Geeek A60 User manual

A60 INSTALLATION GUIDE
Version 1.0
201912A
All manuals and user guides at all-guides.com

all-guides.com

B
F
E
A
SCREWS LIST
M4x16mm
X4
D
G H
M3 Nut
X32
M4x8mm
X14
M3x8mm
X52
M3x5mm
X6
15mm Standoff X4
30mm Standoff X2
45mm Standoff X4 6#32x10mm
X4
Screws for Radiator
X8
C
I
M3x10mm
X6
All manuals and user guides at all-guides.com

Aluminum Frame
Installation
Please read the “Aluminum Frame
installation”before assembling this case
Screw
Nut
Acrylic
Panel
All manuals and user guides at all-guides.com

STEP 01 Aluminum Frame Installation
E 4X
All manuals and user guides at all-guides.com

STEP 02 Install the Standoffs on the Left Upper and Lower Side Brackets
G 4X 45mm 4X
All manuals and user guides at all-guides.com

STEP 03 Install the Step 2 on Left Upper and Lower Aluminum Frames
D 5X G 5X
All manuals and user guides at all-guides.com

all-guides.com

G 3X D 3X
STEP 04 Install the HDD Bracket on the Right Aluminum Frame
All manuals and user guides at all-guides.com

STEP 05 Install the Rear Panel & Power Extension Cable
F 4X
05-1
Please use the screws inside the bag (power extension
cable) to install the power extension cable.
05-2
G 2X
All manuals and user guides at all-guides.com

STEP 06 Install the Bottom Panel & Footpad
D 6X
G 6X
Screws for Foot pad
4X
Please use the screws inside the bag (Foot pad) to
install the power extension cable.
We suggest to complete all the installations and cable
management first and install the bottom panel at last. It
will be easier for the assembly.
G
All manuals and user guides at all-guides.com

STEP 07 Install the Motherboard
H 4X
All manuals and user guides at all-guides.com

STEP 08 Install the Power Supply Bracket
C 4X
15mm 4X
G 4X
All manuals and user guides at all-guides.com

all-guides.com

STEP 09 Install the PSU Holder
D 4X
G 4X
When you have difficulties during the assembly, you can
remove the bottom panel first before assembly.
All manuals and user guides at all-guides.com

10-2
10-1
I 4X
G 8X
F 3X
10-3
STEP 10 Install the 2.5”HDD
All manuals and user guides at all-guides.com

STEP 11
H 2X
11-2
11-1
25mm 2X
I 2X
11-3
Install the PCIe Riser Cable (Optional
Purchase)
All manuals and user guides at all-guides.com

F 2X 12-1
12-2
STEP 12 Install and Secure the Graphic Card
All manuals and user guides at all-guides.com

STEP 13 Install the Power Switch, Front USB and Panel
13-1
13-2
13-3
G 4X F 4X
All manuals and user guides at all-guides.com
