Geeek A30 V2 User manual

A30 V2 INSTALLATION GUIDE
Version 2.0
2008A
All manuals and user guides at all-guides.com

Screws for Fan Screws for Power
Supply M3 T type Nut
M4x14mm M4x8mm M3x8mm M3x5mm M3x10mm
25mm Standoff x2
40mm Standoff x4
A1 : Thumb Screw x8
A2 : M3x5mm x11
A2
A1
SCREWS LIST
All manuals and user guides at all-guides.com

Screw
Nut
Acrylic
Panel
Aluminum Frame
Installation
Please read the “Aluminum Frame
installation”before assembling this case
All manuals and user guides at all-guides.com

STEP 01
Aluminum Frame Installation
E 4X
E
215mm
230mm
230mm
All manuals and user guides at all-guides.com

STEP 02
I
Install the M/B Standoffs
40mm 4X
I
I
I
I 4X
All manuals and user guides at all-guides.com

STEP 03
Install ①Left Upper and ②Lower Side
Brackets on the Aluminum Frame I
D
G 3X
D 5X
1
2
I 2X
G
I
All manuals and user guides at all-guides.com

STEP 04
Install Right Side Brackets on the Aluminum Frame
G 3X
D 3X
D
G
All manuals and user guides at all-guides.com

F
STEP 05
Rear Panel Installation
F 4X
All manuals and user guides at all-guides.com

STEP 06
①Bottom Panel and ②Foot Pad Installation
G 4X
D 4X
G
D
1
2
A2
A2 4X
All manuals and user guides at all-guides.com

STEP 07
Power Supply Installation
C 3X
C
All manuals and user guides at all-guides.com

Install the Standoffs on the Left Upper and Lower Side Brackets
STEP 08
M/B Installation
H
H 4X
Highly recommend to install the CPU cooler and
ram before installing the motherboard.
All manuals and user guides at all-guides.com

STEP 09
PCIe Riser Cable Installation
(Optional Purchase) 1
2
3
H
I
H 2X
25mm 2X
I 2X
All manuals and user guides at all-guides.com

STEP 10
2.5” SSD/HDD Installation
2
A2
A2 7X
1
A2
All manuals and user guides at all-guides.com

STEP 11
Install and Secure the Graphic Card
1
2
H
H 1X
All manuals and user guides at all-guides.com

STEP 12
USB 3.0 Cable and 92mm Fan (Optional Purchase)
Installation B 8X
B
G 4X
G
All manuals and user guides at all-guides.com

STEP 13
Top Panel Installation
G 4X
D 4X
G
D
All manuals and user guides at all-guides.com

STEP 14
①Power Switch and ②Front Panel Installation
F
F 4X
All manuals and user guides at all-guides.com

STEP 15
1
2
All manuals and user guides at all-guides.com

STEP 16
①Side Cover and ②PSU Cover Installation
F
F 2X
1
2
All manuals and user guides at all-guides.com

STEP 17
Side Panels Installation
A1
A1 8X
