Geevon T208614C-1 User manual
Description of control
1.Alarm icon
2.Symbol Radio Control RCC
3.Time display
4.Display low battery indicator
5.Snooze icon
6.Weekday display
7.Calendar display
8.Outdoor temperature
9.Outdoor sensor signal strength
10.Tendency outdoor temperature
11.Moon phase
12.Indoor temperature
13.In/Outdoor temperature max/min record
14.Sensor low battery indicator
15.Tendency indoor temperature
16.LIGHT/SNOOZE button
17. CH button
18. DOWN/MEM button
19. UP /RCC/ 12/24 button
20. MODE /ALARM button
21. Battery Compartment 3xAAA (batteries not included)
22. Stand bracket
23. Wireless signal indicator (Flashes when data is being sent to the
display unit)
24. Integrated hang hole
25. Compartment 2xAAA batteries (batteries not included)
Package Contents:
1. Display Unit
2. Outdoor Sensor
3. Instructions Manual
Installing or Replacing Batteries:
•We recommend using high quality alkaline batteries for the best product
performance.
•Heavy duty or rechargeable batteries are not recommended.
•The outdoor sensor requires high quality alkaline batteries in low
temperature conditions. Cold
temperatures could cause other batteries to function improperly.
•Do not mix old and new batteries. Do not mix alkaline, standard, and/or
rechargeable batteries.
Default settings
3. Default week: SUN
4. Default temperature: °F
5. Default alarm:AM 6:00,default snooze time: 5min.
Display / Keys Details:
There are totally 5 keys for the alarm clock,they are included:
MODE/ALARM, UP/12/24, DOWN/MEM, CH, LIGHT/SNOOZE.
1. MODE/ALARM buttons:
a. Press and hold for 3 seconds during normal mode to enter setting
mode.
b. Press MODE/ALARM button during normal mode to enter alarm mode.
2.UP/RCC/12/24 buttons
a.In normal display mode, press this button to switch 12/24 hour.
b.Press and hold for 3 seconds to turn on or turn off RCC.
c.In alarm mode,press this button to open and close alarm.
d. Press to increase the setting value during setting.
e. Press and hold 3 seconds button for fast adjust during setting mode.
3.DOWN/MEM buttons:
a.Press the button to display max/min temperature.
b.Press and hold the button 3 seconds to clear the record of MAX/MIN
temperature.
c.Press the button to display tendency in/outdoor temperature icon.
d. Press to increase the setting value during setting.
e. Press and hold 3 seconds button for fast adjust during
setting mode.
4.CH buttons:
a. In normal display mode, press and hold to search RF.
5. LIGHT/SNOOZE buttons:
a.In alarm mode,press the button to open snooze mode.
b.In normal mode, press this button to turn on/off the backlight.
Manually Setting the Time, Date & Units:
1.Press and hold down the "MODE" button for 3 seconds the hour display starts
to flash, use “UP” or “DOWN” buttons to set the correct hour.
2.Press "MODE" button to confirm your setting, the minute display starts to
flash, use “UP” or “DOWN” buttons to set the correct minute.
3.Press "MODE" button to confirm your setting, the year display starts to flash,
use “UP” or “DOWN” buttons to set the correct year.
4.Press "MODE" button to confirm your setting, the month display starts to flash,
use “UP” or “DOWN” buttons to set the correct month.
5.Press "MODE" button to confirm your setting, the date display starts to flash,
use “UP” or “DOWN” buttons to set the correct date.
6.Press "MODE" button to confirm your setting,the DAYLIGHT SAVING TIME
display, use the “UP” or “DOWN”buttons to select turn on or off the DAYLIGHT
SAVING TIME.
7.Press "MODE" button to confirm your setting, the TIME ZONE display,use the
“UP” or “DOWN” buttons to select the TIME ZONE.The TIME ZONE order
is:EST AST HAST AKST PST MST CST.
8.Press "MODE" button to confirm your setting, the temperature Unit starts to
flash,use “UP” or “DOWN” buttons to set the correct temperature Unit.
9.Press "MODE" button to confirm your setting and to end the setting
procedures, enter the normal mode.
NOTE: You will automatically exit settings mode if no buttons are pressed for 30
seconds. Enter settings mode again at any time by pressing and holding the
MODE button for 3 seconds.
Setting the Alarm:
1.In normal display mode, press ALARM button enter alarm mode.Use
“UP” button to open and close alarm.
2.Under the alarm mode,Press and hold the ALARM button,the hour
display starts to flash, use “UP” or “DOWN” buttons (press and hold to fast
adjust) to set the correct hour.
3.Press and hold the ALARM button,the minute display starts to flash, use
“UP” or “DOWN” buttons (press and hold to fast adjust) to set the correct
minute. And press the ALARM button again to exit alarm settings.
4.To turn the alarm ON or OFF, press the ALARM button to enter alarm
mode, press the UP button to ON or OFF the alarm. The “ ” symbol
should show next to the clock display when alarm is set to ON. Press the
UP button again to turn off the alarm, when the alarm is set to OFF, the
“ ”symbol should not display.
5.When the alarm is in operation it will begin beeping with one short beep
and continue with many short beeps if the alarm
rings longer than 20 seconds. You can snooze the alarm for 5 minutes by
pressing the LIGHT/SNOOZE button.
Indoor / outdoor temperature
1.Indoor temperature -10°C – 70°C
2.Outdoor temperature-40°C – 70°C
Accuracy
1. Temperature accuracy: -40°C ~ -20°C: ± 4°C
-20°C ~ 0°C: ± 2°C
0°C ~ +50°C: ±1°C
GEEVON Digital Wall Clock with Thermometer
Item No.T208614C-1
User Manual
Thank you for purchasing T208614C-1 Digital Wall Clock.
Please take a moment to read this guide
and store it for future reference
1. Default time: 12:00 (Time form: 12H)
2. Default date: 01/01 (Year: 2017, date form: M/D)
Note: when the temperature in 50°C ~ 70°C range, the temperature is
only for reference.
MAX/MIN Temperature
1.Press a the MEM button to display the maximum temperature. Note the MAX
on the display.
2.Press the MEM button again to display the minimum
temperature. Note the MIN display.
3.Press and hold the MEM button for 5 seconds to clear the MAX/MIN
temperature readings.
Low Battery Indicator
If the low battery indicator is displayed on the LCD for either the outdoor
sensor or the display unit, immediately change the batteries to prevent
disruptions in communications of the devices.
Moon Phase
Important Placement Guidelines
a. The sensor must be placed outside to observe outdoor
conditions. It is water resistant and designed for general outdoor use,
however, to prevent damage place the sensor in an area which is protected
from the direct weather elements and direct sunshine. The best location is 4
to 8 feet above the ground with permanent shade and plenty of fresh air to
circulate around the sensor.
b. Display unit and outdoor sensor must be within 200 feet of each other.
c. In order to maximize the wireless range, place units away from large
metallic items, thick walls, metal surfaces or other objects that may limit
wireless communications.
d. To prevent wireless interferences, place both units at least 3 feet away from
electronic devices (EX: TV, computer, microwave etc.)
Outdoor Sensor Placement
a. The sensor must be placed outside to observe outdoor conditions. It is
water resistant and designed for general outdoor use, however, to prevent
damage place the sensor in an area which is protected from the direct
weather elements and direct sunshine. The best location is 4 to 8 feet
above the ground with permanent shade and plenty of fresh air to circulate
around the sensor.
b. Display unit and outdoor sensor must be within 100 feet of each other.
c. In order to maximize the wireless range, place units away from large
metallic items, thick walls, metal surfaces or other objects that may limit
wireless communications.
d. To prevent wireless interferences, place both units at least 3 feet away
from electronic devices (EX: TV, computer, microwave etc.)
Outdoor Sensor Function:
a. Once the display unit has been set up and the channel synchronized
with the outdoor sensor, the display unit will begin the registration process.
It can take up to 3 minutes to complete the registration, where the display
unit will search for an RF (Radio Frequency) signal from the outdoor
sensor. The outdoor sensor signal strength will show the connection
strength to the outdoor sensor. If there are no bars or if bars are not show-
ing at its maximum strength (4 bars) (3) try placing the outdoor sensor or
display unit elsewhere for better connection.
b. If the RF Signal was lost and not reconnected, the outdoor
temperature level will begin to flash after 1 hour of lost connection. If no
connection was found after 2 hours only a dotted line ‘ - - - ’ will be
displayed in place of the temperature level.
c. To manually restart the RF registration, press and hold the “CH” button
for 3 seconds. The display unit will now search for the RF signal for the
next 3 minutes.
TROUBLESHOOTING:
Problem Possible Solution
Flashing of the outdoor reading is generally an
indication of wireless interference.
1. Bring both of the sensor and display indoors, side
by side and remove batteries from each.
2. Power the weather station as described in
Getting started.
3. Insert the batteries in the external sensor.
Automatic data will be transmitted.
1. Reload the batteries of both outdoor sensor
and main unit.
(Please refer to the SENSOR SETUP section.)
2. Press and hold the CH button to receive RF
signal.
3. Relocate the main unit and/or the outdoor
sensor. The units
must be within 200 ft (60m) of each other.
4. Make sure both units are placed at least 3 ft
(1m) away from
electronics that may interfere with the wireless
communication
(such as TV, microwave, computer, radio, etc).
5. Do not use heavy duty or rechargeable
batteries. The outdoor sensor requires lithium
batteries in low temperature conditions. Cold
temperatures would cause alkaline batteries work
improperly.
6. Do not mix old and new batteries.
1. Temperature accuracy:
-40°C ~ -20°C: ± 4°C
-20°C ~ 0°C: ± 2°C
0°C ~ +50°C: ±1°C
2. When it is first stalled,it takes at least 1 Hour
to have accurate
temperature data.
3. Make sure both the main unit and sensor are
placed out of
direct sunlight and away from any heat sources,
vents or
moisture sources.
4. Do not tamper with the internal components.
1. To maximize wireless range, place units away
from large metallic
items, thick walls, metal surfaces, or other objects
that may limit
wireless communication.
2. Please immediately change the batteries if the low
battery indicator
is displayed on the LCD for sensor.
3. Do not clean any part of the product with
benzene,thinner or other
solvent chemicals. When necessary, clean it with a
soft cloth.
4. Never immerse the product in water. This will
damage the product.
5. Do not subject the product to extreme force,
shock, or fluctuations
in temperature.
If the temperature is higher than the detection
range, HH will
display on screen for indication; if lower than
the detection
range, LL will display on screen for indication.
If your Geevon product does not operate properly after trying the
troubleshooting steps, contact the seller on your order page or
Outdoor
Reading
Is Flashing
or Showing
Dashes
No outdoor
sensor
reception
Inaccurate
temperature
/humidity
Care and
maintenance
"HH/LL"
display
in indoor
and/or
outdoor
temperature
Other Geevon Clock manuals
