GHP Group FA40 BTU Series Manual

Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 877-447-4768 8:30 a.m. – 4:30 pm CST, Monday – Friday
or email us at [email protected]
www.ghpgroupinc.com
USER’S MANUAL AND OPERATING INSTRUCTIONS
C US
PROPANE CONSTRUCTION HEATER
GENERAL HAZARD WARNING
FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH
THIS HEATER, CAN RESULT IN DEATH, SERIOUS BODILY INJURY AND PROPERTY LOSS,
OR DAMAGE FROM THE HAZARDS OF FIRE, EXPLOSION, BURN, ASPHYXIATION, CARBON
MONOXIDE POISONING, AND/OR ELECTRICAL SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS SHOULD
USE OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN INSTRUCTION
MANUAL, LABELS, ETCETERA, CONTACT THE MANUFACTURER.
CONSUMER: Retain this manual for future reference.
Printed in China IMLPFDG - MCR
GHP Group, Inc.
6440 W Howard St
Niles, IL 60714-3302
RMC-FA40DGD/DGD-01 (40,000 BTU/HR, FORCED - AIR)
RMC-FA60DGD/DGD-01 (30,000/60,000 BTU/HR, FORCED - AIR)
RMC-FA125DGD/LPFA125DGD/DGD-01 (70,000/125,000 BTU/HR, FORCED - AIR)
RMC-FA150DGD/DGD-01 (120,000/150,000 BTU/HR, FORCED - AIR)
RMC-FA40/DGP/DGP-01 (40,000 BTU/HR, FORCED - AIR)
RMC-FA60/DGP/DGP-01 (30,000/60,000 BTU/HR, FORCED - AIR)
RMC-FA125/DGP/DGP-01 (70,000/125,000 BTU/HR, FORCED - AIR)
LPFA125H/LPFA125H-01
RMC-FA150/DGP/DGP-01 (120,000/150,000 BTU/HR, FORCED - AIR)
ANS Z83.7-2017 CSA 2.14-2017
Contruction Heater
Adequate ventilation must be provided.
FA60 BTU Series FA125 BTU Series
FA40 BTU Series

Introduction & Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
• Air Quality Hazard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
• General Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
• Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
• Unpacking Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 7
• Size & Capacity Of Propane Cylinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
• Installation To The Propane Gas Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
• Relling The Propane Gas Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
• Leak Checking & Positioning Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
• Lighting & Shutdown Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 11
• Test Firing Heater & Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
• Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
• Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 - 14
Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14, 18, 20
PROPANE CONSTRUCTION HEATER ILLUSTRATED / PARTS BREAKDOWN:
RMC-FA40 & 60 SERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
RMC-FA125DGD, LPFA125H & RMC-FA150DGD . . . . . . . . . . . . . . . . . . . . . . 17
RMC-FA125DGP/DGP-01 & LPFA125DGD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
• Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
TABLE OF CONTENTS
WARNING: NOT FOR HOME OR RECREATIONAL VEHICLE USE.
WARNING
: FIRE, BURN, INHALATION, AND EXPLOSION HAZARD, KEEP SOLID
COMBUSTIBLES, SUCH AS BUILDING MATERIALS, PAPER OR CARDBOARD, A SAFE
DISTANCE AWAY FROM THE HEATER AS RECOMMENDED BY THE INSTRUCTIONS.
NEVER USE THE HEATER IN SPACES WHICH DO OR MAY CONTAIN VOLATILE OR
AIRBORNE COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE, SOLVENTS, PAINT
THINNERS, DUST PARTICLES OR UNKNOWN CHEMICALS.
2
PROPANE CONSTRUCTION HEATER
WARNING
: Using this heater in a residential garage requires that the heater is positioned
so that it is protected against any possible damage by a moving vehicle, etc. It must be
positioned so that the base of the heater is no less than 18 in (450 mm) above the garage oor or
8 ft (2450 mm) in repair garages. The heater must be placed on a stable surface. Do not place it on
a chair, ladder, etc. Raising the heater will reduce BUT NOT eliminate the possibility of lighting the
vapor of any ammable liquids which may be improperly stored or accidentally spilled. If the smell of
gasoline is present, DO NOT operate this heater until the area has been properly ventilated.
WARNING: CONSTRUCTION HEATERS ARE NOT FOR USE IN
GARAGES IN CANADA.
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
WARNING:
This product and the fuels used to operate this product (liquid propane),
and the products of combustion of such fuels, can expose you to chemicals including benzene,
which is known to the State of California to cause cancer and reproductive harm.
For more information go to www.p65Warnings.ca.gov

PROPANE CONSTRUCTION HEATER
The heater is designed and approved for use as a construction heater under ANS Z83.7 CSA 2.14. It is hard
to anticipate every use which may be made of this heater. CHECK WITH YOUR LOCAL FIRE SAFETY
AUTHORITY IF YOU HAVE QUESTIONS ABOUT APPLICATIONS.
DYNA-GLO PROPANE FORCED AIR CONSTRUCTION HEATERS
This is a direct-red forced air construction heater for either indoor construction or outdoor use. Its intended
use is primarily the temporary heating of buildings or structures under construction, alteration or repair. All the
products of combustion generated by the heater are forced through the heater and released into the area being
heated. This heater operates at approximately 98%+ combustion efciency but still produces a small amount
of carbon monoxide. Humans can tolerate small amounts of carbon monoxide for short periods. Carbon
monoxide can build up in a heated space and failure to provide adequate ventilation could result in poisoning
or death.
PROPANE CONSTRUCTION HEATER
34
Other standards govern the use of fuel gases and heat producing products in specic applications.
Your local authority can advise you about these.
IMPORTANT: READ THIS USER’S MANUAL CAREFULLY AND COMPLETELY BEFORE TRYING
TO OPERATE OR SERVICE THIS HEATER. IMPROPER USE OF THIS HEATER CAN CAUSE
SERIOUS INJURY OR DEATH FROM FIRE, EXPLOSION AND CARBON MONOXIDE POISONING.
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
WARNING
: NOT FOR USE WITH DUCT WORK.
• Do not use this heater for heating human living quarters.
• Use of direct-red heaters in the construction environment can result in exposure to levels of CO, CO2, and
NO2considered to be hazardous to health and potentially life threatening.
• Do not use in unventilated areas
• Know the signs of CO and CO2poisoning
▫Headaches, stinging eyes
▫Dizziness, disorientation
▫ Difculty breathing, feels of being suffocated
• Proper ventilation air exchange (OSHA 29 CFR 1926.57) to support combustion and maintain acceptable
air quality shall be provided in accordance with OSHA 29 CFR Part 1926.154, ANSI A10.10 Safety
Requirements for Temporary and Portable Space Heating Devices and Equipment used in the Construction
Industry or the Natural Gas and Propane Installation Codes CSA B149.1
▫Periodically monitor levels of CO, CO2and NO2existing at the construction site – at the minimum at the
start of the shift and after 4 hours.
▫Provide ventilation air exchange, either natural or mechanical, as required to maintain acceptable indoor
air quality
WARNING
Air Quality Hazard

PROPANE CONSTRUCTION HEATER
34
SPECIFICATIONS
FA40 Series
FA60Series
FA125 Series FA150 Series
40,000BTU/hr
30,000BTU/hr
60,000BTU/hr
70,000BTU/hr
125,000BTU/hr
120,000BTU/hr
150,000BTU/hr
Propane Propane Propane Propane
CylinderPressure CylinderPressure CylinderPressure CylinderPressure
5psig 5psig 5psig 5psig
11"W.C 11"W.C 11"W.C 11"W.C
1.9lbs/hr0.86kg/hr
1.4lbs/hr0.63kg/hr
2.8lbs/hr1.27kg/hr
3.3lbs/hr1.5kg/hr
5.8lbs/hr2.63kg/hr
5.6lbs/hr2.54kg/hr
7.0lbs/hr3,18kg/hr
120V,60Hz,1Ø 120V,60Hz,1Ø 120V,60Hz,1Ø 120V,60Hz,1Ø
Amperage Load 0.68amps 0.65amps 0.7amps 0.7amps
Fan
Unload
Load
3550rpm
3000rpm
3570rpm
3300rpm
3580rpm
3300rpm
3580rpm
3300rpm
Piezo/ManualSpark
ContinuousSpark ContinuousSpark ContinuousSpark
0.16"(4mm) 0.16"(4mm) 0.16"(4mm) 0.11"(2.8mm)
19.3"x8.3"x13.5"
(49.0x21.1x34.2)cm
19.3"x8.3"x13.5"
(49.0x21.1x34.2)cm
26.2"x11.8"x15"
(66.6x30.0x38.1)cm
25.6"x11.8"x15"
(65.0x30.0x38.1)cm
25.6"x11.8"x15"
(65.0x30.0x38.1)cm
Size(LxWxH)
ManifoldPressure
GasConsumption
ElectricalInput
Ignition
SparkGap
ModelNo.
InputRating
TypeofGas
GasSupplyPressureto
RegulatorMaximum
Minimum(forpurposeof
InputAdjustment)
USA 8-Hr Time weighted average
(OSHA 29 CFR 1926.55 App A)
CO 50 ppm
CO25000 ppm
NO2
USA – Ceiling Limit
(Short Term Exposure Limit = 15 minutes)
CO
CO2
NO25 ppm
Canada 8-hr time weighted average
WorkSafe BC OHS Guidelines Part 5.1
and Ontario Workplaces Reg 833
25 ppm
5000 ppm
3 ppm (Reg 833)
Canada STEL (15 minutes Reg 833/1 hour
WSBC) WorkSafe BC OHS Guidelines Part
5.1 and Ontario Workplaces Reg 833
100 ppm
15000 ppm (WSBC)
30000 ppm (Reg 833)
1.0 ppm (WorkSafeBC)
5.0 ppm (Reg 833)
• Ensure that the ow of combustion and ventilation air exchange cannot become obstructed.
• As the building ‘tightens up’ during the construction phases ventilation may need to be increased.

PROPANE CONSTRUCTION HEATER
Accidents are always tragic especially because so many of them could have been prevented with little care
and judgment. There are some basic good practices, we hope you will follow for safe use of your heater.
• Children should be carefully supervised, when they are in the area.
• Always maintain proper clearance from combustible materials. Minimum clearance from combustibles:
Side - 24” (61 cm); Top - 48” (121.9 cm); Front - 72” (183 cm). Floor - combustible. Not for use on nished oors.
• Heater must be placed on level and stable surface.
• Never place anything including clothes or other ammable items on the heater.
• The appliance area shall be kept clear and free from combustible materials, gasoline and other ammable
vapours and liquids.
• Do not modify or operate a heater which has been modied.
• Adequate clearance for accessibility and for combustion & ventilation air supply must be maintained at all
times when the heater is operating.
• Service and repair should be done by a qualied service person. The heater should be inspected
before each use and at least annually by a qualied person. More frequent cleaning may be required as
necessary. Do not service while hot or operating.
• Never connect heater to an unregulated gas supply.
• The heater is shipped from the factory for LP(Propane) gas. This heater is for use with propane gas only,
do not convert heater to any other gas. Installation must conform to local codes or, in the absence of local
codes, with the standard for the Storage and Handling of Liqueed Petroleum Gases ANSI/NFPA 58 and the
Natural Gas and Propane Installation Code CSA B149.1
• The minimum and maximum inlet pressures to the regulator from the gas tank are 5 psi and bottle pressure,
respectively. Use only the regulator & hose assembly provided with the heater. Inspect the regulator/hose
assembly prior to each use of the heater. If there is excessive abrasion or wear, or hose is cut, replace with
regulator/hose assembly listed on the parts list prior to using this heater.
• Gas supply connections should be checked using a 50/50 solution of liquid dish soap and never use a ame
to check for gas leaks.
• The electrical connection & grounding must comply with National Electrical Code. ANSI/NFPA 70 or in
Canada CSA C22.1, Canadian Electrical Code, Part 1. Use only a properly grounded three
(3) prong receptacle.
• Do not restrict inlet or outlet by any means. The ow of combustion and ventilation air is not to be obstructed.
• This heater should not be directed toward any propane-gas container within 20 ft (6M). The heater must be
located at least 6 ft. (1.83 m) in the U.S.; or (ii) 10 ft. (3 m) in Canada, from any propane gas container.
• The propane cylinder supply system must be arranged to provide for vapour withdrawal from the
operating cylinder.
• This heater is not to be used with external thermostats, timers or other devices that control or alter electrical
supply to the heater.
• Installation of this Appliance at altitudes above 2000 ft. (610 m) shall be in accordance with local codes, or
in the absence of local codes the, National Fuel Gas Code, ANSI Z223.1 / NFPA 54, or National Standard of
Canada, Natural Gas and Propane Installation Code, CSA B149.1.
• For either indoor or outdoor use. Adequate ventilation shall be provided in accordance with OSHA 29 CFR
1926.154, Safety Requirements for Temporary and Portable Space Heating Devices and Equipment ANSI
A10.10, ANSI 223.1 / NFPA 54, Liquied Petroleum Gas Code, NFPA 58 or the National Gas and Propane
Installation Code, CAN B149.1 as appropriate.
PRODUCT FEATURES
• Portable & Stable • 100% Safety Shutoff System
• Wind Resistant & Rain Protected • Continuous Adjustable Input Ratings
• Continuous Spark Ignition or (Except FA40)
Piezo Electric Spark Ignition
GENERAL SAFETY INSTRUCTION
IMPORTANT SAFETY INSTRUCTION
WARNING
: Motor and fan must be running before lighting, during operation and at shutdown,
in order to prevent a ame-out condition which could result in personal injury or property damage.
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
56
Assembly Components and Instructions for Steel Base Units:

PROPANE CONSTRUCTION HEATER
56
UNPACKING HEATER
1. Remove heater from carton.
2. Remove all protective packing applied to heater for shipment.
3. Retain cartons and packaging material until unit is operated and found in good condition.
4. Check heater for any shipping damage. If heater shows any external or internal
damage, promptly inform dealer/distributor where you purchased heater.
Assembly Components and Instructions for Steel Base Units:
1. Assembling the Cord Wrap Attachments:
(FA125 - FA150 Series Only)
Parts Required:
4 Screws (ST3.5x10),
and 2 Cord Wrap Attachments
Place the cord wrap attachment
as shown, then use Phillips
screwdriver to tighten the
screws and secure the
cord wrap attachments.
2. Regulator and Hose Connection:
(All Models)
See gure on right.
Connect the hose tightly to
the heater using a wrench.
Please also refer to
page 8 in the manual.
Tighten, clockwise,
use a wrench
Hose Assembly
Assembly Time:
5 Minutes
Contents:
All Models: Unit, Manual, Hose and Regulator
Assembly
FA125 - FA150 Series Includes:
2 Cord Wrap Attachments, 4 Screws (ST3.5x10)
Tools required for assembly:
All Models: Adjustable Wrench
FA125 - FA150: Phillips Head
Screw Driver
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!

PROPANE CONSTRUCTION HEATER
INFORMATION ON SIZE * CAPACITY OF PROPANE GAS CYLINDERS:
The chart below shows the number and size of propane tanks needed to run this heater.
*Less gas is vaporized at lower temperatures.
You may need two or more 100 pound (45 kg) tanks or one larger tank in colder weather.
(See the parts list for your model of heater to get the specied regulator assembly.)
The propane (LP) gas tank must also be equipped with the following:
• A collar to protect the Propane gas valve.
• A shutoff valve terminating a Propane gas cylinder valve outlet as specied in the
American National Standards for Compressed Gas Cylinder Valve Outlets and Inlet
Connections.
• A safety relief valve having direct communications with the vapor space of the tank.
• An arrangement of vapor withdrawal.
The propane (LP) gas pressure regulator and hose assembly supplied with
this heater must be used without alteration.
The hose assembly shall be visually inspected prior to each use of the heater. If it is evident
that there is excessive abrasion or wear, or the hose is cut, it must be replaced prior to the
heater being put into operation. The replacement hose assembly shall be that specied
by the manufacturer.
Number of Tanks
Temperature
(°F-°C) at
tank 40,000-60,000 BTU/h 125,000 BTU/h 150,000 BTU/h
1 - 20lb (9kg) 2 - 100lb (45kg) 2 - 100lb (45kg)
1 - 20lb (9kg) 2 - 100lb (45kg) 2 - 100lb (45kg)
1 - 20lb (9kg) 2 - 100lb (45kg) 3 - 100lb (45kg)
1 - 20lb (9kg) 3 - 100lb (45kg) 3 - 100lb (45kg)
2 - 20lb (9kg) Use Larger Tank Use Larger Tank
1 - 100lb (45kg) Use Larger Tank Use Larger Tank
Above
32°F (0°C)
32°F (0°C)
20°F (-7°C)
10°F (-12°C)
-10°F (-23°C)
-20°F (-29°C)
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
78

PROPANE CONSTRUCTION HEATER
INSTALLATION TO THE PROPANE GAS TANK
IMPORTANT: You must use a propane/LP gas supply cylinder that is compatible with the connection device
provided with the hose and regulator.
REFILLING THE PROPANE GAS TANK
ALL NEW CYLINDERS MUST BE PURGED BEFORE THE FIRST FILLING.
• Turn heater gas valve knob and gas tank valve to OFF position.
• Propane tank valve equipped with the old style tting has LEFT HANDED THREADS. Turn POL tting
CLOCKWISE to loosen. Protect POL tting when disconnected from tank.
• Have tank lled by your local Propane gas supplier.
• Fasten full Propane tank and connect POL tting to tank valve by turning COUNTERCLOCKWISE.
• With heater gas valve knob still in the OFF position, turn ON tank valve and check for leaks
with soap solution.
WARNING
: Purging and lling of LP gas tanks must be performed by personnel who
has been thoroughly trained in accepted LP gas industry procedures. Failure to follow
these instructions may result in explosion, re, severe personal injury, or death.
1. Provide propane/LP supply system. Ensure that the valve on the cylinder is fully closed by turning the knob
fully clockwise ( ). Ensure that the cylinder is fully upright for vapor withdrawl. (see size/capacity, page 7).
2. Connect hose to heater inlet. (See Figure 1). Tighten rmly using a wrench. You must use the regulator
supplied with heater.
3. Connect fuel gas tting hose/regulator assembly to propane LP tank(s).
(See gure 2) Turn POL Fuel tting counterclockwise into threads on tank. Tighten
rmly using a wrench. Some models have a hand wheel that can be used to tighten the tting. This hand
wheel can be slid off of the nut so that a wrench can also be used to tighten the tting. IMPORTANT:
Position regulator so that hose leaving the regulator is in a horizontal position.
4. Open propane/LP supply valve on propane/LP tank(s) slowly. NOTE: If not opened slowly, excess ow
device in regulator may stop gas ow. If this happens, close propane/LP supply valve, wait one minute
(or until you hear a click) and open again slowly.
5. Check all connections for leaks. Apply a 50/50 solution of liquid dish soap and water to gas joints.
Bubbles forming show a leak that must be corrected.
6. Close propane / LP supply valve before attempting to repair connection.
Propane/LP
Supply Valve
Propane/LP
Tank
Regulator
POL Fuel Gas
Fitting Hose to
Heater
FIGURE 2
Connector Inlet
Hose to Regulator
Hose Fitting
FIGURE 1
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
78

PROPANE CONSTRUCTION HEATER
PROPANE SAFETY
Propane is safe to use when properly handled. Careless handling of the Propane gas tank could
result in re and/or an explosion. Therefore:
• Always keep tank/cylinder securely fastened in an upright position.
• Avoid tipping tank on its side when connected to a regulator since this may cause damage to
diaphragm in regulator.
• Handle valves with care.
• Never connect an unregulated Propane tank to construction heater.
• Do not subject Propane tank to excessive heat.
• Tightly close the gas shutoff valve on the Propane tank after each use.
• The POL tting must be protected when disconnected from the propane tank.
• Never store a Propane gas tank inside a building or in the vicinity of any gas burning appliance.
THE DISCONNECTED TANK MUST NEVER BE STORED IN A BUILDING, GARAGE
OR ANY OTHER ENCLOSED AREA.
LEAK CHECKING
Check all gas connections with a soap solution to be sure they are tight and leak proof.
• The installation of your heater must meet all local codes and/or gas utility requirements or, in the
absence of local codes, with the Storage and Handling of Liqueed Petroleum Gases, ANSI/ NFPA
58 and the Natural and Propane Installation Code, CSA B149.1.
• The minimum clearances to combustible construction: Side - 24” (61 cm); Top - 48” (121.9 cm);
Front - 72” (183 cm); Floor - combustible, must be maintained at all times.
• The hose assembly should be visually inspected prior to each use of the heater. If it is evident that
there is excessive abrasion or wear, or the hose is cut, it must be replaced prior to the heater being
put into operation.
• The replacement hose assembly shall be that specied by the manufacturer (Refer to parts list).
LIGHTING INSTRUCTIONS
WARNING
: Motor and fan must be running before lighting, during operation and shutdown, in
order to prevent a ame-out condition which could result in personal injury or property damage.
NOTE: This heater uses a continuous spark ignition system. This unit will continue to make a clicking/
ticking sound at all times before ignition, after ignition and during operation, regardless of valve knob
positioning.
1. Connect power cord to a properly grounded three (3) prong 120V, 60Hz, single phase receptacle.
2. Turn gas valve knob clockwise to OFF position.
3. Wait ve (5) minutes to clear any gas. Then smell for gas, if you don’t smell gas, go to next step.
4. Turn gas supply ON by turning Propane tank valve counterclockwise .
5. Push in and turn gas control knob counterclockwise to “LOW/IGN”. This will light the burner. If
needed, keep pressing control knob until the burner lights and keep depressing and turning from
OFF to LOW/IGN on Piezo electric spark models. (“HIGH/IGN”: In case of FA40 series)
6. Keep the valve knob depressed for at least 30 seconds after lighting the burner. After 30 seconds
release valve knob.
7. If burner does not stay lit, repeat the lighting procedure.
8. When burner is lit, turn gas valve knob counterclockwise to desired setting. (All models, except
FA40 series).
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
910

PROPANE CONSTRUCTION HEATER
SHUTDOWN INSTRUCTIONS
TEST FIRING HEATER
Test re your construction heater, following the lighting instructions applicable to the gas control sys-
tem employed. Leak test all gas connections with soap solution. Soap bubbles indicate gas leakage.
DO NOT use a match or ame to test for gas leaks.
STORAGE
Never store a Propane gas tank inside a building or in the vicinity of any gas or oil burning appliance.
When the Propane tank is not disconnected from the construction heater, the gas tank and heater
must be stored outdoors in a well ventilated area, out of the reach of children. If for any reason the
heater is to be stored indoors, the tank must be disconnected and stored outdoors in a well ventilated
area out of reach of children, in accordance with the standard for the the Storage and Handling of
Liqueed Petroleum Gases, ANSI / NFPA 58 and CSA B149.1, Natural Gas and Propane Installation
Code. The plastic tank valve plug supplied with your tank must be tightly installed when the tank is
disconnected from the heater.
MAINTENANCE INSTRUCTIONS
1. Turn unit off, allow heater to fully cool and disconnect propane hose before performing any Mainte-
nance
functions. Unplug the unit from the 120V receptacle.
2. Keep unit clean and keep the inside of the torpedo housing debris free.
3. Have unit checked by a qualied technician at least once a year, preferably prior to the heating
season.
WARNING
: Motor and fan must be running before lighting, during operation and at shutdown,
in order to prevent a ame-out condition which could result in personal injury or property damage.
Turn gas valve knob clockwise to OFF position.
Turn gas supply OFF by turning Propane tank valve clockwise to close.
Disconnect the power cord once the heater has cooled to ambient temperature.
REPLACEMENT PARTS
Warning: Use only original replacement
parts. This Heater must use design-specic
parts. Do not substitute or use generic parts.
Improper replacement parts could cause
serious or fatal injuries.
This will also protect your warranty coverage
for parts replaced under warranty.
Parts warranty and non-warranty: Contact
authorized dealers of this product. If they can
not supply original replacement part(s), either
contact your nearest Parts Central or GHP
Group Inc., Technical Service Department at
1-877-447-4768.
When calling GHP Group Inc., have ready:
• your name
• your address
• how heater was malfunctioning
• serial number of heater
• model number of heater
• replacement part number
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
910

PROPANE CONSTRUCTION HEATER
Always be sure to follow proper maintenance procedures, by cleaning the heater once per
month during regular usage, and check spark gap at least once per season.
     
 




     
 




     
 
   

   
   
   
 
 
1. 

2. 
3. Electrode
     
  

   
   
TROUBLESHOOTING:
PROBLEM POSSIBLECAUSE CORRECTIVEACTION
TROUBLESHOOTING
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
11 12

PROPANE CONSTRUCTION HEATER
WIRING DIAGRAMS
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
11 12

PROPANE CONSTRUCTION HEATER
WIRING DIAGRAMS
*
*125K Models only
*125K Sólo modelos
*125K Les modèles Seulement
*
*
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
13 14

MODELS: FA40 Series
FA60 Series
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
PROPANE CONSTRUCTION HEATER
REPLACEMENT PARTS LIST
1
234
5
6
7
8
910
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
13 14

40SERIES 50SERIES 60SERIES
1 INNERSHELLASSEMBLY 1 2304818 2304818 2304818
2 NOZZLE 1 *2304829 *2304942 *2325121
3 FLAMECAP 1 2304819 2304819 2325120
4 THERMALSWITCHBRACKET 1 2304826 2304826 2304826
5 THERMALSWITCH 1 2201373 2201563 2201599
6 NOZZLENUT 1 2304578 2304578 2304578
7 SPARKPLUGASSEMBLY 1 2201375 2201375 2206033
8 THERMOCOUPLEASSEMBLY(1130/1474425L) 1 2304885 2304885 2304885
9 GASTUBINGASSEMBLY 1 2304830 2304830 2304830
OUTERSHELLORANGE 1 2305403 2305403 2305403
OUTERSHELLBLACK 1 2315915 2315915 2315915
OUTERSHELLGRAY 1 2315956 2315956 2315956
OUTERSHELLBLUE 1 2315312 2315312 2315312
11 CORDWRAP(selectmodelsonly) 2 N/A N/A N/A
HANDLEASSEMBLYBLACK 1 2101447 2101447 2101447
HANDLEASSEMBLYGRAY 1 2305426 2305426 2305426
12.1 SCREWHANDLEFRONT 1 2001355 2001355 2001355
12.2 SCREWHANDLEFRONT 1 2001077 2001077 2001077
12.3 NUTHANDLEREAR 1 2000384 2000384 2000384
13 MOTORSUPPORT 1 2304823 2304823 2304823
13.1 MOTORMOUNTINGBOLT 2 2001332 2001332 2001332
13.2 SLEEVE 1 2304949 2304949 2304949
14 MOTORASSEMBLY 1 2305909 2305447 2304547
14.1 MOTORFAN 1 2304821 2304821 2304821
FANGUARDBLACK 1 2304828 2304828 2304828
FANGUARDGRAY 1 2305411 2305411 2305411
16 MOTORBRACKET 1 2304937 2304937 2304937
17 VALVEGAS 1
GS22FA40 GS22AFA60 GS22AFA60
18 PRESSURESWITCH 1
N/A N/A N/A
19 VALVEBRACKET 1 2304624 2304624 2304624
BASEASSEMBLYBLACK 1 2304923 2304923 2304923
BASEASSEMBLYGREY 1 2305405 2305405 2305405
21 POWERCORDASSEMBLY 1 2201368 2101670 2101670
22 GASCONNECTORINLET 1 2304831 2304831 2304831
23 CAPACITOR 1 2201372 2201372 2201372
BASELOWERBLACK 1 2304925 2304925 2304925
BASELOWERGREY 1 2305407 2305407 2305407
KNOBGASVALVEBLACK 1 2101451 2101451 2101451
KNOBGASVALVEORANGE 1 2305466 2305466 2305466
HEIGHTCONTROLLERBLACK 1 2304927 2304927 2304927
HEIGHTCONTROLLERGREY 1 2305409 2305409 2305409
HEIGHTCONTROLSCREWBLACK 1 2304510 2304510 2304510
HEIGHTCONTROLSCREWORANGE 1 2305467 2305467 2305467
28 LEADWIREASSEMBLY 1 2201371 2201371 2201371
29 SPARKMODULE 1 N/A 2201391 2201391
30 PCBASSEMBLY 1 2201369 2201369 2201369
REG&HOSEASSEMBLY10FT(3M) 1 KR106021031 KR106021031 KR106021031
REG&HOSEASSEMBLY10FT(3M)w/HANDWHEEL 1KR10602HW1031 KR10602HW1031 KR10602HW1031
REG&HOSEASSEMBLY(QCC)10FT(3M) 1 *TYQ9C3000 *TYQ10C3000 *TYQ10C3000
REG&HOSEASSEMBLY15FT(4.6M) 1 KR106021531 KR106021531 KR106021531
REG&HOSEASSEMBLY15FT(4.6M)w/HANDWHEEL 1 KR10602HW1531 KR10602HW1531 KR10602HW1531
REG&HOSEASSEMBLY(QCC)15FT(4.6M) 1 *TYQ9C4572 *TYQ10C4572 *TYQ10C4572
*VERSIONNOTSHOWNINEXPLODEDVIEW
DESCRIPTION
PARTNUMBER
10
12
15
QTY
25
26
27
31
Article
No.
20
24
Article
No.
DESCRIPTION QTY PART NUMBER
1INNER SHELL ASSEMBLY 1 2304818 2304818
2 NOZZLE 1 *2304829 *2325121
3 FLAME CAP 1 2304819 2325120
4 THERMAL SWITCH BRACKET 1 2304826 2304826
5 THERMAL SWITCH 1 2201373 2201599
6 NOZZLE NUT 1 2304578 2304578
7SPARK PLUG ASSEMBLY 1 2201375 2206033
8THERMOCOUPLE ASSEMBLY (1130/1474-425L) 1 2304885 2304885
9GAS TUBING ASSEMBLY 1 2304830 2304830
10 OUTER SHELL - BLACK 1 2315915 2315915
OUTER SHELL - BLUE 1 2315312 2315312
11 HANDLE ASSEMBLY - BLACK 1 2101447 2101447
11.1 SCREW - HANDLE FRONT 1 2001355 2001355
11.2 SCREW - HANDLE FRONT 1 2001077 2001077
11.3 NUT - HANDLE REAR 1 2000384 2000384
12 MOTOR SUPPORT 1 2304823 2304823
12.1 MOTOR - MOUNTING BOLT 1 2001332 2001332
12.2 SLEEVE 1 2304949 2304949
13 MOTOR ASSEMBLY 1 2305909 2304547
13.1 MOTOR - FAN 1 2304821 2304821
14 FAN GUARD - BLACK 1 2304828 2304828
15 MOTOR BRACKET 1 2304937 2304937
16 VALVE - GAS 1 GS22-FA40 GS22A-FA60
17 PRESSURE SWITCH 1 N/A N/A
18 VALVE BRACKET 1 2304624 2304624
19 BASE ASSEMBLY - BLACK 1 2304923 2304923
20 POWER CORD ASSEMBLY 1 2201368 2101670
21 GAS CONNECTOR INLET 1 2304831 2304831
22 CAPACITOR 1 2201372 2201372
23 BASE LOWER - BLACK 1 2304925 2304925
24 KNOB GAS VALVE - BLACK 1 2101451 2101451
25 HEIGHT CONTROLLER - BLACK 1 2304927 2304927
26 HEIGHT CONTROL SCREW - BLACK 1 2304510 2304510
27 LEAD WIRE ASSEMBLY 1 2201371 2201371
28 SPARK MODULE 1 N/A 2201391
29 PCB ASSEMBLY 1 2201369 2201369
30
REG & HOSE ASSEMBLY - 10FT (3M) 1 KR10602-10-31 KR10602-10-31
REG & HOSE ASSEMBLY - 10FT (3M) w/HANDWHEEL 1 KR10602-HW10-31 KR10602-HW10-31
REG & HOSE ASSEMBLY (QCC) - 10FT (3M) 1 *TYQ-9C-3000 *TYQ-10C-3000
REG & HOSE ASSEMBLY -15FT (4.6M) 1 KR10602-15-31 KR10602-15-31
REG & HOSE ASSEMBLY - 15FT (4.6M) w/HAND WHEEL 1 KR10602-HW15-31 KR10602-HW15-31
REG & HOSE ASSEMBLY (QCC) - 15FT (4.6M) 1 *TYQ-9C-4572 *TYQ-9C-4572
40 SERIES 60 SERIES
PROPANE CONSTRUCTION HEATER
REPLACEMENT PARTS LIST
15 16

MODELS: RMC-FA125DGD/LPFA125H
RMC-FA150DGD
PROPANE CONSTRUCTION HEATER
PROPANE CONSTRUCTION HEATER ILLUSTRATED / PARTS BREAKDOWN
15 16

ITEM
No. DESCRIPTION QTY
PART NUMBER
125 SERIES 150 SERIES
1 INNER SHELL ASSEMBLY 1 2304929 2304929
2 NOZZLE 1 5030077 2304944
3 FLAME CAP 1 2325122 2304931
4 THERMAL SWITCH BRACKET 1 2315515 2001355
5 THERMAL SWITCH 1 2201373 2201373
6 NOZZLE NUT 1 2304945 2304945
7 SPARK PLUG ASSEMBLY 1 2206034 2201393
8 THERMOCOUPLE ASSEMBLY (1130/1474--425L) 1 2304885 2304885
9 GAS TUBING ASSEMBLY 1 2325138 2304947
10
OUTER SHELL -- BLACK 1 N/A N/A
OUTER SHELL -- GRAY 1 2315916 2315916
11 CORD WRAP (select models only) 2 2101423 2101423
12 HANDLE ASSEMBLY -- BLACK 1 2101447 2101447
12.1 SCREW -- HANDLE FRONT 1 2001355 2001355
12.2 SCREW -- HANDLE FRONT 1 2001077 2001077
12.3 NUT -- HANDLE REAR 1 2000384 2000384
13 MOTOR SUPPORT 1 2304823 2304823
13.1 MOTOR -- MOUNTING BOLT 2 2001332 2001332
13.2 SLEEVE 1 2304949 2304949
14 MOTOR ASSEMBLY 1 2304548 2304548
14.1 MOTOR -- FAN 1 2304936 2304936
15
FAN GUARD -- BLACK 1 2304939 2304939
FAN GUARD -- GRAY 1 2305412 2305412
16 MOTOR BRACKET 1 2304938 2304938
17 VALVE -- GAS 1 GS22A--FA125 GS22A--FA150
18 PRESSURE SWITCH 1 2305976 2305976
19 VALVE BRACKET 1 2304624 2304624
20 BASE ASSEMBLY -- BLACK 1 2304924 2304924
21 POWER CORD ASSEMBLY 1 2101673 2101673
22 GAS CONNECTOR INLET 1 2304831 2304831
23 CAPACITOR 1 2301390 2301390
24 BASE LOWER -- BLACK 1 2304926 2304926
25 KNOB GAS VALVE -- BLACK 1 2101451 2101451
26 HEIGHT CONTROLLER -- BLACK 1 2304928 2304928
27 HEIGHT CONTROL SCREW -- BLACK 1 2304510 2304510
28 LEAD WIRE ASSEMBLY 1 2201371 2201371
29 SPARK MODULE 1 2201391 2201391
30 PCB ASSEMBLY 1 2201369 2201369
31
REG & HOSE ASSEMBLY -- 10FT (3M) 1 GR109--10--38 GR109--10--38
REG & HOSE ASSEMBLY -- 10FT (3M) w/HANDWHEEL 1 GR109--HW10--38 GR109--HW10--38
REG & HOSE ASSEMBLY(QCC) -- 10FT (3M) 1 *TYQ--6D1--3000 *TYQ--6E1--3000
REG & HOSE ASSEMBLY --15FT (4.6M) 1 GR109--15--38 GR109--15--38
REG & HOSE ASSEMBLY --15FT (4.6M) w/HAND WHEEL 1 GR109--HW15--38 GR109--HW15--38
REG & HOSE ASSEMBLY(QCC) --15FT (4.6M) 1 *TYQ--6D1--4572 *TYQ--6E1--4572
* VERSION NOT SHOWN IN EXPLODED VIEW
PROPANE CONSTRUCTION HEATER
REPLACEMENT PARTS LIST
17

WARRANTY
LIMITED WARRANTY:
DUTIES OF THE OWNER:
This heating appliance must be operated in accordance with the written instructions furnished with this heater. This warranty shall not excuse
the owner from properly maintaining this heater in accordance with the written instructions furnished with this heater. A bill of sale, canceled
check or payment record must be kept to verify purchase date and establish warranty period. Original carton should be kept in case of warranty
return of unit.
WHAT IS NOT COVERED:
1. Damage resulting from use of improper fuel.
2. Damage caused by misuse or use contrary to the owners manual and safety guidelines.
3. Damage caused by a lack of normal maintenance.
4. Fuses
5. Use of non-standard parts or accessories.
6. Damage caused in transit. Freight charges on warranty parts or heaters to and from the factory shall be the responsibility of the owner.
This warranty does not imply or assume any responsibility for consequential damages that may result from the use, misuse, or the lack of
routine maintenance of this heating appliance. A cleaning fee and the cost of parts may be charged for appliance failures resulting from lack of
maintenance. This warranty does not cover claims which do not involve defective workmanship or materials. FAILURE TO PERFORM
GENERAL MAINTENANCE (INCLUDING CLEANING) WILL VOID THIS WARRANTY.
THIS LIMITED WARRANTY IS GIVEN TO THE PURCHASER IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY OF FITNESS FOR A PARTICULAR PURPOSE. THE
REMEDY PROVIDED IN THIS WARRANTY IS EXCLUSIVE AND IS GRANTED IN LIEU OF ALL OTHER REMEDIES. IN NO EVENT WILL
GHP GROUP, INC. BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Some states do not
allow the exclusion or limitation of incidental or consequential damages so the above limitation or exclusion may not apply to you.
CLAIMS HANDLED AS FOLLOWS:
1. Contact your retailer and explain the problem.
2. If the retailer is unable to resolve the problem, contact our Customer Service Dept. detailing the heater model, the problem, and proof
of date of purchase.
3. A representative will contact you. DO NOT RETURN THE HEATER TO GHP GROUP,INC. unless instructed by our Representative.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
TO REGISTER THE WARRANTY ON YOUR HEATER, PLEASE FILL OUT THIS CARD COMPLETELY
AND MAIL WITHIN 14 DAYS FROM DATE OF PURCHASE OR REGISTER ON-LINE AT www.ghpgroupinc.com
NAME: ______________________________________ PHONE: ( ) __________________ EMAIL: ____________________________
ADDRESS: _________________________________ CITY: ______________________________ STATE: __________ ZIP: ____________
MODEL: ____________________ SERIAL #: _______________________________________ DATE PURCHASED: __________________
DEALER PURCHASED FROM: ____________________________________________ TYPE OF STORE: __________________________
CITY & STATE WHERE PURCHASED: ______________________________________________ PRICE PAID: _______________________
Please Take a Minute To Give Us Your Answers To The Following Questions.
All Responses Are Used Solely For Market Research And Are Held In Strict Confidence.
Who primarily decided this purchase? Male Female 18-24 25-39 40-59 60 and over
Purpose of Purchase? _______________________________________________________________________________________________
Do you own any other portable heaters? Yes No If yes, type____________________________brand_____________________
How do you intend to use your new heater? Construction Site Farm Warehouse/Commercial Garage/Outbuilding Other
How did you become aware of this heater? In-Store Display Newspaper Ad Magazine Ad Friend/Relative
TV Commercial Store Salesperson Other ___________________________
What made you select this heater? Style Size/Portability Price Package Brand Other ___________________
Do you: own rent Would you recommend this heater to a friend? Yes No
Please give us your comments:________________________________________________________________________________________
THANK YOU FOR COMPLETING THIS FORM!
Information will be held confidential.
This limited warranty is extended to the original retail purchaser of this Forced Air/Convection/Radiant Heater and warrants against any defect
in materials and workmanship for a period of one (1) year from the date of retail sale (lifetime warranty for the brass nozzle burner only). GHP
Group, Inc., at it’s option, will either provide replacement parts or replace or repair the unit, when properly returned to the retailer where
purchased or one of our service centers as directed by GHP Group, Inc., within one (1) year of retail purchase. (Shipping costs, labour costs,
etc. are the responsibility of the purchaser.)
17

WARRANTY REGISTRATION
IMPORTANT: We urge you to fill out your warranty registration card within fourteen (14)
days of date of purchase. You can also register your warranty on the internet at
www.ghpgroupinc.com. Complete the entire serial number. Retain this portion of the card
for your records.
SAVE THIS CARD!
Place
Postage
Stamp
Here
GHP Group, Inc.
8280 Austin Avenue
Morton Grove, IL 60053-3207
GHP Group, Inc.
8280 Austin Ave.
Morton Grove, IL 60053-3207
Tel: [phone]
www.ghpgroupinc.com
8280 Austin Avenue
Morton Grove , IL.
6 0 053-3207
Tel: ( 847 ) 324 - 5900
Fax: ( 847 ) 324 - 5901
Toll Free (877) GHP Group
( 8 7 7 ) 44 7 - 4 7 6 8
www.ghpgroupinc.com
GHP
GHP Group, Inc.
6440 W Howard St
Niles, IL 60714-3302
Tel: [phone]
www.ghpgroupinc.com
GHP Group, Inc.
6440 W Howard St
Niles, IL 60714-3302
