User Manual
EXT-DP-CP-FM10
DisplayPort Fiber Optic
Pigtail Modules

DisplayPort Fiber Optic Pigtail Modules
Important Safety Instructions
ii
GENERAL SAFETY INFORMATION
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this product near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install or place this product near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided for
your safety. If the provided plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. To reduce the risk of electric shock and/or damage to this product, never handle or
touch this unit or power cord if your hands are wet or damp. Do not expose this
product to rain or moisture.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally,
or has been dropped.
15. Batteries that may be included with this product and/or accessories should never be
exposed to open ame or excessive heat. Always dispose of used batteries
according to the instructions.

Warranty Information
Gefen warrants the equipment it manufactures to be free from defects in material and
workmanship.
If equipment fails because of such defects and Gefen is notied within two (2) years from
the date of shipment, Gefen will, at its option, repair or replace the equipment, provided
that the equipment has not been subjected to mechanical, electrical, or other abuse or
modications. Equipment that fails under conditions other than those covered will be
repaired at the current price of parts and labor in effect at the time of repair. Such repairs
are warranted for ninety (90) days from the day of reshipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including without
limitation, any implied warranty or merchantability or tness for any particular purpose, all of
which are expressly disclaimed.
1. Proof of sale may be required in order to claim warranty.
2. Customers outside the US are responsible for shipping charges to and from Gefen.
3. Copper cables are limited to a 30 day warranty and cables must be in their original
condition.
The information in this manual has been carefully checked and is believed to be accurate.
However, Gefen assumes no responsibility for any inaccuracies that may be contained
in this manual. In no event will Gefen be liable for direct, indirect, special, incidental, or
consequential damages resulting from any defect or omission in this manual, even if
advised of the possibility of such damages. The technical information contained herein
regarding the features and specications is subject to change without notice.
For the latest warranty coverage information, refer to the Warranty and Return Policy under
the Support section of the Gefen Web site at www.gefen.com.
PRODUCT REGISTRATION
Please register your product online by visiting the Register Product page under the
Support section of the Gefen Web site.
iii
DisplayPort Fiber Optic Pigtail Modules

iv
Gefen, LLC
c/o Customer Service
20600 Nordhoff St.
Chatsworth, CA 91311
Telephone: [phone]
[phone]
Fax: [phone]
Email: [email protected]
Visit us on the Web: www.gefen.com
Technical Support Hours: 8:00 AM to 5:00 PM Monday - Friday, Pacic Time
DisplayPort Fiber Optic Pigtail Modules
is a trademark of Gefen, LLC.
Important Notice
Gefen, LLC reserves the right to make changes in the hardware, packaging, and any
accompanying documentation without prior written notice.
© 2013 Gefen, LLC. All Rights Reserved.
All trademarks are the property of their respective owners.
Contacting Gefen Technical Support
iv
DisplayPort Fiber Optic Pigtail Modules

vv
Operating Notes
• Both the Sender and Receiver pigtail modules have power receptacles and must be
connected to the included power supplies for proper operation.
• The maximum extension distances are listed based on the type of ber optic cable
that is being used:
► OM1: Up to 300 meters
► OM2 and OM3: Up to 1000 meters
DisplayPort Fiber Optic Pigtail Modules

vi
Features
• Extends DisplayPort up to 3300 feet (1000 meters) over a single-strand of 50/125µm
multimode (OM2 / OM3) SC-terminated ber optic cable
• Supports 1080p Full HD at 120Hz and dual-link resolutions up to
2560 x 1600 (WQXGA)
• Compliant with DisplayPort 1.1 standard
• Fiber optic transmission eliminates electromagnetic interference (EMI)
• Pigtail design relieves stress and clutter on the source and display connector panels
• HDCP and DPCP-compliant
• DDC bi-directional support
• Compact Sender and Receiver modules provide a clean, easy installation
• FCC and CE compliant for EMI/RFI emission
Packing List
The DisplayPort Fiber Optic Pigtail Modules ships with the items listed below. If any of
these items are not present in your box when you rst open it, immediately contact your
dealer or Gefen.
• 1 x DP Extender 1FO - Sender Pigtail module
• 1 x DP Extender 1FO - Receiver Pigtail module
• 2 x 5V / 2A DC Power Supplies
• 1 x Quick-Start Guide
Features and Packing List
DisplayPort Fiber Optic Pigtail Modules

3GSDI Audio Embedder
Table of Contents
viii
DisplayPort Fiber Optic Pigtail Modules
01 Getting Started
Cable Layout ......................................................................................................... 2
Sender Module.............................................................................................. 2
Receiver Module ........................................................................................... 3
Installation ............................................................................................................. 4
Connecting the DisplayPort Fiber Optic Pigtail Modules............................... 4
Sample Wiring Diagram ................................................................................ 4
Power Indicators ........................................................................................... 5
02 Appendix
Specications ........................................................................................................ 8

DisplayPort Fiber Optic
Pigtail Modules
01 Getting Started
Cable Layout ......................................................................................................... 2
Sender Module.............................................................................................. 2
Receiver Module ........................................................................................... 3
Installation ............................................................................................................. 4
Connecting the DisplayPort Fiber Optic Pigtail Modules............................... 4
Sample Wiring Diagram ................................................................................ 4
Power Indicators ........................................................................................... 5

page | 2
Sender Module
ID Name Description
1 Fiber optic connector Connect an SC-terminated ber optic
cable from this connector to the ber optic
connector on the Receiver pigtail module.
2 Power indicator This LED will glow bright blue when one
of the included 5V DC power supplies is
connected to the power receptacle on the
Sender module.
3 Power receptacle Connect the included 5V DC power supply
to this power receptacle on the Receiver
pigtail module. Both the Sender and
Receiver module have power receptacles
and must be connected to the included
power supplies for proper operation.
4 DisplayPort connector Connect this end of the Sender pigtail
module to the computer or other
DisplayPort source.
Getting Started
Cable Layout
1 2 4
3

Receiver Module
ID Name Description
1 Fiber optic connector Connect an SC-terminated ber optic
cable from this connector to the ber optic
connector on the Sender pigtail module.
2 Power indicator This LED will glow bright blue when one
of the included 5V DC power supplies is
connected to the power receptacle on the
Receiver module.
3 Power receptacle Connect the included 5V DC power supply
to this power receptacle on the Receiver
pigtail module. Both the Sender and
Receiver module have power receptacles
and must be connected to the included
power supplies for proper operation.
4 DisplayPort connector Connect this end of the Receiver pigtail
module to the display.
page | 3
Getting Started
Panel Layout
1 2 4
3

Connecting the DisplayPort Fiber Optic Pigtail Modules
1. Connect the Sender pigtail module to the computer or other DisplayPort source.
2. Connect the Receiver pigtail module to the display.
3. Connect a single strand of SC-terminated ber optic cable between the ber optic
connectors on the Sender and Receiver pigtail module. Refer to the Operating
Notes for information on ber optic cable-types and distances.
4. Connect the included 5V DC power supplies to both the Sender and Receiver
modules.
Sample Wiring Diagram
page | 4
Getting Started
Installation
Computer
DisplayPort
Display
Receiver
Sender
DISPLAYPORT
EXT-DP-CP-FM10
FIBER OPTIC CABLE

page | 5
Power Indicators
The power indicators on both the Sender and Receiver modules of the DisplayPort Fiber
Optic Pigtail Modules provide information about the current power state.
• If the power indicator on both the Sender and Receiver module glows bright blue, then
both the Sender and Receiver module are powered.
• If either power indicator is off, then the module is not powered. Ensure that the power
adapter is securely connected to the power receptacle on the module.
Getting Started
Installation
Sender module
Power cable
Power cable
Power indicator
Power indicator
Receiver module
SC ber cable
SC ber cable

DisplayPort Fiber Optic
Pigtail Modules
02 Appendix
Specications ........................................................................................................ 8

page | 8
Appendix
Specications
Supported Formats
Resolution (max.) • 2560 x 1600
Electrical
Video bandwidth • 3.5 Gb/s (per channel)
Power indicators (Sender / Receiver) • 1 x LED, blue
Connectors
Video Input (Sender) • 1 x DisplayPort 20-pin, male
Video Output (Receiver) • 1 x DisplayPort 20-pin, male
Link (Sender / Recceiver) • 1 x SC-type
Operational
Power Supply (Receiver) • 5V / 2A DC
Power Consumption • 1.5W (max.)
Operating Temperature • +32 to +122° F (0 to +50° C)
Storage Temperature • -4 to +158° F (-20 to +70° C)
Operating Humidity • 10 to 80% RH (non-condensing)
Physical
Dimensions (W x H x D) • 1.50” x 0.47” x 3.51”
(38.10mm x 11.93mm x 89.15mm)
Shipping Weight • 1.0 lb (0.45 kg)
