geratech EGE-11CD User manual

EGE-11CD
HDMI Audio Extractor

EGE-11CD
HDMI Audio Extractor
1
DISCLAIMERS
The information in this manual has been carefully checked and is believed to be accurate.
Geratech Technology assumes no responsibility for any infringements of patents or other
rights of third parties which may result from its use. Geratech Technology assumes no
responsibility for any inaccuracies that may be contained in this document. Geratech
also makes no commitment to update or to keep current the information contained in this
document. Geratech Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval
system, or any of its part translated into any language or computer le, in any form or by
any means— electronic, mechanical, magnetic, optical, chemical, manual, or otherwise—
without express written permission and consent from
Geratech Technology.
© Copyright 2012 by Geratech Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be trademarks of the
companies with which they are associated.

EGE-11CD
HDMI Audio Extractor
EGE-11CD
HDMI Audio Extractor
2
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate this equipment
and before connecting the power supply.
Please keep the following in mind as you unpack and install this equipment:
• Always follow basic safety precautions to reduce the risk of re, electrical shock and
injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain, moisture or nstall this
product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any openings or empty slots
in the unit, as you may damage parts inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if it is damaged.
• Do not allow anything to rest on the power cabling or allow any weight to be placed
upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or openings in the unit
housing that provide ventilation and allow for sufcient space for air to circulate around
the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VS1 06/11/12 First Release
VS2 27/12/12 Reword the feature and the
statements for audio EDID

EGE-11CD
HDMI Audio Extractor
3
CONTENTS
1. Introduction ............................................................................. 4
2. Applications ............................................................................. 4
3. Package Contents ................................................................... 4
4. System Requirements ............................................................ 4
5. Features ................................................................................... 4
6. Operation Controls and Functions ....................................... 5
6.1 Top Panel ............................................................................ 5
6.2 Right Panel ......................................................................... 6
6.3 Left Panel ........................................................................... 6
6.4 Front Panel ......................................................................... 7
6.5 Rear Panel .......................................................................... 7
7. Connection Diagram ............................................................... 8
8. Specications .......................................................................... 9
9. Acronyms ............................................................................... 10

EGE-11CD
HDMI Audio Extractor
EGE-11CD
HDMI Audio Extractor
4
1. INTRODUCTION
The HDMI Audio Extractor allows you to extract audio signals from your HDMI source.
When connecting to a TV or display you don’t always get the best audio, or in the case of
a PC monitor, no audio at all. So with this Audio Extractor you can take your original HDMI
audio signal and convert it to digital optical or analog Stereo (L/R) audio. This means that
you can output your audio signal to external speakers or extend your audio signal pathway.
2. APPLICATIONS
• Audio extraction for video only displays
• Extend your audio signal
• Audio extraction for non-HDMI AV receivers or wider audio systems
3. PACKAGE CONTENTS
• HDMI Audio Extractor
• 5 V/1.2 A Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
HDMI equipped source device and display (TV/monitor) and/or amplier/active speakers
with connection cables.
5. FEATURES
• Compliant with HDMI, HDCP 1.2 and DVI 1.0
• Supports HDMI audio sampling rates up to 192 kHz
• Supports Optical S/PDIF sampling rates up to 48 kHz
• Supports TMDS clock frequency rate 225 MHz
• Supports high-bit-rate (HBR) audio
• No HDMI output connection is required to receive audio at the analog and optical
outputs
• Maximum input and output HDMI cable length can run up to 15 meters at 1080p at 8-bit
resolution
• Low power consumption
• Supports EDID management for audio formats, can switch among built-in EDID (LPCM
2CH/Bitstream) and external EDID (TV)
• Supports 3D signal

EGE-11CD
HDMI Audio Extractor
5
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Top Panel
1 Power LED: The Power LED will illuminate in blue when the unit is
connected to the power supply and switched on.
2 Link LED: The Link LED will illuminate in green when both the source and
the display are connected and have established a link. This LED will also
blink once while the power is turned on.

EGE-11CD
HDMI Audio Extractor
EGE-11CD
HDMI Audio Extractor
6
6.2 Right Panel
1
1TV/Bitstream/2CH LPCM: This switch allows users to select the source's audio
EDID.
TV Mode: Switch to TV mode for the HDMI source to output audio per the EDID of
connected TV or AV receiver, supports up to LPCM 7.1 channels.
Bitstream Mode: Switch to Bitstream mode for the HDMI source to output Bitstream
audio per the built-in EDID, supports up to compressed audio 5.1 channels.
2CH LPCM Mode: Switch to 2CH LPCM mode for the HDMI source to output LPCM
2 channels audio per the built-in EDID.
Note: Depending on the input audio format, the unit may not output audio through
all output port., For example, the L/R analog output port will have no audio when the
input audio format is other than LPCM 2CH.
2 Power:
Switches the unit ON or puts the device into standby mode.
6.3 Left Panel
1 DC 5V: Connect to the 5V DC power supply into the unit and plug the adaptor to an
AC wall outlet.

EGE-11CD
HDMI Audio Extractor
7
6.4 Front Panel
1 HDMI In: Connect to a source device such as a DVD/Blu-ray player with an HDMI
cable.
6.5 Rear Panel
1 HDMI Out: Connect to the display (TV/monitor) with an HDMI cable for video and
audio signal output. No HDMI output connection is required to send audio through
the analog and optical outputs.
2Optical Out: Connect to audio equipment such as an amplier or Hi-Fi system with
an optical cable for digital audio output. Supports up to bitstream audio 5.1CH and
LPCM 2CH.
3L/R Out: Connect to audio equipment such as an amplier or active speakers with
a stereo RCA cable for audio output. Supports analog stereo output only.

EGE-11CD
HDMI Audio Extractor
EGE-11CD
HDMI Audio Extractor
8
7. CONNECTION DIAGRAM

EGE-11CD
HDMI Audio Extractor
9
8. SPECIFICATIONS
Input Port 1×HDMI
HDMI Audio Sampling Rate Up to 192 kHz
Optical Audio Sampling Rate Up to 48 kHz
Output Ports 1×HDMI, 1×Optical,1×L/R
HDMI Audio Format LPCM 2/5.1/7.1CH, Dolby 5.1, DTS 5.1,
DD+, D-TrueHD & DTS-HD
Optical Audio Format LPCM 2CH, Dolby 5.1 & DTS 5.1
L/R Audio Format Analog Stereo 2CH
Power Supply 5 V/1 A linear power adaptor (US/EU Standards,
CE/FCC/UL Certied) Or 5 V/1.2 A switching power
adaptor (with universal plug, CE/FCC/UL certied)
ESD Protection Human body model:
± 8kV (air-gap discharge)
± 6kV (contact discharge)
Dimensions 90.7 mm (W)×85.8 mm (D)×34 mm
(H)
Weight 107 g
Chassis Material Plastic
Silkscreen Color White
Operating Temperature 0 ˚C~40 ˚C/32 ˚F~104 ˚F
Storage Temperature −20 ˚C~60 ˚C/−4 ˚F~140˚F
Relative Humidity 20 ~ 90 % RH (non-condensing)
Power Consumption 2.1 W

EGE-11CD
HDMI Audio Extractor
EGE-11CD
HDMI Audio Extractor
10
9. ACRONYMS
ACRONYM COMPLETE TERM
HDCP High-bandwidth Digital Content Protection
HDMI High-Denition Multimedia Interface
