General GEM130 User manual

INSTRUCTION MANUAL
3355 Enterprise Avenue, Suite 160
Fort Lauderdale, Florida 33331
Tel: 954.202.7419 Fax: 954.202.7337
www.thelegacycompanies.com
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING YOUR MIXER
COMMERCIAL MIXERS
MODEL:GEM130
R

FOOD Mixer Operation Instruction
General Description
This is a kind of changing speed gear mixer. With its planetary stirring design, it has a compact
structure, high efficiency, power saving and easy operation. It will be provided to you as an ideal
assistant for bread and cake making.
Technical parameters
Name
Barrel
Volume
(L)
Power
(KW)
Weight
(Kg)
Speed of stirring shaft (r/min)
Overall
Dimensions(mm)
1stSpeed
2ndspeed
3rdspeed
10
0.5
75
108
195
355
485*410*635
20
1.1
90
108
195
355
600*600*780
30
1.5
180
91
166
282
700*620*1200
Main External Parts of Mixer
1. Gear change hand lever
2. Stirring shaft
3. Mixer
4. Stainless barrel
5. Power switch

6. Bent lever
7. Safety guard(may choose the fitting)
8. Support
Operation Instruction
Standard power supply V/ Hz AC. (Please use a plug with 3 wide contacts and
good grounding.)
Installation of Mixer: Put the stirring shaft 2 in Mixer 3 and rotate it in clockwise direction.
Starting procedure: Pull the gear change hand lever 1 to position 1 before staring, then turn on
the power switch 5 and set the speed required. After the mixer is in normal operation, pull the
hand lever6 to the highest point and lift the support 7 to the highest position.
Speed transformation: if you want to change the speed, please turn off the power switch 5 first,
and then pull the gear change hand lever 1 to the position required.
Shutting down: hen the operation is completed, turn off the power switch 5 first, then pull the
gear change hand lever 1 to position 1,and pull back the hand lever 6to the lowest point and
finally disconnect power supply.
Accessories and Functions
①Spherical mixer: Used for stirring of liquid materials, such as cream and egg.
Recommended speed: mid or high speed.
②Plate mixer: Used for stirring of paste, powder, and fragmental materials, such as stuffing,
cake dough. Recommended speed: Start with low speed, end with mid speed.
③Hook mixer: Used for stirring of more sticky materials, such as dough. Recommended
speed: low speed.
Notes
①The power socket must be provided with a good ground wire to guarantee the mixer’s
good grounding through it .There will be a electric shock if no ground wire or an
improper grounding mounted. The ground wire can never be connected with gas pipe,
water pipe, lightning rod or telephone line. Electric leakage should be checked after
installation. Once the power line damaged, the user must replace them in the special
maintain Service Company.
②Don’t put your hand into the stirring barrel during operation. Power supply should be
disconnected before the mixer is going to be installed.
③Don’t operate the mixer beyond the time limit to prevent reduction of its service life.
④The mixer should be mounted on a stable and clean place, Keep it away from overheated
or over wet places and away from equipment which has strong electromagnet or can
produce strong electromagnet.
⑤Keep the machine clean constantly. Disconnect power supply before maintenance. Clean
it with a piece of soft and a bit wet cloth. Don’t clean it with liquid or spraying detergent.

Maintenance
Clean the bowl and stirrer daily or after use to maintain hygiene standard. Clean the
mixer with wet soft cloth. Do not use liquid or corrosive spraying detergent to clean the
mixer.
The transmission gear box is greased in factory. Check the greasing each 6 months. To
add or refill grease, open the top cover, then fill grease from aperture or replace the grease
directly.
TROUBLE SHOOTING
Problems!
Causes!
Solutions!
Tool!shaft!does!not!rotate!
after!starting!the!machine!
Loosen!electric!wiring!
Check!electric!wiring!
tighten!those!loose!
connects!
Oil!leakage!
The!seal!rings!are!worn!out!
Replace!seal!rings!
Motor!temperature!raises!
while!reduced!output!speed!
Too!low!voltage!
Check!the!power!supply!
Over@loaded!
Reduce!load!
The!speed!of!mixing!is!too!
high!or!use!a!wrong!stirrer!
Select!a!suitable!speed!and!
stirrer!
The!mixing!knocks!with!the!
bowl!
The!stirrer!or!bowl!is!
deformed!
Repair!of!replace!the!stirrer!
or!bow!
Abnormal!noise!and!high!
temperature!from!gearbox!
Insufficient!lubrication!
Add!or!replace!the!grease!
Warning!
If the equipments out of function, please make sure be serviced by professional person of
please turn to special service point!


PARTS OF 30 L MIXERS
SER.NO.
PART.NO
PART NAME
SER.NO
PART.NO
PART NAME
1
40705900
Hook
47
40704000
Body housing
2
40705800
Beater
48
40704200
Bowl hold kits
3
40706000
Wire Whip
49
40705100
Support
4
40708200
Safety guard
50
50307009
Clamp plate 18
5
50401008
Bowl
51
50304012
Nut M8*1.5
6
40707300
Top cover
52
50405038
Base
7
50405064
Screw
53
50301005
Bearing 6203
8
50406021
Spring
54
40700500
Transmission shaft
support
9
50405029
Pin shaft
55
50313016
Key 5*16
10
40703400
Shifting yoke
56
50312005
Circlips for shaft 17
11
40502900
Cam-gear shifter
57
40701700
Gear
12
40503100
Plate-shifter index
58
50405042
Bushing
13
40700200
Handle-shifter
59
40701400
Gear box
14
40700300
Handle set
60
50405025
Worm pole
15
50405044
Turn set M6
61
50402037
Brand
16
40700100
Speed handle
62
40700400
Motor
17
50405015
Plug attachment hub
63
50405037
Back housing
18
40701900
Attachment hub
64
40702400
Internal gear
19
50405065
Spring
65
50305075
Tighten yoke
M8x25
20
50405026
Circlips
66
50405049
Crank lever
21
40701800
Gear
67
40700900
Handle-shifter
22
50405033
Hood ring
68
40700800
Gear
23
50312007
Circlips for shaft 19
69
40703200
Bushing
24
40702600
Planet gear
70
40700700
Worm wheel
25
40702700
Operating shelf
71
40702900
Mid-gear wheel gear
26
50301007
Bearing 6205
72
40703100
Washer

27
50310009
Oil seal
73
40703000
Plug cover 1
28
50306036
Pin 10*38
74
50304007
Nut M12
29
40702800
Working shaft
75
50308007
Spring washer 12
30
40703600
Declutch shift shaft
76
50301004
Bearing 6202
31
50307006
Plate 10
77
40700600
Gear wheel
32
40701300
Main shaft
78
50313016
Key 5x15
33
50304006
Nut M10
79
50312008
Circlips for shaft 20
34
40701100
Top batter valve cap
80
50312003
Circlips for shaft 15
35
50405032
Flat valve cap
81
40703300
Plug cover 2
36
50301006
Bearing 6204
82
50501031
Motor
37
40701200
Main shaft plug
cover
83
50405050
Rubber set
38
40701500
Super machine parts
84
50506026
Green button
39
40701000
Gear
85
50506030
Red button
40
50405041
Bushing
86
40705500
Crank lever
41
40702000
Sleeve
87
40705700
Handle-shifter
42
40702100
Gear
88
40705300
Connecting rod
43
40702200
Clamp plate
89
50307008
Clamp plate 14
44
50301008
Bearing 6206
90
50406022
Spring
45
40702300
Bushing
91
50307007
Clamp plate 12
46
50310015
Oil seal 40*62*8
