GeoVision GV-CBW120 User manual

Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use. ICH264-QG-Z-EN
Quick Start Guide
GV-IP Camera H.264

© 2014 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in
part, without the written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is
accurate. GeoVision, Inc. makes no expressed or implied warranty of any
kind and assumes no responsibility for errors or omissions. No liability is
assumed for incidental or consequential damages arising from the use of
the information or products contained herein. Features and specifications
are subject to change without notice. Note that memory card slot (local
storage) is not supported for Argentina.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: [phone]
Fax: [phone]
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV
series products are trademarks of GeoVision, Inc. Windows and Windows
XP are registered trademarks of Microsoft Corporation.
June 2014

Safety Notice
For GV-CBW120 and GV-CBW220:
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference and (2) this device must accept any interference received,
including interference that may cause undesired operation of the device.
UL Certification for GV-MFD120/130/220/320/520
The GV-IPCAM H.264 uses a 3.0V CR2032 Lithium battery as the power
supply for its internal real-time clock (RTC). The battery should not be
replaced unless required!
If the battery does need replacing, please observe the following:
•Danger of Explosion if battery is incorrectly replaced
•Replace only with the same or equivalent battery, as recommended
by the manufacturer
•Dispose of used batteries according to the manufacturer's instructions
i

Contents
Introduction................................................................................vii
Options ......................................................................................xix
Note for Connecting to GV-System.........................................xxi
Note for Recording...................................................................xxii
Note for Adjusting Focus and Zoom.....................................xxiii
Note for Installing Camera Outdoor ......................................xxiv
Note for Closing the Bullet Camera Cover............................xxvi
Note for USB Storage and WiFi Adapter..............................xxvii
1. Box Camera..............................................................................1
1.1 Packing List...............................................................................1
1.2 Overview...................................................................................2
GV-BX120D / 130D Series / 140DW / 220D Series / 320D
Series / 520D........................................................................2
GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series /
2500 Series / 3400 Series / 5300 Series...............................4
1.3 Accessory Installation................................................................6
1.3.1 C-Mount Lenses...........................................................6
1.3.2 Infrared Illuminators (GV-IR LED / GV-IR LED T2).......7
1.4 Connecting the Camera.............................................................9
GV-BX120D / 130D Series / 140DW / 220D Series / 320D
Series / 520D........................................................................9
GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series /
2500 Series / 3400 Series / 5300 Series.............................11
2. Ultra Box Camera...................................................................13
2.1 Packing List.............................................................................13
2.2 Overview.................................................................................14
2.3 Installation...............................................................................15
2.4 Connecting the Camera...........................................................17
3. Target Box Camera................................................................18
3.1 Packing List.............................................................................18
ii

3.2 Overview.................................................................................19
3.3 Installation...............................................................................20
3.4 Connecting the Camera...........................................................22
4. IR Arctic Box Camera ............................................................23
4.1 Packing List.............................................................................23
4.2 Overview.................................................................................24
4.3 Installation...............................................................................25
4.4 Connecting the Camera...........................................................29
4.4.1 Wire Definition............................................................29
5. Mini Fixed Dome & Mini Fixed Rugged Dome .....................31
5.1 Packing List.............................................................................31
5.2 Overview.................................................................................32
GV-MFD120 / 130 / 220 / 320 / 520 ....................................32
GV-MFD1501 Series / 2401 Series / 2501 Series / 3401 Series
/ 5301 Series.......................................................................34
GV-MDR.............................................................................36
5.3 Installation...............................................................................39
GV-MFD Series...................................................................39
GV-MDR Series..................................................................41
5.4 Connecting the Camera...........................................................45
5.4.1 Wire Definition............................................................45
5.4.2 Power and Network Connection.................................46
5.4.3 Vehicle Installation.....................................................47
6. Target Mini Fixed Dome.........................................................48
6.1 Packing List.............................................................................48
6.2 Overview.................................................................................49
6.3 Installation...............................................................................50
6.4 Connecting the Camera...........................................................52
7. Bullet Camera.........................................................................53
7.1 Packing List.............................................................................53
7.2 Overview.................................................................................54
iii

7.3 Installation...............................................................................55
7.3.1 Adjusting the Angles ..................................................57
7.3.2 Adjusting Lens and Inserting a Memory Card.............60
7.3.3 Inserting the Sun-Shield Cover...................................62
7.4 Connecting the Camera...........................................................63
7.4.1 Wire Definition............................................................63
7.4.2 Connecting the Power Cable......................................65
8. Ultra Bullet Camera................................................................66
8.1 Packing List.............................................................................66
8.2 Overview.................................................................................67
8.3 Installation...............................................................................69
8.4 Connecting the Camera...........................................................73
8.4.1 Wire Definition............................................................73
8.4.2 Power Connection......................................................74
8.4.3 Waterproofing the Cable ............................................75
9. Target Bullet Camera.............................................................77
9.1 Packing List.............................................................................77
9.2 Overview.................................................................................78
9.3 Installation...............................................................................80
9.4 Connecting the Camera...........................................................83
9.4.1 Wire Definition............................................................83
9.4.2 Power Connection......................................................84
10. Vandal Proof IP Dome (Part I) .............................................85
10.1 Packing List...........................................................................85
10.2 Overview...............................................................................87
10.3 Installation.............................................................................89
10.3.1 Hard-Ceiling Mount ..................................................89
10.3.2 In-Ceiling Mount.......................................................95
10.4 Connecting the Camera.........................................................98
10.4.1 Wire Definition..........................................................98
10.4.2 Connecting the Power Cable..................................100
iv

11. Vandal Proof IP Dome (Part II) ..........................................101
11.1 Packing List.........................................................................101
11.2 Overview.............................................................................104
11.3 Installation...........................................................................106
11.4 Connecting the Camera.......................................................116
11.4.1 Connecting the Power Cable..................................116
11.4.2 Connecting the I/O Device......................................117
12. Fixed IP Dome ....................................................................118
12.1 Packing List.........................................................................118
12.1.1 Packing List for Hard-Ceiling Mount .......................118
12.1.2 Packing List for In-Ceiling Mount............................119
12.2 Overview.............................................................................120
12.3 Installation...........................................................................122
12.3.1 Hard-Ceiling Mount ................................................122
12.3.2 In-Ceiling Mount.....................................................126
12.3.3 Wall-Surface Mount................................................130
12.4 Connecting the Camera.......................................................132
13. Cube Camera......................................................................133
13.1 Packing List.........................................................................133
13.2 Overview.............................................................................134
13.3 Installation...........................................................................136
13.4 Connecting the Camera.......................................................138
14. Advanced Cube Camera....................................................139
14.1 Packing List.........................................................................139
14.2 Overview.............................................................................140
14.3 Installation...........................................................................142
14.4 Connecting the Camera.......................................................144
15. PT Camera..........................................................................145
15.1 Packing List.........................................................................145
15.2 Overview.............................................................................147
v

vi
15.3 Installation...........................................................................149
15.3.1 Ceiling Mount.......................................................149
15.3.2 L-Shaped Wall Mount..........................................151
15.4 Connecting the Camera.......................................................154
16. Accessing the Camera.......................................................155
16.1 System Requirement...........................................................155
16.2 Accessing the Live View......................................................156
16.2.1 Checking the Dynamic IP Address .........................157
16.2.2 Configuring the IP Address.....................................159
16.2.3 Configuring the Wireless Connection......................161
16.3 Adjusting Image Clarity........................................................165
16.3.1 Using Focus Adjustment Cap.................................167
17. The Web Interface..............................................................169
18. Upgrading System Firmware.............................................172
19. Restoring to Default Settings............................................174
19.1 Using the Web Interface......................................................174
19.2 Directly on the Camera........................................................175
Box Camera......................................................................175
Ultra Box Camera and Target Box Camera.......................176
Mini Fixed Dome...............................................................177
Mini Fixed Rugged Dome..................................................178
Target Mini Fixed Dome....................................................178
Bullet Camera...................................................................179
Ultra Bullet Camera...........................................................179
Target Bullet Camera........................................................180
Vandal Proof IP Dome ......................................................181
Fixed IP Dome..................................................................182
Cube Camera ...................................................................182
Advanced Cube Camera...................................................183
PT Camera.......................................................................184

Introduction
Welcome to the GV-IPCam H.264 Quick Start Guide. In this quick guide,
you will find information on the installation and basic configurations of the
GV-IPCam H.264 series.
Camera Model No. Description
GV-BX120D Varifocal
Lens
1.3 MP Low Lux, H.264,
D/N, Auto Iris, f: 2.8 ~ 12
mm, F/1.4, 1/3’’ CS Lens
GV-BX130D-0 Varifocal
Lens
1.3 MP H.264, D/N, Auto
Iris, f: 2.8 ~ 12 mm, F/1.4,
1/3’’ CS Lens
GV-BX130D-1 Fixed
Lens
1.3 MP H.264, D/N, Fixed
Iris, f: 4 mm, F/1.5,
1/3’’ CS Lens
GV-BX140DW
1 MP H.264, D/N
WDR Pro, Fixed Iris,
f: 2.8 ~ 12 mm,
F/1.4, 1/3’’ CS Lens
GV-BX220D-2 2 MP, H.264 D/N, Auto Iris,
f: 2.8 ~ 6 mm, F/1.3, 1/3’’
CS Lens
Box
Camera
GV-BX220D-3
Varifocal
Lens
2 MP, H.264 D/N, Auto Iris,
f: 2.8 ~ 12 mm, F/1.4, 1/3’’
CS Lens
vii

Camera Model No. Description
GV-BX320D-0 3 MP, H.264 D/N,
Auto Iris, f: 3.1 ~ 8 mm,
F/1.2, 1/3’’ CS Lens
GV-BX320D-1 3 MP, H.264 D/N,
Auto Iris, f: 2.8 ~ 6 mm,
F/1.3, 1/3’’ CS Lens
GV-BX520D
Varifocal
Lens
5 MP, H.264 D/N, Manual
Iris, f: 4.5 ~ 10 mm, F/1.6,
1/2’’ CS Lens
GV-BX1200-0F
GV-BX1300-0F
GV-BX1500-0F
GV-BX2500-0F
1.3 MP Low Lux / 1.3 MP /
1.3 MP Super Low Lux / 2
MP Super Low Lux, H.264
D/N, Fixed Iris, f: 4 mm,
F/1.5, 1/3’’ CS Lens
GV-BX1200-1F
GV-BX1300-1F
GV-BX1500-1F
GV-BX2500-1F
1.3 MP Low Lux / 1.3 MP /
1.3 MP Super Low Lux / 2
MP Super Low Lux, H.264
D/N, Fixed Iris, f: 8 mm,
F/1.6, 1/2.5’’ CS Lens
Box
Camera
GV-BX1200-2F
GV-BX1300-2F
GV-BX1500-2F
Fixed
Lens
1.3 MP Low Lux / 1.3 MP /
1.3 MP Super Low Lux,
H.264, D/N, Fixed Iris, f: 12
mm, F/1.6, 1/2.5’’ CS Lens
viii

Camera Model No. Description
GV-BX2400-0F
GV-BX3400-0F
2 MP / 3 MP, H.264 D/N,
WDR Pro, Fixed Iris, f: 4
mm, F/1.5, 1/3’’ CS Lens
GV-BX2400-1F
GV-BX3400-1F
2 MP / 3 MP, H.264 D/N,
WDR Pro, Fixed Iris, f: 8
mm, F/1.6, 1/2.5’’ CS Lens
GV-BX2400-2F
GV-BX3400-2F
2 MP / 3 MP, H.264 D/N,
WDR Pro, Fixed Iris, f: 12
mm, F/1.6, 1/2.5’’ CS Lens
GV-BX1200-3V
GV-BX1300-3V
GV-BX1500-3V
GV-BX2400-3V
GV-BX2500-3V
1.3 MP Low Lux / 1.3 MP /
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux, H.264 D/N, Auto
Iris, f: 2.8 ~ 12 mm, F/1.4,
1/2.7” CS Lens
GV-BX2400-4V
GV-BX3400-4V
2 MP / 3 MP, H.264 D/N,
WDR Pro, Auto Iris, f: 3 ~
10.5 mm, F/1.4, 1/2.7” CS
Lens
GV-BX3400-5V 3 MP, H.264 D/N, WDR
Pro, Auto Iris, f: 2.8 ~ 6 mm,
F/1.3, 1/3’’ CS Lens
GV-BX5300-6V
Varifocal
Lens
5 MP, H.264 D/N,
Manual Iris, f: 4.5 ~ 10 mm,
F/1.6, 1/2’’ CS Lens
Box
Camera
GV-BX1500-8F
GV-BX2400-8F
GV-BX2500-8F
GV-BX3400-8F
GV-BX5300-8F
Fixed
Lens
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro /
5 MP, H.264, D/N, Fixed
Iris, f:2.8 mm, F/1.8, 1/2.5”
CS Lens
ix

Camera Model No. Description
GV-UBX1301-0F
GV-UBX1301-1F
GV-UBX1301-2F
1.3 MP, H.264 D/N, Fixed
Iris, f: 3 / 4 / 8 mm, F/1.6,
1/3” M12 Lens
GV-UBX2301-0F
GV-UBX2301-1F
GV-UBX2301-2F
2 MP, H.264 D/N, Fixed
Iris, f: 3 / 4 / 8 mm, F/1.6,
1/3” M12 Lens
Ultra Box
Camera
GV-UBX3301-0F
GV-UBX3301-1F
GV-UBX3301-2F
Fixed
Lens
3 MP, H.264 D/N, Fixed
Iris, f: 3 / 4 / 8 mm, F/1.6,
1/3” M12 Lens
Target
Box
Camera
GV-EBX1100-0F
GV-EBX1100-1F Fixed
Lens
1.3 MP Low Lux, H.264
D/N , Fixed Iris, f: 2.8 / 3.8
mm, F/1.8, 1/2.7’’ M12
Lens
GV-BX120D-E 1.3 MP Low Lux, H.264,
D/N, Auto Iris, f: 2.8 ~ 12
mm, F/1.4, 1/3’’ CS Lens
GV-BX220D-E 2 MP, H.264 D/N, Auto Iris,
f: 2.8 ~ 6 mm, F/1.3, 1/3’’
CS Lens
GV-BX320D-E 3 MP, H.264 D/N,
Auto Iris, f: 2.8 ~ 6 mm,
F/1.3, 1/3’’ CS Lens
GV-BX520D-E 5 MP, H.264 D/N,
Manual Iris, f: 4.5 ~ 10 mm,
F/1.6, 1/2’’ CS Lens
IR Arctic
Box
Camera
GV-BX1500-E
Varifocal
Lens
1.3 MP, Super Low Lux,
H.264, D/N, Auto Iris, f: 3 ~
10.5 mm, F/1.4, 1/2.7’’ CS
Lens
x

Camera Model No. Description
GV-BX2400-E
GV-BX3400-E
2 MP / 3 MP, H.264, D/N,
WDR Pro, Auto Iris, f: 3 ~
10.5 mm, F/1.4, 1/2.7’’ CS
Lens
IR Arctic
Box
Camera
GV-BX5300-E
Varifocal
Lens 5 MP, H.264, D/N,
Manual Iris, f: 4.5 ~ 10 mm,
F/1.6, 1/2’’ CS Lens
GV-MDR120 1.3 MP Low Lux, H.264,
Color, Fixed Iris, f: 4 mm,
F/1.5, 1/3’’ M12 Mount
GV-MDR220
GV-MDR320
GV-MDR520
2 MP / 3 MP / 5 MP, H.264,
Color, Fixed Iris, f: 2.54
mm, F/2.8, 1/2.5’’ M12
Mount
GV-MDR1500-0F
GV-MDR2400-0F
GV-MDR2500-0F
GV-MDR3400-0F
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro,
H.264, Color, Fixed Iris, f:
2.1 mm, F/1.8, 1/3’’ M12
Mount
GV-MDR1500-1F
GV-MDR2400-1F
GV-MDR2500-1F
GV-MDR3400-1F
GV-MDR5300-1F
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro /
5 MP, H.264, Color, Fixed
Iris, f: 2.8 mm, F/2.0, 1/3’’
M12 Mount
Mini
Fixed
Rugged
Dome
GV-MDR1500-2F
GV-MDR2400-2F
GV-MDR2500-2F
GV-MDR3400-2F
GV-MDR5300-2F
Fixed
Lens
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro /
5 MP, H.264, Color, Fixed
Iris, f: 3.8 mm, F/1.8, 1/3’’
M12 Mount
xi

Camera Model No. Description
GV-MDR1500-3F
GV-MDR2400-3F
GV-MDR2500-3F
GV-MDR3400-3F
GV-MDR5300-3F
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro /
5 MP, H.264, Color, Fixed
Iris, f: 8 mm, F/1.6, 1/3’’
M12 Mount
Mini
Fixed
Rugged
Dome GV-MDR1500-4F
GV-MDR2400-4F
GV-MDR2500-4F
GV-MDR3400-4F
GV-MDR5300-4F
Fixed
Lens 1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro /
5 MP, H.264, Color, Fixed
Iris, f: 12 mm, F/1.6, 1/3’’
M12 Mount
GV-MFD120 1.3 MP Low Lux, H.264,
Color, Fixed Iris, f: 4.05
mm, F/1.5, 1/3’’ M12 Mount
GV-MFD130
GV-MFD220
GV-MFD320
GV-MFD520
1.3 MP / 2 MP / 3 MP / 5
MP, H.264, Color, Fixed
Iris, f: 2.54 mm, F/2.8,
1/2.5’’ M12 Mount
GV-MFD1501-0F
GV-MFD2401-0F
GV-MFD2501-0F
GV-MFD3401-0F
GV-MFD5301-0F
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro /
5 MP, H.264, Color, Fixed
Iris, f: 2.8 mm, F/2.0, 1/3’’
M12 Mount
Mini
Fixed
Dome
GV-MFD1501-1F
GV-MFD2401-1F
GV-MFD2501-1F
GV-MFD3401-1F
GV-MFD5301-1F
Fixed
Lens
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro /
5 MP, H.264, Color, Fixed
Iris, f: 4 mm, F/1.5, 1/3’’
M12 Mount
xii

Camera Model No. Description
GV-MFD1501-2F
GV-MFD2401-2F
GV-MFD2501-2F
GV-MFD3401-2F
GV-MFD5301-2F
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro /
5 MP, H.264, Color, Fixed
Iris, f: 8 mm, F/1.6, 1/3’’
M12 Mount
GV-MFD1501-3F
GV-MFD2401-3F
GV-MFD2501-3F
GV-MFD3401-3F
GV-MFD5301-3F
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro /
5 MP, H.264, Color, Fixed
Iris, f: 12 mm, F/1.6, 1/3’’
M12 Mount
Mini
Fixed
Dome
GV-MFD1501-4F
GV-MFD2401-4F
GV-MFD2501-4F
GV-MFD3401-4F
Fixed
Lens
1.3 MP Super Low Lux / 2
MP WDR Pro / 3 MP WDR
Pro, H.264, Color, Fixed
Iris, f: 2.1 mm, F/1.8, 1/3’’
M12 Mount
Target
Mini
Fixed
Dome
GV-EFD1100-0F
GV-EFD1100-1F Fixed
Lens
1.3 MP Low Lux, H.264
D/N , Fixed Iris, f: 2.8 / 3.8
mm, F/1.8, 1/2.7’’ M12 Lens
GV-BL120D
GV-BL130D
GV-BL220D
GV-BL320D
1.3 MP Low Lux / 1.3 MP / 2
MP / 3 MP H.264, D/N, Auto
Iris, f: 3 ~ 9 mm, F/1.2,
1/2.7’’, ø 14 mm
Bullet
Camera GV-BL1200
GV-BL1300
GV-BL1500
GV-BL2400
GV-BL2500
GV-BL3400
Varifocal
Lens 1.3 MP Low Lux / 1.3 MP /
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro,
H.264, D/N, WDR Pro, Auto
Iris, f: 3 ~ 9 mm, F/1.2,
1/2.7’’, ø 14 mm
xiii

Camera Model No. Description
GV-BL1210
GV-BL1510
GV-BL2410
GV-BL2510
GV-BL3410
Motorized
Varifocal
Lens
1.3 MP Low Lux / 1.3 MP
Super Low Lux / 2 MP
WDR Pro / 2 MP Super
Low Lux / 3 MP WDR
Pro, H.264, D/N, Auto Iris,
3X Optical Zoom, f: 3 ~ 9
mm, F/1.2, 1/2.7’’, ø 14
mm
Bullet
Camera
GV-BL5310 Motorized
Varifocal
Lens
5 MP H.264, D/N, Auto
Iris, 2X Optical Zoom,
f: 4.5 ~ 9 mm, F/1.2,
1/2.7’’, ø 14 mm
GV-UBL1211
GV-UBL1511
GV-UBL2411
GV-UBL2511
GV-UBL3411
Motorized
Varifocal
Lens
1.3 MP Low Lux / 1.3 MP
Super Low Lux / 2 MP
WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro,
H.264, Auto Iris, 3X
Optical Zoom, f: 3 ~ 9
mm, F/1.2, 1/2.7’’ ø 14
mm Lens Mount
GV-UBL1301-0F
GV-UBL1301-1F
GV-UBL1301-2F
GV-UBL1301-3F
1.3 MP, Fixed Iris, f: 3 / 4 /
8 / 12 mm, F/1.6, 1/3’’
M12 Lens Mount
Ultra
Bullet
Camera
GV-UBL2401-0F
GV-UBL2401-1F
GV-UBL2401-2F
GV-UBL2401-3F
Fixed Lens 2 MP, Fixed Iris, WDR
Pro, f: 3 / 4 / 8 / 12 mm,
F/1.6, 1/3’’ M12 Lens
Mount
xiv

Camera Model No. Description
Ultra
Bullet
Camera
GV-UBL3401-0F
GV-UBL3401-1F
GV-UBL3401-2F
GV-UBL3401-3F
Fixed Lens
3 MP, Fixed Iris, WDR
Pro, f: 3 / 4 / 8 / 12 mm,
F/1.6, 1/3’’ M12 Lens
Mount
Target
Bullet
Camera
GV-EBL1100-0F
GV-EBL1100-1F Fixed Lens
1.3 MP Low Lux, H.264
D/N , Fixed Iris, f: 3.8 / 6
mm, F/1.8, 1/2.7’’ M12
Lens Mount
GV-FD120D
GV-FD220D
GV-FD320D
1.3 MP Low Lux / 2 MP / 3
MP, H.264, D/N, Auto Iris,
f: 3 ~ 9 mm, F/1.3, 1/3’’ ø
14 mm Mount
GV-FD1200
GV-FD1500
GV-FD2400
GV-FD2500
GV-FD3400
1.3 MP Low Lux / 1.3 MP
Super Low Lux / 2 MP
WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro,
H.264, D/N, Auto Iris, f: 3
~ 9 mm, F/1.2, 1/2.7’’ ø 14
mm Mount
GV-FD5300
Varifocal
Lens
5 MP, H.264, D/N, Auto
Iris, f: 4.5 ~ 10 mm, F/1.6,
1/2.5’’ CS Mount
Fixed IP
Dome
GV-FD1210
GV-FD1510
GV-FD2410
GV-FD2510
GV-FD3410
Motorized
Varifocal
Lens
1.3 MP Low Lux / 1.3 MP
Super Low Lux / 2 MP
WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro,
H.264, D/N, Auto Iris, , 3x
Optical Zoom, f: 3 ~ 9
mm, F/1.2, 1/2.7’’ ø 14
mm Mount
xv

Camera Model No. Description
GV-VD120D
(IK10+, Transparent Cover)
GV-VD121D
(IK10+, Smoked Cover)
GV-VD122D
(IK7, Transparent Cover)
GV-VD123D
(IK7, Smoked Cover)
1.3 MP H.264, D/N,
Low Lux, Auto Iris
GV-VD220D
(IK10+, Transparent Cover)
GV-VD221D
(IK10+, Smoked Cover)
GV-VD222D
(IK7, Transparent Cover)
GV-VD223D
(IK7, Smoked Cover)
2 MP H.264, D/N,
Auto Iris
GV-VD320D
(IK10+, Transparent Cover)
GV-VD321D
(IK10+, Smoked Cover)
GV-VD322D
(IK7, Transparent Cover)
GV-VD323D
(IK7, Smoked Cover)
3 MP H.264, D/N,
Auto Iris
Vandal
Proof IP
Dome
GV-VD1500
(IK10+, Transparent Cover)
GV-VD2400
(IK10+, Transparent Cover)
GV-VD2500
(IK10+, Transparent Cover)
GV-VD3400
(IK10+, Transparent Cover)
Varifocal
Lens
1.3 MP Super Low
Lux / 2 MP WDR
Pro / 2 MP Super
Low Lux / 3 MP
WDR Pro, H.264,
D/N, Auto Iris
xvi

Camera Model No. Description
GV-VD1530
(Coming)
GV-VD2430
(Coming)
GV-VD2530
(Coming)
GV-VD3430
(Coming)
High Power IR
LEDs,
Varifocal Lens
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP
Super Low Lux / 3 MP
WDR Pro, H.264, D/N,
Auto Iris
GV-VD1540
GV-VD2440
GV-VD2540
GV-VD3440
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP
Super Low Lux / 3 MP
WDR Pro, H.264, D/N,
Auto Iris, 3X Optical
Zoom, f: 3 ~ 9 mm, F/1.2,
1/2.7’’ ø 14 mm Lens
Mount
GV-VD5340
High Power IR
LEDs,
Motorized
Varifocal Lens 5 MP, H.264, D/N, Auto
Iris, 3X Optical Zoom,
f: 3.3 ~ 9 mm, F/1.2,
1/2.7’’ ø 14 mm Lens
Mount
GV-VD2540-E
2 MP Super Low Lux,
H.264, D/N, Auto Iris, 3X
Optical Zoom, f: 3 ~ 9
mm, F/1.2, 1/2.7’’ ø 14
mm Lens Mount
Vandal
Proof IP
Dome
GV-VD5340-E
High Power IR
LEDs,
Motorized
Varifocal
Lens, Extreme
Temperature
Tolerance
5 MP, H.264, D/N, Auto
Iris, 3X Optical Zoom,
f: 3.3 ~ 9 mm, F/1.2,
1/2.7’’ ø 14 mm Lens
Mount
xvii

Camera Model No. Description
GV-CA120
GV-CA220
1.3 MP / 2 MP,
H.264, Fixed Iris,
f:3.35 mm, F/2.4,
1/3’’ M12 Lens
Advanced
Cube
Camera GV-CAW120
GV-CAW220
Fixed
Lens 1.3 MP / 2 MP,
H.264, Wireless,
Fixed Iris, f:3.35
mm, F/2.4, 1/3’’
M12 Lens
GV-CB120
GV-CB220
1.3 MP / 2 MP,
H.264, Fixed Iris,
f: 3.35 mm, F/2.4,
1/3’’ M12 Lens
Cube
Camera GV-CBW120
GV-CBW220
Fixed
Lens 1.3 MP / 2 MP,
H.264, Wireless,
Fixed Iris, f: 3.35
mm, F/2.4, 1/3’’
M12 Lens
PT
Camera
GV-PT130D
GV-PT220D
GV-PT320D
Fixed
Lens
1.3 MP / 2 MP / 3
MP H.264 D/N,
Fixed Iris
For a detailed user’s manual, see GV-IPCam H.264 User’s Manual on the
Software CD.
xviii
