GefenTV GTV-HDMI-2-COMPSVIDS User manual

HDMI To Composite/S-Video Scaler
User Manual
www.gefentv.com
GTV-HDMI-2-COMPSVIDS
®

ASKING FOR ASSISTANCE
Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday Pacific Time
Write To:
Gefen, LLC
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefen.com
[email protected]
Notice
Gefen, LLC reserves the right to make changes in the hardware, packaging and
any accompanying documentation without prior written notice.
HDMI To Composite/S-Video Scaler is a trademark of Gefen, LLC
© 2011 Gefen, LLC, All Rights Reserved
All trademarks are the property of their respective owners
Rev A9

CONTENTS
1 Introduction
2 Operation Notes
3 Features
4 Panel Layout
5 Panel Descriptions
6 Connecting And Operating Instructions
6 HDMI To Composite/S-Video Scaler
7 Specifications
8 Warranty

1
Congratulations on your purchase of the HDMI To Composite/S-Video Scaler.
Your complete satisfaction is very important to us.
GefenTV
GefenTV is a unique product line catering to the growing needs for innovative
home theater solutions. We specialize in total integration for your home theater,
while also focusing on going above and beyond customer expectations to ensure
you get the most from your hardware. We invite you to explore our distinct
product line and hope you find your solutions. We will be happy to assist you in
finding a solution for your particular needs. Please call us so we can better assist
you with your particular needs.
The GefenTV HDMI To Composite/S-Video Scaler
The new GefenTV HDMI to Composite Scaler lets you transform HDMI video of
resolutions from 480p to 1080p into Composite video or S-Video, properly sized
to view optimally on your display.
How It Works
Simply connect your HDMI video source to the HDMI input jack of the GefenTV
HDMI to Composite Scaler. Connect your Composite or S-Video display cable to
the correct video output jack on the Scaler’s rear panel. RCA-type analog audio
output jacks and Coaxial S/PDIF digital audio output jacks allow for the connec-
tion of an audio Receiver or other device to receive the audio signal embedded
in the HDMI signal. Power-cycle all connected components. You will then have
HDMI video playing on your Composite or S-Video display with simultaneous
audio out.
Note regarding 480i / 576i resolutions on the inputs:
The main purpose for the GTV-HDMI-2-COMPSVID is to downscale high defini-
tion digital video to standard definition NTSC / PAL analog signals.
The GTV-HDMI-2-COMPSVID does not accept input video resolutions of 480i
and 576i due to a limitation of the internal circuitry. A workaround is to connect
devices with these output resolutions directly to displays. Source devices operat-
ing at resolutions of 480i / 576i will almost always have analog outputs such as
Component, S-Video or Composite Video jacks.
INTRODUCTION

2
READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE HDMI TO COMPOSITE/S-VIDEO SCALER
• The HDMI To Composite/S-Video Scaler converts HDTV input resolutions of
480p, 576p, 720p, 1080i and 1080p at 50/60 Hz to either NTSC 480i or PAL
576i.
• Supported PC input resolutions include 640x480@60Hz, 800x600@60Hz,
1024x768@60Hz, 1280x1024@60Hz, 1600x1200@60Hz, and
1920x1200@60Hz.
• The HDMI To Composite/S-Video Scaler will cross-convert between some
digital audio formats. Both the digital and analog audio outputs are active at
all times. The HDMI To Composite/S-Video Scaler will not, however, down-
mix multi-channel digital audio formats to 2 channel analog stereo. Please
see the chart on page 6 for more info.
• This device supports both NTSC and PAL video standards. This device
maintains the aspect ratio of the original signal.
• Please be sure to set the proper output format for your television. NTSC
60Hz is commonly used in the United States and Japan, while PAL 50Hz is
commonly used in European countries. Using the improper format will result
in a unrecognizable picture and may damage your TV set.
• The HDMI To Composite/S-Video Scaler is HDMI 1.2 Compliant.
• HDCP encrypted HDMI sources are not supported by this device. If a
connected HDMI source requires HDCP the outgoing video signal will result
in a black screen.
OPERATION NOTES

3
Features
• HDMI to Composite / S-Video conversion plus scaling
• HDMI pass-through
• Supports 480p to 1080p HDMI input resolutions at 50/60 Hz.
• Outputs 480i / 576i signal for Composite/S-Video Display devices
• Supports both NTSC and PAL formats
Package Includes
(1) HDMI To Composite/S-Video Scaler
(1) 6 Foot HDMI Cable (M-M)
(1) 5V DC Power Supply
(1) User’s Manual
FEATURES

4
Front Panel
Back Panel
1
798
6
5
432
PANEL LAYOUT

5
1 Stereo Analog Audio Output
2 RCA stereo analog audio outputs. Connects to the display or a audio
Receiver. Only 2 channel LPCM from the HDMI input can be passed to these
outputs. Multi-channel bit-stream such as Dolby Digital will not be passed to this
output.
2 Composite Analog Video Output
RCA composite video output. Connect to a composite input on a television. 480i
and 576i are the only resolution output options.
3 S-Video Analog Video Output
S-Video video output. Connect to a s-video input on a television. 480i and 576i
are the only resolution output options.
4 Digital Audio Output
Coaxial digital audio output. Connects to the display or a audio Receiver. 2
channel LPCM and multi-channel bitstream can be output from this connector.
5 Video Format Output Switch
Switch between NTSC (60Hz) and PAL (50Hz) output. Please ensure that you
use the proper output for you television. Using the wrong format will result in a
unrecognizable picture and may damage your television.
6 Under/Over Scan Switch
Most analog television sets were designed to accept an over-scanned signal.
If the resulting video signal displays a black border around the edges, use
the over-scan option. If the resulting video signal is stretched far beyond the
television’s edge, use the under-scan option.
7 HDMI Input
Connect the HDMI source to this input connector. This will accept both video
and audio through the HDMI connector.
8 5V DC Power Supply Input
Connect the included 5V DC power supply to this input.
9 Power LED
This LED will become active once the included power supply is properly
connected.
PANEL DESCRIPTIONS

6
How to Connect the HDMI To Composite/S-Video Scaler
1. Connect the HDMI source to the HDMI To Composite/S-Video Scaler’s HDMI
input using the supplied HDMI cable.
2. Connect the display to the HDMI To Composite/S-Video Scaler’s composite
or s-video outputs using user supplied cables.
3. Connect the HDMI To Composite/S-Video Scaler’s stereo analog audio
output to the display or audio Receiver. Optionally, you can connect the
digital coaxial output to the display or an audio Receiver.
4. Ensure that the proper video output format is set using the NTSC/PAL format
switch on the rear panel of the unit. Please consult your television’s manual
for the proper input format type.
5. Connect the included 5V DC power supply to the HDMI To Composite/S-
Video Scaler.
6. Once you have a video image on-screen, use the under/over scan switch to
adjust the image’s size.
NOTE: The HDMI To Composite/S-Video Scaler will cross convert between some
digital audio formats. Both the digital and analog audio outputs are active at all
times. The HDMI To Composite/S-Video Scaler will not, however, down-mix multi-
channel digital audio formats to 2 channel analog stereo. Please see the chart
below for supported input and output formats.
INPUT ►HDMI
MULTICHANNEL
LPCM
HDMI
2 CHANNEL
LPCM
HDMI
DOLBY DIGITAL
& DTS
OUTPUT ▼
DIGITAL
COAXIAL
YES
*2 CHANNEL YES YES
ANALOG
STEREO
MINI-JACK
NO YES NO
*2 channels are the front right and front left speakers. It will not down-mix multi-channel to 2 channel audio
CONNECTING AND OPERATING INSTRUCTIONS

7
Input Video Signal .................................................................................... 1.2V p-p
Input Sync Signal ............................................................................... 5V p-p (TTL)
Horizontal Frequency Range .................................................................31-70 KHz
Vertical Frequency Range ......................................................................50-60 KHz
Power Supply .............................................................................................. 5V DC
A/V Input .............................................................. (1) HDMI Type A, 19-pin female
Video Outputs .................................................... (1) Composite RCA / (1) S-Video
Audio Outputs ........................ (2) L/R RCA analog audio, (1) S/PDIF digital audio
Power Consumption ..................................................................... 7.5 Watts (max)
Power Supply .............................................................................................. 5V DC
Shipping Weight ............................................................................................ 4 lbs.
SPECIFICATIONS

8
WARRANTY
G
e
f
en warrants the equipment it manu
f
actures to be
f
ree
f
rom de
f
ects in material
and workmanship.
I
f
equipment
f
ails because o
f
such de
f
ects and
G
e
f
en is noti
fi
ed within two
(
2
)
y
ears
f
rom the date o
f
shipment,
G
e
f
en will, at its option, repair or replace the
e
quipment, provided that the equipment has not been sub
j
ected to mechanical,
e
lectrical, or other abuse or modi
fi
cations. Equipment that
f
ails under conditions
other than those covered will be repaired at the current price o
f
parts and labor in
eff
ect at the time o
f
repair.
S
uch repairs are warranted
f
or ninet
y
(
90
)
da
y
s
f
rom
the da
y
o
f
reshipment to the Bu
y
er.
This warrant
y
is in lieu o
f
all other warranties expressed or implied, includin
g
without limitation, an
y
implied warrant
y
or merchantabilit
y
or
fi
tness
f
or an
y
p
articular purpose, all o
f
which are expressl
y
disclaimed.
1. Proo
f
o
f
sale ma
y
be required in order to claim warrant
y
.
2.
C
ustomers outside the U
S
are responsible
f
or shippin
g
char
g
es to and
f
rom
G
e
f
en.
3
.
C
opper cables are limited to a 30 da
y
warrant
y
and cables must be in their
ori
g
inal condition.
The in
f
ormation in this manual has been care
f
ull
y
checked and is believed to
be accurate. However,
G
e
f
en assumes no responsibilit
y
f
or an
y
inaccuracies
that ma
y
be contained in this manual. In no event will
G
e
f
en be liable
f
or
direct, indirect, special, incidental, or consequential dama
g
es resultin
g
f
rom
an
y
de
f
ect or omission in this manual, even i
f
advised o
f
the possibilit
y
o
f
such
dama
g
es. The technical in
f
ormation contained herein re
g
ardin
g
the
f
eatures and
s
peci
fi
cations is sub
j
ect to chan
g
e without notice.
For the latest warrant
y
covera
g
e in
f
ormation, please visit
G
e
f
en’s Warrant
y
web
p
a
g
e at http:
//
www.
g
e
f
en.com
/
kvm
/
aboutus
/
warrant
y
.
j
s
p
P
RODUCT REGISTRATIO
N
P
lease re
g
ister
y
our product online b
y
visitin
g
Gefen’s web site at
http://www.
g
efen.com/kvm/Re
g
istr
y
/Re
g
istration.
j
sp

20600 Nordhoff St., Chatsworth CA 91311
1-800-545-6900 818-772-9100 fax: [phone]
www.gefen.com [email protected]
Rev A9
