Gefen HDMI-241N User manual

HDMI Switcher
USER MANUAL
www.gefen.com

Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00 AM to 5:00 PM Monday through Friday.
Write To:
Gefen Inc.
C/O Customer Service
20600 Nordhoff St.
Chatsworth, CA 91311
www.gefen.com
[email protected]
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
HDMI Switcher is a trademark of Gefen Inc.
© 2007 Gefen Inc., All Rights Reserved
ASKING FOR ASSISTANCE

TABLE OF CONTENTS
Introduction
Features
Panel Descriptions
Connecting and Operating the HDMI Switcher
RMT2-IR Installation
IR Conflict Codes
IR Extender Installation
Specifications
Warranty
1
2
3
4
5
6
7
8
9

Congratulations on your purchase of the Gefen HDMI Switcher. Your complete satisfac-
tion is very important to us.
Gefen’s line of HDMI switches, extenders, and splitters are designed to make yourA/V
equipment use more comfortable, more productive and less expensive.
The HDMI Switcher allow access to multiple HDMI devices, using a single HDMI display
while the HDTV extender product line can extend HD video signal up to 1640 feet (500
meters).
Gefen products offer solutions for noise, space and security concerns, data center con-
trol, information distribution, conference room presentation, school and corporate train-
ing environments.
Our Commitment
Gefen will always offer the finest quality product at the best possible price. Included in
that price is a lifetime of support from a team of outstanding engineers.
The Gefen HDMI Switcher allows two HDMI devices to be switched easily in to one
HDMI compatible monitor or projector. The HDMI Switcher can also be placed at the
end of a long HDMI cable to regenerate the HDMI signal.
INTRODUCTION
1

FEATURES
Features
• Switches easily between any two HDMI sources
• Maintains 480i, 480p, 720p, 720i, and 1080i, 1080p resolutions
• Extends any HDMI compliant device by regenerating the HDMI signal
• Maintains high resolution video—beautiful, sharp HDTV resolutions up to 1080P
are easily achieved. For computer users, the 2x1 HDMI Switcher conforms with HDMI
specifications for resolutions up to 1920 x 1200.
• Supports DDWG standard for HDMI compliant monitors
• Supports HDCP compliant devices
• Optional RMT-2 remote control
• Installs in seconds
Includes:
(1) HDMI Switcher
(2) 6’ HDMI cables (M-M)
(1) 5V DC Power Supply
(1) RMT2-IR
(1) Manual
2

PANEL DESCRIPTIONS
Connects to
5VDC power supply
Connects to IR
extender IR eye Indicates if port 1 or
port 2 is selected Selects port 1
or port 2
3
HDMI In 2
HDMI In 1 HDMI Out

CONNECTING AND OPERATING THE HDMI SWITCHER
How to Connect the HDMI Switcher to your devices
1 Connect the supplied HDMI to HDMI cables from the HDMI sources into the HDMI
Switcher Input.
2Connect the cable from your display (monitor or projector) into the HDMI Out of the
HDMI Switcher.
3Plug the 5VDC power supply into the HDMI Switcher.
How to Operate the HDMI Switcher
1 Use the front panel push button to switch between sources.
2 Alternatively, use the RMT2-IR remote control port to remotely toggle between sources.
4

RMT2-IR INSTALLATION
1. Remove battery cover from the back of the RMT2-IR remote.
2. Verify that dip switches 1 & 2 are in the down (OFF) position.
3. Insert the battery, hold the battery so that you can see the positive side facing up. The
side that is not marked must be facing down.
4. Test the RMT2-IR remote by pressing ONLY one button at a time. The indicator light
on the remote will flash once each time you press a button. WARNING: Do not press
multiple buttons simultaneously and do NOT press buttons rapidly. These actions will
cause the remote to reset and steps 1-4 will have to be repeated.
Note: The RMT2-IR ships with two batteries. One battery is required for operation, the
second battery is complimentary.
5
The optional IR extender allows you to re-
locate your HDMI Switcher and still have IR
control of the HDMI Switcher

IR CODE CONFLICTS
How to Resolve IR Code Conflicts
There are matching pairs of dip switches underneath the Switcher unit (outlined below)
and under the remote battery cover. Each has two switches which need to be matched for
the remote to work. There are 4 possible sets of IR codes and at least one of these sets
should be able to resolve any IR conflicts with other home theater devices.
6

IR EXTENDER INSTALLATION
How to Connect the IR Extender
1 Plug the IR extender into the Remote port on the front of the Switcher Unit
2Flip the Dip Switch #1 underneath the unit from the set that is not outlined on the
previous page to the ON position
7
IR CODES
In the event of IR conflicts, please do the following:
1. Remove the battery cover from the back of the RMT4-IR remote.
2. Locate the Dip Switches above the batteries.
3. Switch the Dip Switches on the RMT4-IR to any of the combinations pictured below.
4. Dip Switches 1 and 2 in the RMT4-IR correspond with Dip Switches 3 and 4 on the
bottom of the 4x1 DVI Switch respectively. Switch the switches on the bottom of the 4x1
DVI Switch to match the dip switches on the RMT4-IR. The 4x1 DVI Switcher is now set
to a new IR Code.
12
Remote Channel 0:
12
Remote Channel 1:
12
Remote Channel 2:
12
Remote Channel 3:

SPECIFICATIONS
8
Video Amplifier Bandwidth ................................................................................ 1.65 Gbps
Input Video Signal ......................................................................................... 1.2 volts p-p
Input DDC Signal .................................................................................... 5 volts p-p (TTL)
Single Link Range ......................................................................................... 1920 x 1200
HDMI Input/Output Connector Type .............................................. Type A (19 pin) female
Power Consumption ................................................................................ 15 Watts (max.)
Power Supply ......................................................................................................... 5V DC
Dimensions ............................................................................................. 4”D x 1”W x 4”H
Shipping Weight ....................................................................................................... 4 lbs.

Gefen Inc. warrants the equipment it manufactures to be free from defects in material
and workmanship.
If equipment fails because of such defects and Gefen Inc. is notified within two
(2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace
the equipment, provided that the equipment has not been subjected to mechanical,
electrical, or other abuse or modifications.
Equipment that fails under conditions other than those covered will be repaired at the
current price of parts and labor in effect at the time of repair. Such repairs are warranted
for ninety (90) days from the day of reshipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including without
limitation, any implied warranty or merchantability or fitness for any particular purpose,
all of which are expressly disclaimed.
1. Proof of sale may be required in order to claim warranty.
2. Customers outside the US are responsible for shipping charges to and from Gefen.
3. Copper cables are limited to a 30 day warranty and cable must be free from any
scratches, markings, and neatly coiled.
The information in this manual has been carefully checked and is believed to be
accurate. However, Gefen Inc. assumes no responsibility for any inaccuracies that may
be contained in this manual. In no event will Gefen Inc., be liable for direct, indirect,
special, incidental, or consequential damages resulting from any defect or omission
in this manual, even if advised of the possibility of such damages. The technical
information contained herein regarding HDMI Switcher features and specifications is
subject to change without notice.
