geratech EGE-UHD-4HDB-1431L User manual

EGE-UHD-4HDB-1431L
1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter,
60m with IR,PoC, Light Version(not include 507RX)

EGE-UHD-4HDB-1431L
1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter,
60m with IR,PoC, Light Version(not include 507RX)
DISCLAIMERS
The information in this manual has been carefully checked and is believed to be accurate.
Geratech assumes no responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Geratech assumes no responsibility for any inaccuracies that may be contained in
this document. Geratech also makes no commitment to update or to keep current the
information contained in this document.
Geratech reserves the right to make improvements to this document and/or product at any
time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval
system, or any of its part translated into any language or computer le, in any form or by
any means—electronic, mechanical, magnetic, optical, chemical, manual, or otherwise—
without express written permission and consent from Geratech.
© Copyright 2014 by Geratech.
All Rights Reserved.
Version 1.0 August 2014
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be trademarks of the
companies with which they are associated.

EGE-UHD-4HDB-1431L
1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter,
60m with IR,PoC, Light Version(not include 507RX)
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate this equipment
and before connecting the power supply.
Please keep the following in mind as you unpack and install this equipment:
• Always follow basic safety precautions to reduce the risk of re, electrical shock and
injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain, moisture or install this
product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any openings or empty slots
in the unit, as you may damage parts inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if it is damaged.
• Do not allow anything to rest on the power cabling or allow any weight to be placed
upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or openings in the unit
housing that provide ventilation and allow for sufcient space for air to circulate around
the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 06/08/14 Preliminary Release

EGE-UHD-4HDB-1431L
1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter,
60m with IR,PoC, Light Version(not include 507RX)
CONTENTS
1. Introduction................................................................................1
2. Applications ...............................................................................1
3. Package Contents .....................................................................1
4. System Requirements...............................................................1
5. Features......................................................................................2
6. Operation Controls and Functions ..........................................3
6.1 Front Panel.............................................................................3
6.2 Rear Panel..............................................................................4
6.3 IR Cable Pin Assignment........................................................4
7. Connection Diagram .................................................................5
8. Specications ............................................................................6
8.1 CAT5e/6/7 Cable Specication...............................................7
9. Acronyms ...................................................................................7

EGE-UHD-4HDB-1431L
1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter,
60m with IR,PoC, Light Version(not include 507RX)
1
1. INTRODUCTION
The HDMI over HDMI and CAT5e/6/7 Splitter can split and distribute a single HDMI input
and 2-way IR control to up to three CAT5e/6/7 outputs and includes a simultaneous HDMI
bypass output. It supports resolutions up to 1080p Full HD, 4Kx2K timing, 3D and multi-
channel digital audio formats. The HDMI bypass output can be connected to an HDMI
display or cascaded to another splitter. The three CAT5e/6/7 outputs can be connected
to CAT5e/6/7 to HDMI Receivers to extend the operating distance up to 60 meters with
Power Over Cable feature.
2. APPLICATIONS
• Household entertainment sharing and control
• Lecture room display and control
• Showroom display and control
• Meeting room presentation and control
• Classroom display and control
3. PACKAGE CONTENTS
• HDMI over HDMI & CAT5e/6/7 Splitter
• IR Receiver x 1
• IR Blaster x 1
• 24V DC Power Adaptor
• Power Cord
• Operation Manual
4. SYSTEM REQUIREMENTS
• Source equipment with HDMI output connector
• Display TV/Monitor with HDMI input connector
• HDMI over CAT5e/6/7 Receivers with industry CAT5e/6/7 cables

EGE-UHD-4HDB-1431L
1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter,
60m with IR,PoC, Light Version(not include 507RX)
2
5. FEATURES
• HDMI with 3D & 4Kx2K supported, HDCP and DVI compliant
• Simultaneous HDMI and CAT5e/6/7 outputs
• Supports data rate from 250Mbps up to 3Gbps
• Supports wide range of PC resolutions from VGA to WUXGA(RB) and HDTV resolutions
up to 4Kx2K (3840x2160@24/25/30Hz & 50/60 YUV_420 and 4096x2160@24Hz &
50/60 YUV_420).
• Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio
transmission (32~192kHz sample rate)
• Supports distances up to 60 meters through CAT5e/6/7 cables
• Supports selection of Standard or TV EDID settings
• Supports Power over Cable (PoC) feature
• Supports USB service port
• Supports Bidirectional IR control
• The 3D signal display follow by display TV’s EDID
Note:
1. This system was tested with CAT6/23AWG cables, results may vary with cables of
a different specication.
2. Displaying HDMI 4Kx2K resolution require the standard 4Kx2K HDMI cable and
display in order for proper image displaying.
3. The PoC function is designed for powering compatible Receiver units only non-PoC
Receivers will need their own power supply. Receivers of another brand may not be
compatible.

EGE-UHD-4HDB-1431L
1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter,
60m with IR,PoC, Light Version(not include 507RX)
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
SYNC LINK EDID SERVICE
HDMI IN POWER
HDMI OUT
DC 24V
STDTV
1 2 3 4 5 6 87
1HDMI IN: Connect with source equipment such as DVD/Blu-ray or PS3 player.
2SYNC: This LED will illuminate when the HDMI input port connected to an active
source.
3HDMI OUT: Connect to HDMI display for instant image display or cascade with another
family type Transmitter.
4HDMI LINK: This LED will illuminate when HDMI output is connected to TV or display
monitor.
5EDID STD/TV: The default factory setting is on STD, leave as it is when the display is
properly. When in TV mode, the unit will detect the 1st CAT5e/6/7 output’s EDID when
it obtain a 4Kx2K EDID and send out the signal accordingly to other output ports. If the
1st CAT5e/6/7 output is without a 4Kx2K's EDID the unit will detect all output's EDID
and send out the signal that all outputs can accept.
This device obtain the last memory function therefore, the device
will use the last output port 1's EDID when output port 1 is not connected to a display
after power cycling or switching in between the EDID setting.
STD EDID’s video at 1080p@60Hz and audio at LPCM 2CH.
6SERVICE: This slot is reserved for factory service only.
7POWER LED: Once the power supply is connected the LED will illuminate
8DC 24V: Plug the 24V DC power supply into the unit and connect the adaptor to an AC
outlet.

EGE-UHD-4HDB-1431L
1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter,
60m with IR,PoC, Light Version(not include 507RX)
4
6.2 Rear Panel
MODE LINK MODE LINK MODE LINK
IR IN IR OUT
23
1
CAT5e /6/7 OUT
1 2 3
1IR IN: Connect with IR Extender to receive IR signal from Transmitter side and blast out
at Receiver side. Ensure that remote controller being used is within the direct line-of-
sight of the IR Extender.
2IR OUT: Connect with IR Blaster to blast out the IR signal received from the Receiver
side. Place the IR Blaster in direct line-of-sight of the equipment to be controlled.
3CAT5e/6/7 OUT 1~3: Connect these ports to CAT5e/6/7 to HDMI Receivers with
CAT5e/6/7 cable to extend the signal up to 60m.
6.3 IR Cable Pin Assignment
3
1
3
1
2
2
Power
IR Blaster Signal
NC
IR Signal
Power
Grounding
IR Extender
IR Blaster

EGE-UHD-4HDB-1431L
1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter,
60m with IR,PoC, Light Version(not include 507RX)
5
7. CONNECTION DIAGRAM
MODE
LINK
MODE
LINK
MODE
LINK
IR IN IR OUT 231
CAT5e/6/7 OUT
SYNC LINKEDID SERVICE
HDMI IN POWER
HDMI OUT
DC 24V
STD TV
IR BLASTER
1.5m
60°
IR RECEIVER
7m
3m 3m
60°
m
CAT5e/6 In
Link
IR1 Extender
IR2 Blaster
Power
Blu-ray or PS3 Player
3D TV/Display
3D TV/Display
HDMI
HDMI

EGE-UHD-4HDB-1431L
1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter,
60m with IR,PoC, Light Version(not include 507RX)
6
8. SPECIFICATIONS
Video Bandwidth 340Mbps/10.2Gbps
Input ports 1 x HDMI,
1 x IR IN,
1 x USB (Service only)
Output ports 1 x HDMI,
1 x IR OUT,
3 x CAT5e/6/7
Resolution Up to 4Kx2K (3840x2160@24/25/30Hz &
50/60 YUV_420/4096x2160@24Hz & 50/60
YUV_420)
HDMI Input & Output
Cable Distance
Up to 10m@1080p 8/12-bit
CAT5e/6/7 Output Cable
Distance
Up to 60m
IR Frequency 30~50kHz
Power Supply 24V / 2.7A DC (US/EU standards, CE/FCC/UL
certied)
Dimensions 145 mm(W) x 190 mm(D) x 30 mm(H)/
Jacks Excluded
145 mm(W) x 199 mm(D) x 30 mm(H)/
Jacks Included
Weight 592 g
Chassis Material Metal
Silkscreen Color Black
ESD Protection Human body model:
±8kV (air-gap discharge)
±4kV (contact discharge)
Operating Temperature 0°C ~ 40°C
Storage Temperature -20˚C ~ 60˚C / -4 ˚F ~ 140 ˚F
Relative Humidity 20 ~ 90% RH (non-condensing)
Power Consumption 33W

EGE-UHD-4HDB-1431L
1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter,
60m with IR,PoC, Light Version(not include 507RX)
7
8.1 CAT5e/6/7 Cable Specication
Cable
Type
Range Pixel clock
rate
Video Data
Rate
Supported Video
CAT5e/6/7 60 m <=225 MHz <=5.3 Gbps
(HD Video)
Up to 1080p, 60 Hz,
36 bits, 3D (data rates
lower than 5.3 Gbps or
below 225MHz TMDS
clock)
40 m >225 MHz > 5.3 Gbps
(Ultra HD
Video)
4K2K, 30Hz video
formats
CAT6/7 60 m >225 MHz > 5.3 Gbps
(Ultra HD
Video)
4K2K, 30Hz video
formats
9. ACRONYMS
ACRONYM COMPLETE TERM
4Kx2K 3840x2160 / 4096x2160
DTS Digital Theater System
EDID Extended Display Identication Data
HDCP High-bandwidth Digital Content Protection
HDMI High-Denition Multimedia Interface
HDTV High-Denition Television

EGE-UHD-4HDB-1431L
1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter,
60m with IR,PoC, Light Version(not include 507RX)
8
