revel
Spec Features
— RockShox Dart 2 fork w/ 100mm travel
— Shimano Alivio/Deore 8-speed drivetrain w/ triple crankset, Avid disc brakes
— Giant Sport handlebar, stem & seatpost
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
frame
SIZES XS,S,M,L,XL,XXL
COLOUR Black / Green
FRAME ALUXX-grade butted aluminum
FORK RockShox Dart 2, 100mm travel
SHOCK N/A
componentS
HANDLEBAR Giant Sport low-rise 31.8mm
STEM Giant Sport
SEATPOST Giant Sport 30.9x375mm
SADDLE Giant Sport MTB
PEDALS Alloy platform
DriVetrain
SHIFTERS Shimano Alivio
FRONT DERAILLEUR Shimano Alivio
REAR DERAILLEUR Shimano Deore long cage
BRAKES Avid BB5 160mm ball-bearing disc
BRAKE LEVERS Tektro Alloy
CASSETTE SRAM PG-830 11-32T 8SPD
CHAIN KMC Z72
CRANKSET Shimano Alivio Octalink 22/32/42T
BOTTOM BRACKET Shimano Octalink
WHeeLS
RIMS Giant XC alloy double wall 32H
HUBS Formula Alloy
SPOKES Stainless Steel 14g
TIRES Kenda Small Block 8 26x2.1”
EXTRAS
Specifications and availability subject to change without notice.
Specifications
Actual
Frame Size Part
Number Head
Angle Seat
Angle* Toptube** Headtube Chainstay Wheelbase Standover
Height***
inches degrees degrees inches inches inches inches inches
XS 14 2117200 69.0 72.5 21.3 4.7 16.7 40.6 28.5
S 16 2117201 69.0 72.5 22.4 5.1 16.7 41.6 28.8
M 18 2117202 69.0 72.5 22.8 5.7 16.7 42.4 30.2
L 20 2117203 69.0 72.0 23.3 6.3 16.7 42.9 31.4
XL 22 2117204 69.0 72.0 24.3 7.1 16.7 43.5 31.9
XXL 24 2117205 69.0 72.0 25.0 7.9 16.7 44.1 32.4
frame geometry
A B C D E F G H
$
OFF-road | Lifestyle | Recreation
