Geemarc t-LOOP User manual

CONTENTS 2
INTRODUCTION 3
Unpacking the t-LOOP 4
INSTALLATION
Setting Up 5
Low Batteries 5
USING THE t-LOOP 6
TROUBLESHOOTING 8
SAFETY INFORMATION 9
GUARANTEE 10
RECYCLING DIRECTIVES
2
CONTENTS

Congratulations on purchasing your Geemarc t-LOOP amplified
powered neckloop from Sound SolutionsTM. The Geemarc t-LOOP
can be used with cellular or landline telephones together with a
hearing aid that has a t-coil. The Geemarc t-LOOP can also be used
as an amplified audio neckloop for a variety of audio devices using
the 2.5mm to 3.5mm adapter provided.
This neckloop uses an induction loop system which helps people
who use a hearing aid to hear sounds more clearly because it
reduces or cuts out background noise. The Geemarc t-LOOP
transforms the sound emitted by an telephone/audio device into an
acoustic field compatible with hearing aids set to the T position.
Simply plug the neckloop into your telephone and you can make and
receive calls as normal without needing to hold the telephone. The
microphone in the Geemarc t-LOOP allows you to speak directly to
the caller.
Note: users of digital hearing aids must make sure their aids
have been programmed for use with the ‘T’ setting.
This neckloop can be used with telephones equipped with a 2.5mm
microphone/headset socket (Geemarc products such as AMPLI
Dect, CL200, 400, 600, 1400 are good examples). It is also com-
patible with most mobile telephones (you may need to purchase a
connector if your cellular telephone does not have a suitable 2.5mm
headset socket).
Its is important that you read the instructions below in order to use
your Geemarc t-LOOP to its full potential. Keep this user guide in a
safe place for future reference.
3
INTRODUCTION

4
INTRODUCTION
Unpacking the Geemarc t-LOOP
When unpacking the Geemarc t-LOOP, you should find the follow-
ing in the box:
• 1 Neckloop and neckloop unit
• 2.5mm telephone connector plug
• 2 AAA 1.5V alkaline batteries
• 2.5mm to 3.5mm adapter
• 1 User Guide

5
INSTALLATION
Setting Up
NOTE: Ensure your telephone equipment is UL/ETL approved
before connecting the Geemarc t-LOOP. Please refer to your tele-
phone user guide.
Open the battery compartment found on the back of the Geemarc t-
LOOP. Insert the 2 supplied alkaline batteries (AAA size, 1.5V type)
into the battery compartment. Check the battery polarity diagrams
in the battery compartment when inserting the batteries. Replace
the battery cover.
Note: The Geemarc t-LOOP must not be connected to the telephone
when installing the batteries.
Do not use rechargeable batteries. Do not put batteries into the
household rubbish, pay attention to battery regulations regarding
battery disposal.
Low Batteries
The low battery indicator will turn red to indicate the batteries should
be changed. The indicator will only turn red while in use. Replace
the batteries as soon as possible.

6
USING THE GEEMARC t-LOOP
Making and Receiving Calls
Place the wire around your neck. Insert the round connector plug
into the Neckloop Quick Disconnect plug; this forms a loop around
your neck. Ensure you have double clicked the connection.
Connect the 2.5mm plug of the Geemarc t-LOOP into the telephone’s
2.5 mm headset jack
Switch your hearing aid to T (or MT) mode.
Press the ON/OFF button; you are ready to speak through your
Geemarc t-LOOP. The green light will turn on.
Make and receive calls as normal (refer to telephone user guide)
The volume of the Geemarc t-LOOP can be adjusted by using the
volume control knob found on the bottom of the Geemarc t-LOOP.
This gives up to 30 dB gain.
Press the ON/OFF button when the call is finished. The green light will turn off.
Reset your hearing aid if necessary.
Do not forget to turn OFF your Geemarc t-LOOP at the end of
the call. Failure to do this will drain the batteries after about 30
hours.
Note: The Geemarc t-LOOP has a built in microphone hence you
do not need to hold the telephone to your ear. Instead, you can use
it with a belt clip or place it on a flat surface such as a table.
If your telephone does not have a 2.5mm jack, you may need an
adapter. Check with the telephone manufacturer.

7
USING THE GEEMARC t-LOOP
Using as a Personal Audio Neckloop
The Geemarc t-LOOP can be converted easily to a 3.5mm amplified
Audio Neckloop. Simply plug the 2.5mm end of Geemarc t-LOOP
into the 2.5mm to 3.5mm adapter provided, then insert the adapter
into your device with a 3.5mm audio jack e.g. a CD player, MP3 or
any device that has an 8-16 Ohm audio output through a 3.5mm
jack.
Note: Only use the adapter supplied when connnecting the Gee-
marc t-LOOP to an audio device.
The Geemarc t-LOOP is compatible with cell phones that provide
stereo music. In order for the Geemarc t-LOOP to work, you must
use an adapter that converts the 2.5mm connector on the cell
phone to function as standard mono connector. You can get these
adapters from your cell phone manufacturer. You will need to need
to check that the 2.5mm connector on the cell phone will work with a
standard mono hands-free headset such as the Geemarc t-LOOP.

8
The LED is Red
• Change the batteries
There is no sound from my Geemarc t-LOOP
• Ensure the headset is securely plugged in
• Ensure the volume is correctly adjusted
• Ensure the batteries are not flat
• Ensure the batteries are inserted correctly
• Ensure the Geemarc t-LOOP is switched on
• Ensure the telephone is switched on
There is a weak sound from my Geemarc t-LOOP
• The batteries may be running out
• Turn up the volume on the Geemarc t-LOOP
• Turn up the volume on the telephone
• Check your hearing aid
TROUBLESHOOTING

9
General
Do not open the unit. Contact the helpline for all repairs.
Avoid dropping the unit.
Keep the Geemarc t-LOOP out of small children’s reach.
Cleaning
Clean the Geemarc t-LOOP with a soft cloth. Never use polishes
or cleaning agents - they could damage the finish or the electrics
inside.
Environmental
Do not expose to direct sunlight.
Always ensure there is a free flow of air over the surfaces of the
Geemarc t-LOOP
Do not place any part of your product in water and do not use it in
damp or humid conditions e.g. bathrooms.
Do not expose your product to fire or other hazardous conditions.
If the Geemarc t-LOOP is not in use do not store it with batteries
installed for an extended length of time.
Avoid using the telephone during electrical storms as there is a
remote risk of receiving an electric shock from lightning.
If you suspect a gas leak in the area do not use the telephone. The phone’s
electrical contacts could create a spark, which could ignite leaking gas.
SAFETY INFORMATION

10
Sonic Alert warrants the device against any defect in materials or
workmanship for the period of one year from the date of purchase.
Should you experience a problem, contact our customer service
department
Be sure to save your sales receipt as proof of purchase date should
you need warranty service.
Within a period of one year from purchase date, Sonic Alert will
repair or replace (our discretion) your device at no cost, if a defect
in materials or workmanship is found. If we elect to replace your
device , we may replace it with a new or reconditioned product of
the same or similar design.
Repair or replacement will be warranted for a period of 90 days or
the original time on the original warranty, whichever is longer.
The warranty does not cover accidents, negligence or breakage to
any parts. This includes shipping damage, failure to follow instruc-
tions, misuse, fire, floods, use of incompatible accessories, Acts
of God or failure in your device service carrier’s line service. The
product must not be tampered with or taken apart by anyone who
is not an authorized
Sonic Alert representative. Tampering with the phone will void ant
written or implied warranties
Sonic Alert shall not be responsible for loss of time, inconvenience
, property damage caused by your device or any other accidental
or consequential damages
Warranty service is available only with proof of purchase
GUARANTEE

11
IMPORTANT : UPOUR RECEIPT IS PART OF YOUR WARRANTY
AND MUST BE RETAINED AND PRODUCED IN THE EVENT OF
A WARRANTY CLAIM
Simply send the Geemarc t-LOOP (postpaid) and a copy of your
sales slip as proof of purchase to:
Sonic Alert Inc., 1050 E. Maple Road, Troy MI 48083
1050 East Maple Rd.
Troy, MI 48083
Ph: 248577 5400
Fax: [phone]
www.sonicalert.com
GUARANTEE
Ug_t-LOOP_En_Ed03
