Giant TCR ALLIANCE 0 User manual

on-road |performance |Competition
Experience the one-of-a-kind ride quality of Giant’s unique Alliance technology, which blends
the best characteristics of both composite and aluminum. You get amazing power transfer for the
sprints and a supple ride for long days in the saddle.
— Complete 10-speed SRAM RIVAL (black) groupset
— Lightweight Giant Connect SL handlebar and stem
— Fi’zi:k Pave CX saddle
— Lighter Mavic CXP22 wheelset
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Specifications and availability subject to change without notice.
Features
Frame TechnologySpecifications
Actual
Frame Size Part Number Head Angle Seat Angle* Toptube** Headtube Chainstay Wheelbase Standover Height***
centimeters degrees degrees centimeters centimeters centimeters centimeters inches
XS 43.0 385452 71.0 74.5 52.0 12.0 40.5 97.7 28.4
S 46.5 385453 72.0 73.5 53.5 13.5 40.5 97.4 29.2
M 50.0 385454 73.0 73.0 55.5 15.0 40.5 98.0 30.1
M/L 53.5 385455 73.0 72.5 57.0 17.0 40.5 99.2 31.1
L 55.5 385456 73.0 72.5 58.5 18.5 40.5 100.6 31.6
XL 58.5 385457 73.0 72.0 60.5 20.0 40.5 102.1 32.3
frame geometry
on-road |performance |Competition
DEVASTATINGLY QUICK FOR THE CITY-LIMIT
SPRINT. LIGHT AND AGILE FOR THE RACE TO THE
SUMMIT. A WELL-ROUNDED COMPETITOR, JUST
LIKE YOU.
TCR
ALLIANCE 0
FRAME
SIZES XS,S,M,M/L,L,XL
COLORS Composite/Red
FRAME Alliance Composite/Aluminum
Technology
FORK Advanced-Grade Composite, Alloy
OverDrive Steerer
SHOCK N / A
COMPONENTS
HANDLEBAR Giant Connect SL, 31.8
STEM Giant Connect SL
SEATPOST Giant Connect SL Composite, 30.9
SADDLE Fi'zi:k Pave CX w/ Manganese rails
PEDALS Not Included
DRIVETRAIN
SHIFTERS SRAM Rival
FRONT DERAILLEUR SRAM Rival
REAR DERAILLEUR SRAM Rival
BRAKES SRAM Rival
BRAKE LEVERS SRAM Rival
CASSETTE SRAM Force 1070 12x25, 10 Speed
CHAIN SRAM PC 1050
CRANKSET SRAM Rival, 39/53
BOTTOM BRACKET SRAM GXP, External
WHEELS
RIMS Mavic CXP22, Custom Color
HUBS Formula sealed Cartridge Bearing
24/28h
SPOKES SAPIM Race, 14/15g
TIRES Michelin Lithion 2, 700x23 Folding
EXTRAS
