Genex GXD8 Quick start guide

GenexResearch Limited
…………………………………………………………………………….
GXD8 Operational Manual
……………………………………………………………………………
Revision 1.0
interstage
Phistersvej 31, 2900 Hellerup, Danmark
Telefon [phone], fax [phone]
www.interstage.dk
-pro audio with a smile

GXD8 Operational Manual Rev 1.0 Contents
Genex Research Limited Page i
CONTENTS
CONTENTS........................................................................................................................................I
IMPORTANT NOTES........................................................................................................................1
Unpacking...................................................................................................................................1
Power.........................................................................................................................................1
Location......................................................................................................................................1
Mounting Positions......................................................................................................................1
Conformity..................................................................................................................................1
Technical Support.......................................................................................................................1
LAYOUT OF THIS MANUAL.............................................................................................................2
INTRODUCTION TO THE GXD8.......................................................................................................3
Description..................................................................................................................................3
OPTIONS .........................................................................................................................................3
FRONT PANEL DESCRIPTION ........................................................................................................4
Panel Buttons.............................................................................................................................4
AUDIO...............................................................................................................................................5
AUDIO FORMATS ..............................................................................................................................5
Standard Input Format................................................................................................................5
Input/Output Formats Available Through Expansion Cards..........................................................5
AES Input Configuration..............................................................................................................5
Bit Split Decode..........................................................................................................................6
Audio Mute .................................................................................................................................6
SINGLE-ENDED OUTPUT....................................................................................................................6
CLOCKS...........................................................................................................................................7
Lock Mode..................................................................................................................................7
Precision.....................................................................................................................................7
Wide...........................................................................................................................................7
Clock Source..............................................................................................................................7
Master........................................................................................................................................7
AES............................................................................................................................................7
External Word Clock...................................................................................................................7
Slot One .....................................................................................................................................7
Slot Two .....................................................................................................................................7
Sample Rate...............................................................................................................................7
METERS AND INPUT LEVEL...........................................................................................................9
Peak Hold...................................................................................................................................9
Fine PPM....................................................................................................................................9
Over Sensitivity...........................................................................................................................9
Output Gain Level.......................................................................................................................9
BACK PANEL.................................................................................................................................10
SPECIFICATION.............................................................................................................................11
D/A Performance......................................................................................................................11
Miscellaneous...........................................................................................................................11

GXA8 Operational Manual Rev 1.0 Important Notes
Genex Research Limited Page 1
Important Notes
Unpacking
After unpacking the GXD8, save all the packing materials in case you ever need to
ship the unit. Thoroughly inspect the GXD8 for signs of damage. Report any shipment
damage to the carrier at once. The following accessories are included with the
GXD8:-
1.Power Cable.
2.User Guide.
3.Four mounting feet and screws.
4.Four rack mounting bolts.
Power
•This unit is equipped with voltage-selectable linear power supply. Please ensure
that the correct voltage for you region is selected (110V or 220V) before plugging
into the supply.
•Make sure that the unit is turned off before connecting the power plug to the
socket.
•Please be sure to connect the power cord to the AC inlet on this unit before
connecting the power plug to the socket.
•When disconnecting the power plug from the socket, do not pull the cord but hold
the plug to avoid damaging the cord.
•Avoid damaging the power cord.
•If the unit is not to be used for a long period of time, unplug the cord from the
socket.
•It is normal for this unit to become warm whilst being operated.
Location
•Avoid using this device in extreme heat, humidity or where it may be affected by
dust or vibration.
•Do not place or drop anything heavy on the unit or its power cable.
•Ensure that the GXD8 has adequate ventilation space on all sides. We
recommend at least 1U rack space top and bottom.
Mounting Positions
Do not mount the GXD8 upside down.
Conformity
The GXD8 bears the 'CE' mark and is therefore fully compliant.
Technical Support
Technical Support is available on line through the Genex web site at:
http://www.genex.co.uk/ or by emailing: [email protected].

GXD8 Operational Manual Rev 1.0 Layout of this Manual
Genex Research Limited Page 2
Layout of this Manual
Sections in this manual appear in the following order.
1.A brief introduction to the feature set and a list of options.
2.A detailed front panel description with a functional description of every
front panel button and display. This section should be used as a quick
guide and reminder to basic front panel operations.
3.A description of the audio formats supported
4.An explanation of the clock structure
5.Rear panel schematics and connector details

GXD8 Operational Manual Rev 1.0 Introduction to the GXD8
Genex Research Limited Page 3
Introduction to the GXD8
Description
The GXD8 is a professional, 8-channel, digital to analogue audio converter,
supporting all standard sample rates from 44.1kHz up to 192kHz up to 24 bits. It also
supports the Sony DSD format (1-bit, 2.8224MHz sample rate ∆Σ) when married with
the DSD upgrade kit (available separately).
All settings are available from the intuitive front panel with no complex menu
structures to navigate. The front panel also includes 8 high resolution peak power
meters (PPMs), one for each channel.
As standard, the GXD8 is fitted with four AES/EBU digital inputs providing eight
channels of analogue audio output up to 96kHz and four channels of output for
192kHz (an additional four channels are available via the AES expansion card). In
addition, expansion card with ADAT, TDIF, SDIF and workstation interfaces on are
available.
Options
•8-channel DSD upgrade kit. Includes the input and processor card
•8-channel AES expansion input and output card
•ADAT input / output card
•TDIF input / output card
•8-channel SDIF2 input card
•Workstation input / output card

GXD8 Operational Manual Rev 1.0 Front Panel Description
Genex Research Limited Page 4
Front Panel Description
Panel Buttons
1. Mute
Mutes the digital audio output from the unit
2. Over Sensitivity
This button determines how many
consecutive maximum value sample will
trigger the “OVER” LED to light
3. Peak Delay
Sets the peak hold of the PPMs to either
on, delay (2 seconds) or off
4. Fine PPM
Changes the PPM mode to a scale of
±1dB centred around –12, -14, -16, -18
and –20dBFS to aid input level calibration
5. Clear Peak Hold
Clears any peak or over LEDs on the
PPMs that are lit
6. Configuration
Selects between the following input
sources: AES, slot one (digital) and slot
two (digital). In addition, for AES input the
output format can be set to either PCM or
DSD via the decoded bitsplit format
7. Lock Mode
Selects between the “wide” and “precision”
lock modes when the unit is locked to an
external clock source.
8. Clock Source
Selects the clock source for the unit –
master (internal precision-cut quartz
crystal), external word clock, slot one or
slot two
9. AES Input
Chooses between single, dual or quad-
wire. Obviously, not all modes are
available for all sample rates
10. Bit Split
Selects if to decode a PAQRAT bit-
splitting format (PCM mode) or a 4-wire
“DSD over AES” format.
11. Bit Depth
Displays resolution of input audio
12. Sample Rate
Allows selection of 44.1kHz, 48kHz,
88.2kHz, 96kHz, 176.4kHz and 192kHz.
This button does not function in DSD
mode (forced to 44.1kHz) or in slave clock
mode (locks automatically to input rate)
13. PPM DISPLAY
The PPM displays consists of eight
columns of 14 segments each,
representing channels 1 to 8 respectively.
The meters are digital and are calibrated
in dBFS, with the top segment
representing 0dBFS. Peak values can be
set to decay immediately, be held for 2
seconds before decaying, or can be held
until the CLEAR PEAK HOLD button is
pressed.
Note the overload segments remain on
until cleared by the pressing the CLEAR
PEAK HOLD button.

GXD8 Operational Manual Rev 1.0 Audio
Genex Research Limited Page 5
Audio
Audio Formats
This section describes how to configure the audio output section of the GXD8.
The following parameters can be adjusted;
Standard Input Format
AES.
Input/Output Formats Available Through Expansion Cards
AES (expansion card to provide 8 channel dual wire 192kHz output)
SDIF-2 output
SDIF-2 input
TDIF
ADAT
DSD (Direct Stream Digital) – input only
What is Direct Stream Digital?
DSD was invented and developed by the Sony Corporation. It is designed to remove
some of the potential artifacts introduced by the decimation filter in a conventional
analogue to PCM digital conversion process. The DSD modulator generates a
2.8224MHz bitstream per channel, which is a slightly larger bandwidth than for 24 bit
96kHz PCM audio.
AES Input Configuration
You can select single wire, dual wire or quad wire. The setting refers to the position of
consecutive samples within an audio carrier.
In single wire mode each consecutive audio sample for a given track is located within
that track. For the AES format this means that one AES cable can carry two tracks of
information.
Dual wire mode means that each consecutive audio sample is contained in adjacent
tracks. For the AES format this means that one AES cable can carry only one track of
information.
Quad wire mode means that successive audio samples rotate through four adjacent
tracks. For the AES format this means that two AES cables carry one track of
information.
In master clock mode:-
•at 44.1kHz or 48kHz sample-rate, the AES output is single wire and the button is
disabled.
•at 88.2kHz or 96kHz sample-rate, the AES output can be either single or dual
wire.
•at 176.4kHz or 192kHz sample-rate, the AES output can be either dual or quad
wire.
In slave clock mode:
•with an input clock of 44.1kHz or 48kHz, the AES output can be single, dual or
quad
•with an input clock of 88.2kHz or 96kHz, the AES output can be single or dual

GXD8 Operational Manual Rev 1.0 Audio
Genex Research Limited Page 6
SAMPLE RATE
Input
configuration
available 44.1kHz 48kHz 88.2kHz 96kHz 176.4kHz 192kHz
1-2
Tracks Single Single Single Dual Single Dual Dual Quad Dual Quad
3-4
Tracks Single Single Single Dual Single Dual Dual Quad* Dual Quad*
5-6
Tracks Single Single Single Dual* Single Dual* Dual* Dual*
NUMBER OF TRACKS
7-8
Tracks Single Single Single Dual* Single Dual* Dual* Dual*
* - only available with the AES, TDIF, ADAT or SDIF expansion card in slot 2
Bit Split Decode
Two different bit-split formats are used depending on whether the GXD8 is in PCM or
DSD mode.
PCM mode. The Paqrat®format is supported. This allows 24-bit recordings to be
made in legacy 16-bit recorders. Two channels on the recorder are required per 24-
bit audio channel. The left channel contains the first 16-bits and may be monitored.
The right channel contains the top eight bits plus a rather unpleasant tone (750Hz at
48kHz; 689Hz at 44.1kHz) at –19dBFS. The tone provides signal present
confirmation for the level meters on the recorder but should not be monitored through
any speakers.
DSD mode. Decodes to stereo on outputs one and two a DSD bitstream bit-mapped
across eight 16-bit PCM channels (i.e., 4 AES cables). This allows stereo DSD
recordings to be made on legacy 8-channel 16-bit PCM machines. Tape based
recorders may still not be suitable however as the error correction techniques that
have to be employed for digital tape will further corrupt the DSD stream over and
above any errors on the tape in the first place!
Audio Mute
The mute button mutes the audio at the outputs only, right at the converters The
PPMs will still display the input level.
Single-ended Output
It is possible to connect the balanced output of the GXD8 to a single-ended input. However, as the
output is electronically balanced, the following precautions should be followed or the audio will be very
distorted and noisy:
•Connect Pin 2 (signal) of the XLR to the target input
•Connect Pin 1 (ground) of the XLR to the target ground
•DO NOT connect the negative signal of the XLR output (pin 3), to ground (pin 1). Instead,
leave the pin unconnected.

GXD8 Operational Manual Rev 1.0 Clocks
Genex Research Limited Page 7
Clocks
It is vitally important that the clock used at the point of conversion between the analogue and digital
domains is stable and accurate. Ideally the GXD8 should be the clock master wherever possible, as
the unit uses a very stable fixed crystal oscillator to generate it’s own clocks. However, operating with
the GXD8 in master mode is not always possible, so the unit provides several methods for locking to
external sources where necessary.
Lock Mode
Precision
The precision locking mode should always be selected in the first instance. The
precision mode uses a very heavily damped phase locked loop that is designed to
severely attenuate any clock jitter present on the input source. The downside is, that
if the input clock varies or drifts too much in frequency, then lock will not be possible.
Wide
Wide mode should be used when the precision mode is not capable of locking to the
external source. A more relaxed phase locked loop is selected in this mode, with less
attenuation of jitter.
Clock Source
The clock source can be either Master, external word-clock, slot one or slot two.
Master
This selects the precision quartz crystal oscillator. This is the preferred lock source.
The audio converter should always be the clock master wherever possible.
AES
Selects the AES inputs as the clock source. The unit will lock to the first AES input
that is connected (i.e., if AES input 1/2 is not connected it will lock to AES 3/4 and so
on).
External Word Clock
This selects the word clock input BNC at the back of the unit. The frequency should
be x1 sample rate for single wire, ½ sample rate for dual-wire and ¼ sample rate for
quad-wire.
Slot One
This selects the card in slot 1 as the clock source.
Slot Two
This selects the card in slot 2 as the clock source.
Note that the DSD and SDIF cards cannot provide a clock source.
Sample Rate
The GXD8 supports the following PCM sample rates:-
44.1kHz; 48kHz; 88.2kHz; 96kHz; 176kHz; 192kHz
In addition, when locked to an external clock, the GXD8 supports all modified rates based around
44.1kHz and 48kHz (±0.1%, ±4%). The GXD8 may also lock to 32kHz, although this is not
guaranteed. Input clock rates from to 50kHz, plus 88.2kHz and 96kHz may be applied.
When the GXD8 is in MASTER clock mode, the sample-rate is selected pressing the sample rate button
until the desired rate is indicated.
When locked to an external clock source, the incoming clock rate will be calculated and indicated. The
LED will flash until the unit has obtained lock. If the incoming rate is a “modified” rate, then the up or

GXD8 Operational Manual Rev 1.0 Clocks
Genex Research Limited Page 8
down arrow will also light to indicate a pull-up or pull-down rate respectively (see note below). The
sample rate button is disabled in this case. However, single, dual or quad-wire mode can now be
selected. The indicated rate will change based on the output wire configuration. For example:-
•A clock rate of 48kHz is connected to the clock input and detected:
In single-wire mode, a sample-rate of 48kHz will be indicated
In dual-wire mode, a sample-rate of 96kHz will be indicated
In quad-wire mode, a sample-rate of 192kHz will be indicated
In this way, the GXD8 always displays the actual sample rate rather than the external clock rate.
Note that when locked to a clock rate of 88.2kHz or 96kHz only single or dual-wire mode may be
selected.
NOTE: When either of the pull-up / pull-down LEDs are lit, the GXD8 is using a fast reacting, wide
locking RC Phase Locked Loop instead of its variable crystal oscillators. As a result, the
GXD8 may not notice if you subsequently change the incoming sample rate, particularly if you
change from a ±0.1% modified to the unmodified rate. In this case, to ensure the GXD8 locks
to the new unmodified rate using its variable crystal oscillator (which has far greater jitter
performance and thereby greater audio conversion quality), the unit should be forced to re-
lock (just cycle the unit through to master clock mode and back again).
