Genlantis CoolCLAVE Blue User manual

Personal Ozone and UV Sterilizer
INTRODUCTION: CoolCLAVE™ BLUE is a unique and innovative laboratory
bench top sterilizer from Genlantis. This unit improves on the original and
successful CoolCLAVE™ and CoolCLAVE™ Plus units. The new CoolCLAVE BLUE
uses a more powerful light bulb that produces both UV and ozone to sterilize
items of all kinds like gloves, pipettes, pipette tips, face masks, protective
eyewear, masks, and much more. To disinfect items, simply place them inside
the CoolCLAVE BLUE Sterilizer and press the time cycle button. The anti-
microbial properties of simultaneous ozone gas and UV light provide a dual and
powerful sanitizing effect capable of eliminating more than 98% of common
pathogenic organisms (bacteria, fungus, virus, etc.) in 15 minutes. The
antimicrobial properties of ozone also eliminate the odors produced by various
organisms providing a deodorizing effect as well. Best of all, the CoolCLAVE BLUE
sterilizer is very safe, efficient, and easy to use.
Note and Disclaimer
*The Genlantis CoolCLAVE™ BLUE Personal UV and Ozone Sterilizer is not a replacement or substitute for autoclaves, and should not be used to
sterilize equipment for use in medical or surgical applications of any kind. The CoolCLAVE BLUE sterilizing cycles can eliminate most surface
contaminants, especially bacterial and fungal, but only at lower densities that are typical in normal operating environments, such a lab benches or
general surfaces. Genlantis makes no claims and offers no guarantees of any kind that a CoolCLAVE cycle(s) will eliminate 100% of all contaminants
and under all possible circumstances.
PRECAUTIONS
(a) Read all instructions before using the appliance. Use this appliance only for its intended use as described in this manual.
(b) Do not attempt to operate the CoolCLAVE™ BLUE with the door open. Do not tamper with the door seal or latch mechanism.
(c) The CoolCLAVE BLUE unit emits ozone gas when operating. TO AVOID EXPOSURE TO OZONE, CAREFULLY FOLLOW
INSTRUCTIONS IN OPERATIONS SECTION BELOW.
(d) Do not operate this appliance if it has a damaged cord or plug, if it is not working properly, or if it has been damaged or
dropped.
(e) Do not store this appliance outdoors, or use it near water– for example near sinks or water baths.
(f) Do not immerse cord or plug in water; keep cord away from heated surfaces.
(g) Do not attempt to repair or open the unit unless you are a qualified repair technician.
TECHNICAL DETAILS
Electrical Specifications
E34110B: 110 volts AC,
6
0 Hz.
10
W.
E34220B: 220 volts AC,
5
0 Hz.
10
W.
UV Lamp
Specifications
UV
-
C T5 glass; G5 base 2
-
pin;
10
Watts
1
8
5
nm wavelength,
630
µW
/cm
2
@
6
inches.
Outside Dimensions (
W
x D x H
)
12 ¾ x 8 ½ x 9 ¾ (324 x 216 x 247 mm)
Inside Chamber Dimensions (W x D x H)
12 x 7
⅜ x 7 (305 x 187 x 178 mm)
–
10 L
capacity
Weight
7 lbs. (3.2 kg.)
Operating cycles
15 minutes / 30 minutes / 45 minutes / 60 minutes
Specifications
Ozone Range: 53
-
63
Ozone maximum = 63 ppm
UV wavelength = 254 nm
Warranty
1 year
Catalog #
Description/Content
Quantity
E34110B CoolCLAVE™ Blue Ozone & UV Sterilizer, 110V 1 Unit
E34220B CoolCLAVE™ BLUE Ozone & UV Sterilizer, 220V 1 Unit
Shipping and
Storage:
CoolCLAVE™ BLUE is shipped at room
temperature.
Related Products Catalog #
CoolCLAVE™ BLUE UV Lamp, 1 each E34UVB1
Ozilla™ Ozone Sterilizer, 110V E400110
Ozilla™ Ozone Sterilizer, 220V E400220
BioCooler™ Cold Box, 48 x 1.5 ml tubes E100100
BioCooler™ Cell Storage Box, 42 x 2 ml cryogenic tubes E100200
Mini BioCooler™ Cold Box, 8 x 1.5 ml tubes E100300
BioCooler Midi Cold Box, 12 x 2.0 ml tubes E100500
Dr. Spin Personal Centrifuge-Teal E200200

VKM200825 Genlantis Page 2 of 2
6044 Cornerstone Court W. Suite E. San Diego, CA 92121  Toll Free [phone]  U.S. & Canada [phone]  www.genlantis.com
2020 Genlantis and Gene Therapy Systems, Inc.
OPERATION
1. Plug power cord into wall outlet, open the door and place objects
to sterilize inside the chamber on either bottom or upper shelf.
Items on upper shelf will be more readily exposed to UV light
radiation, and items on lower shelf will be more exposed to ozone
gas (heavier than air).
NOTE: because the CoolCLAVE™ BLUE uses UV light and ozone gas,
you are able to safely and effectively sterilize the surfaces of most
types of materials such as plastics, metals, paper products, pipet
tip boxes, and even agar plates. The CoolCLAVE BLUE is not able to
sterilize any liquids or solutions.
2. Close the CoolCLAVE BLUE door and press the Power Button until it clicks in place; digital display will show “00”.
3. To select the cycle time, press the Timer Button once (15-min. run time), twice (30 min.) three times (45 min.), and four times
(60 min.).
4. The Display will show the selected run time, and the UV bulb will automatically turn on and start to count down.
NOTE: the unit’s door is equipment with a safety switch that will automatically turn the unit off if the door is opened during a
run cycle.
5. Once the cycle is finished, open the door of the unit while keeping face away so to avoid inhaling ozone gas. Air the chamber
slightly and remove your items for use.
PERFORMANCE
Graph on the right shows performance tests on a CoolCLAVE
Blue Unit. Typical ozone levels expected average 55 ppm.
MAINTENANCE
The CoolCLAVE™ BLUE is a very low maintenance unit and
does not require any scheduled or regular service.
(a) Keep your CoolCLAVE BLUE unit clean at all times
by wiping the interior and exterior surfaces with a
water dampened towel. To avoid damaging the
unit, do not use any detergents or solvents.
(b) Unplug the unit from the power outlet when the
CoolCLAVE BLUE is in storage or will not be used for
extended periods of time.
(c) Avoid damaging the unit by putting heavy objects on top of it.
(d) Replacing UV-C light Bulbs: The CoolCLAVE BLUE units use a special UV-C light bulb that produce ozone. Please contact
Genlantis to obtain the correct light bulb replacement.
(e) IMPORTANT: UV bulb waste disposal: At the end of rated life, when this lamp is removed from service it will be
subjected to the current Toxic Characteristic Leaching Procedure (TCLP) prescribed by the Environmental Protection
Agency. According to TCLP tests these UV lamps are considered hazardous waste under the Universal Waste Rules.
Generators should evaluate all of the disposal options, which may be available in the particular country, state, or city in
which the generator’s facility is located. The generator should check with federal, state and local officials for guidance.
The purchase price paid for the
CoolCLAVE™
BLUE
grants end users a non
-
transferable, non
-
exclusive license to use the unit in a
laboratory
or professional
setting, and for sterilizing purposes only as described in this manual. This use license excludes and without limitation, resale, repackaging, or modification of
the unit in any way and without prior notification of and approval by Genlantis.
Under no circumstances shall the CoolCLAVE BLUE unit be used on food or drink products intended for human or animal consumption. At all times, care and
attention should be exercised in handling and using the CoolCLAVE unit by following the instructions in the manual, using common sense lab practices, and
wearing protective clothing and eyewear as needed.
Purchasers may refuse this license by returning the CoolCLAVE BLUE unit unused and its original packaging. By keeping or using the CoolCLAVE unit, you agree
to be bound by the terms of this license. The laws of the State of California shall govern the interpretation and enforcement of the terms of this license.
Genlantis Establishment is registered under Environmental Protection Agency (EPA) ID Number 91845-CA-001
Power Button
Timer Button
