Geotech GEM5000 User manual

GEM5000 Gas Analyser
Operating Manual
Geotechnical Instruments (UK) Ltd
Sovereign House
Queensway
Leamington Spa
Warwickshire
CV31 3JR
Eng and
Te : [phone]
Fax: [phone]
Emai : sa [email protected]
Website: www.geotech.co.uk

OMGEM5KN1.01 GEM5000 gas analyser
Page 2  Copyright Geotech (UK) Limited
This page is intentiona y eft b ank.

OMGEM5KN1.01 GEM5000 gas analyser
able of contents
1.0 MANUAL GUIDELINES ....................................................................................... 6
1.1 Document history ............................................................................................. 6
1.2 Hazard warnings and safety symbo s .................................................................. 6
1.3 Notes .............................................................................................................. 6
2.0 IN RODUC ION ................................................................................................ 7
2.1 Safety instructions ............................................................................................ 7
2.2 Instructions for safe use .................................................................................... 8
2.3 MCERTS (app ied for) ...................................................................................... 10
2.4 Dec aration of conformity ................................................................................ 10
3.0 HE GEM5000 GAS ANALYSER ........................................................................... 13
3.1 The GEM5000 ................................................................................................ 13
3.2 GEM5000 standard product .............................................................................. 14
4.0 GEM5000 OP IONAL PRODUC S AND ACCESSORIES ...................................... 15
4.1 Optiona products ........................................................................................... 15
4.1.1 Pitot tube (optiona ) .................................................................................. 15
4.1.2 Orifice p ate (optiona ) ............................................................................... 15
4.1.3 Temperature probe (optiona ) ..................................................................... 15
4.1.4 Anemometer (optiona ) .............................................................................. 15
4.1.5 H
2
S fi ter (optiona ) ................................................................................... 16
4.1.6 Gas ana yser manager – GAM (optiona ) ...................................................... 16
4.1.7 GPS (optiona ) .......................................................................................... 16
4.1.8 B uetooth dong e (optiona ) ........................................................................ 16
4.2 Instrument accessory products ......................................................................... 17
5.0 GEM5000 INS RUMEN FEA URES ................................................................. 18
5.1 Physica characteristics of the instrument pane .................................................. 18
5.2 Ana yser features and keys .............................................................................. 19
5.3 Instrument connection points ........................................................................... 20
6.0 GENERAL OPERA IONAL INS RUC IONS ....................................................... 21
6.1 Switching the instrument on ............................................................................ 21
6.1.1 Power on se f-test ........................................................................................ 21
6.2 Switching the ana yser off ............................................................................... 21
6.3 Instrument status icons ................................................................................... 22
6.4 Instrument LED power states ........................................................................... 23
6.5 Changing between parameters ......................................................................... 23
6.6 Entering data ................................................................................................. 23
6.7 Instrument main gas read screen ..................................................................... 24
6.8 Storage ......................................................................................................... 24
6.9 Battery/charging ............................................................................................ 24
6.10 C eaning instructions .................................................................................... 25
6.11 Memory ...................................................................................................... 25
6.12 Warning and error codes............................................................................... 26
7.0 OPERA OR SE INGS ..................................................................................... 27
7.1 Menu key ...................................................................................................... 27
7.2 Device settings .............................................................................................. 27
7.2.1 Date and time .......................................................................................... 27
7.2.2 B uetooth ................................................................................................. 28
7.2.3 Device information .................................................................................... 29
7.2.4 Diagnostics .............................................................................................. 29
7.2.5 Navigation (optiona ) ................................................................................. 30
7.3 User settings ................................................................................................. 31

OMGEM5KN1.01 GEM5000 gas analyser
Page 4  Copyright Geotech (UK) Limited
7.3.1 Operating anguage ................................................................................... 31
7.3.2 Units of measurement ............................................................................... 32
7.3.3 Se ect by route/group (requires GAM).......................................................... 33
7.3.4 Adjust back ight ........................................................................................ 33
7.3.5 Adjust vo ume .......................................................................................... 34
7.3.6 Technician ogin ........................................................................................ 34
7.4 Operation settings .......................................................................................... 35
7.4.1 Timers ..................................................................................................... 35
7.4.2 Gas Check ................................................................................................ 36
7.4.3 View data ................................................................................................ 37
7.4.4 Set a arms ............................................................................................... 38
7.4.5 Adjust f ow fai ......................................................................................... 39
7.5 Exit menu ...................................................................................................... 39
8.0 AKING READINGS ......................................................................................... 40
8.1 Pre iminary checks before taking readings (best practice) .................................... 40
8.2 Update site data ............................................................................................. 41
8.3 Specia action ................................................................................................ 41
8.4 GEM ana yser in GA mode ................................................................................ 42
8.5 The gas f ow measurement screen .................................................................... 43
8.6 How to use an anemometer (optiona ) .............................................................. 43
8.7 How to use a pitot tube (optiona ) .................................................................... 46
8.8 How to use an H
2
S fi ter (optiona ) .................................................................... 47
8.8.1 Cross gas effects on chemica ce s .............................................................. 47
8.8.2 Cross-gas effects on methane, carbon dioxide and oxygen ............................. 47
8.9 How to use a temperature probe (optiona ) ........................................................ 50
8.10 How to identify a boreho e using the GPS feature (optiona ) .............................. 51
8.11 Taking gas and f ow measurement ................................................................. 53
9.0 CALIBRA ION ................................................................................................. 54
9.1 Ca ibration introduction ................................................................................... 54
9.2 Frequency of ca ibration – best practice ............................................................. 54
9.3 Ca ibration gases ............................................................................................ 55
9.4 Ca ibration set-up ........................................................................................... 56
9.5 Ca ibration equipment ..................................................................................... 56
9.6 Gas ana yser .................................................................................................. 57
9.7 Ca ibration processes – best practice ................................................................. 57
9.7.1 Check zeros – zero using air ....................................................................... 58
9.7.2 Check zeros – zero using N
2
....................................................................... 59
9.7.3 Ca ibration (Check Spans) – mixtures 1, 2 & 3 .............................................. 60
9.8 Restore to factory ........................................................................................... 61
9.9 Ca ibration history .......................................................................................... 61
9.10 Ca ibration summary .................................................................................... 61
10.0 PROBLEM SOLVING ...................................................................................... 62
10.1 Warning and error disp ay ............................................................................. 62
11.0 EVEN LOG .................................................................................................. 63
12.0 SERVICE ...................................................................................................... 64
13.0 WARRAN Y POLICY ..................................................................................... 65
14.0 SAMPLE CER IFICA E OF CALIBRA ION ...................................................... 66
15.0 IMPOR AN NO ICE O ALL CUS OMERS .................................................... 68
16.0 APPENDICES – SAFE Y INS RUC IONS ....................................................... 69
16.1 Instructions for safe use – Ita ian anguage ..................................................... 69

GEM5000 gas analyser OMGEM5KN1.01
 Copyright Geotech (UK) Limited Page 5
16.2 Instructions for safe use – German anguage ................................................... 77
16.3 Instructions for safe use – French anguage .................................................... 86
16.4 Instructions for safe use – Spanish anguage ................................................... 95
17.0 GLOSSARY OF ERMS ................................................................................ 104

OMGEM5KN1.01 GEM5000 gas analyser
Page 6  Copyright Geotech (UK) Limited
1.0 Manual guidelines
1.1 Document history
Issued
By Issue Date Change Control ID Issue No.
Reason for Change
LA JAN 2012 OMGEM5KN 1.01 New Instructions.
1.2 Hazard warnings and safety symbols
Warning
Information in this manua that may affect the safety of users
and others is preceded by the warning symbo .
Caution - Fai ure to fo ow the correct information may resu t in
physica injury which in some cases cou d be fata . If the
equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment may be
impaired.
Genera product abe symbo s are isted as fo ows:
CE conformity-The CE-
marking is the manufacturer's
statement to the EU
authorities that the product
comp ies with a re evant CE-
marking Directives.
If the CSA mark appears with
the indicator "US" or "NRTL" it
means that the product is
certified for the U.S. market, to
the app icab e U.S. standards.
VDE mark is a symbo for
e ectrica , mechanica ,
therma , toxic, radio ogica
and other hazards.
Separate co ection, hand ing
and disposa for waste e ectrica
and e ectronic equipment and
its
components.
E ectric shock warning. Refer to operators manua .
Doub e insu ated construction
- does not require an Earth.
Specific marking of exp osion
protection (ATEX on y).
II 2G Equipment group and
category. G = gases; the type
of exp osive atmosphere.
IECEx icenced mark
(IECEx on y).
Fuse. Equipment for indoor use on y.
1.3 Notes
Important/usefu information and instructions are shown c ear y throughout the manua in
a note format. For examp e:
 Note: For further information p ease contact Technica Support at Geotech (UK) Limited
on [phone] or emai technica @geotech.co.uk

GEM5000 gas analyser OMGEM5KN1.01
 Copyright Geotech (UK) Limited Page 7
2.0 Introduction
This manua exp ains how to use the GEM5000 andfi gas ana yser. The GEM5000 has
additiona functiona ity to the GA5000 gas ana yser. The GA5000 measures gas
concentrations on y, whereas the GEM5000 measures f ow and gas concentrations. The
GEM5000 measures f ow and ca cu ates the ca orific va ues of the gas as we as being a
usefu too for ba ancing the gas fie d. The GEM5000 gas ana yser may be used to monitor,
ca cu ate, adjust and record the f ow at each monitoring point.
This instrument may a so be used in GA5000 mode of operation if required. The operator
may change the ana yser between a gas extraction monitor (a GEM5000 gas ana yser) or a
andfi gas ana yser (a GA5000 gas ana yser). The mode of operation can be changed from
the ‘Specia Action’ menu. P ease refer to section ‘8.0 – Taking Readings’ for further
instruction.
The 5000 series of gas ana ysers comp ies with Part 15 of the FCC Ru es. Operation is subject
to the fo owing two conditions:
1) This device may not cause harmfu interference.
2) This device must accept any interference received, inc uding interference that may cause
undesired operation.
2.1 Safety instructions
Warning
The 5000 series of gas ana ysers can be used for measuring gases
from andfi sites and other sources as described in this manua .
The operator may be exposed to harmfu gases during the use of the
instrument. Inha ing these gases may be harmfu to hea th and in
some cases may be fata .
It is the responsibi ity of the user to ensure that he/she is adequate y
trained in the safety aspects of the gases being used and appropriate
procedures are fo owed. In particu ar, where hazardous gases are
being used the gas exhausted from the ana yser must be piped to an
area where it is safe to discharge the gas.
Hazardous gas can a so be expe ed from the instrument when
purging with c ean air.
 Note : Gas ana ysers are a sensitive piece of scientific equipment, and shou d be
treated as such. If the equipment is used in a manner not specified by the
manufacturer, the protection provided by the instrument may be impaired.

OMGEM5KN1.01 GEM5000 gas analyser
Page 8  Copyright Geotech (UK) Limited
2.2 Instructions for safe use
For A EX and IECEx the 5000 series of gas analysers are certified to Hazardous
Area Classification
II 2G Ex ib IIA 1 Gb ( a = -10ºC to +50ºC)
It is vita instructions are fo owed c ose y. It is the responsibi ity of the operator to
determine the protection concept and c assification required for a particu ar app ication.
(Reference European ATEX Directive 94/9/EC, Annex II, 1.0.6.)
The fo owing instructions app y to equipment covered by certificate numbers SIRA
11ATEX2197X and IECEx Directive SIR 11.0089X:
•The equipment may be used with f ammab e gases and vapours with apparatus
group IIA and temperature c ass T1.
•The equipment is on y certified for use in ambient temperatures in the range -10ºC
to +50ºC and shou d not be used outside this range.
•The equipment must not be used in an atmosphere of greater than 21% oxygen.
•Repair of this equipment sha be carried out in accordance with the app icab e code
of practice.
•When used in a hazardous area on y use GF5.2 temperature probe (SIRA
11ATEX2197X and IECEx SIR11.0089X). For connector C, the GF5.4 anemometer
(BVS 04ATEXE194) for use with ATEX on y. The ana yser shou d not be connected
to any other devices in the hazardous area inc uding the GF-USB ead (connector A)
or GF3.9 battery charger (connector B) supp ied with the ana yser.
Do not charge, recharge or open in a potentially explosive atmosphere.
In hazardous area only use “ emperature Probe GF5.2” in Connector B.
Connector C (Uo=10V,lo=5mA,Po=50mW,Ci=0,Li=0,Co=100uF,Lo=1000mH),
Connector B (Uo=5V,lo=6mA,Po=7mW,Ci=0,Li=0,Co=100uF,Lo=1000mH)
MAXIMUM NON-HAZARDOUS SUPPLIES:
Connector A - Um=6V Connector B - Um=10.1V
•If the equipment is ike y to come into contact with aggressive substances, e.g.
acidic iquids or gases that may attack meta s, or so vents that may affect po ymeric
materia s, then it is the responsibi ity of the user to take suitab e precautions, e.g.
regu ar checks as part of routine inspections or estab ishing from the materia ’s data
sheet that it is resistant to specific chemica s that prevent it from being adverse y
affected, thus ensuring that the type of protection is not compromised.
•The re ative pressure range is +/-500 mbar. Note, however, that the input pressure
shou d not exceed +/- 500 mbar re ative to atmospheric pressure and the output
pressure shou d not exceed +/- 100 mbar re ative to atmospheric pressure.

GEM5000 gas analyser OMGEM5KN1.01
 Copyright Geotech (UK) Limited Page 9
For CSA (Canada) the 5000 series of gas analysers are certified to Hazardous
Area Classification
CLASS 2258 03 - PROCESS CONTROL EQUIPMENT - Intrinsica y Safe and Non-Incendive
Systems - For Hazardous Locations
Ex ib IIA:
Mode GA 5000, GEM 5000 and BIOGAS 5000 Methane Detectors; portab e, battery
powered with non-fie d-rep aceab e Battery Pack P/N 20087; intrinsica y safe and
providing intrinsica y safe circuits (“[ib]” for Zone 1) to Mode GF5.2 Temperature Probe
(Connector B) and with entity output parameters as tabu ated be ow; Temperature Code
T1; -10 ºC ≤ Tamb. ≤ +50ºC.
Connector Entity Parameters
Uo
(V) Io (mA) Po (mW) Co (uF) Lo (mH) Ci (uF) Li (mH)
B 5.0 6 7 100 1000 0 0
C 10.0 5 50 100 1000 0 0
 Note: This device has been investigated for e ectrica safety features on y.
For CSA (USA) the 5000 series of gas analysers are certified to Hazardous Area
Classification
CLASS 2258 83 - PROCESS CONTROL EQUIPMENT - Intrinsica y Safe and Non-Incendive
Systems – For Hazardous Locations - CERTIFIED TO U.S. STANDARDS
AEx ib IIA:
Mode GA 5000, GEM 5000 and BIOGAS 5000 Methane Detectors; portab e, battery
powered with non-fie d-rep aceab e Battery Pack P/N 20087; intrinsica y safe and
providing intrinsica y safe circuits (“[ib]” for Zone 1) to Mode GF5.2 Temperature Probe
(Connector B) and with entity output parameters as tabu ated be ow; Temperature Code
T1; -10 ºC ≤ Tamb. ≤ +50ºC.
Connector Entity Parameters
Uo
(V) Io (mA) Po (mW) Co (uF) Lo (mH) Ci (uF) Li (mH)
B 5.0 6 7 100 1000 0 0
C 10.0 5 50 100 1000 0 0
 Note: This device has been investigated for e ectrica safety features on y.

OMGEM5KN1.01 GEM5000 gas analyser
Page 10  Copyright Geotech (UK) Limited
2.3 MCER S (applied for)
MCERTS is the UK Environment Agency's Monitoring Certification Scheme. The scheme
provides a framework within which environmenta measurements can be made in
accordance with the Agency's qua ity requirements. The scheme covers a range of
monitoring, samp ing and inspection activities.
The GEM5000 instrument is MCERTS certified on y if:
•
••
•The MCERTS ogo appears on the screen after initia power on.
 Note: MCERTS - Cross sensitivity tests using hydrogen su phide were not carried
out on this instrument. Therefore, users shou d be aware if H
2
S is present
on sites, as there may be an interferentia effect.
MCERTS promotes pub ic confidence in monitoring data and provides industry with a
proven framework for choosing monitoring systems and services that meet the
Environment Agency's performance requirements.
The Environment Agency has estab ished its Monitoring Certification Scheme (MCERTS) to
de iver qua ity environmenta measurements. The MCERTS product certification scheme
provides for the certification of products according to Environment Agency performance
standards, based on re evant CEN, ISO and nationa standards.
MCERTS certified instruments have been tested by an independent body to ensure that
they meet certain performance requirements. In addition the manufacturer of an MCERTS
product is regu ar y audited to ensure that the performance requirements of the
certification are being continua y met.
The 5000 series of gas ana ysers have been certified to Version 3.1 of the ‘Performance
Standards for Portab e Emission Monitoring Systems’.
2.4 Declaration of conformity
Products •GA5000 - Landfi Gas Ana yser
•GEM5000 - Landfi Gas Ana yser and Extraction Monitor
•BIOGAS 5000 – Anaerobic Digester Gas Ana yser
Geotechnica Instruments (UK) Limited dec ares that the item(s) described above are in
comp iance with the fo owing standards:
A EX Directive 94/9/EC
Certification body SIRA Certification Service
Notified body number 0518
Address Rake Lane, Ecc eston, Chester, CH4 9JN
SIRA certificate number SIRA 11ATEX2197X

GEM5000 gas analyser OMGEM5KN1.01
 Copyright Geotech (UK) Limited Page 11
Standards applied EN60079-0 :2006
EN60079-0 :2009
EN60079-11 :2007
IECEx
Certification body SIRA Certification Service
Notified body number 0518
Address Rake Lane, Ecc eston, Chester, CH4 9JN
IECEx certificate number SIR 11.0089X
Standards applied IEC60079-0 :2004 Ed4
IEC60079-0 :2007 Ed5
IEC60079-11 :2006 Ed5
CSA (Canada and USA)
Certification body CSA Internationa
Address 178 Rexda e Bou evard, Toronto, ON, Canada M9W 1R3
CSA Certificate number CSA 11 2445306
Standards applied C22.2 No. 0-10 - Genera Requirements – Canadian
E ectrica Code, Part II
CAN/CSA-C22.2 No. 60079-0:07 - E ectrica apparatus for
exp osive gas atmospheres - Part 0: Genera
Requirements
CAN/CSA-C22.2 No. 60079-1:07 - E ectrica apparatus for
exp osive gas atmospheres - Part 1: F ameproof
enc osures "d"
CAN/CSA-E60079-11:02 - E ectrica apparatus for
exp osive gas atmospheres - Part 11: Intrinsic Safety "i"
ANSI/UL 60079-0:09 - E ectrica Apparatus for Exp osive
Gas Atmospheres - Part 0: Genera Requirements
ANSI/UL 60079-1:09 - E ectrica Apparatus for Exp osive
Gas Atmospheres - Part 1: F ameproof Enc osures “d”
ANSI/UL 60079-11:09 - E ectrica apparatus for Exp osive
Gas Atmospheres - Part 11: Intrinsic Safety “i”

OMGEM5KN1.01 GEM5000 gas analyser
Page 12  Copyright Geotech (UK) Limited
EMC Directive 2004/108/EC
EN 301 489 Pt 1 (V1.9.1 – 2011-04)
EN 301 489 Pt 17 (V2.1.1 – 2009-05)
EN 301 489 Pt 19 (V1.2.1 – 2002-11)
BS EN 61000-3-2: 2006 + A2:2009
BS EN 61000-3-3: 2008
E ectromagnetic compatibi ity
and Radio spectrum Matters (ERM);
E ectroMagnetic Compatibi ity (EMC)
standard for radio equipment and services;
Part 1: Common technica requirements
E ectromagnetic compatibi ity
and Radio spectrum Matters (ERM);
E ectroMagnetic Compatibi ity (EMC)
standard for radio equipment;
Part 17: Specific conditions for
Broadband Data Transmission Systems
EMC for broadband data transmission
systems
E ectromagnetic compatibi ity and Radio
spectrum Matters (ERM);
E ectroMagnetic Compatibi ity (EMC) standard
for radio equipment and services;
Part 19: Specific conditions for Receive On y
Mobi e Earth Stations (ROMES) operating in
the 1,5 GHz band providing data
communications
EMC for Receive On y Mobi e Earth Stations
(ROMES)
E ectromagnetic compatibi ity (EMC). Limits.
Limits for harmonic current emissions
(equipment input current ≤ 16 A per phase)
E ectromagnetic compatibi ity (EMC). Limits.
Limitation of vo tage changes, vo tage
f uctuations and f icker in pub ic ow-vo tage
supp y systems, for equipment with rated
current ≤ 16 A per phase and not subject to
conditiona connection
Signed:
Dr. Roger Ri ey
NPI Director and Authorised Person

GEM5000 gas analyser OMGEM5KN1.01
 Copyright Geotech (UK) Limited Page 13
3.0 he GEM5000 gas analyser
3.1 he GEM5000
GEM5000 gas ana yser
The GEM5000 gas ana yser is designed to monitor andfi gas extraction systems.
Benefits:
•
••
•A ows ba ancing of gas extraction site.
•
••
•Maximise power generation from site.
•
••
•Fie d proven.
•
••
•Standardises monitoring routines.
•
••
•Easy transfer of data.
•
••
•GPS for comp iance.
Features:
•
••
•ATEX certified.
•
••
•MCERTS approved.
•
••
•H
2
compensated CO.
•
••
•Ca cu ates f ow (m
3
/hr) and ca orific va ue (kW or BTU).
•
••
•Technician og-in.
•
••
•Event og.
•
••
•Two instruments in one (GA and GEM mode).
•
••
•Measures static and differentia pressure.
•
••
•Simu taneous disp ay of gases.
•
••
•Storage of changes in set-up of gas fie d.
Applications:
•
••
•Gas extraction fie ds.
•
••
•F are monitoring.
•
••
•Landfi sites.

OMGEM5KN1.01 GEM5000 gas analyser
Page 14  Copyright Geotech (UK) Limited
3.2 GEM5000 standard product
GEM5000
Reference:
A Hard carry case
B In- ine water trap tubing & fi ter
C Gas ana yser instrument
D Operating manua CD
E Mains battery charger and adaptors:
-UK
-Europe
-US
-Austra ia
F H
2
S fi ter (optiona – if the compensated CO ce is fitted)

GEM5000 gas analyser OMGEM5KN1.01
 Copyright Geotech (UK) Limited Page 15
4.0 GEM5000 optional products and accessories
4.1 Optional products
The GEM5000 gas ana yser has a number of optiona products for purchase which enhance
the usabi ity and enab e further ana ysis of data and reading information.
 Note: For more information on the features isted in this section p ease contact Sa es at
Geotech (UK) Limited on [phone] or emai Sa [email protected].
4.1.1 Pitot tube (optional)
The GEM5000 gas ana yser enab es the use of a pitot tube to aid accurate f ow
measurement. The pitot tube is used for gas extraction systems and the pressure
readings are taken in mbar. High gas f ow is ca cu ated in the ana yser in m
3
/hr (metres
cubed per hour).
4.1.2 Orifice plate (optional)
Geotech (UK) Limited recommends the use of orifice p ates as good practice when using
the GEM5000 gas ana yser, enab ing repeatabi ity in f ow measurement via a fixed
method. Orifice p ates are a specia ised product and configuration and Geotech (UK)
Limited does not current y manufacture or se spare parts for this product. P ease refer
to a specia ist supp ier if the use of Orifice p ates is required.
4.1.3 emperature probe (optional)
The GEM5000 gas ana yser has the faci ity to automatica y disp ay and record the
boreho e temperature via an optiona temperature probe.
When a temperature probe is fitted the temperature reading wi be disp ayed on the
‘Main Gas Read Screen’ and recorded with a other data.
 Note: Temperature probes with an Ex abe are part of the GEM5000 Ex certification
SIRA 11ATEX2197X and IECEx SIR11.0089X, and therefore certified for use
under the same conditions as the ana yser.
4.1.4 Anemometer (optional)
The GEM5000 gas ana yser has the faci ity to automatica y disp ay and record high f ow
via an optiona anemometer probe. It is designed to p ug into the instrument and
instant y provide a f ow indication. An anemometer probe adds f ow measurements to
the professiona reporting abi ity of the GEM5000 range a ong with gas concentrations,
pressure and temperature.
The anemometer has a simp e connection, a narrow diameter measurement head
(11mm), a wide temperature operating range (up to 80
o
C) and indicates f ows up to 40
m/sec.
When an anemometer probe is fitted to the ana yser the f ow wi be disp ayed in the
‘Main Gas Read Screen’ and recorded with a other data.
F ow can be measured in either m/s (gas ve ocity) or m
3
/hr (vo ume f ow rate). In order
to ca cu ate the vo ume f ow rate the pipe diameter wi need to be entered into the
instrument, either manua y or via the Gas Ana yser Manager software.
 Note: The anemometer probe is part of the ana yser Ex certification BVS 04ATEXE194
for use with ATEX on y and is therefore certified for use in a potentia y
exp osive atmosphere. To use the m
3
/hr option the firmware software within
the ana yser must be set at the time of manufacture.

OMGEM5KN1.01 GEM5000 gas analyser
Page 16  Copyright Geotech (UK) Limited
4.1.5 H
2
S filter (optional)
The GEM5000 gas ana yser has the capabi ity to use an H
2
S fi ter and is required as
standard if the compensated CO ce is fitted and configured at the time the instrument is
manufactured. H
2
S gas can have a cross-gas effect on the CO reading. By using a fi ter,
the H
2
S is removed from the gas samp e, therefore providing a more accurate CO
reading.
The fi ter on y needs to be used when you are trying to get rid of any possib e cross gas
effects H
2
S might have on other gases. Do not use the fi ter on a boreho es.
4.1.6 Gas analyser manager – GAM (optional)
Gas Ana yser Manager (GAM) enab es the operator to maximise the operation of the gas
ana yser. It enab es direct communication with the unit, features a simp e up oad and
down oad faci ity and is fu y compatib e with the atest Microsoft™ operating systems.
Features:
•
••
•Organisation and transfer of boreho e IDs and readings to and from the gas
ana yser.
•
••
•Configuration of the gas ana yser.
•
••
•F exib e grouping of the IDs.
•
••
•Structured organisation of transferred data.
•
••
•Automatic detection of instrument type and avai ab e options.
•
••
•Secure data mode to prevent tampering.
•
••
•First time set-up wizard.
•
••
•Enab e f ow measurements for GEM5000 gas ana ysers.
4.1.7 GPS (optional)
An optiona GPS feature is avai ab e for the GEM5000 gas ana yser. It enab es the site
engineer to automatica y ocate boreho e IDs using GPS sate ite signa from predefined
boreho e IDs up oaded from Gas Ana yser Manager or set on the ana yser when out in the
fie d prior to taking a reading. The GPS reading data is stored for each measurement
reading providing an audit trai confirming that a reading was taken.
4.1.8 Bluetooth dongle (optional)
An optiona B uetooth feature enab es the operator to set and uti ise B uetooth
techno ogy. This may be usefu when down oading gas readings from the ana yser to the
PC instead of connecting the ana yser to a PC via a USB ead. B uetooth may a so be
used to transfer Site IDs to other 5000 series gas ana ysers if required. B uetooth is
activated by p ugging the dong e into a pc USB port and switching on the B uetooth
option feature in the settings on the ana yser.

GEM5000 gas analyser OMGEM5KN1.01
 Copyright Geotech (UK) Limited Page 17
4.2 Instrument accessory products
Optiona accessory and rep acement parts must ONLY be purchased for the GEM5000 gas
ana yser direct from Geotech (UK) Limited or your agent. P ease contact
sa [email protected] for further detai s on pricing and how to order.
Ref Description Order
Code
A Hard carry case GF2.5
B Hard carry case backpack (hard carry case not inc uded) GF2.6
C Soft carry case GF5.1
D Battery charger and adaptors GF3.9
E Anemometer (ATEX certified) GF5.4
F H
2
S/Hydrocarbon fi ters
H
2
S/Hydrocarbon fi ters (pack of 5) GF6.4 GF6.5
G Temperature probe (ATEX certified) GF5.2
H Pitot tube kit PITOT
I In- ine water trap fi ter & tubing GF1.8
J Water trap with barbed fi ters (pack of 10)
Water trap with barbed fi ters (pack of 30) GA4.9 GA4.9(30)
K Gas ports connectors (pack of 10) MC10
L Samp ing tube 5m ength f exib e PVC tubing (3/16”id) GA2.3
M Spare window for the soft carry case GF5.3
N Gas Ana yser Manager (GAM)
USB ead
B uetooth dong e
GAM
GFUSB
BLUEDON
O Check gas regu ator and tubing for ca ibration gas.
Ca ibration gas canister. P ease contact
sa [email protected] for gas canister concentrations
GA6.8

OMGEM5KN1.01 GEM5000 gas analyser
Page 18  Copyright Geotech (UK) Limited
5.0 GEM5000 instrument features
5.1 Physical characteristics of the instrument panel
Front view: Reference:
Back view: Reference:
A Main Gas Read Screen
B Soft-keys
C Back ight Key
D Menu Key
E Key 2 – Page Up
F Key 4 – Scro Left
G Pump Key
H
I
LED Light
On/Off Key
J Assistance Key
K Key 6 – Scro Right
L Key 8 – Page Down
M Enter Key
N Genera Keys
O Mode Number
P Seria Number
Q
R
S
Part Number
Certification Number
Reca ibration Due
A
B
C
D
G
E
F
I
H
J
K
L
M
N
O
P
Q
R
S

GEM5000 gas analyser OMGEM5KN1.01
 Copyright Geotech (UK) Limited Page 19
5.2 Analyser features and keys
Ref Feature Function
A Main Read Screen Start and end screen when using the instrument.
B Soft-keys
The function of the three ‘soft-keys’ on the front of the instrument pane is determined by menu
options taken. Functions vary from screen to
screen.
C Back ight Key Enab es the operator to back ight the ana yser
disp ay pane .
D Menu Key
Press the ‘Menu’ key to view and maintain User, Device and Operation settings.
E Page Up Key A so ‘Key 2’. Press scro up to view further
information on the instrument screen.
F Scro Left Key
A so ‘Key 4’. Enab es the operator to scro eft to disp ay more information.
G Pump Key Press the ‘Pump’ key to start or stop the pump.
H
I
LED Light
On/Off Key
LED power ight is visib e on the front of the
ana yser when the instrument is powered on.
Press the ‘On/Off’ key brief y to switch the
instrument on and off.
J Assistance Key
Press the ‘Assistance’ key to view he p text re evant to the ana yser screen you are current y
disp aying.
K Scro Right Key
A so ‘Key 6’. Press scro right to view further information on the instrument screen.
L Page Down Key
A so ‘Key 8’. Enab es the operator to scro down to disp ay more information.
M
Enter Key The ‘Enter’ key accepts/confirms choices made by the operator. A so required to confirm numeric
data entry.
N
O
Genera Keys
Mode Number
Keys 0, 1, 2, 3, 4, 5, 6, 7, 8, 9
Instrument mode type identification.
P
Seria Number Unique identification for the instrument. Verification of the seria number wi be required if
Technica Support assistance is needed.
Q
R
S
Part Number
Certification Number
Reca ibration Due
Manufacturer part number.
Disp ays instrument certification information.
The date disp ayed is the date the instrument is
due to be ca ibrated.

OMGEM5KN1.01 GEM5000 gas analyser
Page 20  Copyright Geotech (UK) Limited
5.3 Instrument connection points
op view:
Ref: Connection Point: Function:
A Connector A Attach the USB ead for PC-to-ana yser
connectivity.
B In et Port & Static Pressure Port
(White port) Attach the samp e tube to take a gas samp e. A so used to measure the static pressure.
C Differentia Pressure Port
(B ue port)
Attach the samp e tube to measure
differentia pressure.
D Connector B Attach the temperature probe and a so used
to attach the mains charger to the ana yser
for charging.
E Gas Out et Port
(Ye ow port) The gas out et port is the point at which the samp e gas is expe ed. Tubing may a so be
attached to the port.
F
Connector C Attach the anemometer.
G Dust Caps Dust caps used to protect the connector
points of the instrument.
