1x4 DVI Monitor
Switcher
USER MANUAL
www.gefen.com

Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00 AM to 5:00 PM Monday through Friday.
Write To:
Gefen Inc.
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefen.com
[email protected]
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
1x4 DVI Monitor Switcher is a trademark of Gefen Inc.
© 2007 Gefen Inc., All Rights Reserved
ASKING FOR ASSISTANCE

TABLE OF CONTENTS
Introduction
Features
Panel Descriptions
Connecting and Operating the 1x4 DVI Monitor Switcher
RMT4-IR Installation
Specifications
Warranty
1
2
3
4
5
6
7

Congratulations on your purchase of the ex•tend•it 1x4 DVI Monitor Switcher. Your com-
plete satisfaction is very important to us.
Gefen’s line of DVI switches, extenders, and splitters are designed to make yourA/V
equipment use more comfortable, more productive and less expensive.
The 1x4 DVI Monitor Switcher allow access to multiple DVI displays, using a single DVI
source while the DVI extender product line can extend the DVI video up to 1640 feet
(500 meters).
The ex•tend•it line offers solutions for noise, space and security concerns, data center
control, information distribution, conference room presentation, school and corporate
training environments.
Our Commitment
Gefen will always offer the finest quality product at the best possible price. Included in
that price is a lifetime of support from a team of outstanding engineers.
The ex•tend•it 1x4 DVI Monitor Switcher allows four DVI displays to be switched easily
from one DVI source. The 1x4 DVI Monitor Switcher can also be placed at the end of a
long DVI cable to regenerate the DVI signal.
INTRODUCTION
1

FEATURES
Features
• Connects a DVI/HDMI source to multiple DVI or HDMI compatible monitors or
projectors
• Maintains highest single link video resolution (1920x1200x60hz)
• Supports DDWG standard for DVI compliant monitors
• Installs in minutes
Includes:
(1) 1x4 DVI Monitor Switcher
(1) 6’ DVI-D cables (m-m)
(1) 5VDC Power Supply
(1) RMT4-IR
2

PANEL DESCRIPTIONS
3
LED Indicators
IR Eye
DVI out 1
5v Power
DVI out 2
Contact
Closure
DVI out 3
DVI In
DVI out 4
IR Extender Port

CONNECTING AND OPERATING THE 1X4 DVI MONITOR SWITCHER
How to Connect the 1x4 DVI Monitor Switcher to your devices
1 Connect the supplied DVI cable from the DVI source into the 1x4 DVI Monitor Switcher
Input.
2Connect the cables from your displays (monitor or projector) into the DVI Outputs of
the 1x4 DVI Monitor Switcher.
3Plug the 5v power supply into the DVI Monitor Switcher.
4Plug the 5v power supply into the wall outlet.
How to Operate the 1x4 DVI Monitor Switcher
1 Use the RMT4-IR remote control to remotely switch between sources.
2 Alternatively, use a RMT4 remote control port to remotely switch between sources.
4

RMT4-IR INSTALLATION
1. Remove battery cover from the back of the RMT4-IR remote.
2. Verify that dip switches 1 & 2 are in the down (OFF) position.
3. Insert the battery, hold the battery so that you can see the positive side facing up. The
side that is not marked must be facing down.
4. Test the RMT4-IR remote by pressing ONLY one button at a time. The indicator light
on the remote will flash once each time you press a button. WARNING: Do not press
multiple buttons simultaneously and do NOT press buttons rapidly. These actions will
cause the remote to reset and steps 1-4 will have to be repeated.
Note: The RMT4-IR ships with two batteries. One battery is required for operation, the
second battery is complimentary.
5

SPECIFICATIONS
6
Video Amplifier Bandwidth ................................................................................. 1.65 GHz
Input Video Signal ......................................................................................... 1.2 volts p-p
Input DDC Signal .................................................................................... 5 volts p-p (TTL)
Single Link Range ......................................................................................... 1920 x 1200
DVI Input/Output Connector Type ........................................................................... DVI-D
Power Consumption ................................................................................ 15 Watts (max.)
Power Supply .......................................................................................................... 5VDC
Dimensions .......................................................................... 9.125”W x 1.125”H x 3.25”D
Shipping Weight ....................................................................................................... 4 Lbs

Gefen Inc. warrants the equipment it manufactures to be free from defects in material
and workmanship.
If equipment fails because of such defects and Gefen Inc. is notified within two
(2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace
the equipment, provided that the equipment has not been subjected to mechanical,
electrical, or other abuse or modifications.
Equipment that fails under conditions other than those covered will be repaired at the
current price of parts and labor in effect at the of repair. Such repairs are warranted for
ninety (90) days from the day of reshipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including without
limitation, any implied warranty or merchantability or fitness for any particular purpose,
all of which are expressly disclaimed.
1. Proof of sale may be required in order to claim warranty.
2. Customers outside the US are responsible for shipping charges to and from Gefen.
3. Copper cables are limited to a 30 day warranty and cable must be free from any
scratches, markings, and neatly coiled.
The information in this manual has been carefully checked and is believed to be
accurate. However, Gefen Inc. assumes no responsibility for any inaccuracies that
may be contained in this manual. In no event will Gefen Inc., be liable for direct,
indirect, special, incidental, or consequential damages resulting from any defect
or omission in this manual, even if advised of the possibility of such damages. The
technical information contained herein regarding 1x4 DVI Monitor Switcher features and
specifications is subject to change without notice.
WARRANTY
7
