Genexis FiberTwist Series User manual

F-
FiberTwist–Series
Installation Guide
All manuals and user guides at all-guides.com

Buton oveview Pot oveview
LC/APC
coupler
Unlock buton
Remove FiberTwist or Blind Cover – press and
hold while wisting counterclockwise
All manuals and user guides at all-guides.com

Box contents
• Genexis FiberTwist-F-
Label position
The product label is positioned on the
back of the active device.
Important: Instructions need
to be followed precisely and
uninterrupted. This minimizes
the risk of damage to the iber
optic connectors, causing a severe
degradation of signal qualiy.
Dierent language versions of this document and additional product information
are availableon htps:genexis.euproductibewistdownloads
Installation guide
Remove Blind Cover (if present)
. Press and hold the unlock buton (see buton oveview).
. Rotate the Blind Cover counterclockwise till it blocks.
. Remove the Blind Cover from the baseplate (FTU) by pulling
it towards yourself.
. Store the Blind Cover in a safe place.
All manuals and user guides at all-guides.com

Remove dust cap
. Take the FiberTwist out of the box.
. The dust cap is connected to the red string
located on the rear of the FiberTwist.
. Remove the dust cap by pulling the red string.
. Store the dust cap in a safe place.
Twist!
. Place the FiberTwist on the FTU as shown in the picture below,
in a –degree angle.
. Rotate clockwise until it clicks into place.
. Make sure the FiberTwist is aligned squarely on the FTU,
each edge must line up directly with the FTU below.
. Remove the green dustcap from the LCAPC coupler, connect your
iber gateway to the LCAPC pot using a iber patch cable.
Your FiberTwist is now installed!
All manuals and user guides at all-guides.com

Revision . - May - Copyright ©  Genexis Netherlands B.V. All rights reseved.
Genexis assumes no responsibiliy for any inaccuracies in this document. Genexis reseves
the right to change, modify, transfer, or othewise revise this publication without notice.
