GEAppliances JGP320EV User instructions

Revised 3/96
GE Appliances
JGP320EV—Built-In Gas Cooktop
Dimensions (in inches) Counter Installation Dimensions (in inches)
For answers to your GE appliance questions, call
GE Answer Center®service, 800.626.2000.
Cooktop
3-1/4
28-1/2
19-1/2
30-1/4 21-1/4
Electrical junction
box 12" MIN. 
below countertop
30" MIN. to
unprotected
cabinet
Cut should 
not interfere
with cabinet
structure at
front
3" MIN.
clearance to
side wall
3" MIN.
clearance to
side wall
18" MIN. 
to cabinet
1-3/4" to
rear wall
13" MAX.
depth
Note: Allow 5-3/4" depth 
at rear for electrical 
and gas connections.
AGA Requirement: All gas cooktop models required 3-1/2"
free area below countertop surface to combustible material.
Requires 18" minimum from cooktop to adjacent overhead
cabinets.
Note: If installing a gas sealed burner model with a GE
Telescopic Downdraft System, consult both cooktop and
downdraft installation instructions packed with product
before installing. Cooktop gas/electric supply may needs
to be re-routed to install downdraft.
Electrical Rating: 120V, 60Hz, 5A
Installation With Single Wall Oven Information:
30" Gas Cooktops are approved for use over select GE 27"
Wall Ovens. 30" and 36" Gas Cooktops are approved for use
over select 30" Wall Ovens. Refer to cooktop and wall oven
installation instructions, [Pub. No. 31-10167 (JKP18AV/17WV/
16GV/15AV/14WV/13GV/ JKS05GV); Pub. No. 31-10125
(JTP18AV/17WV/16GV/14WV/13GV)] packed with product for
current dimensional data.
Installation Information: Before installing, consult
installation instructions packed with product for current
dimensional data.

Revised 3/96
GE Appliances
JGP320EV—Built-In Gas Cooktop
RIGHT
LEFT
LEFT
RIGHT
OFF
OFF
OFF
OFF
Features and Benefits
•White or Black Lift-Up Cooktop
• 30" Porcelain-Enameled Cooktop
• Color-Matched Glass Control Panel
• Standard Cooktop Burners
• Standard Porcelain Steel Grates
• Electronic Pilotless Ignition
• One-Piece Chrome Drip Pans
