GeneralAire AC-22 User manual

This air cleaner is designed for use in systems up to 2000 CFM. For higher airflows additional units
may be required. See Typical Installations below.
FOR INSTALLATION IN THE
RETURN AIR DUCT OF ANY
FORCED AIR HEATING AND
COOLING SYSTEM
INSTALLER: PLEASE FILL OUT AND MAIL GUARANTEE CARD AFTER INSTALLATION
IS COMPLETE. LEAVE INSTALLATION INSTRUCTIONS WITH HOME OWNER
MODEL AC-22
HIGH EFFICIENCY
AIR CLEANER
INSTALLATION INSTRUCTIONS
HIGH BOY COUNTER-FLOW
RETURN AIR RETURN AIR
WARM AIR
WARM AIR
WARM AIR
GENERALAire AC-22
HIGH EFFICIENCY AIR CLEANER
IMPORTANT: A 26 INCH CLEARANCE MUST BE ALLOWED FOR REMOVAL OF THE MEDIA FRAME
ASSEMBLY FROM THE CABINET.
1. Turn off electricity to furnace.
2. Pull front cover off and slide media carrier out of air cleaner cabinet. Discard packing material.
3. Remove and discard existing furnace air filter.
4. Install cabinet in return air system. Duct supports are recommended to support weight of cabinet.
5. Refer to care and maintenance instructions for installation of air cleaner media and pleat spacers.
6. Slide the media frame assembly into the cabinet. Be sure the airflow arrow on the media frame points toward
the furnace blower. The plastic pleat spacers are always on the downstream side of the filter media.
7. Install condition indicator and nameplate in upright orientation.
8. Turn on electricity and furnace, calibrate condition indicator and check performance of all equipment.
LOW BOY
RETURN AIR
WARM AIR
GENERALAire
FLOW THRU
SERIES HUMIDIFIER
Fresh Indoor Air Quality

The condition indicator gauge will show when media replacement is required. Use Air Cleaner media assembly Part No. 12758.
CARE AND MAINTENANCE
Slide the assembled media frame into the air cleaner
cabinet. Be sure the airflow arrow on the media frame
points toward the furnace blower. The plastic pleat
spacers are always on the downstream side of the
filter media. Attach outer cover.
Turn on electricity and run furnace blower on highest
speed. Calibrate condition indicator, with a small
screwdriver adjust the calibration screw to put the
pointer in the center of the “FILTER IS CLEAN” range.
Install the plastic pleat spacers, being careful to insert
one support finger between each pleat. Press each
end of the pleat spacers down firmly to fully engage
the media frame. Pleat spacers may snag on air
cleaner cabinet if not pressed down below media
frame rail.
Place new media pack (Part No. 12758) onto the media
frame. Slide media pack toward foam gasket. Line up
holes in the cardboard strips with the holes in the
media frame.
Turn off electricity to furnace. Pull front cover off and
slide media carrier out of air cleaner cabinet. Place air
cleaner media frame on table with plastic pleat spacers
on top. Loosen pleat spacers by gently lifting at each
end. Carefully remove all pleat spacers. Lift used air
cleaner media out of frame for disposal and clean
media frame.
AIR
FILTER
BLOWER
RETURN
AIR
GAGE
1 2
3 4
5
FILTER
CONDITION
FILTER IS CLEAN
CHANGE FILTER

PARTS LIST
PRESSURE DROP SCHEDULE
22-22 FILTER PAPER
END SEAL KIT
22-7 MEDIA FRAME ASSEMBLY
22-13 PLEAT
SPACER
FORM NO. 22-20 Rev. A Litho in U.S.A.
FILL OUT AND MAIL THIS
WARRANTY CARD AND
LITERATURE REQUEST FORM
MEDIA AIR CLEANERS
ELECTRONIC TEMPERATURE
COMPENSATING HUMIDISTAT
UV AIR PURIFIERS
HEPA AIR CLEANER
HUMIDIFIERS
ELITE STEAM HUMIDIFIERS
AIR FILTER GAGE
FUEL OIL FILTERS AND
ACCESSORIES
CFM IN W.C.
600 0.03
800 0.05
1000 0.07
1200 0.08
1400 0.12
1600 0.14
1800 0.17
2000 0.18
22-14 SEAL - NAMEPLATE
22-18 SEAL - COVER
22-1 AIR CLEANER
CABINET
22-19 NAMEPLATE AC-22
G99-18 FILTER GAUGE ASSEMBLY
22-6 COVER
12758 AIR CLEANER
MEDIA ASS'Y

The High Efficiency Air Cleaner will also provide marked reduction of
household dust and smudging particles so you can also expect a
reduction in dusting and cleaning.
The Air Cleaner has no electrical components and therefore requires
minimum service. It does not generate ozone and is not affected by
fluctuations in air temperature and relative humidity.
The Media Condition Indicator will show when the Air Cleaner media
needs changing. Media life of three years is not uncommon.
Changing the Media more frequently than suggested by the Condition
Indicator is not normally required.
This air cleaner, if properly registered by the return of the attached warranty registration card to the manufacturer, is warranted to the consumer against
defects in materials and workmanship for the lifetime of the product. The air cleaner media and seals are not covered by this limited warranty. Any other
defective parts will be repaired without charge except for removal, reinstallation and transportation costs. To obtain repair service under this limited
warranty, the consumer must send the defective part or the complete unit to the manufacturer.
THERE ARE NO EXPRESS WARRANTIES COVERING THIS AIR CLEANER OTHER THAN AS SET FORTH ABOVE, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY EXCLUDED. THE MANUFACTURER ASSUMES NO
LIABILITY IN CONNECTION WITH THE INSTALLATION OR USE OF THIS PRODUCT, EXCEPT AS STATED IN THIS LIMITED WARRANTY. THE
MANUFACTURER WILL IN NO EVENT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Some states do not allow either
limitations on implied warranties, or exclusions from incidental or consequential damages, so the above exclusion and limitation may not apply to you.
Any questions pertaining to this limited warranty should be addressed to the manufacturer. (U.S.A.: The manufacturer has elected not to make available
the informal dispute settlement mechanism which is specified in the Magnuson-Moss Warranty Act.)
GENERAL FILTERS, INC. CANADIAN GENERAL FILTERS, LTD.
43800 GRAND RIVER AVE. 39 CROCKFORD BLVD.
NOVI, MICHIGAN 48375-1115 SCARBOROUGH, ONTARIO M1R3B7
WWW.GENERALAIRE.COM WWW.CGFPRODUCTS.COM
Your High Efficiency Air Cleaner is an investment in comfort and protection for your family. The Air Cleaner is much more efficient than ordinary furnace
air filters, and you may expect benefits if you suffer from allergies caused by pollen, dust and other airborne allergens. The High Efficiency Air Cleaner is
not a cure for allergy problems but you may discover that closing the house during the pollen season, and operating the heating and cooling system
blower continuously, will provide substantial relief.
ABOUT THE HIGH EFFICIENCY AIR CLEANER
LIMITED WARRANTY
