Gigabyte Aivia Uranium User manual

Contents
Introduction
Package Content & Support
Installation
Mouse Instructions
GHOST Macro Station
GHOST Macro Engine
Battery & Charging
Safety
Maintenance
Users’ manual in other languages can be downloaded from GIGABYTE’s o󰘲cial website.
Please visit www.gigabyte.com for more product information.
02
02
03
06
08
11
22
23
24

2 Aivia Uranium
Introduction
The Aivia Uranium wireless gaming mouse equipped with revolutionary
GHOST Macro Station which allows dynamic mouse status update and
prompt assignment for mouse buttons. Introducing GIGABYTE’s patent
pending technology, built-in memory into the receiver ensures your gaming
commands are executed directly from the receiver and free from any risk of
signal loss or delay.
With 6500dpi, 1000Hz polling rate, and amazing 50hrs continuous gaming
capability, Aivia Uranium performs as well cordless as it does corded, giving
you an unparalleled freedom of frenzy motion on the battlefield.
Support
Register your Aivia Uranium on the Aivia Forum www.aivia.gigabyte.com for
free online technical support.
Package Contents
• Aivia Uranium Wireless Gaming Mouse
• GHOST Macro Station (OLED receiver)
• 2*AA NiMH 2100mAh Rechargeable Battery
• Spare Teon Mouse Feet Pads
• Cleaning Cloth
• Users’ Guide

Aivia Uranium 3
Installation
Connect the GHOST Macro Station
OS support: Windows® 98/ 2000/ XP/ 7/ 8
Insert AA Rechargeable Batteries
We’ve included 2 rechargeable NiMH batteries, but it will also run on normal
AA alkaline batteries.
1
2

4 Aivia Uranium
Install Aivia GHOST Engine
Download the Aivia GHOST software from GIGABYTE's of cial website
for further macro recording.
Instant Power Charging
Pull out the charging cable for instant power supply.
You can use the mouse while charging.
3
4

Aivia Uranium 5
Install Aivia GHOST Engine Synchronize Mouse and Receiver
The re-pairing process is needed only when the mouse loses connection
with the receiver.
5

6 Aivia Uranium
Mouse Instructions
– Left Click
– Right Click
– Scroll Click and 4-direction Wheel
– On-the- y DPI Adjustment
– Wheel Controller Lock
– Pro le Switch
– Gaming Button (unassigned)
– Gaming Button (unassigned)
– Gaming Button (forward)
– Gaming Button (backward)
– Power & Wheel Indicator
Switch On
Low Power Blinking red light
Live-editing
Mode
Blue LED continuously
lit up till unlocked
(refer to page08 GHOST
Macro Station)
Blue LED lit up for 5sec
Power & Wheel Indicator

Aivia Uranium 7
– Micro USB Connector Jack
– Twin-eye Laser Sensor
– Pairing Button (Connect)
– Power ON/OFF
– AA Battery Slot
– Screen Brightness Adjustment
– OLED Display
– 5-color Pro le Indicator
– Retractable Micro USB Charging Cable
– Built-in GHOST Macro Engine

8 Aivia Uranium
GHOST macro station is your control center built for your gaming task,
features dynamic status display, hot-switchable macro system and instant
charging dock.
Dynamic Display Mode
Dynamic update and display DPI value, report rate, gaming profiles, and
remaining battery life of your Aivia Uranium.
Live Editing Mode
Prompt re-assign macro hotkeys and set-up DPI value directly through
GHOST station.
Switch on the “wheel controller lock” to use the mouse wheel like a D-pad
controller for OLED on-screen settings.
GHOST Macro Station
Aivia Uranium
Tilt right to enter
Tilt left to go back
Scroll up and down to select items
Press down on wheel to con rm changes

Aivia Uranium 9
GHOST Macro Station
Profile
Select one of the profiles you
wish to program
Select a mouse button you
wish to program
1
4
2
3
3
Select the function category:
Basic/Key Mapping/Macro
(refer to page13)
Choose the function and
press scroll click to confirm
setting

10 Aivia Uranium
Scroll backward and for ward
the wheel to adjust DPI value
for both X and Y axle.
Press scroll click to save
the change
Scroll backward and forward
the wheel to adjust how fast
the reports
(125/142/166/200/250/333/
500/1000Hz selectable)
Press scroll click to save
the change
11
2
DPI Value
Select the DPI stage you wish
to define
Report Rate

Aivia Uranium 11
GHOST Macro Engine
GHOST Macro Engine supports Windows 98, Windows 2000, Windows XP,
Windows 7, and Windows 8.
MAIN PAGE
The main page is the home page when you first install GHOST Macro Engine.
More than one model may appear when you install other Aivia products.
1. Choose the Aivia model you wish to set up.
2. Click “PROFILES” to set up button assignments for the particular model.
3. Click “SETTINGS” to set up performance, lighting, and manage pro les.
You may also link to or for more product information.
You may also link to or for more product information.
You may also link to or for more product information.

12 Aivia Uranium
PROFILES
In the PROFILES tab, there are 5 pro les which appear as 5 LED bars
underneath PROFILE to program for your speci c games.
A single LED bar indicates the current profile you are accessing. For each
profile, you can assign either BASIC functions or advanced MACROS to
particular buttons. Click on any mouse button you wish to set up, you will then
enter into the function menu.
( T h e r e a r e a l s o h i d d e n b u t t o n s b y c l i c k i n g t h e d o w n w a r d a r r o w h e a d -
is to reset all settings for the current profile back to default;
is to reset all 5 pro les back to factory default.)
is to reset all settings for the current profile back to default;
is to reset all settings for the current profile back to default;
is to reset all 5 pro les back to factory default.)
is to reset all settings for the current profile back to default;

Aivia Uranium 13
KEY MAPPING
BASIC
1. Select any button function you wish to change, and click or
double-click to save the changes
2. or click to ignore the change and go back to
previous page
3. or click to return the default setting.
1. Select any button function you wish to change, and click or
double-click to save the changes
2. or click to ignore the change and go back to
previous page
3. or click to return the default setting.
KEY MAPPING
You may simply maps a mouse button to a specific key on the keyboard,
includes A~Z, num1~0, F1~F12

14 Aivia Uranium
MACROS
Macro depot is where you can pre-record a series of keystrokes and button
presses with precise time interval for gaming commands. Here you have 70
blank macro cartridges. Pre-de ne the macro scripts and then assign to any
mouse buttons.
Select any empty macro and click , and you will then enter into
the macro depot.
Select any empty macro and click , and you will then enter into

Aivia Uranium 15
How to record a macro script?
1. Understanding your Tool Box
Enable to stop
Disable to stop
Chose your recording objects
Enable to stop
Disable to stop
Enable / Disable Pause Key to stop recording
Record both keystrokes and mouse
button press.
Record keystrokes, mouse button press
and also cursor’s coordinates.
Only record keystrokes but ignore
mouse button press.
Only record mouse button press
but ignore keystrokes.
Record mouse button press and also
cursor’s coordinates.

16 Aivia Uranium
Time delay (interval)
Action mode
Do NOT record any time delay in-between
commands.
Record the real delay in-between as how it
is entered.
Key-in the time interval as a fixed
time delay.
Execute a macro once as press the
mouse button once.
Execute a macro continuously, and press
again to stop the running macro.
Execute a macro continuously until you
release the assigned button.

Aivia Uranium 17
Type on (the blue box) to rename this
macro. Moreover, you may also change icon of your
personal macro by clicking on
Click to save the editing of this macro.
Click to end recording
2. Now begin to record a macro
3. More:
You may the macros you’d edited to the PC, and also
a macro back to GHOST macro engine.
Click to end recording
Type on (the blue box) to rename this
You may the macros you’d edited to the PC, and also
a macro back to GHOST macro engine.
Click to save the editing of this macro.
Modify your tool box buttons to set up your recording
preference.
Click and start keying in keystrokes or button
presses.
You may also insert additional commands from the
“Quick-insert bar” the left menu.

18 Aivia Uranium
MANAGE PROFILES
SENSITIVITY
WHEEL SETTINGS
REPORT RATE
You may either disable or enable a whole profile and also
change the color of the profile indicator in this page.
Sensitivity is how fast the mouse cursor travels across
the screen.You can create 4 preferred sensitivity stages
by moving the single adjusting slider, and click to set
different sensitivity value of X-Y axis independently.
Default: 800 / 1600 / 3200 / 5600 DPI.
You can adjust the scrolling and tilt speed by moving the
knob on the slider.
The report rate determines the time intervals that your
PC retrieves data from your mouse. You can switch
between to 125Hz, 142Hz, 166Hz, 200Hz, 250Hz, 333Hz,
500Hz, or 1000Hz on the slider.
Default setting: 500Hz
SETTINGS

Aivia Uranium 19
SCREEN SAVER
The OLED screen will shows screen saver logo when the
mouse stop working for 10mins. Except the default logo,
you can customize the other display logo as a screen
saver for your GHOST Macro Station.
You may directly import a photo (bmp format only) from PC or manually draw
on the bitmap.

20 Aivia Uranium
COOLING TIMER
The cooling timer allows you to release a specific
command again in the game which would limit the
command execution interval. There are three timers for
pre-setup.
Select a mouse button which you would use for a gaming command
Input the cooling time interval
Type on the reminder script for this timer to remind yourself
Select the show-up effect: Highlight/ Blinking
Click Enable/ Disable to activate the timer
1
1
2
2
3
3
4
4
5
5
Note!
The cooling timer is effective only when running Aivia GHOST. Exiting the
Aivia GHOST software will automatically close the timer function.
