Genesis 2.6 hocl fogger User manual

Please read instructions carefully to ensure proper use.

Specications
Product Conguration
Conguration
Type Name Genesis 2.6
Rated Voltage110V-60Hz
Rated Current1400W
Dispensing Capacity 1.056 US Gallons
Discharge Rate.317 gal/min
Spray Distance ~9-30 ft
Particle Size 20~50㎛
Dimensions25.79in x 7.87in x 12.2in
Weight9.48lbs
Cord Length19.6 ft
oMain body
oShoulder strap
oUser’s guide
①Main body ②Nozzle ③Air control switch
④Solution control valve ⑤Motor housing ⑥Tank cap
⑦Power Cord ⑧Fuse ⑨Shoulder strap ring
①
⑧
⑦
⑥③
④
⑤⑨
②

Operation
After pouring an appropriate amount of water or solution into the tank, close
the cap of the tank completely.
.1
. Turn the air control switch (ⓐ) counter-clockwise, then ensure that the solution
control valve (ⓑ) is completely locked by turning clockwise before connecting
the power line.
2
. Face the spray nozzle in the direction you’d like to work and turn the air control
switch (ⓒ) clockwise to adjust the speed of the air.
3
. After conrming that your air speed will not aect your surroundings,
adjust the amount of water or solution by opening the solution control valve (ⓓ).
4
Stop operation
1. Make sure to completely close the solution control valve (ⓔ) so that the nozzle
is no longer ejecting any water or solution.
2. Turn the air control switch (ⓕ) counter-clockwise and stop the motor.
3. Removethe power cord.
4. Empty the solution tank and clean it.
5. Fill the tank with clean water and run the machine to ush the tank and nozzle.
How to use
ⓔ
ⓕ
ⓐ
ⓑ
ⓒ
ⓓ

HOCl
. Do not fog with solution stonger than 200ppm.1
Power line
. It may be convenient to have an additional extension cord. When using one,
please make sure that it is rmly connected to the units cord.
1
. If using an extension cord, please be sure to use 120V/15A/3C (ground) or higher.2
Be mindful of your power cord as this work is generally done in humid
surroundings.
.3
Tip for users
•
By spraying ultra-ne particles, solution is applied evenly to the entire object
due to thelong suspension time and rotary atomizationeect.
•
sitceffelortnocesaesidrotsepelihwdeziminimsinoitulosfonoitpmusnoC
maximized due tothe spray system of the ultra-ne particles.
•
Fatigue of the wrists can be minimized by moving the ejection nozzle up and down.
•
The built-in designof theejection nozzle makes storage easy.
•
The speed, distance, and amount of spray is easily controllable.
•
It can be used for cleaning and sanitizing large buildings, oces, restrooms, public buildings,
and hospitals.
Features

Part Drawing
Parts List
Module Name No Part-NameSpec. CODE-NO Q’TY
Body set
1 Cover_LAPN-001 1
2 Cover_RAPN-002 1
4 Cover case_LAPN-004 1
5 Cover case_RAPN-005 1
8 RackAPN-008 8
28 Spring8-20APN-028 8
39
Shoulderstrap ring APN-039 2
24 Shoulderstrap pinAPN-024 1
Motor housing
set
3MotorhousingAPN-003 1
6
Motorhousing cover APN-006 1
31 O-ringG-120APN-031 1
Motor13 Motor1.4kW APN-013 1
Tank set
9 TankAPN-009 1
22 Water nippleAPN-022 1
23 Air nippleAPN-023 1
32 O-ringG-45APN-032 1
33 O-ring P7 APN-033 1
34 O-ringP10APN-034 1
36 Flange nut M8 APN-036 1
37 Flange nut M10APN-037 1
ModuleName No Part-NameSpec. CODE-NO Q’TY
Tank cap 7 Tank cap APN-0071
35 O-ringAN325APN-0351
Valve 10 Valve 1/4“APN-010 1
Switch 11 Switch 100kAPN-011 1
12 Knob Red APN-012 1
Air nozzle 14 Air nozzle APN-014 1
Nozzle set
15 Bel cup APN-015 1
16 Bear housingAPN-016 1
17 Turbine APN-017 1
18 Gasket APN-018 1
19 Bearing bush APN-019 1
20 Shaft APN-020 1
21 TubeAPN-021 1
25 BearingS6901ZZ APN-025 1
Fuse set 26 Fuse 5*20 10AAPN-026 1
27 Fuse holder 5*20 APN-027 1
PCB 29 PCB
120V, 1400W APN-029 1
Power cord 30 Power cord 10A 6mAPN-030 1
Shoulder
strap 38 Shoulderstrap APN-038 1

Please check the following before calling a repair center.
When the machine is not working
•Check that the power cord is plugged in.
•Check that the electrical outlet is working properly.
•Check if the voltage is 120V.
•Check the fuse.
•If the machine is not working after the fuse is replaced, contact your
dealer.
•If the suction hose inside thetankis clogged, removeforeignmatter.
•Please note that heat is generated in the main body even during normal
operation.
•If, during operation, parts are damaged due to heat, please contact
the repair center.
In order to prevent accidents during operation, please read the user’s guide
before use.
•Please use an appropriate outlet with a grounded circuit breaker.
•Donot use when thepower lineis wet. Donot touch thecord withwet hands.
•Do not plug more than one plug into the electrical outlet.
•Check the status of the power cord before operation. If damaged, call a
certied technician for replacing the cord.
•Always unplug the cord from the electrical outlet when the machine is not in
use
•When the machine is wet, never plug into an electrical outlet.
•Do not spray toward humans, electric appliances, eletrical outlets, etc.
•Keep away from children or unauthorized persons.
•Only use manufacturer-recommended parts.
•
•Be careful of re and shock.
•Do not use water mixed with impurities, or ammable materials.
•If there is unusual noise, smell, or smoke in the machine, unplug immediately
and contact an authorized service center.
•When cleaning the machine, unplug rst, and do not use water or detergent.
•Make sure to clean thetank after each use, and keep away from children.
•Keep the machine in a dry place away from direct sunlight.
Before Contacting the Repair Center
Precautions for use and storage
Storage Precautions
To prevent damage to objects, keep a proper distance when spraying at the
maximun setting.

•Warranty standard
ehtmorfraeyenonihtiwnoitarepolamronrednugninoitcnuflamfoesacnI-
date of purchase, the machine will be repaired free of charge.
•Product Replacement
Products within one year from the date of purchase, with the following conditions:-
Malfunctioning under normal operation, repaired but still experiencing the same
issue.
·
· When repair is not possible
· If some critical parts need repairs
•Non-warranty standard
· Malfunctioning dueto user error
· User negligence
· Natural disasters (Fire, salt damage, ood, earthquake, lightning, etc.)
· User carelessness
·
If theproductisnot repairedatour servicecenter
· If the product is arbitrarily disassembled or modied
· Malfunctioning dueto abnormal power supply orany otherdevice
· If used beyond its intended purpose
· In case of consumableparts
· In case there is no name plate
· In case of using solution that is ammable or which can damage the product
Warranty Standards
Warranty Complaints type
Compensation details
Within the warranty
period
After the warranty
period
In case of
malfunctioning
under
normal operation
Asking for repairafterpurchase Repairfree of charge Repairfree of charge
Same failure recurred
(three times) Product replacementNon-warranty
Repair is not possible even
when parts are available Product replacement -
If repairs necessary on critical
parts after purchase Product replacement -
Malfunctioning
due to
user error
When repair possibleCost for repair Charged repair
When repair impossible
Cost for replacement -
• The Company is not responsible for accidents caused by customer error.
This guide is subject to change without prior notice. Please check at the time of purchase.
•

Warranty
Thank you for buying this product. It has passed a strict quality control and inspection
process.
Product name Purchase date
Model name Mfg. No.
Buyer NamePhone
Add.
Dealer NamePhone
Add.
1.
2.
3. Theparts are available for 3 years aftertheproduct is discontinued.
4. Warranty period is one year from the day of purchase.
If you have failure of the product within 12 months of the pruchase date, it will
be repaired by warranty standards. Please contact your dealer.
Repair after warranty period
a. Failure due to user’s carelessness
b. Failure due to natural disasters
c. After the warranty period
d. When there is no warranty
e. If the product has been modied
