DVI CAT5 4X
Extender
EXT-DVI-CAT5-4X
User Manual

Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday.
Write To:
Gefen Inc.
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefen.com
[email protected]
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and
any accompanying documentation without prior written notice.
DVI CAT5 4X Extender is a trademark of Gefen Inc.
© 2008 Gefen Inc., All Rights Reserved
All trademarks are the property of their respective companies
ASKING FOR ASSISTANCE

CONTENTS
1 Introduction
2 Operation Notes
3 Features
4 Sender Panel Descriptions
5 Receiver Panel Descriptions
6 Connecting And Operating The DVI CAT5 4X Extender
7 Manual Equalization Procedure
8 Dip Switch Location Diagram
9 Network Cable Wiring Diagram
10 Rack Mount Installation
11 Mounting Plate Installation
12 Specifications
13 Warranty

1
Congratulations on your purchase of the DVI CAT5 4X Extender. Your complete
satisfaction is very important to us.
Gefen
Gefen delivers innovative, progressive computer and electronics add-on solutions
that harness integration, extension, distribution and conversion technologies.
Gefen’s reliable, plug-and-play products supplement cross-platform computer
systems, professional audio/video environments and HDTV systems of all sizes
with hard-working solutions that are easy to implement and simple to operate.
The Gefen DVI CAT5 4X Extender
The DVI CAT5 4X Extender is the perfect solution for anyone who needs to send
multiple (up to four) DVI video sources to multiple (up to four) DVI displays in
remote locations at the same time.
The DVI CAT5 4X Extender has 4 DVI video inputs. The DVI sources are sent to
up to four DVI CAT5 MS receivers via industry standard CAT-5, CAT-5e or CAT-6
cables. Distances of up to 300 feet for 1080i video, and 150 feet for 1080p video
are possible. Signal auto-equalization is set by default and will provide optimal
image reproduction for cable runs of 130 feet or less. Manual equalization is
available for cable runs at greater distances.
How It Works
Connect your DVI video sources to the DVI CAT5 4X Extender’s inputs using the
supplied DVI cables. Run two CAT-5, CAT-5e or CAT-6 network cables from the
DVI CAT5 4X Extender to each of the DVI CAT5 MS Receivers. Lastly, connect
up to four DVI displays to the DVI CAT5 MS receivers at the remote locations.
INTRODUCTION

READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE DVI CAT5 4X EXTENDER
The• DVI CAT5 4X Extender and DVI CAT5 MSR units are housed in a metal
box for better RF shielding.
The maximum cable extension is 300 feet (91 meters) for video resolutions• of 1080i and below.
The maximum cable extension is 150 feet (45 meters) for video resolutions• of 1080p.
The DDC cable (for each pair or extensions) does not need to be run if the• source does not require HDCP or DDC. In this scenario, a single CAT-5,
CAT5e or CAT-6 cable for the video can be run. If DDC is still required while
HDCP is not, the use of an EDID storage device (part# EXT-DVI-EDIDN,
EXT-DVI-EDIDP) can be used to transmit DDC information back to the
source with this single cable solution.
If EMI is present anywhere near the RJ-45 video cable runs, it may• be necessary to use shielded RJ-45 cable. This is to prevent possible
interference from degrading the video signal. Using shielded cable, however,
will reduce the maximum distance that the RJ-45 cable can be run.
Power supply for the receiver should not be connected unless you are using• the single CAT-5, CAT-5e or CAT-6 cable solution listed above.
Extensions under 130 feet can use Auto EQ (which is on by default).• Extensions over 130 feet will require you to manually EQ your signal (see
page 5).
Each cable run must be one continuous run from one end to the other. No• splices or use of punch down blocks.
High quality CAT-6 cabling should be used for maximum performance.•
Do not use stranded or low/no skew cabling. Solid core cabling should be• used for maximum performance.
HDCP Compliant.•
2
OPERATION NOTES

3
Features
Easily distribute four DVI sources to four remote DVI displays•
Extends video signals up to 300 feet over CAT-5, CAT-5e or CAT-6 network• cable
Maintains 1920 x 1200, 1080p, and 2k resolution video•
Package Includes
(1) 4X DVI CAT5 Sender
(4) DVI CAT5 MS Receivers
(4) 6 foot DVI cable (M-M)
(4) 5V DC power supply
(1) 24V DC power supply
FEATURES

4
Front Panel
Back Panel
Front
Panel
Video 4
RJ45 Outputs
Video 4
DVI Input
Power LED
Video 3
DVI Input
Video 2
DVI Input
Video 1
DVI Input
24V DC Power Input
Video 3
RJ45 Outputs
Video 2
RJ45 Outputs
Video 1
RJ45 Outputs
SENDER PANEL DESCRIPTIONS

5
Front Panel
Back Panel
DVI Output
VIDEO
RJ-45 Input
DDC
RJ-45 Input
5V DC
Power Input
Power LED
Indicator
EQ trim pot
RECEIVER PANEL DESCRIPTIONS

6
How to Connect the DVI CAT5 4X Extender
Connect your sources (up to four) to the DVI CAT5 4X Extender unit’s DVI1. inputs using the supplied DVI cables.
Connect your displays (up to four) to the DVI CAT5 MSR receiver unit’s2. DVI outputs using user supplied DVI cables.
Connect both CAT-5, CAT-5e or CAT-6 cables (DDC and Video) between3. the DVI CAT5 4X Extender and each DVI CAT5 MSR receiver.
NOTE: If field terminating network cable, please adhere to the TIA/EIA-568-B
standard. Please see page 9 for more information.
Plug the 24V power supply into the DVI CAT5 4X Extender sender.4.
NOTE: In most scenarios, the 5V DC external power supply for the receiving
units will not be required. Operational power is supplied by the sending unit via
the connected DDC CAT-5, CAT-5e or CAT6 cable. If the power LED indicator on
the receiving units are not on, please check to make sure that the RJ-45 cables
are not crossed (DDC to video and video to DDC).
Power on the displays.5.
Power on the sources.6.
NOTE: If an image is not being shown on the display, please check all cabling for
proper connections and follow the steps outlined below and in the next section.
DVI CAT5 4X EXTENDER CONFIGURATION
The DVI CAT5 4X Extender and DVI CAT5 MSR receivers have built-in auto
equalization that will automatically tune out any unwanted video noise. This
feature is reliable with premium cable runs up to a maximum of 130 feet. It may
be necessary to disable this feature if there is either no video being displayed on
initial start-up, there is video noise in the image, or the cable run exceeds 130
feet. First, verify that all the proper connections have been made and that all
devices are powered on before attempting to disable auto equalization. Please
follow the section on the next page to manually equalize the video signal.
CONNECTING AND OPERATING THE DVI CAT5 4X EXTENDER

7
MANUAL EQUALIZATION PROCEDURE
The DVI CAT5 4X Extender and DVI CAT5 MSR receiver units both have sets of
dip switches located on the underside of their casings. There is a piece of silver
metallic tape that must be removed to expose these dip switches. The DVI CAT5
4X Extender unit carries 4 banks of 4 dip switches. Each DVI CAT5 MSR receiver
carries one bank of 4 dip switches. Dip switches 1 and 2 on both the sending and
receiving units are used in this procedure. Dip switches 3 and 4 are not used. By
default, dip switch 2 on each bank of the DVI CAT5 4X Extender should be in the
ON position, and all dip switches on each DVI CAT5 MSR receiving unit should
be in the OFF position (Auto EQ On). To turn off auto equalization, turn dip switch
1 on the receiving units to the ON position (Auto EQ off). With these settings,
please follow the steps below to equalize the picture.
Insert a small flat head tool into the trim pot on the receiver unit.1.
Turn the trim pot in a clockwise fashion until it comes to a stop. Do not force2. the trim pot beyond this point. Doing so may render the trim pot useless.
Slowly turn the trim pot counter-clockwise in millimeter increments until the3. image stabilizes and all video noise disappears.
Carefully remove the adjustment tool.4.
NOTE: If your cable run is beyond 130 feet, or the steps above do not produce
any video, it may be necessary to increase the boost from the sending unit. Use
the chart below to increase the senders to medium boost by changing the DVI
CAT5 4X Extender’s dip switches. Once a new boost setting is set, repeat steps
1 through 4 from above. If this still does not produce and image, increase the
boost to high and repeat the EQ process.
Sender Dip Switch Settings
Setting Switch 1 Switch 2
Medium Boost OFF OFF
No Boost (Default) OFF ON
High Boost ON OFF
NOT USED ON ON
Receiver Dip Switch Settings
Setting Switch 1 Switch 2
Manual EQ ON OFF
Auto EQ (Default) OFF OFF

8
DVI CAT5 4X Extender
DVI CAT5 MSR
Remove Tape
Equalization
Trim Pot
Auto EQ Dip Switches
1432
1432
Boost Dip Switches
Remove Tape
FRONT
DIP SWITCH LOCATION DIAGRAM

12345678
Gefen has specifically engineered their products to work with the TIA/EIA-568-B
specification. Please adhere to the table below when field terminating cable for
use with Gefen products. Failure to do so may produce unexpected results and
reduced performance.
CAT-5, CAT-5e, and CAT-6 cabling comes in stranded and solid core types.
Gefen recommends using solid core cabling. CAT-6 cable is also recommended
for best results.
Each cable run must be one continuous run from one end to the other. No splices
or use of punch down blocks.
Pin Color
1 Orange / White
2 Orange
3 Green / White
4 Blue
5 Blue / White
6 Green
7 Brown / White
8 Brown
9
NETWORK CABLE WIRING DIAGRAM

10
Rear of unit
Front of unit
Rack mount ears are provided for installation of this unit into a 1U rack mount
space.
Locate the side screws on the unit.1. Remove the front 2 screws that are located closest to the front of the unit.2. Using the removed screws, screw the rack mounting bracket into the unit.3. Repeat the procedure on the opposite side of the unit.4.
1
2
3
4
RACK MOUNT INSTALLATION

11
1
2
3
Remove the rubber
feet covering the screws
off the bottom of the
unit.
Remove the screws.
Line up the mounting
plates and screw it on to
the unit.
Mounting Plate Installation
MOUNTING PLATE INSTALLATION

12
Video Amplifier Bandwidth ..............................................................4 x 165 MHz
Input Video Signal .......................................................................... 1.2 Volts p-p
Input DDC Signal ..................................................................... 5 Volts p-p (TTL)
Single Link Range ..............................................................1080p / 1920 x 1200
DVI Connector Type ...................................... DVI-I 29 Pin Female (digital only)
Link Connector .......................................................................................... RJ-45
Power Consumption ................................................................... 60 watts (max)
Transmitter Power Supply ...................................................................... 24V DC
Receiver Power Supply ........................................................................... 5V DC
Dimensions ..............................................................17” W x 1.75” H x 5.875” D
Shipping Weight ........................................................................................10 lbs.
SPECIFICATIONS
