will blinkonce if you pressany button or turn the cycle knob.

GEAppliances.com
Wash Cycles-Cycle Selector Knob
Thewash cyclecontrols the type of washing process.TheCycleSelector knob can be turned in either direction. Turningthe knob after
starting acycle will stop the washer and change the cycle/options to the new selection.PressStartto begin the new cycle selection.
NOTE:When the knob isturned to another cycle,the tub light isturned on to assist in loading.
Thechart below will helpyou match the wash cycle setting with your clothing.
Speedwash For smallloads of lightly soileditems that areneeded inu hurry.Provideslightwash/rinse and short high speedspin.
Delicates For lingerieand special-curefabrics with lightto normal soil.Provideslightwash and low speedspin.
Jeans For washing medium to lightly soiled jeans. Providesnormal wash and medium speedspin.(Forheavily
soiled workjeans, use Whites cycle.)
HeavyDuty/HeowSoil An above normal cycle for heavilysoiled or stained clothes.A soak cycle isadded and the agitate cycle is extended
for extra cleaning.This more aggressive cycle should be usedsparingly.
Dark Colors For non-colorfast cottons and blends or items that are labeledcold wash. Providesnormal wash and medium speed
spin.
Whites For heavy to lightly soiled whites, household linens, work and play clothes. Provides a heavy wash and a high
speedspin.
Normal/LightColors For heavy to lightly soiled colorfast cottons, household linens,work and play clothes.Thiscycle providesthe best
overallcleaning and should be usedfor most everydayitems.Providesnormal wash and mediumspeed spin.
Towels/Sheets Provides periods of agitation and soak tailored for washing towels and sheets. Providesnormal wash and a
high speed spin.
Bulky Items/ For large coats, bed spreads, mattress covers, sleeping bags and similar large and bulky items. Large items
Comforters, Pillows such as blankets, comforters, jackets and small rugs. Provides a normal wash and an extra heavy spin.
Quick Rinse Rinsesand spins non-soiled items where o rinse only isdesired. Provides on extra light wash and on
extra high speed spin. Fabric Softener and Extra Rinseoptions ore availablewith this cycle.
Drain & Spin Fordrainingthe tub and spinningwater out ofthe clothes.
BASKETcleon Use for cleaning the basket of residue and odor. Recommended use of at least once per month.
NOTE:Never load laundry while using BASKETcleon.The laundry may become damaged or contaminated.
Seethe Core and Cleaning section.
Settings
Individual settings for agitation (Soil),water temperature (Temp), and spin (Spin) can be set from the minimum (lowest in column) to
maximum (highest in column). In general, the higher up the column, the more washer energy will be used.
NOTE:Higher Spin speeds typically reduce dryer time/energy usage (i.e.reduces total energy when using both o washer and o dryer).

Operating instructions.
Cycle Options
Delay Wash
WhentheDelayWashbuttonisrepeatedlypressed,thedelaytimeissetfrom 1(01H)to9 (09H)hoursandbackto clear(00H)hours.Ifyou
pressandholdtheDelayWashbuttonfor] seconds,itwillimmediatelyreset.
Fabric Softener
Setthis option to provide a deeprinse or when manually adding fabric softener to the rinse cycle.NOTE:Thisoption is not allowed for some
cycles.When allowed, it may change other settings (e.g.Spin may go to a higher setting) to maximize performance.
NOTE:Do not usefabric softener dispensing balls with thiswasher. Theydo not work correctly in high efficiency washers.
eWash
When the eWash button is pressed, the cycle changes to its most energy efficient settings and all of the eMonitor lights will light to indicate
that the most efficient settings are on. Ifyou change settings, the eWash light will go off and the number of eMonitor lights will decrease (or
increase) to indicate decreased (or increased) energy efficiency settings.
Additional Options
Soak
This option beginswith a brief agitation, soaks for a specified period oftime, then moves through the rest of the cycle automatically.
Repeatedpressing of the Soak button will add 15minutes, then 50 minutes and then return back to 0soak minutes.
Extra Rinse
When you useextra detergent or bleach to clean heavily soiled clothes, usethe Extra Rinse option to better remove additional residues.
NOTE:Thisoption isnot allowed for some cycles.
Control Lock
You can lock the controls to prevent any selections from being made. Oryou can lock the controls after you have started a cycle.Children
cannot accidentally start the washer by touching buttons with this option selected.
To lock the washer controls, pressand hold both the Soak and Extra Rinsebuttons for 5seconds. Thecontrol lock icon will light up when it
ison.
To unlock the washer controls, pressand hold both the Soak and Extra Rinsebuttons for 5seconds.
NOTE: The Power button can stiff be used when the machine is locked.
Signal
Selectfor an end of cycle signal.
Automatic Load Sensing
This provides the correct amount of water suited to the size and type of load placed in the unit. The washer will not fillwith water
during automatic load sensing ifthe lid is open. When the lid is closed the machine is able to begin filling with water in order to
sense the load size.
NOTE: This is ahigh efficiency washing machine with lnfusor TM wash action. This system requires less water while providing effective
cleaning action. You may notice that the water level is lower than on your previous washer. This is normal for an lnfusorm-equipped
washer.
Average Small Load Average Medium Load Average Large Load
Clothes Level
Water Level
ClothesLevel
WaterLevel
ClothesLevel
WaterLevel
6

About washer features. GEAppliances.corn
Laundry Additives
\
Liquid Bleach
Liquid Bleach
To add liquid bleach to the next load, pour in the left
opening.
Thewater fill dilutes liquid chlorine bleach asthe
washer fillsfor the wash cycle.
J_J Check clothing care labelsfor special
instructions.
r_ Measure liquid bleach carefully, following
instructions on the bottle.
[] Neverpour undiluted liquid chlorine bleach
directly onto clothes or into the wash
basket.
[] Do not pour powdered bleach into bleach
compartment.
F31 Beforestarting the washer, pour measured
amount of bleach directly into bleach
compartment. Avoid splashing or over-filling
dispenser,tfyou prefer to use powdered
bleach,add it into the wash basket with your
detergent.
[] Do not mix chlorine bleach with ammonia
or acidssuch asvinegar and/or rust
remover.Mixing con produce atoxic gas
which may causedeath.
Softener
k Softener
Softener
To add liquid fabric softener to the next load, press
the Fabric Softener button and pour the softener
into the right opening. The liquid will be added at
the optimum time in the rinse cycle.
NOTE: if using delay mode, add liquid softener
to the dispenser and then fill the dispenser to
the MAXfill level with water.
DO NOT put detergent packets in
dispenser compartments. Laundry
detergent packets should only be added
directly to the wash tub following the
manufacturer's directions.
Detergent
Toadd either powder or liquid detergent to the
wash cycle, pour it in the washer basket.
Pretreatment
To add liquid pretreatment (e.g.OxiClean®)to the
next wash cycle, pour it in the washer basket.
F_ Check clothing care labelsfor special
instructions.
r_ Measure liquid pretreatment carefully, following
instructions on the bottle.
[] Beforestarting the washer, pour measured
amount of pretreatment directly into the
compartment.

Loading
Always follow
and using the washer.
fabric manufacturer's care label when laundering.
ProperUseof Detergent
Add detergent before adding items so that the
detergent can work effectively. Using too little or
too much detergent isa common cause of laundry
problems,
Uselessdetergent ifyou have softwater, a smaller loud
or a lightly soiled load.
GErecommends the useof High Efficiency
detergents in all EnergyStar rated washers.
HEdetergents are formulated to work with low water
wash and rinsesystems.HEdetergents reduce
the oversudsing problems commonly associated
with regular detergents.
Forspots,apply pre-treatment to itemsas recommended
on the product label.Application shouldbe made in
the basketto preventoverspruywhich may causethe
coloring on the lid or graphicsto fade.
When using high efficiency or concentrated detergents,
consult the product label to determine amount required
for optimum performance. Excessivedetergent will
negatively impact wash performance.
SortingWashLoads
Sort by color (whites,lights,colors),soillevel,
fabric type (sturdycottons, easy care, delicates) and whether the fabric produces lint(terry cloth,
chenille)or collects lint (velveteen,corduroy).
8
- Fire Hazard
Never place items in the washer that are dampened with gasoline or other flammable liquids.
Nowasher can completely remove oil.
Donot dry anything that has ever had any type of oil on it (including cooking oils).
Doing sosocan result in death, explosion,or fire.
theWasher
Load dry items loosely in the washer basket.Forbest
results,load itemsevenly and looselyaround the
outside of the basket.Toadd items after washer has
started, press Unlock Lid, lift the lid and submerge
additional items around the outside of the basket. Close
the lid and pressStart to resume.
[] Do not place large items such as sheets,blankets
and towels across the InfusorTM. Loadthem around
the outside of the basket.
[] Donot put lawn or sofa cushions into the washer as
they are too big to move.Removeouter coversand
ONLYwash them.
Loading Examples*
SPEEDWASH
JEANS TOWELS/SHEETS NORMAL DELICATES* 12-4 GARMENTS)
5 Jeans 2 Bath Sheets 4 Pillowcases 7Bras 2 Casual Wear
5 Work Wear Shirts
4 Work Wear Pants
S Bath Towels/
12 Washcloths
6 Hand Towels/
2Terrydoth Bath Mats
OR
2 Flat Queen-Sized
Sheets
2 Fitted Queen-Sized
Sheets
4 Pillowcases
2 Hand Towels
2 Flat Sheets/
2 Fitted Sheets
2 Bath Towels/
4 Washcloths
OR
6 Shirts (Men's
or Women's)
4 Pair Pants (Khakis
or Twills)
ST-shirts
7Pairs of Boxers
4 Pairs of Shorts
OR
BT-shirts
4 Pairs of Sweatpants
4 Sweatshirts
2 Hoodies
7 Pairs of Socks
7Pairs of Underwear
5 Slips
2 Camisoles
4 Nightgowns
*Using a nylon mesh
bag for small items is
recommended.
Work Shirts
1 Pair Casual Wear
Work Pants
OR
5 Soccer Uniforms

NO teS. GEAppliances.com

About Appliance Communication.
Energy Smart TM
in some select locations,electric utilities ore
beginning to run consumer trials where they
communicate directly with household appliances
to reduce energy consumption during periods of
high energy costs.Tocommunicate with on electric
utility,your home would needto be equipped
with o Smart Electric Meter,and your appliance
would need to hove on Appliance Communication
Module (ACM)installed.Smart Metersand ACM's
ore currently not available directly to consumers.
Consumers need to be solicited bytheir electric
utility before they con participate in field trials
testing these new communication solutions.
Ifyou ore part of opreviously arranged electric
utility trial where your utility isin communication
with your appliances,your appliance will receive
energy reduction signals from the utility.When the
energy reduction signal has been received,your
appliance will display on "ES"on the display and/
or the Energy Smart iconwill illuminate on the
front panel. Theappliance will respond byreducing
energy consumption or delaying the start of the
cycle.
TheEnergy Smart mode con be overridden by:
- Holding the Delay Wash button for 3seconds to
return the washer to normal operation.
Energy Smart installation and system connection
instructions are included with the ACM.
10

Care and cleaning of the washer. GEAppliances.com
Pour into the
washerbasket
/
/
/
/
/
/
/
Cleaning the Interior
of the Washer
To clean the interior of the washer, select the
BASKETclean feature on the control panel. This
BASKETclean cycle should be performed, at a
minimum, once per month. This cycle will use
more water, in addition to bleach, to control
the rate at which soils and detergents may
accumulate in your washer.
NOTE:Read the instructions below completely
before starting the BASKETclean cycle.
1. Remove any garments or objects from the
washer and ensure the washer basket is
empty.
2. Open the washer lid and pour one cup or 250
ml of liquid bleach or other washing machine
cleaner into the basket.
3_
4.
Closethe lid and select the BASKETclean
cycle. Push the Start button.
When the BASKETclean cycle isworking, the
display will show the estimated cycle time
remaining. The cycle will complete in about
90 minutes. Do not interrupt the cycle.
BASKETclean may be interrupted by pressing the
Start pad in between cycles. A power outage in
the house might also interrupt the cycle. When
the power supply is back, the BASKETclean cycle
resumes where it had stopped. When interrupted,
be sure to run a complete BASKETdean cycle
before using the washer. If the Power pad is
pressed during BasketClean, the cycle will be
lost.
IMPORTANT:
[] Run BASKETclean with ! Cup (250 ml) of
bleach once a month.
[] After the completion of a BASKETclean cycle,
the interior of your washer may have a bleach
smell.
[] It is recommended to run a light color load
after the BASKETclean cycle.
11

Before you call for service...
_roubleshooting Tips
Save time and money! Review the charts on the following pages,
or visit GEAppliances.com. You may not need to call for service.
WATER Possible Causes What To Do
Short spray and delay
after pushing the Start
button
Lid was openedand closed
between cycle selection and
start
. Thisis normal. SeeFUNCTIONALITYCHECKin the Safety
Instructions section.
Water level seems low
Banging sound during
drain
Too many suds
This is normal . Water may not cover the top levelof the clothes.
Thisis normal for this high efficiencywasher.
Drain stand pipe istoo low
Soft water
Too much detergent
Type of detergent
. Thedrain hose must exceed 32" height at some point between
the washer back and the drain pipe.
• Try lessdetergent.
. Measure your detergent carefully. Uselesssoap ifyou have
soft water, a smaller load or a lightly soiledload.
. Switchto HE@ detergent.
Water leaks Type of detergent • Switchto HE@ detergent.
Using too much detergent . Use lessdetergent. Uselesssoap ifyou havesoft water,
in washer a smaller load or a lightly soiled load.
Fill hoses or drain hose is . lake sure hoseconnections are tight at faucets and
improperly connected rubber washers are installed.Make sureend of drain hose
iscorrectly inserted in and secured to drain facility.
Household drain may . Checkhousehold plumbing. You may need to call
be clogged a plumber.
Drain hose rubs on wall . lake sure drain hosedoes not make contact with the wall.
lay cause excessivewear on the hose.
Constant water pressure . Tighten hoses at the faucets and turn the water off after each use.
to the fill hoses at the . Checkcondition of the fill hoses;they should be replaced
water source every 5 years.
Water temperature Cooler water temperatures . New laundry detergents have been formulated to work
seems incorrect provide improved energy with cooler water temperatures without affecting wash
efficiency performance.
Water supply is turned off . Turn both hot and coldfaucets fully on and make sure hoses
or improperly connected are connected to correct faucets. NOTE:Water valvesare marked
"H" and "C"and internal valve screensare color coded.
Water valve screens are . Turnoff the water source and remove the water connection
stopped up hosesfrom the upper back of the washer. Usea brush or
toothpick to clean the screens inthe machine. Reconnect
the hosesand turn the water back on.
Cool/Cold Water when . Thisis normal. PerfecTempsenseswater temperature and
selecting Hot optimizes for best results.Coldwater isadded periodically
when hot isselected.
House water heater is . lake sure housewater heater isdeliveringwater at
not set properly !20°F-!40°F (48°C-60°C).
Water pumped out before Lid lifted or cycle was put in . Resetcycle.
cycle is complete pause for over 8 hours
Water won't drain Drain hose is kinked or . Straighten drain hose and make sure washer is not sitting on it.
improperly connected . Top of drain outlet should be less than 6 ft (1.8 m)
above floor.
Washer pauses at the This is normal . The washer is sensing the load.
beginning of cycles
Washer pauses during The Auto Soak Option . This is normal. The washer alternates between agitate and
wash cycle was chosen soak during these cycles to get your clothes cleaner with
lesswear.
Washer pauses during This is normal . Thewasher may pause during the spin cycleto remove
spin cycle soapy water more efficiently.
12

GEAppliances.com
OPERATION Possible Causes What To Do
Washer does not fill This is normal . The lid must be closed for washer to fill or operate.
when lid is open
Washer won't operate Washer is unplugged • Make sure cord is plugged securely into a working outlet.
Water supply is turned off • Turn both hot and cold faucets fully on.
Controls are not set properly • Check controls.
Lid is open--safety feature • Close lid and press Start.
prevents agitation and
spinning when lid is up
Circuit breaker/fuse is • Check house circuit breakers/fuses. Replace fuses or
tripped/blown reset breaker. Washer should have a separate outlet.
Electronics need to be reset • Unplug washer, wait 2 minutes, plug back in and press Start.
Start was not pressed ,, PressStart.
Lid magnet missing ,, Call for service.
Dispenser not dispensing Laundry detergent packet . Laundry detergent pockets should not be used in the dispensers.
properly placed in dispenser They should only be added directly to the wash basket following the
manufacturer's directions.
Unexplained time and/or Changing options • This is normal. Several options will change other options to
settings changes maximize washer performance.
Movement inside machine Shifting mechanism is • When the machine is manually turned off, the shifter will
when shut off disengaging the motor disengage the motor before completely shutting down.
If lid is raised before the motor isdisengaged, it will resume
when lid is closed.
Basket seems loose Basket moves or rotates freely • Washer basket does not have a traditional brake. Basket will
move freely. This is normal.
PERFORMANCE Possible Causes What To Do
Clothes too wet Incorrect cycle selected. • Make sure the cycle selected matches the load you are
washing. Somefabrics will feel wetter when rinsedwith cold water.
Wash load out of balance • Redistribute loud in washer and run through Drain &Spin cycle.
Colored spots Incorrect use of fabric •Check fabric softener package for instructions and follow
softener directions for using dispenser.
• Make sure you have selected the Fabric Softener option.
• Pretreat stain and rewash using Quick Rinse cycle before drying.
Dye transfer • Sort whites or lightly colored items from dark colors.
Greyed oryellowed Detergent amount • Be sure to follow detergent manufacturer's directions.
clothes Hard water • Use a water conditioner like Calgon brand or install
a water softener.
Water is not hot enough • Make sure water heater is delivering water at
120°F-!40°F (48°C-60°C).
Washer is overloaded • Loosely load clothes no higher than the top row of holes in the
washer basket. For best results, load items around the outside
of the basket.
Dye transfer • Sort clothes by color. If fabric label states wash separately,
unstable dyes may be indicated.
Lint or residue on Clothes are air or line dried • Ifyou do not dry your clothes with a clothes dryer, your
clothes clothes may retain more lint.
Incorrect sorting • Separate lint producers from lint collectors.
Washing too long • Wash small loads for a shorter time than larger loads.
Detergent not dissolving • Rewash using Quick Rinse cycle with Extra Rinse option.
• Try a liquid detergent.
• Use warmer water temperature.
Overloading • Loosely load clothes inthe washer basket. For best results, load
items around the outside of the basket.
Incorrect use of fabric
softener ,, Check fabric softener package for instructions
and follow directions for using dispenser.
•Make sure you have selected the Fabric Softener option. 13

Before you call for service...
Troubleshooting Tips
PERFORMANCE (cont.) Possible Causes What To Do
Pilling Result of normal wear on poly-. Whilethis is not caused bythe washer, you can slow the
cotton blends and fuzzy fabrics pilling processbywashing garments insideout.
Snags, holes, tears, rips Pins, snaps, hooks, sharp . Fastensnaps,hooks,buttons and zippers.
or excessivewear buttons, belt buckles, . Removeloose items likepins,objects in pockets and
zippers and sharp objects sharp buttons.
left in pockets • Turn knits(which snag easily)inside out.
Undiluted chlorine bleach . Checkbleach package instructions for proper amount.
. Never add undiluted bleachto wash or allow clothes to
come in contact with undiluted bleach.
Chemicals like hair bleach or . Rinseitemsthat may havechemicals on them before
dye, permanent wave solution washing. UseQuick Rinse cyclewith Extra Rinseoption.
Wrinkling Incorrect wash and . Match Cycleselectionto the type of fabric you are washing
dry cycles (especiallyfor easy care loads).
Improper sorting . Avoid mixing heavy items (likework clothes)with light items
(likeblouses).
• Try a fabric softener.
Overloading or incorrect • Looselyloadclothesinthe washer basket
water level
Repeated washing in . Wash inwarm or cold water.
water that istoo hot
SOUNDS Possible Causes Reason
Washer seems This is normal . Thewasher isvery quiet during portions of the wash cycle.
too quiet
"Metallic clicking" Shifter mechanism is . Thedrive systemwill engage at the start of agitate and
engaging or disengaging disengage when agitate iscomplete. This occurs multiple
times during the wash.
Back and forth "swoosh" Electric motor reversing . Thismachine hasa drivesystem that doesn't usegears.
or light "clicking" sound direction Thissound isthe motor rotating back and forth to clean
during agitate your laundry.
Quick short agitation Clothing redistribution . Atthe end of agitate, the motor makes short agitation strokes
sounds at end of agitate to redistribute the load.
"Click" when water Relay switch . Therelay makes a click sound when activated.Thewater
stops filling levelactivates the relay and stopsfilling.
"Clicking" behind Control Automatic Temperature . Two valvesmix cold and hot water. The "clicking" iswhen either
Panel during fill Control Valve valve turns on or off to raiseor lower the fill water temperature.
Water flow changes Automatic Temperature . Two valvesmix cold and hot water. The flow changes when either
during fill Control Valve valveturns on or off to raiseor lower the fill water temperature.
Motor "whining up" or Motor ramping up/down . Themotor will speed up incrementally during the spin cycle.
"coasting down" in spin during spin cycle When spin iscomplete, itwill coast until it stops.
"Humming" Water drain pump . Thedrain pump will make a humming sound when pumping
out water after agitation stops and continue until spin iscomplete.
"Gurgling" Water drain pump . When the pump starts drawing in air,It starts to gurgle.
Thewasher shouldthen begin spinning and the sound will
continue until it is done spinning.
Water "swishing" This is normal • Thiswasher usesa InfusorTM wash action.Water swishingwhile
the unit isagitating isnormal,especiallywith smaller loads.
Washer is noisy Washer is uneven , Tolevelthe washer, adjust the leveling legsby rotating the
individual leg in the proper direction for up or down.
14

GE Washer Warranty.
All warranty service provided by our Factory Service Centers,
or an authorized Customer Care®technician. Toschedule service,
on-line, visit us at GEAppliunces.com, or call 800.GE.CARES
(800.432.2737). Please have serial number and model number
available when calling for service.
Staple your receipt here.
Proof of the original purchase
date is needed to obtain service
under the warranty.
Servicing your appliance may require the use of the onboard data port for diagnostics. This gives a GE
Factory Service technician the ability to quickly diagnose any issues with your appliance and helps GE
improve its products by providing GE with information on your appliance. If you do not want your appliance
data to be sent to GE, please advise your technician NOT to submit the data to GE at the time of service.
For The Period Of: We Will Replace:
One Year Any factory specified part of the washer which fails due to a defect in materials or workmanship.
From the date of the During this limited one-year warranty, we willalso provide, free of charge, all labor and related
original purchase service to replace the defective part.
What Is Not Covered:
[] Service trips to your home to teach you how to use
the product.
[] Improper installation, delivery or maintenance.
[] Failure of the product if it isabused, misused, or
used for other than the intended purpose or used
commercially.
[] Replacement of house fuses or resetting of circuit breakers.
[] Products which are not defective or broken, or which are
working as described in the OwneKs Manual.
[] Damage to the product caused by accident, fire, floods
or acts of God.
[] Incidental or consequential damage caused by possible
defects with this appliance.
[] Defects or damage due to operation in freezing
temperatures.
[] Damage caused after delivery.
[] Product not accessible to provide required service.
EXCLUSION OF INPLIED WARRANTIES--Your sole and exclusive remedy is product repair us provided in this Limited
Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for u particular purpose,
are limited to one year or the shortest period allowed by law.
Thiswarranty isextended to the original purchaser and any succeedingowner for products purchased for home usewithin
the USA.If the product islocatedin an area where servicebyaGEAuthorized Servicerisnot available,you may be responsible
for atrip chargeor you may berequired to bring the product to an Authorized GEServicelocation. InAlaska,the warranty excludesthe
costof shipping or servicecallstoyour home.
Ifyou need to order replacement parts, we recommend that you only use GEfactory specified parts. These parts are designed to work
with your appliance and are manufactured and tested to meet GEspecifications.
Somestates do not allow theexclusionor limitation of incidental or consequentialdamages.Thiswarranty givesyou specificlegal
rights,andyou may alsohave other rights which vary from stateto state. Toknow what your legal rights are,consultyour local or
state consumeraffairs officeoryour state'sAttorney General
Warrantor: General Electric Company. Louisville, KY /40225
15

Consumer Support.
GEAppliances Website GEAppliances.com
Have a question or need assistancewith your appliance?Try the GEAppliancesWebsite 24 hours a day,
any day of the year! Forgreater convenience and faster service,you can now download Owner's Manuals,
order parts or even schedule serviceon-line.
Schedule Service GEAppliances.com
Expert GErepair service is only one step away from your door. Get on-line and schedule your service at
your convenience any day of the year! Or call 800.GECARES(800.432.2737) during normal business hours.
RealLifeDesign Studio GEAppliances.com
GEsupports the Universal Designconcept-products, servicesand environments that can be used by
people of all ages,sizesand capabilities. We recognize the need to designfor a wide range of physicaland
mental abilities and impairments. Fordetails of GE'sUniversal Designapplications, including kitchen design
ideasfor peoplewith disabilities,checkout our Website today. Forthe hearing impaired, pleasecall800.TDD.
GEAC(800.833.4322).
Extended Warranties GEAppliances.com
Purchase a GEextended warranty and learn about special discounts that are available while your warranty
isstill in effect.Vou can purchase it on-line anytime, or call 800.626.2224during normal businesshours.
GEConsumer Home Serviceswill still be there after your warranty expires.
Partsand Accessories GEAppl ianceparts.com
Individuals qualified to servicetheir own appliances can have parts or accessoriessent directly to their homes
(VISA,MasterCard and Discovercards are accepted).Order on-line today, 24 hours every day or by phone
at 800.626.2002 during normal business hours.
If you need to order replacement parts,we recommend that you only useGEfactory specified parts.These
parts are designed to work with your appliance and are manufactured and tested to meet GEspecifications.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.
Contact Us GEAppl iances.corn
If you are not satisfied with the serviceyou receivefrom GE,contact uson our Website with all the details
including your phone number, or write to: General Manager, Customer Relations
GEAppliances,Appliance Park
Louisville,KY40225
RegisterYourAppliance GEAppliances.cam
l Register your new appliance ondine--at your convenience! Timely product registration will allow for
enhanced communication and prompt serviceunder the terms ofyour warranty, should the need arise.
You may also mail inthe pre-printed registration card included in the packing material.
16

GEAppliances.com
Instrucciones
de seguridad .................. 2,]
Instrucciones de operaci6n
C6mo cargar y usar
la lavadora......................... 8
Comunicaci6n del
Electrodom6stico ............. 10
Cuidado y limpieza
de la lavadora ...................... 9
Funciones .......................... 7
Instrucciones de uso ............ 4-6
Consejos para la soluci6n
de problemas .............. to-t2
Soporte al consumidor
Garantia .......................... 15
Piezas yaccesorios ........... 3, 16
Soporte al consumidor ............ 14
)
_i!_i[_
i
Impreso enlos Estados Unidos
ENERGYSTAR
Como socio de Energy Star®,GE
ha confirmado que este producto
cumple las directrices de Energy
Star®relativas al rendimiento
energ@ico.
Escriba el nF_mero de modelo
y de serie aqui:
No. de modelo
No. de serie
Puede encontrarlos _
bajo la puerta
de la lavadora. 49-90486-1 05-13 GE

INFORMACION DESEGURIDAD IIvlPORTANTE.
LEA TODASLAS INSTRUCCIONESANTES DE USAR.
m
A ste eselsfmbolode alertade seguridad.Elmismoalertasabrepotencialesriesgosque lepuedenproducirla muerte o lesiones
tanto a ustedcoma aotras personas.Todoslosmensajesde seguridadestar6nacontinuaci6ndelsfmbolode alertade seguridad
y con la palabra"PELIGRO","ADVERTENCIA"o "PRECAUCION".Estaspalabrassedefinencoma:
Indica una situaci6n de riesgoque, si no seevita, producir(i la muerte o lesiones graves.
_ Indica una situaci6n de riesgoque, si no seevita, podria producir la muerte o lesionesgraves.
_ Indica una situaci6n de riesgoque, si no seevita, podria resultar en lesionesmenores o moderadas.
INSTRUCCIONESIMPORTANTESDESEGURIDAD
Para reducir el riesgo de muerte, incendio, explosi6n,descargas el_ctricas o lesionessabre lospersonas al
usar su electrodom_stico, siga las precauciones b6sicas, incluyendo Iosiguiente
[] Leatodas lasinstruccionesantesde usaresteelectrodom_stico.
[] NOlave ni seque prendas queen forma previa hayan sido secadas, lavadas, mojadas o manchadas con gasolina, solventes
de limpieza en seco,u otras sustanciasinflamables o explosivas,ya que despidenvapores que se podrfanencender o explotar.
[] NOagregue gasolina, solventes de limpieza en seco, U otras sustancias inflamables o explosivas al agua de lavado. Estas
sustancias despiden vapores que se podrfan prender fuego o explotar.
[] Bajo ciertas condiciones, se podr6 producir gas de hidr6geno en un sistema de agua caliente que no fue usado por 2
semanas o m6s. ELGASDEHIDROGENO ESUN EXPLOSIVO.Siel sistema de agua caliente no fue usado por dicho periodo,
antes de usar una lavadora, abra todos los grifos de agua caliente ydeje que corra agua de cada uno durante varios minutos.
Estoliberar6 cualquier gas de hidr6geno acumulado. Debido a que el gas es inflamable, NOfume ni use una llama abierta
durante este proceso.
[] NOpermita que los ninosjueguen sabre o dentro de este [e-mail] el electrodom@sticose usecerca de
ninos, ser6 necesario supervisarlos de cerca.Antes de dejar la lavadora fuera de servicioo de deshacerse de @sta,quite la
puerta o la tapa. Si no se siguen estas instrucciones, se podr6 producir la muerte o lesiones personales.
[] NOintroduzca las manos en el electrodom@sticosiel tambor o agitador seencuentra en movimiento a fin de evitar enredos
accidentales.
[] NOinstale ni guarde este electrodom@sticodonde quede expuesto a losfactores clim6ticos.
[] NOmanipule indebidamente los controles, reparar ni reemplazar cualquier parte del electrodom@stico o realizar cualquier
otro trabajo t@cnico,a menos que esto sea especfficamente recomendado en las instrucciones de mantenimiento del
usuario o en instrucciones publicadas sabre reparaciones del usuario, que entienda ypara las cuales posea las destrezas
necesarias.
[] Mantenga el 6rea alrededor de su electrodom@sticolimpia yseca a fin de reducir la posibilidad de resbalones.
[] NOintente usar este electrodom@sticosi seencuentra daflado, funcionando mal, parcialmente desensamblado, o sitiene
partes faltantes o rotas, incluyendo un cable o enchufe da_ado.
[] Desenchufeel electrodom@sticoo apague el disyuntor antes de realizar el servicio [e-mail] bot6n Power
(Encendido)NOdesconecta el encendido.
[] Paraacceder alas instruccionesde conexi6n a tierra, lea los"RequisitosEl@ctricos"ubicados en lasInstruccionesde Instalaci6n.
GUARDE ESTAS INSTRUCCIONES

GEAppliances.com
INSTALACIC)NCORRECTA
_Lo Iovodorose debe instolorycolocor correctomente de ocuerdocon losinstruccionesde instoloci6n,antes de utilizorlo.Si no
recibi6 la hoja con instrucciones de instalaci6n, puede obtener una visitando GEAppliunces.com o Ilamando al
800.GE.CARES (800.432.2737).
AsegOresede que la manguera de agua caliente est# []
conectada a la v61vula"H"(interna proyectada de color
rojo)y que la manguera de agua fria est6 conectada a la []
valvula "C"(interna proyectada de color azul).
Instaleo almacenela lavadoraen un lugardonde
no est@expuestaa temperaturas bajo ceroni alas
inclemenciasclimdticas,ya que esto puede provocarda_os
irreversiblese invalidarlagarantfa.
Conectecorrectamentea tierra la lavadorade conformidad
contodos losc6digosyordenanzasregulatorias.Sigala
informaci6n de Instrucciones
de instalaci6n.
"_ -Riesgo de DescargaEl_ctrica
Enchufe en un tomacorriente con conexi6n a tierra de
3 cables.
NO retire la conexi6n a tierra.
NO UTILICEun cable de extensi6n.
NO UTILICEun enchufe adaptador con este artefacto.
Si no cumple con esto, se podr6 producir la muerte,
incendio o descarga el#ctrica.
Serecomienda una extensi6n opcional de la manguera
de drenaje para descargas en alturas de 60"a 96".
Esta lavadora no incluye mangueras de suministro de
agua.
GErecomienda enf6ticamente el uso de piezas
especificadas de f@brica.A continuaci6n se encuentra
una lista de mangueras de f6brica disponibles para la
compra. Estas mangueras est6n fabricadas yprobadas
para cumplir con lasespecificacionesde GE
GErecomiendaenf@icamenteelusodemanguerasnuevas
de suministrode agua.Lasmanguerassedesgastanconel
tiempoydebenreemplazarsecada5 ahospara reducirel
riesgodefallasen lasmanguerasydahosprovocadospor el
agua.
Piezas yaccesorios
Solidteloson-line hoy mismoa GEApplianceparts.com, las
24 horas del d[ao portel#fono a1800.626.2002en horatio
normal de trabajo.
NOmero de Pieza Accesorio
PHI4XI0002
0
PH14X10005
Hangueras de goma de
suministro de agua de 4 pies
Hangueras trenzada de
suministro de agua de 4 pies
WH49X30!
WXI0XI0011
Extensi6nde la Hanguerade Drenaje
Limpiador Tide@para Lavadoras*
WX7X! Bandeja del Pisode la Lavadora
DR07X!0005 Cablede 6'
4CONTROLDE LA FUNCIONALIDAD
[] Sila tapa es abierta entre losciclos(esdecir,sin pausar y
reiniciarel ciclo actual, cambiar ciclos una vez iniciados,
etc.),presionar el bot6n Start (Inicio)bar6 que la lavadora
abra el agua fria durante 5 segundos,seguido de un
retraso de !0 segundos antes de bloquear la tapa e iniciar
el ciclo.
[] Si latapa es abierta durante este per[odode 15 segundos,
la palabra Pause(Pausa)comenzar6 a moverse a trav#s
de la pantalla. Sedeber6 presionar el bot6n .Start(Iniciar)
nuevamente para reiniciarel ciclo.
. CUANDO NO ESTEEN USO
[] CierrelasIlavesde paso minimizar lasfugas en caso
de que se produzca una rotura o grieta. Compruebe el
estado de lasmangueras de Ilenado;GErecomienda el
cambio de las mangueras cada 5 ahos. GUARDE ESTAS INSTRUCCIONES
*Tide@es una marca registrada de Procter & Gamble. ]

Instrucciones de uso.
Esposible que las funciones y apariencias varien con relaci6n a su modelo a Io largo del manual.
Paso 1
Agregue et suavizante al
dosificador para suavizante;
para m6s detalles, lea la p6gina 7.
• Agregue el detergente, GE
recomienda el uso de
detergentes de Alto Eficiencia
en todas JasJavadoras
cJasificadas por Energy Star,
Paso 2
Paso 3@ O"
CE3
CE3
Agreguelasprendassinajustaralrededor
del InfusorTM. Sobrecargar el tambor
puedeproducirunimpactonegativoenel
desempe_odelavado.Consulte la p(_gina8
para obtener ejemplosde cargo sugeridos.
Cierre la tapa. NOTA:La lavadora
no comienza a Ilenarse con la tapa
abierta,
• Seleccione el tamaBo de cargo
yotras opciones de lavado,
incluyendo la opci6n del Suavizante.
Seleccione el ciclo de lavado,
Paso 4
• Oprima Start.
Normal
Start Whites igl,tco_o_s
Dark Colors
Heavy Duty
Pause
(Unlock Lid}
Delicate
Towels ISheets
Bulky Items
Quick Rinse
Drain & Spin
]ASKETclean
Controles
Power (Encendido)
Presione para "activar" la pantalla. Sila pantalla esta activa, presione para que la lavadora quede en el modo inactivo.
NOTA:Presionar POWER (Encendido) no desconecta el electrodom6stico del suministro de corriente.
Start and Pause (Inicio y Pausa)
Presione Start (lnicio)para comenzar el ciclo. NOTA: La tapa se deberci cerrar para que la lavadora se Ilene y el ciclo comience, iSila tapa estci
cerrada, la tapa se bloquear& el detergente sera dispensado,y "FILL"(Llenar)se visualizara a trav6s de la pantalla.
PresionarStart (Inicio)otra vezhara Pause (Pausa)el ciclo yla luz del indicador de Start (Inicio)titilar&
Paracontinuar el ciclo, presione Start flnicio) nuevamente. Sila mciquina queda pausada por mcisde 24 horas, el ciclo sera cancelado. Si el
agua permanece en la mciquina,seleccione el ciclo Drain &Spin (Drenary Girar)para drenar el tubo ydesagotar el agua de la lavadora.
Display and Status Lights (Pantalla y los Luces de Status (Estatus))
Pantalla:
La pantalla muestra el tiempo restante apro×imado hasta elfinal del ciclo.
NOTA:Eltiempo delciclo es afectado par el tiempo que toma Ilenar la lavadora. Estodepende de la presi6n del agua en su hogar.El
temporizador "inteligente" "registra" la cantidad de tiempo quetarda en Ilenarsela lavadora yajusta eltiempo total de forma consecuente.
Adem6s, esta pantalla "mostrarA" el estado de la lavadora:
•bALAnCINg Comienzo del ciclo de rebalanceo para redistribuir la ropa. Sedetiene una vez completado el rebalanceo.
CYCLEPrEP Siente el tama_o de la carga seca antes del Ilenado (normal).
•dELAY Cuando Delayed Wash (Lavado Retrasado) es iniciado. Reemplazado con tiempo estimado cuando comienza el ciclo.
End Fin del ciclo actual.
•ES Lavadoraen uninicio retrasado(m6ximode4 horas)esperandoindicesinferioresde corriente (consuttela secci6nEnergySmart).
FILL Durante los primeros 45 minutos de un Ilenado, se muestra el tiempo de fin de ciclo estimado. Para el resto del tiempo
de Ilenado, "FILL"(Llenado)se muestra hasta que el mismo se completa.
H20 SUPPLY No puede sentir el nivel del agua (es posible que las vcilvulas est6n apagadas).
•Lid Elciclo se detuvo porque la tapa estciabierta. Cierre la tapa.
LOAdSenSE Siente el tama_o de la carga mojada (normal).
•PAUSE Elciclo fue pausado debido a que la tecla Start/Pause (lnicio/Pausa) fue presionado yla lavadora fue configurada
en Pause (Pausa).Presione el bot6n Start (lnicio) nuevamente para reiniciar el ciclo.
Lucesde estado del ciclo:
Huestra sila lavadora est6 en el ciclo SOAK (Enjuagar), WASH (Lava#, RINSE (Enjuagar) oSPIN (Girar).
Los laces de estado de/as funciones indican (lea los secciones FyG para mcis detalles):
EnergySmart® EIEnergySmartfueseleccionada.Consuitesecci6nAcercadela Comunicaci6ndelElectrodom_stico.
Lid Locked Lavadora est6 bloqueada - titilarci una vez si presiona cualquier bot6n o gira perilla de ciclo.
(Tapa Bloqueada)
