General Titanium Series User manual

TRL-10G
GREEN ROTARY LASER
INSTRUCTION MANUAL

2
SAFETY
Read the following safety instructions before
attempting to operate this product.
Keep these instructions in a safe place or store in the
carry case for future reference.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR
FUTURE REFERENCE.
WARNING: Read and understand all
instructions.
• Use the laser only with the specifically designated
batteries.
• Store the laser out of reach of children and other
untrained persons. Lasers are dangerous in the
hands of untrained users.
• Use only accessories that are recommended for
your model.
• Tool service must be performed only by qualified
repair personnel. Repairs, service or maintenance
performed by unqualified personnel will void the
warranty. Only approved and authorised service
technicians can carry out warranty repairs.
• Do not use optical tools such as a telescope or
transit to view the laser beam. Serious eye injury
could result.
• Do not place the laser in a position which may
cause anyone to intentionally or unintentionally
stare into the laser beam. Serious eye injury could
result.
• Do not position the laser near a reflective surface
which may reflect the laser beam toward anyone’s
eyes. Serious eye injury could result.
• Do not use optical tools to view the laser beam.
• Do not set up the tool at a position where the laser
beam can cross any person at head height.
!

3
• Do not let children come in contact with the laser.
• Turn the laser off when it is not in use. Leaving
the laser on increases the risk of staring into the
laser beam.
• Do not operate the laser around children or allow
children to operate the laser. Serious eye injury
may result.
• Do not remove or deface warning labels.
• Position the laser securely on a level surface.
Damage to the laser or serious injury could result
if the laser falls.
WARNING: Do Not Disassemble
The Laser.
There are no user serviceable parts inside.
Disassembling the laser will void all warranties on
the product. Do not modify the product in any way.
Modifying the tool may result in hazardous laser
radiation exposure.
!
!
CAUTION: Class 3 Laser Product
• Never look into the laser beam directly and
intentionally.
• Do not use optical tools to view the laser beam.
• Do not set up the tool at a position where the
laser beam can cross any person at head height.
• Do not let children come in contact with the laser.
SAFETY (continued)

4
ITEM CHECKLIST
Please ensure the following items are included with your laser level.
If anything is missing please contact your retailer.
Laser glasses Carry case Mains power adaptor
/ indoor charger
Rechargeable
battery pack
Laser target
Tripod&StaRemote controlGeneral Titanium
Series TRL-10G
INCHES CM
1
1
2
3
4
5
6
7
2
3
MANU AL
GRADE TILT
ALARM
RPM
MANUAL
GRADE
SLEEP
MODE
Detector & clamp
This accessory is only included in
the TRL-10G Package variant (88170)
i

5
MANU AL
GRADE TI LT
ALARM
RPM
Rotating laser port Protective lighthouse
Control panel
Charging port
LASER OVERVIEW: FRONT

6
LASER OVERVIEW: CONTROL PANEL
Power
Power indicator
Manual grade mode
Tilt alarm
Speed control
MANUAL
GRADE
TILT
ALARM
RPM
X / Y axis indicator
(Manual grade mode)
X-axis = solid LED light
Y-axis = flashing LED light
Tilt alarm indicator

7
LASER OVERVIEW: BASE
5/8” x 11 thread for
horizontal operation
on a tripod
Battery thumb screw
Charging port

8
REMOTE CONTROL OVERVIEW: FRONT
Sleep mode
Speed control
Manual grade mode
Grade adjustment (manual mode)
MANUAL
GRADE
SLEEP
M ODE
Grade adjustment (manual mode)

9
REMOTE CONTROL OVERVIEW: BACK
Battery compartment

10
Speaker on / off Detection mode
LCD display screen
LED indicator
LED indicator
LED indicator
Laser sensor
Screen backlight (hold)
Power on / off (detector)
DETECTOR OVERVIEW: FRONT

11
DETECTOR OVERVIEW: LCD SCREEN
Brightness indicator
Arrow indicator
Arrow indicator
Battery indicator
Centre alignment
Detection mode
Speaker indicator

12
Battery compartment
Speaker
Staff clamp mounting point
LCD display screen
DETECTOR OVERVIEW: BACK

13
POWER SUPPLY
Rechargeable battery pack
• The instrument is supplied with a rechargeable
Ni-MH battery pack that is located in the base of
the instrument.
• The rechargeable battery pack is supplied only
partially charged. Charge the rechargeable battery
pack before use. Keep the rechargeable battery
pack in the carry case when not in the laser level.
• The power indicator light will flash when the
battery is low. The instrument should be re-
charged as soon as possible.
• Battery pack capacity decreases at low
temperatures; a depleted pack may not function
when cold.
USING YOUR LASER
Indoor charger
• The indoor charger is for indoor use only.
• Do not store in locations where moisture can be
present or where the chargers could be exposed
to extreme temperatures.
• If a charger becomes damaged, stop using
immediately and seek a replacement.
WARNING: Only use the supplied charger.
Using an incorrect charger will void the
warranty. Do not charge alkaline batteries.
!

14
USING YOUR LASER (continued)
!
Charging the rechargeable battery pack
• Insert the charger into one of the two charging
ports. The charging ports are located on the
battery pack and underneath the control panel.
Progress will be shown by the power indicator
display on the charger as below:
Red (flashing) = Charger and battery
are not connected.
Red (constant) = Battery is charging
Green (constant) = Battery is charged
• Charging time is approximately 5 hours for a
depleted battery.
The battery pack does not need to be inserted
in the laser whilst charging via the port on the
battery pack.
i
Removing and inserting the rechargeable battery
pack
• Loosen the battery thumb screw on the base of
the instrument and remove the battery pack.
• Insert the battery pack, ensuring the metal pins are
aligned. Tighten the battery thumb screw.
WARNING: Do not attempt to disassemble the
battery pack.
• The unit can also run on alkaline batteries. The
alkaline battery tray is an optional extra which
can be purchased from your retailer.
i

15
USING YOUR LASER (continued)
HORIZONTAL MEASUREMENT SET UP
Level surface set up
• Select a place as close and practical to the work
site as possible, and ensure that the location is
clear of traffic.
• Place the laser level onto a reasonably level
surface with the lighthouse facing upwards.
Tripod set up
• Select a place as close and practical to the work
site as possible, and ensure that the location is
clear of traffic.
• Extend the tripod legs to the required height and
then spread the legs wide enough so that the
tripod platform is stable.
• Place the laser level onto the tripod with the
lighthouse facing upwards and thread the yoke
into the base until firm. Do not over tighten as this
may cause damage to the laser level or tripod.
VERTICAL MEASUREMENT SET UP
Level surface set up
• Select a place as close and practical to the work
site as possible, and ensure that the location is
clear of traffic.
• Place the laser level onto a reasonably level
surface with the control panel facing upwards.

16
OPERATION
Powering on
• Press the power button once and the instrument
will power on and begin automatically self-
levelling. When this levelling process is complete,
the penta prism inside the lighthouse will start
rotating.
• If the instrument is outside the self levelling range
the instrument will not level causing the laser beam
and self-levelling icon to flash continuously. If
this occurs, reposition the instrument onto a level
surface until the instrument can level off.
Powering off
• Press the power button once and the instrument
will power off.
USING YOUR LASER (continued)
Speed control
• Press the speed control button on the remote
control to cycle through various rotational
speeds.
Sleep mode
• Press the sleep button on the remote control
to enter into sleep mode.
• The laser diode will stop spinning and shut
off.
• Please note the laser is not turned off in sleep
mode.
• Press the sleep button on the remote control
to exit sleep mode.
After 60 minutes of inactivity during sleep
mode, the unit will turn off automatically.
i

17
USING YOUR LASER (continued)
Tilt alarm
• Once the instrument has been levelled off the tilt
alarm can be enabled by pressing the tilt alarm
button. The tilt alarm indicator light will flash
continuously whilst active.
• If the instrument is disturbed while the alarm is
active the instrument will stop rotating and will
need to be powered off and on again to reset its
level position.
Setting up a manual grade / slope
• To create a manual grade / slope, press the
manual grade mode button on the laser control
panel or remote control. The instrument will now
be in manual mode with the X-axis active. The LED
X / Y axis indicator on the laser control panel will
display a solid light to indicate X-axis is selected.
• Press the grade adjustment arrow buttons on the
remote control.
• To change to the Y-axis, press the manual grade
mode button. The LED X / Y axis indicator on the
laser control panel will flash to indicate the Y-axis
is selected. The instrument can now be adjusted
on the Y-axis.
• Press the grade adjustment arrow buttons on the
remote control.
• To adjust the grade, press the manual grade
mode button to cycle between X and Y axis
• To cancel manual grade mode, and return to
normal levelling press the power button off and on
again to reset the levelling process.
When in manual mode the instrument will
not self level and correct for vibrations and/or
disturbances.
Grade adjustments can only be made by
pressing the grade adjustment arrow buttons
on the remote control.
i
i

18
USING YOUR REMOTE
POWER SUPPLY
• The remote is powered by two AA alkaline
batteries
Battery replacement
• Remove the battery cover door and the batteries.
• Insert the batteries according to polarity and
replace the battery cover door.
REMOTE OPERATION
• Ensure the instrument is turned on and the laser
head is rotating.
• Press the speed control button to increase or
decrease the speed of the laser head rotation.
• To set up a manual grade / slope refer to page 17.
• Press the sleep button on the remote control to
enter into sleep mode. Press again to exit sleep
mode.

19
USING YOUR DETECTOR
POWER SUPPLY
• The detector is powered by one 9V alkaline
battery.
Battery replacement
• Remove the battery cover door and the batteries.
• Insert the batteries according to polarity and
replace the battery cover door.
MOUNTING THE STAFF CLAMP
• Insert the staff clamp screw into the staff clamp
thread.
• Rotate the nut until the clamp is secured in place.
DETECTOR OPERATION
• Switch the detector on by pressing the power
button. The LCD screen will turn on and the
speaker will emit a small tone to indicate the
instrument is operating.
• The LCD screen will display the battery level,
detection mode and speaker function.
• To change between broad, coarse and fine mode
press the detection mode button.
• To change the speaker volume or turn the speaker
off, press the speaker button.
• Move the detector into the path of the laser beam.

20
• Hold the detector upright for horizontal beams or
rotate 90° for vertical beams.
• The direction arrows or level line on the LCD
screen will indicate the position of the laser
beam. A digital increment display will indicate the
position of the laser beam. The detector will emit
a constant beep once the level position has been
located.
• To turn on the backlight, hold down the mode
button for approximately 3 seconds.
Detector position for horizontal beams
Detector position for vertical beams
USING YOUR DETECTOR (continued)
