GEONFINO G4PRO User manual

Please keep and read this instruction manual before installation, we also
prepared an instruction video to help on Amazon Page. If you need further
assistance, please contact Customer Service by email:
[email protected]
Installation instructions

Installation Overview
Package List
Prepare the door and check dimensions
2
Install the latch and strike
4
Confirm the direction of the door
8
Install the interior assembly
14
Install the keypad
14
ProgrammingInstructions
17
18
20
31
Low Power/Emergency Power
32
33
33
34
35
36

2-1/8"
54mm
Measure to confirm that the backset is either 2-3/8"
or 2-3/4"(60 or 70mm).
Measure to confirm that the hole in the door is 2-
1/8"(54mm).
Measure to confirm that the hole in the door edge
is 1"(25mm).
Measure to confirm that the door is 1-3/5" to
2"(40mm to 50mm) thick.
C
Measure to confirm that the hole in door frame is
drilled a minimum of 1" (25mm) deep.
D
1"
25mm

with the face of
the latch
No, adjustment is
required. Proceed to
the next step.
Rotate and pull the
latch as shown
to extend the latch.
When the door is pushed inwards, the latch
tongue is installed outwards.

Install the strike on the door frame.
IMPORTANT:
Make sure the hole in door frame
is drilled a minimum of 1" (25mm) deep.

keypad handle setting
Once the square pole is fully pressed in with the connecting
pedestal, the front handle can no longer rotate
Interior assembly handle setting
Remove the mounting plate
Please keep press the Button of the Spindle. Then, insert the
spindle into the Knob. (The spindle bump should be aligned
with the hole of the knob) Make sure that the Button is
locked into the hole of Knob.
The connected spindle pushes the knob into the
groove so that the knob is flush with the groove.

Remove the rear handle.
Fix the front handle
with screws.
Fix the front handle
with screws.

Groove
Grab the square pole and pill it outward

Press the lock cover as shown so that the other end is
tilted up to remove the lock cover, and then insert the
key to unlock the lock.
16 17
