GeneMate GP-Series User manual

GP-Series Portable Balances
Operation Manual

TABLE OF CONTENTS
SAFETY PRECAUTIONS………………………………………………………. 1
GETTING STARED……………………………………………………………… 1
INSTALLATION & SET-UP…………………………………………………….. 2
POWER CONNECTION & BATTERY OPERATION…………………………2
LEVELING…………………………………………………………………………3
CALIBRATION…………………………………………………………………… 3
WEIGH MODE SETTINGS........................................................................... 3
BACKLIGHT SETTINGS……….…………….………………………………… 4
AUTO OFF SETTINGS…………..…………………………………………….. 4
TARE FUNCTION…………………..…………………………………………….5
CARE & MAINTENANCE…..……….…………………………………………...5
ERROR MESSAGES & TROUBLESHOOTING GUIDE.….….……….........6
SERVICE & TECHNICAL SUPPORT………………………….……………….7
DISPOSAL……………………………………………………………..………….7
CE COMPLIANCE & MARKING…..………………………………….………...8
SPECIFICATIONS……………………………………………………….……….9
FEATURES……………………………………………………………….……….9
INSTRUMENT DIAGRAM..…………………………………………….………10
i

Congratulations and thank you for selecting a GeneMate GP-Series Portable
balance. Your balance was designed and manufactured to give you years of
service.
SAFETY PRECAUTIONS
-Check the instrument for any visible signs of damage before you apply
power.
-Ensure the power supply is compatible with your instrument AND the local
line voltage.
-Do NOT operate in Hazardous Locations. Consult your Safety Officer with
any questions or concerns.
-Make sure no liquid enters the housing. Use a damp cloth to clean the
instrument.
-Avoid exceeding/overloading the weigh capacity or dropping samples onto
the weigh pan. Weight overload and shock may damage the instrument
and void the warranty.
-When utilizing the battery operation mode, do not mix batteries. Replace all
six batteries at the same time. If the instrument will not be used for an
extended period of time, remove all batteries from the instrument. Failure
to do so may cause leakage and damage to the instrument.
GETTING STARTED
First, check the contents of your shipping carton for the following:
-GP-Series Balance
-Weigh Pan and Sub Pan
-Operation Manual
-Power Adapter
-Weigh Bowl (except GP-123MDS)
Please read your operation manual and follow the instructions for installing
your balance. Please keep your packaging for future transport and remember
to return your Warranty Card.
Page 1

INSTALLATION & SET-UP
- Choose a location that is free from the influences of the following:
-Drafts: fans, heat/air duct, doorways or high traffic areas.
-Vibrations.
-Extreme temperature fluctuations: sunlight, ovens, or environments with
wide ambient temperature changes.
-Voltage Fluctuations. Do not share current with other Instruments that
draw voltage in an inconsistent manner such as fluorescent lights,
centrifuges and the like.
- Place Instrument on a level, rigid surface.
- Level the instrument.
- Allow 30 minutes for warm-up.
- Calibrate. All GP-Series are calibrated at the factory prior to shipment.
Transportation of the instrument plus the differences in barometric pressure,
humidity and ambient temperate conditions require calibration at the point of
use. Calibrate regularly, at least once a week, to ensure accurate weighing
results.
AC POWER CONNECTION & BATTERY OPERATION OPTION
- When connecting power use the original AC adapter supplied with the
balance. Using an unapproved power supply may damage the instrument
and void the warranty.
- Connect the plug to the instrument.
- Ensure the power supply is compatible with your instrument AND the local
line voltage.
- Connect adapter to the power outlet.
- Original Power Supply:
Input: 110 -240 VAC, 50-60 Hz, 400mA
Output: 9VDC, 300 mA
Polarity: Inside = -, Outside = +
Battery Operation: 6 AA
Do not mix batteries. Replace all six batteries at the same time. If the
instrument will not be used for an extended period of time, remove all batteries
from the instrument. Failure to do so may cause leakage and damage to the
instrument.
Page 2

LEVELING
For accurate calibration and weigh results level the balance at installation and
any time the instrument is moved to a new location.
Ensure the two rear feet are fully retracted and adjust the two front feet to level
the balance.
CALIBRATION
Calibration is required at installation (see Installation & Set-up) and at regular
intervals thereafter. Calibrate if the balance is moved to a new location.
1. Allow a 30-minute warm-up period.
2. Remove all items from weigh pan.
3. Press Tare to zero balance – if required.
4. Press CAL Key
The appropriate calibration weight for your balance (see chart below) will
“flash” on the display.
5. Place calibration weight on the weigh pan.
6. When calibration is complete the balance will display the selected
calibration weight value, beep and return to the weigh mode.
Calibrate on a regular basis, we recommend once a week, or more.
Calibration Weight Values
B-1852-120 100g ASTM Class 3*
B-1852-500 500g ASTM Class 4*
B-1852-1500 1000g ASTM Class 4*
B-1852-3000 2000g ASTM Class 4*
B-1852-6000 5000g ASTM Class 4*
* Or Better
WEIGH MODE SETTINGS
THE GP-Series offers five modes of measurement. Press the UNIT KEY to toggle between
weigh modes.
The >indicator inside the display will highlight the selected weigh mode.
GP-SERIES Weigh Modes:
GP-123MDS: g, mg, dwt, ozT, GN
All Other Models: g, dwt, oz, lb, ozT
Page 3

BACKLIGHT SETTINGS
All GP-Series balances come with an adjustable backlight display (on or off).
The factory default setting is on. However, should you wish to deactivate the
backlight feature:
Press ON/OFF Key to turn the power off, press again to turn power on. When
instrument displays ---------
Press TARE KEY until A. OFF appears on the display.
Press UNIT KEY once L. ON will appear on the display.
To toggle between Backlight On (L_ON) and Backlight Off L_OFF) Press
TARE KEY.
Press ON/OFF to turn the power off, Press ON/OFF again to turn on the
power and the scale return to the weighing mode
AUTO SHUTOFF SETTINGS
All GP-Series balances come with an AUTO OFF feature, typically used in the
battery operation mode. The AUTO OFF feature is deactivated at the factory.
However, should you wish to activate the Auto Off feature:
Press ON/OFF Key to turn the power off, press again to turn power on. When
instrument displays ---------.
Press TARE KEY until A. OFF appears on the display.
To toggle between AUTO ON (A. ON) and AUTO OFF (A. OFF) Press TARE
KEY. AUTO ON (A. ON) indicates auto shut off function is active.
Press [ON/OFF] to turn the power off, Press ON/OFF again to turn on the
power and return to the weighing mode.
Page 4

TARE FUNCTION
TARE is defined as net weight. Should you wish to use a beaker, flask or some
other container for your sample simply place the container on the weigh pan
and press the TARE KEY. Please note that any container that is “tared” will
decrease the remaining capacity available on the balance by the weight of the
container.
If you do not use a container for weighing verify the reading is "0" before
placing a sample on the weigh pan. If not, press TARE KEY to display "0".!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
CARE & MAINTENANCE
- Unplug the instrument from the power source and remove all
batteries from the battery compartment.
- Wear appropriate safety protection.
- Clean inside hood when appropriate.
- A damp cloth is recommend for basic cleaning. Do not use solvents
on the instrument housing, sub-pan, keypad, power cord and power
jack.
- Make sure no liquid enters the instrument housing.
- Handle with care to avoid damage to the weigh cell.
- Consult your safety officer with any questions or concerns.
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!Page!5!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!

ERRROR MESSAGES & TROUBLESHOOTING GUIDE
ERROR CODE ISSUE SOLUTION
Blank Display Power Check Adapter & Outlet
ERR-0 Overload Capacity Exceeded Or
Damaged Weigh Cell
ERR-2 Zero Tracking (weight Remove All Weight From
on weigh pan during Weigh Pan and Cycle
power on sequence) Power
Stainless Steel Weigh Reassemble with Weigh
Pan Not Assembled at Pan, Sub Pan and
Calibration Calibrate
ERR-5 Internal Signal Weigh Pan Alignment
Unstable Ensure Weigh Pan & Draft
Ring Placement are Correct
Unstable Power – Check
Power Supply / Transformer
ERR-C Calibration Error Repeat Calibration Process
Incorrect Weight Ensure Correct Calibration Weight
Is Used – See Page 3
ERR-L Calibration Error Repeat Calibration Process
No Weight Placed
On Weigh Pan
ERR-E Memory Error Cycle Power (On/Off Switch)
: Low Battery Replace Batteries
Indicator 6 AA. Replace all
Batteries at Same Time
Page 6

SERVICE & TECHNICAL SUPPORT
If you have ANY questions or require technical, application or service support
please contact BioExpress at 800-999-2901.
Please note that the manufacturer and its affiliates cannot take back any
instrument that has been exposed to biological or hazardous material
contamination for replacement, credit, repair or disposal.
DISPOSAL
Please consider the environment when disposing of your instrument and the
packing material. Please recycle all environmentally friendly waste. Please
contact your local government agency, facilities manager or a commercial
disposal operator on the proper disposal of the instrument, power supply and
batteries.
Page 7

CE COMPLIANCE & MARKING
This instrument complies with European Standards and EC Directives:
Electromagnetic Compatibility (EMC) Council Directive 89/336/EEC
Applicable European Standards:
Limitation of Emissions in accordance with standard EN 61326-1 Class B for
residential areas.
72/23/EEC “Electrical Equipment Design within Certain Voltage Limits”
Applicable European Standards:
EN 60950
Safety Requirements for electrical equipment for measurement, control and
laboratory use Part1: General requirements.
Note:
Modification of this instrument in any manner is the sole responsibility of the
owner/operator. In addition to voiding the warranty, the owner/operator is
responsible to check and if necessary correct any modifications required in
accordance to the standards listed above for immunity to interference.
Operating standards for this instrument are available upon request.
Page 8

SPECIFICATIONS
Model
Capacity
Readability
Linearity
Tare
Range
B-1852-120
120g
0.001g
0.003g
0 to 120g
B-1852-500
500g
0.01g
0.02g
0 to 500g
B-1852-1500
1500g
0.05g
0.1g
0 to 1500g
B-1852-3000
3000g
0.1g
0.2g
0 to 3000g
B-1852-6000
6000g
1.0g
2.0g
0 to 6000g
Common Specifications:
Pan Size:
B-1852-120: 70mm (7.76in) Dia.
All Other Models: 145 x 145mm (5.7 x 5.7in) L x W
Stabilization Time: 3 Seconds
Operating Temperature: 0C to 40C (32-104F)
Power Requirements:
Input: 100 -240VAC, 50-60Hz, 0.4A
Output 9VDC, 300mA
Battery Operation: 6 AA Batteries (not included)
Unit Dimensions:
B-1852-120: 225 x 177 x 124mm (8.9 x 6.7 x 6.2in)
All Other Models: 225 x 177 x 70mm (8.9 x 6.7 x 2.8in)
Weigh Bowl: 200 x 200 x 55mm
(7.9 x 7.9 x 2.2in)
Net Weight: 2 kg (4.4lb)
FEATURES
- Large, Backlit Display - Auto Shut Off Mode
- Automatic Calibration - Low Battery Indicator
- Five Weigh Modes - Overload Protection
- Stainless Steel Weigh Pans - Two-Year Warranty
- Weigh Bowl Included
Page 9

INSTRUMENT DIAGRAM
LEFT SIDE
AC ADAPTER INSERT
WEIGHT DISPLAY
ON/OFF UNIT
CAL TARE
BOTTOM
BATTERY COMPARTMENT
Batteries are not included
DISPLAY
LOW BATTERY INDICATOR
Page 10
