Installation Instructions
ELEKTROMAT
FS 25.20-30,00
Model: 10002912 00002
-en-
Status: 24.07.2022
Pos: null /BA_Module/BA_ Seitenumbruch @ 0\ mod_1190719383361_0.d ocx @ 550 @ @ 1

2
Pos: null /BA_Module/BA_ DA Inhaltsverzeic hnis/BADA000002_M001 @ 5\ mod_1342530432542_28. docx @ 754855 @ @ 1
Table of contents
1Safety-relevant chapter ................................................................................................................................ 3
Explanation of symbols ................................................................................................................................... 3
Specified use .................................................................................................................................................. 3
General safety instructions ............................................................................................................................. 4
2Technical data ............................................................................................................................................. 5
3Product overview ......................................................................................................................................... 6
4Storing ......................................................................................................................................................... 7
5Transport ..................................................................................................................................................... 7
6Mechanical installation ................................................................................................................................. 8
General safety information ............................................................................................................................. 8
Permissible mounting positions ...................................................................................................................... 8
Mounting ......................................................................................................................................................... 9
Connection elements .................................................................................................................................... 10
Work steps .................................................................................................................................................... 11
7Electrical installation .................................................................................................................................. 13
General information ...................................................................................................................................... 13
Attaching the connection cables ................................................................................................................... 14
Mechanical limit switch - function ................................................................................................................. 15
Mechanical limit switch - setting the final limit position................................................................................. 15
8Motor connection ....................................................................................................................................... 18
9Limit switch connection .............................................................................................................................. 18
10Universal brake .......................................................................................................................................... 19
11Maintenance .............................................................................................................................................. 21
Maintenance checklist .................................................................................................................................. 21
Checklist for fault correction ......................................................................................................................... 22
12Disposal ..................................................................................................................................................... 23
13Declaration of Incorporation / Declaration of Conformity ............................................................................ 24
▶▶
Pos: null /BA_Module/BA_ Seitenumbruch @ 0\ mod_1190719383361_0.d ocx @ 550 @ @ 1
Schematic representations are based on product examples. Deviations from delivered
products are possible.

3
Pos: null /BA_Module_M anuell/Allgemeine_ Module/Sicher heitskapitel_Symboler klärung_neueMod ulvorlage @ 64\mod_16055 25028523_28.doc x@ 171 8464 @ 12 @ 1
1Safety-relevant chapter
Explanation of symbols
The following symbols are used in these installation instructions:
DANGER
Safety note: Non-compliance will result in death or severe injury.
WARNING
Safety note: Non-compliance can result in death or severe injury.
CAUTION
Safety note: Non-compliance can result in injury.
NOTICE
Note: Non-compliance can result in material damage and impairment of product functionality.
iNOTE
Note: Points out useful additional information.
Pos: null /BA_Module/BA_ EA Sicherheitskapi tel/01_Bestimmungsg emäße Verwendung/Sic herheitskapite l_bestgemVerwendung_01_ FS @ 55\mod_15935886204 65_28.docx @ 1681720 @ 2 @ 1
Specified use
The drive unit is intended for vertically moving doors for the protection against fire and smoke. The doors close
by gravity in the case of a fire.
Pos: null /BA_Module/ BA_EA Sicherhei tskapitel/01_Besti mmungsgemäße Verwen dung/Sicherheits kapitel_bestge mVerwendung_02_allg emein_nichtATEX @ 55\ mod_1593584398854_28.doc x @ 1681224 @ @ 1
The drive unit must be protected against moisture and aggressive environmental conditions (such as corrosive
substances). The drive units are only suitable for indoor use. Appropriate protective measures must be taken for
outdoor installation. The drive unit is not intended for hazardous areas. The values specified in the technical
data of the drive unit must not be exceeded. The safe operation can only be ensured if used as specified.
Pos: null /BA_Module_M anuell/Allgemeine_ Module/Sicher heitskapitel_Zielgr uppeGfA_neueFormat vorlage @ 61\mod_160258 8992679_28.doc x@ 17085 68 @ 2 @ 1
Target audience of the installation instructions
These installation instructions are intended for competent personnel trained in handling doors.
Competent personnel qualify by specialist knowledge, skills and practical experience. Such personnel
can safely carry out installation, maintenance and modernisation as instructed.
Pos: null /BA_Modu le/BA_EA Sicherhei tskapitel/03_Betri ebssicherheit/Si cherheitskapi tel_Betriebssic herheit @ 62\mod_160 3958969193_28.doc x@ 171 1534 @ @ 1
Safe operation
The safe operation of the product can only be ensured if it is used as specified. Follow the installation
instructions. Observe all specifications, especially warnings, when installing the product in the overall system.
GfA is not liable for damage resulting from non-observance of the installation instructions. The resulting overall
system must be reassessed for its safety in accordance with applicable standards and directives (e.g. CE
marking). These installation instructions refer only to a part of the overall system and are not sufficient as the
sole instructions for the overall system. The installer of the system must prepare the instructions for the overall
system. We recommend entering the danger area of the system only when the drive unit is at a standstill.
Pos: null /BA_Module/BA_ Seitenumbruch @ 0\ mod_1190719383361_0.d ocx @ 550 @ @ 1

4
Pos: null /BA_Module/ BA_EA Sicherhei tskapitel/04_Allge meine Sicherheit shinweise/Sicher heitskapitel_A llgemeineSicherheit shinweise_EU_neue sLayout @ 63\mod_160508 8395059_28.doc x@ 17155 66 @ 2 @ 1
General safety instructions
WARNING
Failure to follow these installation instructions may result in severe injury or death.
Please read these instructions before using the product.
Keep these instructions handy.
Include these instructions when passing on the product to third parties.
WARNING
Danger from improper use of the product!
Do not let children operate the product unsupervised or use as a toy.
WARNING
Danger to life from incorrect installation!
Work carried out improperly may result in death or severe injury from electrical current or falling parts
Allow only competent people to carry out the work.
Disconnect all cables from the power supply.
Observe valid regulations and standards.
Use suitable tools.
Pos: null /BA_Module/BA _EA Sicherheitskapi tel/04_Allgemeine Si cherheitshinweise/ Neue Sicherheitshi nweise/Sicher heitskapitel_Allge meineSicherheitshin weise_unzulässi ge-Krafteinwirkun g-neueMV @ 68\mod_16296994 45249_28.docx @ 1772384 @ @ 1
WARNING
Danger to life from falling objects if the drive unit is subjected to impermissible forces!
Inadmissible forces (examples: collision with a forklift, dropping the drive unit, tearing or pulling on the motor)
lead to damage to the drive unit. There is a risk of severe injury or death from falling objects.
Prevent impermissible forces from acting on the drive unit,
Check the drive unit for damage if impermissible forces have acted on it. Look even for minor damage.
Lock the door during the inspection.
Contact the service department if you have difficulty assessing the damage.
Pos: null /FS_ELEKTROMA TEN_Module/Sicher heitskapitel_FS_Adres se-GfA @ 66\mod_16184013055 11_28.docx @ 1747514 @ @ 1
Pos: null /BA_Module_M anuell/Allgemeine_ Module/BA_Seiten umbruch @ 29\mod_15675928 07787_0.docx @ 1515778 @ @ 1
GfA ELEKTROMATEN GmbH & Co. KG
Wiesenstraße 81
D-40549 Düsseldorf
www.gfa-elektromaten.de
[email protected]

5
Pos: null /Überar beitung_ELEKTROMA TEN-MAL/BA_FA/BAFA_ Module/TD_00_Abtrieb sdrehzahl @ 32\ mod_1581323779969_28. docx @ 1578026 @ 1 @ 1
2Technical data
Designation Unit
Output speed 20 rpm
Pos: null /Überarbei tung_ELEKTROMATEN- MAL/BA_FA/BAFA_Module/ TD_01_Allgemeine_ Technische Daten @ 62\mod _1604419390202_28.doc x@ 1712036 @ @ 1
Output torque 250 (250) 1) Nm
Output / hollow shaft 30,00 mm
Series FS 25 -
Limit switch range
(maximum revolutions of the output / hollow shaft)
20 -
Supply voltage 3N~ 400 V
Operating current 2,00
A
Operating frequency 50 Hz
Power factor cos φ 0,68 -
Safety circuit 24 V
Degree of protection IP 54 -
Temperature range -10 / +40 (+60) 2) °C
Operating sound pressure level < 70 dB(A)
Pos: null /Überarbei tung_ELEKTROMATEN- MAL/BA_FA/BAFA_Module/ TD_02_Zyklen pro Stund e @ 32\mod_1581670412604 _28.docx @ 1579486 @ @ 1
Cycles per hour 12 (8,3)1) h-1
Pos: null /Üb erarbeitung_EL EKTROMATEN-MAL/BA_FA/ BAFA_Modul e/TD_02_Maxi males Haltemo ment @ 32\mod_15 81669413436_28 .docx @ 15794 65 @ @ 1
Max. holding torque 250 Nm
Pos: null /Überarbeitu ng_ELEKTROMATEN-MAL/BA _FA/BAFA_Module/TD _02_Maximale Last @ 32\mod_15 81333858646_28.doc x@ 1 578295 @ @ 1
Max. load - N
Pos: null /Überarbei tung_ELEKTROMATEN- MAL/BA_FA/BAFA_Module/ TD_02_Bremsmoment_Br emsspannung_Glei chrichtertyp @ 32\mod_158 1405686758_28.doc x @ 1578686 @ @ 1
Braking torque 13 Nm
Braking voltage 24 V DC
Rectifier type - -
Pos: null /Überarbei tung_ELEKTROMATEN- MAL/BA_FA/BAFA_Module/ TD_20_Workaround_fe hlende_TechnDate n_POD (2022-04-01 11:41: 06) @ 65\mod_160639856794 3_28.docx @ 1721194 @ @ 1
Series
Designation FS 15 FS 25 FS 50 FS 110
Braking power 16 W 24 W 26 W 26 W
Permissible radial load 3900 N 4350 N 9100 N 17000 N
restoring torque
ELEKTROMATEN 15 Nm 15 Nm 22 Nm 30 Nm
Weight 26.5 kg 46 kg 66 kg 105 kg
Recommendation of number of
teeth for sprocket and pitch
15
3/4“
15
3/4“
15
1“
15
1 1/4“
Pos: null /BA_Module/BA_ FB Abtriebmoment Konstan t/BAFB000001_M001 @ 71\mod _1637686069416_28.doc x @ 1794253 @ @ 1
1) Specification in ( ) according to EN 60335-2-103.
Pos: null /BA_Module/BA_ FC Temperaturbereic h/BAFC000001_M002 @ 71\mod_163 7771456405_28.doc x@ 179447 5 @ @ 1
2) When using a temperature range of +40°...+60°C use half of maximum cycles per hour.
Pos: null /Überar beitung_ELEKTROMA TEN-MAL/BA_FA/BAFA_ Module/TD_10_Erkläru ng_Abtriebsdre hzahl @ 32\mod_15820 92676881_28.doc x @ 1579914 @ @ 1
Output speed
The centrifugal brake limits the output speed in the case of a fire when the power supply fails. In this case, the
output speed is higher than the one in mains operation.
Pos: null /Überarbei tung_ELEKTROMATEN- MAL/BA_FA/BAFA_Module/ TD_10_Erklärung_ max_Haltemoment @ 32\mod_15 82092810843_28.doc x @ 1579935 @ @ 1
Maximum holding torque
Denotes the maximum torque that may act on the drive shaft of the drive unit when the door is stationary.
Pos: null /Üb erarbeitung_EL EKTROMATEN-MAL/BA_FA /BAFA_Modul e/TD_10_Erkläru ng_Betriebsstr om @ 32\mo d_1582093319240 _28.docx @ 15799 77 @ @ 1
Operating current
In door drive units, the operating current can be up to 4 times the rated current for a short time.
Pos: null /Überarbei tung_ELEKTROMATEN- MAL/BA_FA/BAFA_Module/ TD_10_Erklärung_ Zyklen_pro_Stunde @ 32\ mod_1582092878750_28. docx @ 1579956 @ @ 1
Cycles per hour
The specified cycles per hour apply to an even distribution of the cycles per hour that must not be exceeded.
Pos: null /BA_Module_M anuell/Allgemeine_ Module/BA_Seiten umbruch @ 29\mod_15675928 07787_0.docx @ 1515778 @ @ 1

6
Pos: null /FS_ELEKTROMA TEN_Module/Produktüb ersicht/Produktüber sicht_FS_Komponent en_A @ 33\mod_158702217945 2_28.docx @ 1646034 @ 1 @ 1
3Product overview
No. Designation
1 Output shaft: Note the recommendation for the number of teeth on the sprocket and the pitch in the
technical data.
2 Spur gear
3 Intermediate flange with centrifugal brake: In the case of fire, the centrifugal brake regulates the speed
that the door uses to close. In the case of fire, the door closes 10% to 15% faster than with electrical
operation.
4 Motor: three-phase motor with thermal protection switch.
5 Universal brake: Combination of working current brake and spring-applied brake (see chapter Universal
brake).
6 Limit switch cover
Pos: null /BA_Module/BA_ FB Abtriebmoment Konstan t/BAFB000001_M001 @ 71\mod _1637686069416_28.doc x @ 1794253 @ @ 1
1) Specification in ( ) according to EN 60335-2-103.
Pos: null /BA_Module/BA_ FD Daten Endschalter/ BAFD000006_M001 (2022- 07-18 08:25:06) @ 64\mod_ 1605713588033_28.doc x@ 1718826 @ @ 1
CAUTION
Component damage can result!
The maximum current that can be switched over the limit switch is 1A for 230 V AC and 0.4 A for 24V DC.
Pos: null /BA_Module_M anuell/Allgemeine_ Module/BA_Seiten umbruch @ 29\mod_15675928 07787_0.docx @ 1515778 @ @ 1

7
Pos: null /FS_ELEKTROMA TEN_Module/Lagern/ Lagern _ELEKTROMATEN @ 60\ mod_1597916702984_28. docx @ 1698026 @ 1 @ 1
4Storing
Store the product in the original packaging.
Ensure the following environmental conditions for storage:
Closed, dry, dark and vibration-free rooms
Temperatures between +5 °C and +40 °C
Relative humidity less than 70 %, non-condensing
Dust protected
Protected against corrosion (e.g. protection against saltwater)
Protected against chemicals
Pos: null /FS_ELEKTROMA TEN_Module/Transpor tieren/FS_Transpor tieren @ 60\mod_1600172 904687_28.doc x@ 170290 4 @ 1 @ 1
5Transport
Avoid bumps, impacts and vibrations during transport.
CAUTION
Injuries, or damage to the drive unit!
Use aids for lifting and carrying if the weight of the drive unit exceeds 20 kg. Refer to the technical data for
the weight.
Notic
e
Failure of electrical components during operation!
Do not lift the drive unit by the cables.
Lifting points
Lift the product at the position shown.
Use lifting equipment and load suspension devices
with sufficient load-carrying capacity. Refer to the
technical data for the weight of the drive unit.
Pos: null /BA_Module_M anuell/Allgemeine_ Module/BA_Seiten umbruch @ 29\mod_15675928 07787_0.docx @ 1515778 @ @ 1

8
Pos: null /FS_ELEKTROM ATEN_Module/Mechani sche Montage/Allge meine Sicherheitshin weise/FS_MechMontage_a llgSicherheit shinweise @ 60\mod_159 8341728650_28.doc x@ 16989 54 @ 12 @ 1
6Mechanical installation
General safety information
WARNING
Danger to life from electric shock!
Working on the mechanics may damage electrical lines or components. Danger to life or risk of severe injury
from electric current.
Disconnect all cables from the power supply.
Secure the mains disconnector against plugging in or switching on again.
Allow only competent people to carry out the work.
WARNING
Danger to life from moving parts!
Moving parts may cause the risk of injury, for example through impact, shock, crushing, shearing or drawing
in of body parts.
Mount the product 2.5 m above the access level or use additional protective devices to prevent contact.
CAUTION
Injuries from hot surfaces!
The surfaces of the motor can get up to 100 °C during operation. This may cause burns.
Mount the product 2.5 m above the access level or use additional protective devices to prevent contact.
Pos: null /FS_ELEKTROMA TEN_Module/Mechani sche Montage/Zulässi ge Einbaulage/MechMon tage_ZulEinbaulage_ FS_001 @ 60\mod_1598 342530700_28.docx @ 169 8997 @ 2 @ 1
Permissible mounting positions
Mount the drive unit in one of the mounting positions shown in grey. Incorrect mounting positions, for example,
prevent emergency actuation or lead to premature wear due to insufficient lubrication. Other mounting positions
are not permitted.
2
5
1
6
3
4
=
=
Pos: null /BA_Module_M anuell/Allgemeine_ Module/BA_Seiten umbruch @ 29\mod_15675928 07787_0.docx @ 1515778 @ @ 1

9
Pos: null /FS_ELEKTROMA TEN_Module/Mechanisc he Montage/Befestigu ng/FS_MechMontage_B efestigung_BEF8_A GTFS025 @ 60\mod_1598357 154505_28.docx @ 1699222 @ 2@ 1
Mounting
Only use the fastening points shown for mounting the product. Alternative mounting options for separately
available accessories are not described here. Use the mounting instructions of the accessories for this purpose.
Pos: null /BA_Module_M anuell/Allgemeine_ Module/BA_Seiten umbruch @ 29\mod_15675928 07787_0.docx @ 1515778 @ @ 1

10
Pos: null /FS_ELEKTROM ATEN_Module/Mechani sche Montage/Verbindu ngselemente/FS_ MechMontage_Verbindung selemente @ 60\mod_159835 6251599_28.doc x@ 16991 16 @ 2 @ 1
Connection elements
WARNING
Danger to life from falling parts and uncontrolled movements.
The permissible loads on structures, walls, fastenings, connection and transmission elements must not be
exceeded, even with maximum holding or locking torques.
Please note the technical data of the drive unit.
Note the following information on using connection elements.
Also note the documentation of the door manufacturer.

Use only screw connections for mounting.
 Non-detachable connections (e.g. welded or riveted
connections) are not permitted.

Use connection elements with a minimum strength
of 800 N/mm2 (8.8).

Make maximum use of the existing hole diameters.

Use adequately dimensioned washers for
elongated holes.
Pos: null /FS_ELEKTROM ATEN_Module/Mechani sche Montage/Montage dur chführen/FS_Mec hMontage_Arbeitsschr itte_neu @ 66\mod_16166 69356690_28.doc x@ 1741 694 @ 2 @ 1
BAGAE10004_Z001

11
Work steps
WARNING
Danger to life from incorrectly installed transmission elements
A chain with too little or too much tension may skip or break. As a result, parts of the door structure may
become loose and drop. The drive unit or door construction may also suffer damage.
Note the information given below on the selection and use of transmission elements.
Grease the output shaft and key thoroughly. Use
suitable assembly grease.
Mount the sprocket (①). The hub side of the
sprocket points away from the drive unit. The
sprocket must lie fully over the key.
Tighten the fastening screw slightly (②).
Mount the drive unit.
Tighten the fastening screws slightly.
Mount the chain.
The sprockets of the drive unit and door must be
flush.
BAGAE10003_Z00
1
BAGAE10003_Z001

12
Tighten the fastening screw of the sprocket.
Tension the chain. The slack side (Ⓐ) must not
exceed the height of a chain link (Ⓑ).
We recommend using a chain tensioner.
From an angle of 60°, a chain tensioner is required
in the slack side.
Tighten all fastening screws.
Also note the specifications of the door
manufacturer.
Pos: null /BA_Module_M anuell/Allgemeine_ Module/BA_Seiten umbruch @ 29\mod_15675928 07787_0.docx @ 1515778 @ @ 1
=
< 60°

13
Pos: null /FS_ELEKTROMA TEN_Module/Elektri sche Montage durchf ühren/Allgemeine Sic herheitshinweise/ELEK- Montage_ELEK TROMATEN-FS_AllgSicher heitshinweise @ 60\mod _1597921777837_28.doc x @ 1698708 @ 12 @ 1
7Electrical installation
General information
WARNING
Danger to life from electric shock!
Improper wiring may result in severe or fatal injury from electrical current.
Allow only competent people to carry out the work.
Disconnect all cables from the power supply.
WARNING
Danger to life from uncontrolled movements!
Unauthorised switching on of the voltage during assembly and maintenance may lead to injuries as a result of
uncontrolled movements.
Secure the mains supply against being switched on or plugged in again.
WARNING
Danger to life from uncontrolled movements!
Failure of a phase in the motor supply line may lead to uncontrolled movements of the drive unit.
Use fuse protection with an all-round switching circuit breaker with C characteristics.
WARNING
Danger to life from falling parts.
If the motor fails to switch off, the door could overrun the final limit positions. This may lead to a hazard from
falling components.
Use a door control that complies with the EN ISO 60335-1.
Pos: null /BA_Module_M anuell/Allgemeine_ Module/BA_Seiten umbruch @ 29\mod_15675928 07787_0.docx @ 1515778 @ @ 1

14
Pos: null /FS_ELEKTROMA TEN_Module/Elektri sche Montage durchf ühren/Verbindungslei tungen anschließen/FS _ElekMontage_Verbi nden_Motorstecker @ 60\mod_1598362352275 _28.docx @ 1699344 @ 2 @ 1
Attaching the connection cables
WPEVU
Remove the limit switch cover.
Plug in the motor connector.
Pos: null /FS_ELEKTROMA TEN_Module/Elektri sche Montage durchf ühren/Verbindungslei tungen anschließen/FS _ElekMontage_Verbi nden_Endschalter stecker_NES @ 60\mod_159982 2703326_28.doc x@ 17016 78@ @ 1
Connect the limit switch plug.
Pos: null /BA_Module_M anuell/Allgemeine_ Module/BA_Seiten umbruch @ 29\mod_15675928 07787_0.docx @ 1515778 @ @ 1

15
Pos: null /FS_ELEKTROMA TEN_Module/Elektri sche Montage durchf ühren/Endschalter_Fu nktion/Endschal ter_NES_Funktion @ 60\mod_ 1599572889878_28.doc x @ 1700999 @ 2 @ 1
Mechanical limit switch - function
Cams S1 - S6
Use cams S3 and S4 to specify the final limit positions OPEN and CLOSE of the door.
The cams S1/S3 and S2/S4 are mechanically linked. The emergency limit switches S1 and S2 only switch when
the drive unit moves beyond the final limit positions OPEN and CLOSE. The emergency limit switches are
automatically preset with the final limit positions. An actuated emergency limit switch interrupts the safety circuit.
The drive unit switches off.
You can use the auxiliary limit switches S5 and S6 individually through terminals X12.11-13 and X12.14-16 (see
the circuit diagram of cam limit switches).
Terminals 4 to 9: safety circuit
Terminals 4 and 9 form the safety circuit. If the safety circuit is interrupted, the drive unit switches off. Terminals
21 to 26 are factory-fitted with wire links. Instead of the wire links, you can connect additional safety devices
(e.g. safety brake). Terminals 27 and 28 are used for the thermal protection of the motor.
Pos: null /FS_ELEKTROM ATEN_Module/Elektri sche Montage durchf ühren/Endschalter_En dschalter einste llen/ElekMontage_NES _EndlagenEinstel len @ 60\mod_159957298235 0_28.docx @ 1701084 @ 2 @ 1
Mechanical limit switch - setting the final limit position
The following explains how to set the limit switch and thereby specify the final limit positions OPEN and CLOSE.
Check the output rotating direction
Issue an OPEN command.
If the door opens, the output rotating direction is
correct. Continue with setting the final limit position
OPEN.
If the door closes, the output rotating direction is
wrong. Change the output rotating direction before
setting the final limit positions.
Setting the output rotating direction
If the movement direction of the drive unit does not correspond to the movement command, you can change the
rotating direction. If you use a GfA door control, change the output rotating direction by using the programming.
Follow the instructions for the door control. Otherwise change the output rotating direction as explained below.
WARNING
Danger to life from electric shock!
Improper wiring may result in severe or fatal injury from electrical current.
Disconnect all cables from the power supply.

16
Disconnect all cables from the power supply.
Swap L1 and L2 in the supply line.
Then switch the voltage back on.
Setting the final limit position OPEN
Remove the limit switch cover of the drive unit.
Issue an OPEN command until the door has
reached the desired position.
Turn cam S3 to the centre of the switch.
Tighten the screw for coarse adjustment with the
enclosed key.
Check the set position by closing the door until the
cam no longer touches the switch. Then move to
final limit position OPEN.

17
The final limit position OPEN can be corrected by
fine adjustment.
Check the door position after a correction.
Checking and correcting the emergency limit switch OPEN
Setting S3 will automatically preset the emergency limit switch S1. Check whether the preset distance is
sufficient.
WARNING
Danger from falling objects!
If a limit switch does not switch, the drive unit is stopped by the emergency limit switch. If the emergency limit
switch switches too late, the door can be damaged or parts of the door leaf may come loose.
Set the emergency limit switch.
A fixed stop of the door leaf may reduce the danger.
Turn the screw for fine adjustment on cam S1 until
the door stops without risk even when passing the
final limit positions.
Setting the final limit position CLOSE and auxiliary limit switch
Proceed as for setting the final limit position OPEN.
Pos: null /BA_Module_M anuell/Allgemeine_ Module/BA_Seiten umbruch @ 29\mod_15675928 07787_0.docx @ 1515778 @ @ 1

18
Pos: null /BA_Module/BA _MA Motoranschluss/BA MA010027_M002 @ 72\mod_16 45178331047_28.doc x @ 1816174 @ 1 @ 1
8Motor connection
BAMA 0 1 0 02 7_ Z 001
U1 U2
W1
W2 V1
V2
UV WPE
M1
U2W2
U1 V1 W1
V2
F10
X13
UVPEWN
Y1
X14
11 12
rt / rd bl / bu
M1 Motor
X13 Motor plug
X14 Brake plug
Y1 Universal brake
Pos: null /BA_Module/BA_ NA Endschalteranschlu ss/BANA001002_M002 @ 54\ mod_1593499424091_28. docx @ 1680136 @ 1 @ 1
9Limit switch connection
F10 Thermal contact
X12 Limit switch board
S1 Emergency OPEN limit switch
S2 Emergency CLOSE limit switch
S3 OPEN limit switch
S4 CLOSE limit switch
S5
A
dditional limit switch
S6
A
dditional limit switch
Pos: null /BA_Module/BA_ Seitenumbruch @ 0\ mod_1190719383361_0.d ocx @ 550 @ @ 1

19
Pos: null /FS_ELEKTR OMATEN_Module/Br emsen/Universalbre mse/FS_ElekMontage _Universalbrems e_Teil1_Stromzufuhr _allgemein @ 60\ mod_1599563938891_ 28.docx @ 1700841 @ 1 @ 1
10 Universal brake
In the case of a fire, the universal brake opens and the
door closes. For the duration of the assembly of the
door, the universal brake can be switched to the
assembly operating mode.
Connecting the power supply
24 V
The universal brake must be supplied and controlled
externally with a voltage of 24 V DC.
Remove the limit switch cover
Route the cables into the limit switch space. Use
suitable cable glands.
11
12
Connect the power supply to terminals X13-11 and
X13-12.
X13-11 = +
X13-12 = -
Pos: null /FS_ELEKTR OMATEN_Module/Brem sen/Universalbre mse/FS_ElekMontage _Universalbremse_ Teil2_ErkBetriebs art_ohneReed @60\ mod_1599569659446_2 8.docx @ 1700883 @ @ 1
Setting the operating mode
Assembly mode: For the assembly of the door. The braking force is applied when no current is present.
Fire-protection mode (factory-set): For operating the door. When the power supply is interrupted, the door
closes by gravity. The braking force is applied when current is present.
WARNING
Danger to life due to failure!
For the door to close in the case of a fire, the brake must be set to fire-protection mode.
Pos: null /FS_ELEKTR OMATEN_Module/Brem sen/Universalbre mse/FS_ElekMontage _Universalbremse_ Teil3_Betriebsar tEinstellen_al lgemein @ 60\mod_1599571 201816_28.doc x@ 1700934 @ @ 1
Setting the assembly mode
Remove the screw from the hole on the side next to
the guide rail (1).

20
Turn the screw into the centre hole of the guide rail
as far as it will go. The guide rail lifts out of the
groove.
The assembly mode has been set. The braking force is
applied when no current is present.
Setting the fire-protection mode
Close the door.
Remove the middle screw from the hole in the
guide rail (1). The guide rail lowers into the groove.
Turn the screw into the hole on the side of the
guide rail for storage.
Apply 24 V to the brake.
The fire-protection mode has been set. The braking
force is applied when current is present.
Pos: null /BA_Module/BA_ Seitenumbruch @ 0\ mod_1190719383361_0.d ocx @ 550 @ @ 1
