Gefen EXT-HDMI1.3-341 User manual

www.gefen.com
®
3x1 Switcher For
x 1.3
EXT-HDMI1.3-341
User Manual

ASKING FOR ASSISTANCE
Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday PST (Pacific Standard Time)
Write To:
Gefen LLC
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefen.com
[email protected]
Notice
Gefen LLC reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
3x1 Switcher for HDMI 1.3 is a trademark of Gefen LLC
HDMI is a trademark of HDMI.org
© 2010 Gefen LLC, All Rights Reserved
Rev X3
All trademarks are the property of their respective owners.

CONTENTS
1 Introduction
2 Operation Notes
3 Features
4 Panel Layout
5 Panel Descriptions
6 Connecting The 3x1 Switcher for HDMI 1.3
7 Specifications
8 Warranty

1
INTRODUCTION
Congratulations on your purchase of the 3x1 Switcher for HDMI 1.3 . Your com-
plete satisfaction is very important to us.
Gefen
Gefen is a unique product line catering to the growing needs for innovative home
theater solutions. We specialize in total integration for your home theater, while
also focusing on going above and beyond customer expectations to ensure you
get the most from your hardware. We invite you to explore our distinct product
line and hope you find your solutions. Don’t see what you are looking for here?
Please call us so we can better assist you with your particular needs.
Our Commitment
Gefen will always offer the finest quality product at the best possible price. Included
in that price is a lifetime support from a team of outstanding engineers.
Gefen’s line of HDTV switches, extenders, and splitters are designed to make your
A/V equipment use more comfortable, more productive and less expensive. Gefen
offers solutions for home theater, A/V installation, data center, information distribu-
tion, conference room presentation, school and corporate training environments.
The Gefen 3x1 Switcher for HDMI 1.3
Gefen’s 3x1 HDMI Switcher routes high definition video in multiple resolutions up
to 1080p plus multichannel digital audio from any of three sources. Three inputs
accommodate the simultaneous connection of up to three high definition video
sources, such as satellite systems and Blu-Ray players. The output sends the
high definition audio/video signals to a high definition display. Switching is done
via the IR remote that is provided with the unit.
How It Works
Simply connect all sources to the Switcher’s inputs. Then connect the display on
the output port. Once the sources, the Switcher and the display(s) are powered
and connected, simply select the source to view using the I/R remote.

2
FEATURES
Features
• Switches easily between any three HDMI 1.3 sources
• Maintains 480i/p, 576i/p, 720p, 1080i, and 1080p resolutions
• Maintains highest HDMI single link video resolution
• Supports HDCP compliant devices
• HDMI or DVI to HDMI cables are used to connect the inputs and switcher output
• Inputs can be switched with the IR remote control or by using the select button on
the front panel
• Installs in seconds
• Fully HDMI 1.3 compliant
HDMI 1.3 Features:
* Lip Sync Pass Through
* 225 MHz (up to 12 bit YUV 444 supported @ 1080p)
* Deep Color Supported (XV Color Supported)
* Dolby TrueHD & DTS Master Supported
* CEC Source Switching Enabled
Package Includes
(1) 3x1 Switcher for HDMI 1.3
(3) 6 Foot HDMI Cables (M-M)
(1) 5VDC Power Supply
(1) RMT3-IR Remote Control
(1) User's Manual

3
CONNECTING THE 3X1 SWITCHER FOR HDMI 1.3
How to Connect the 3x1 Switcher for HDMI 1.3 to your devices
Connect the supplied cables from the HDMI-compliant sources into the 3x1 Switcher for
HDMI 1.3.
Connect the cable from your display (monitor or projector) into the HDMI output of the 3x1
Switcher for HDMI 1.3.
Plug the 5VDC power supply into the 3x1 Switcher for HDMI 1.3.
How to Control the 3x1 Switcher for HDMI 1.3
Use the RMT3-IR remote control to toggle between sources on the 3x1 Switcher for HDMI
1.3. You can also use the Select Button on the front panel to cycle between the inputs.
EXT-HDMI1.3-341
HDMI 1.3 Source
HDMI 1.3 Source
HDMI 1.3 Source
HDTV
HDMI CABLE
Switcher
Wiring Diagram for the 3x1 Switcher for HDMI 1.3

4
PANEL LAYOUT
Front Panel
Back Panel
24
3
1
9
5
876 10

5
PANEL DESCRIPTIONS
1 Power LED Indicator
This LED will become active once the included 5V DC power supply is properly
connected between the unit and an open wall power socket.
2 I/R (Infrared) Receiver
This receiver will accept command for switching between input devices using
the included RMT3-IR remote control. Line of sight must be preserved between
the remote and unit for proper operation
3 Selected Input LED Indicator
There is a 3 LED array to indicate which source is currently selected on the 3x1
Switcher. The currently selected input will be indicated by an active LED.
4 Input Source Selector Button
Pressing this button will manually switch between as many as three HDMI
sources connected on the rear of the Switcher. The inputs ports (items 6, 7,
and 8 below) can accept (up to three) HDMI-compliant devices. The selected
input source is sent to the single output. Selection of input sources may also
be accomplished using the included RMT-3IR remote control or via the RS-232
serial communication port.
5 I/R Extension Port
This port is used to control input source switching on the 3x1 HDMI Switcher.
6 HDMI Input 1
This port can accept HDMI connections from any HDMI-compliant source
device.
7 HDMI Input 2
This port can accept HDMI connections from any HDMI-compliant source
device.
8 HDMI Input 3
This port can accept HDMI connections from any HDMI-compliant source
device.
9 HDMI Output
This port provides the Switcher’s HDMI output signal to a single HDMI-compliant
output device/display.
10 5V DC Power Supply Input
This receptacle accepts power from the included 5VAC/DC power supply.
Connect the included power supply to an open wall power socket, then connect
the 5V DC power tip to this receptacle.

6
RMT3-IR INSTALLATION
1. Remove battery cover from the back of the RMT3-IR remote.
2. Verify that dip switches 1 & 2 are in the down (OFF) position.
3. Insert the battery, hold the battery so that you can see the positive side facing up.
The side that is not marked must be facing down.
4. Test the RMT3-IR remote by pressing ONLY one button at a time. The indicator
light on the remote will flash once each time you press a button. WARNING: Do
not press multiple buttons simultaneously and do NOT press buttons rapidly.
These actions will cause the remote to reset and steps 1-4 will have to be
repeated.
Note: The RMT3-IR ships with two batteries.

7
IR CODE CONFLICTS
Remote Remote Channel 1:
Remote Channel 2:
Remote Channel 3:
Remote Channel 4:
1 2
1 2
1 2
1 2
How to Resolve IR Code Conflicts
There are matching pairs of dip switches underneath the Switcher unit and under the
remote battery cover. Switch 1 & 2 on the Remote and Switch 1 & 2 (switches 3 and 4
are not used) on the dip switch bank located underneath the unit. These switches need
to be matched for the remote to communicate with the switcher. Switch 1 on the remote
is linked to switch 1 on the unit, and switch 2 on the remote is linked to switch 2 on the
unit. There are 4 possible sets of IR codes and at least one of these sets should be able
to resolve any IR conflicts with other home theater devices.

8
SPECIFICATIONS
Video Amplifier Bandwidth .............................................................................225 MHz
Input Video Signal ....................................................................................1.2 Volts p-p
Input DDC Signal ...............................................................................5 Volts p-p (TTL)
Single Link Resolution .................................1080p/60 10 bit Color Depth, 1920x1200
HDMI Connector .......................................................................Type A 19 Pin Female
Remote Control Port ......................................................................Mini-Stereo 3.5mm
Power Supply ....................................................................................................5V DC
Power Consumption ..............................................................................5 Watts (max)
Dimensions ...............................................................................9.4”W x 1.1”H x 2.7”D
Shipping Weight ..................................................................................................4 lbs.

9

*ma-EXT-HDMI1.3-341*
Rev X1
Pb
20600 Nordhoff St., Chatsworth CA 91311
1-800-545-6900 818-772-9100 fax: [phone]
www.gefenPRO.com[email protected]m
