Geeek A70 PRO User manual

A70 PRO
INSTALLATION GUIDE
Version 1.0 - V2.0
100421

SCREWS LIST / 螺絲盒列表
M4 Thumb ScrewsM3x5mm Screws for Fan 6#32x10mm M3 Nut
J1 M3x5mm
J2 M3x5mm
M3x5mmM3x8mmM4x8mmM4x14mm
J2
J1

Aluminum Frame
Installation
鋁框架安裝說明
Please read the “Aluminum Frame installation”before
assembling this case
安裝前請務必先理解鋁框架如何安裝
Screw
螺絲
Nut
螺母
Acrylic Panel
壓克力板

STEP 01
Aluminum Frame Installation
安裝機身鋁框架
FF 4X

E
H
E 4X
H 4X
STEP 02
Install the HDD Bracket to the right aluminum frame
* If you do not need to install the 2.5” HDD, please skip this step
安裝硬碟支架到右側鋁框架
*如果不安裝2.5”硬碟可以略過此步驟

E
I
I 2X
E 2X
STEP 03
Instasll the middle layer to the left aluminum frame
安裝中層到左側鋁框架

STEP 04
Foodpad and Bottom Panel Installation
安裝底蓋及腳墊G
G 4X
A 5X
A

STEP 05
Back Panel Installation
安裝後面板
E
HE 6X
H 6X
A 3X
A
A
A

STEP 06
Motherboard Installation
安裝主機板
I
I 4X

STEP 07
PCI-e Riser Cable Installation
安裝顯示卡延長線
I
I 2X

STEP 08
GPU Installation
安裝顯示卡
I
2
1
I 2X

D
D 4X
STEP 09 - v1.0
Power Supply and HDMI extension cable Installation
安裝電源供應器及HDMI延長線
J1

DD 4X
STEP 09-1 - v2.0
Power Supply, HDMI extension cable and DP extension cable(Optional) Installation
安裝電源供應器,HDMI延長線及DP延長線(可選)

Power Supply, HDMI extension cable and DP extension cable(Optional) Installation
安裝電源供應器,HDMI延長線及DP延長線(可選)
G
STEP 09-2 - v2.0
G 2X
J1

Power Switch, USB 3.0 Cable and Top Panel Installation
安裝電源開關,USB 3.0連接線及上面板
H
H 4X
G
G 4X
STEP 10 - v1.0

Power Switch and USB 3.0 Cable Installation
安裝電源開關及USB 3.0連接線
STEP 10-1 - v2.0
I 2X
I

Power Switch and USB 3.0 Cable Installation
安裝電源開關及USB 3.0連接線
STEP 10-2 - v2.0
H
H 4X

STEP 11
Fan and Fan Bracket Installation
安裝風扇及風扇支架
J2
E
E
E 6X
J2 6X
J2
C
C 8X

STEP 12
Front Panel Installation
安裝前面板
A
A 6X

STEP 13
2.5” HDD and HDD Bracket Installation
*If you do not need to install the 2.5” HDD, please skip this step
安裝2.5”硬碟及硬碟支架
*如果不安裝2.5”硬碟可以略過此步驟
A
2
1
G
G 3X
A 8X
