GF LUMEX 7927KD-1 Installation guide

User Instructions
and Warranty Information
Important: Read Before Use
Items 7927KD-1 & 7927KD-2
Transfer Bench

Instructions for Use –
Please Read All Instructions Before Use.
Attaching the Leg Extensions
(if not attached already)
1. Place frame on its side on a level surface.
2. Attach leg extensions with suction feet to the frame on the same side as where
the support arm will be. Attach leg extensions with flange tips to frame on
opposite side of frame.
3. The transfer bench legs with suction feet should be the two legs that are to be
placed inside the tub.
NOTE: Ensure leg extension push buttons protrude fully through plastic guide holes.
Attaching the Backrest
1. Determine the side on which the backrest should be mounted by knowing
which direction the user will face when sitting on the bench in the tub.
2. Position the bench upright on a level surface.
3. Locate the channel guides (4 each) on underside of seat. Align backrest
support tubes with channel guides.
4. Slide backrest seat support tubes through channel guides until seat support
tube push buttons protrude fully through channel guide holes.
5. Slide back support onto the seat support tubes until the push buttons protrude fully.
NOTE: Ensure seat support tubes buttons protrude fully through channel guide holes.
CAUTION: Backrest is not designed to support the full weight of the user.
CAUTION: Ensure backrest is facing down correctly before inserting to avoid
improper installation.
Attaching the Support Arm
1. To attach the support arm, position the seat arm against the leg frame and
slide the armrest tubing into the tube openings until it clicks into place. Make
sure that the push buttons fully protrude through the holes in the bracket.
NOTE: An audible “click” will be heard.
2. To remove the support arm, depress the push buttons and pull up.
NOTE: The end with the Support Arm and Suction Feet is the side that should be
inside the tub.
Adjusting Leg Height
1. Depress the height adjustment button and slide the lower leg upward or
downward until the height adjustment button clicks into place in the desired hole.
2. Repeat for other 3 legs.
CAUTION: Ensure that all four legs are adjusted to the same height, and that all
height adjustment buttons protrude fully through adjustment holes before use.
Back Support
Adjustable leg
Suction Tip
Platform
Tip
Support Arm
Using Your Transfer Bench
NOTE: Be sure to move slowly throughout use to prevent injuries.
NOTE: Children or those who need assistance should NOT be left unattended
during use of this product.
From a seated position (such as a wheelchair):
1. Place your wheelchair next to the bench, facing the front of the bathtub.
2. Engage wheelchair locks.
3. Transfer your torso to the transfer bench first, and then lift your legs into the
tub. Move slowly to prevent injuries.
4. After bathing, lift your legs out of the tub first, then your torso.
From a standing position:
1. Sit on the side of the transfer bench that is outside of the tub.
2. Extend your arms to grab the support arm of the bench and slide your body
over onto the bench. Lift each leg over the tub slowly.
3. Position yourself to a comfortable position in center of bench.
4. After bathing, lift your legs out of the tub first, then your torso slowly.

Maintenance
• Useamildsoapandwatersolution,rinsewithclearwater,thendrywithasoft
cloth. Ensure that product is well rinsed before using.
• Neveruseorganicsolvents,abrasivecleaners,orscouringpadsonanypartof
the product.
• Checktandtightnessofallnuts,boltsandknobsweeklytoensurethat
product is safe to use.
• Toguaranteethebestservicefromyourproduct,alwaysspeciy
Lumex replacement parts, available from your GF Health Products, Inc.
authorized distributor.
Safety Guidelines –
Please Read Before Use
WARNING: DO NOT use this product without rst completely reading and
understanding these instructions and any additional instructional material such
as owner’s manuals, service manuals or instruction sheets supplied with this
product. If you are unable to understand the warnings, cautions or instructions,
contact a healthcare professional, dealer or technical personnel before attempting
to use this equipment - otherwise, injury or damage may occur.
WARNING: Users with limited physical capabilities should be supervised or
assisted when using the transfer bench.
WARNING: Item has a maximum weight capacity of 350 lb. EVENLY DISTRIBUTED.
WARNING: GF Health Products, Inc. assumes no responsibility for any damage
or injury caused by improper installation, assembly, or use of this product.
WARNING: Leg extensions with rubber tips MUST be in contact with the oor at
all times.
WARNING: Ensure that the push buttons fully protrude through the same height
adjustment hole of each leg extension. This ensures that the leg extensions are
securely locked in position and that an even height adjustment is achieved.
WARNING: Make certain ALL screws and nuts are tight at all times.
WARNING: Inspect rubber tips on the leg extensions for rips, tears, cracks
or wear or if they are missing. Replace them IMMEDIATELY if any of these
conditions exist.
WARNING: The transfer bench seat MUST be installed before sitting on the
transfer bench.
WARNING: Notice for California Customers - California Proposition 65
WARNING: This product contains a chemical known to the State of California to
cause cancer and reproductive or developmental harm.
WARNING: If components are damaged or missing, contact your
GF Health Products, Inc. distributor immediately.
NOTE: Check ALL parts for shipping damage. If shipping damage is noted,
DO NOT use. Contact carrier/dealer for further instruction.
Limited Warranty
The following warranty information is a SUMMARY of the complete Product
Warranty provided by GF Health Products, Inc.
GF Health Products, Inc. (“GF”) warrants to the original retail purchaser or lessee
(eitheristhe“Customer”)only,thatitwillreplaceorrepaircomponents,atGF’s
sole discretion, that are defective in material or workmanship under normal use
and service. The warranty is for parts only and does not include labor or costs
of shipping. All warranties are conditioned upon the proper use of the product
strictly in accordance with applicable GF instructions. Product provided to users
as rentals must be serviced by the provider and inspected prior to delivery. Each
user must be properly trained on the operation and safety of this product prior
to use. Within the guidelines set forth in this document, the frame is warranted
for five (5) years and the normal wear components such as tips, wheels/casters,
and handgrips are warranted for three (3) months. The applicable warranty period
shallcommencefromdateofshipmenttotheCustomer,unlessthereisan
expiration date on the component in which case the warranty shall expire on the
earlier of the warranty period or the expiration date.
EXCLUSIONS
The warranty does not cover and GF shall not be liable for the following: 1) Defects,
damage, or other conditions caused by misuse, abuse, negligence, alteration,
accident, freight damage, tampering or failure to seek and obtain repair or
replacement in a timely manner; 2) Products not installed, used, or properly cleaned
and maintained; and 3) Labor or shipping charges. Other exclusions apply.
ENTIRE WARRANTY, EXCLUSIVE REMEDY AND CONSEQUENTIAL DAMAGES
DISCLAIMER
THISWARRANTYISGF’SONLYWARRANTYANDISINLIEUOFALLOTHER
WARRANTIES,EXPRESSORIMPLIED.

GF1500006RevA15
Features
• Providesassistancetothosewhohavedifcultysteppingoverthebathtubwalls
• Anodizedaluminumframeislightweight,durable,andrustresistant
• Drainageholesinseatminimizeswaterbuildup
• Reversiblebackresttoaccommodateanybathroom
• SupportArmaidsinlateraltransfer
• Maximumweightcapacity350lbsEVENLYDISTRIBUTED
• DesignedtomeettherequirementsofHCPCScode:E0247/E0248
• LifetimeLimitedWarranty
