Gigaset C285 User manual

C285
GIGASET. INSPIRING CONVERSATION.*
*GIGASET. Pour des conversations inspirées.

3
The handset at a glance
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / kombi_overview.fm / 7/14/11
Version 4, 16.09.2005
The handset at a glance 1Display in idle status
2Charge status of the batteries (page 4)
3Display keys (page 16)
4Control key
tAccess to Calls list.
sAccess to directory.
5Line keys
Answer an incoming call for Line 1/Line 2.
Make a call from Line 1/Line 2.
Start a second call from Line 2 while telephon-
ing from Line 1(page 27).
6End Call key, On/Off key
End call, cancel function, return to idle status,
activate/deactivate handset (press and hold in
idle status).
72.5-mm socket (mono) for headset
8Pound (#) key
Enter # symbol.
Keypad lock on/off (press and hold in idle sta-
tus).
Switch between uppercase and lowercase let-
ters for text entry.
9Redial/Pause key
Open redial list (in idle status) or insert a dial-
ing pause (when editing a number).
10 Microphone
11 Intercom/Hold/Conference key
Set up an internal call (page 28).
Switch between an external call and internal
party (handset/base station, page 29), or
transfer a call during an external call (page 28).
Set up a conference call between an external
line and an internal party (handset/base sta-
tion, page 29). Press and hold the key in hold-
intercom mode.
12 Star (*) key
Ring tone on/off (press and hold).
Switch temporarily to tone dialing (DTMF).
13 Handsfree key
Answer or place a call in speaker mode.
Switch between speaker on and speaker off (in
off-the-hook mode).
14 Talk/Flash key
Answer or start a call.
Key flashes: incoming call.
Add a flash (in the directory).
Send FLASH (when off the hook).
15 Reception indicator (page 4)
Note:
Pictures in this user manual may differ from the
actual product.
Äe
INT 1
31.01. 9:45
1
2
3
4
5
6
7
8
911
13
14
15
10
12
§§§§Menu§

4
The handset at a glance
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / kombi_overview.fm / 7/14/11
Version 4, 16.09.2005
Overview of handset’s display icons
How to change the display language, see
"Example: menu input" on page 10 or
"Changing the display language" on
page 31.
ÄReception indicator
Handset is linked with the base station.
Flashes: the handset is out of range or not
registered
ÓCalls list icon
Entries stored in the Calls list.
Flashes: New missed calls in the Calls list
eCharge status of the batteries
= e U (empty to full)
=flashes: batteries almost empty
= U flashes: batteries charging
îVoice mail envelope
At least one new message on voice
mailbox
Ê
Ë
Is shown when the respective line is off the
hook, in external talk mode, in use mode or
on hold.
Is displayed in the Calls lists to show the
line on which the call came in.
ÇHandsfree icon
Handsfree mode activated
ÅRinger off icon
Ring tone volume of handset is turned off
ÆOff-Hook
Outgoing call initiated or during a call.
Flashes: indicates incoming call, L1CALL /
L2CALL in the display header shows the line
of the incoming call
Õ
Õ
Õ
Answering machine icon
Answering machine is switched on for
either Line 1 or for Line 2 or for both lines.
Flashes: answering machine is recording
or is being operated by another handset
or there are new messages on the
answering machine
Ê
Ë
Ê
Ë

5
The base station at a glance
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / kombi_overview.fm / 7/14/11
Version 4, 16.09.2005
The base station at a glance
1Numeric key pad
2Controlkey
tAccess to Calls list.
sAccess to directory.
3Display keys (page 16)
4Display in idle status
5AnsweringmachineOn/Offkey
Activate/deactivate answering machine.
6Volumekeys
– In idle mode: change the ring tone volume
of the base station.
– During message playback: change the vol-
ume of playback.
– During call: change the volume of the loud-
speaker.
– During call screening: change the volume
of call screening.
7Erasekey
Erase the current message during playback.
Erase all old messages (press and hold in idle
mode).
8 Start/Stop key with integrated LED for Line
1/Line 2
Start/stop playback.
LED status indicator:
–Isonwhenplaying messages on the
respective line.
– Flashes slowly when there is at least one
new message on the answering machine
for the respective line.
– Flashes rapidly when the message memory
for the respective line is full.
9Redial/Pause key
Open redial list (in idle status) or insert a dial-
ing pause (when editing a number).
10 Page key
Page handsets (press briefly).
Start the registration procedure (press and
hold in idle mode). You will hear a beep.
1
2
3
5
6
8
9
10
11
12
14
15
4
7
13
ÊÕÉ×ÅËÕÉ×Å
SUN 09:23 31.01.
§§§§§§§§§Menu§§§§§§§§§
Ê,Ë– Flashes when the respective line is
receiving an incoming call.
– Is on when the respective line is
– Off the hook
– In external talk mode
– On hold or in use mode
– Is displayed in the Calls list to show
the line on which the call came in.
ÕThe answering machine is on.
ÉFlashes when the answering
machine’s message memory is full.
×Flashes when the answering machine
is controlled by a handset.
ÅIs on when the ring tone volume of
the base station is set to zero
(see page 31).

6
The base station at a glance
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / kombi_overview.fm / 7/14/11
Version 4, 16.09.2005
11 Mute key
Mute/unmute microphone.
12 Intercom/Hold/Conference key
Set up an internal call.
Switch between an external call and internal
party (handset/base station), or transfer a call
during an external call.
Set up a conference call between an external
line and an internal party (handset/base sta-
tion). Press and hold the key in hold-intercom
mode.
13 Line keys
Answer an incoming call for Line 1/Line 2.
Make a call from Line 1/Line 2.
Start a second call from Line 2 while telephon-
ing from Line 1 (see page 27).
LED status indicator:
– Flashes rapidly when the respective line is
receiving an incoming call.
– Flashes slowly when a handset is off the
hook on the respective line.
– Flashes very slowly when the respective
line is on hold on the base station.
– Is on when the base station is in talk mode.
14 End Call key
End call, cancel function, return to idle status.
15 Talk/Flash key
Answer or start a call.
Add a flash (in the directory)
Send FLASH (when off the hook).
Please remember:
uIf the answering machine is being oper-
ated from a handset, or if it is recording a
message, you cannot operate it from the
base station.
uIf the start/stop key flashes although the
answering machine is switched off, it
means that there is still at least one new
message that has not been played back.

7
Contents
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / C285_en_IVZ.fm / 7/14/11
Version 4, 16.09.2005
Contents
The handset at a glance . . . . . . . . . . . . 3
Overview of handset’s display icons . . . . . 4
The base station at a glance . . . . . . . . 5
Safety precautions . . . . . . . . . . . . . . . . 8
Notes on the operating
instructions . . . . . . . . . . . . . . . . . . . . . 10
Symbols used . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Example: menu input . . . . . . . . . . . . . . . . . . 10
Gigaset C285 – more than just a
telephone . . . . . . . . . . . . . . . . . . . . . . . 11
First Steps . . . . . . . . . . . . . . . . . . . . . . 11
Package contents . . . . . . . . . . . . . . . . . . . . . . 11
Installing the base station . . . . . . . . . . . . . . 11
Setting up the handset for use . . . . . . . . . 12
Making calls . . . . . . . . . . . . . . . . . . . . . 14
Making an external call . . . . . . . . . . . . . . . . . 14
Ending a call . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Answering a call . . . . . . . . . . . . . . . . . . . . . . . 14
Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Handsfree operation . . . . . . . . . . . . . . . . . . . 15
Operating the telephone . . . . . . . . . 16
Control key . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Display keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Returning to idle status . . . . . . . . . . . . . . . . 17
Menu guidance . . . . . . . . . . . . . . . . . . . . . . . . 17
Writing, editing, and
correcting entries . . . . . . . . . . . . . . . . . . . . . . 17
Using the directory
and lists . . . . . . . . . . . . . . . . . . . . . . . . . 18
Directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Last number redial list . . . . . . . . . . . . . . . . . . 19
Calls list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Operating the answering
machine . . . . . . . . . . . . . . . . . . . . . . . . . 20
Operation using the base
station keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Operation using the handset . . . . . . . . . . . 21
Setting up the answering machine . . . . . 24
Operating when on the move (remote
operation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Using the voice mailbox . . . . . . . . . . 26
Configuring the voice
mailbox for fast access . . . . . . . . . . . . . . . . . . 26
Using several handsets . . . . . . . . . . . 27
Registering and
de-registering handsets . . . . . . . . . . . . . . . . 27
Locating a handset ("paging") . . . . . . . . . . 28
Changing the base station . . . . . . . . . . . . . . 28
Making internal calls . . . . . . . . . . . . . . . . . . . 28
Accepting/rejecting call waiting . . . . . . . . 29
Linking internal callers to an
external call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Making two external calls
simultaneously . . . . . . . . . . . . . . . . . . . . . . . . . 30
Handset settings . . . . . . . . . . . . . . . . . 31
Changing the name of a handset . . . . . . . 31
Changing the display language . . . . . . . . . 31
Setting the display contrast . . . . . . . . . . . . . 31
Activating/deactivating auto answer . . . . 31
Adjusting the loudspeaker
and earpiece volume . . . . . . . . . . . . . . . . . . . 31
Changing ring tones . . . . . . . . . . . . . . . . . . . 31
Activating/deactivating the
key-touch tone . . . . . . . . . . . . . . . . . . . . . . . . . 32
Base station settings . . . . . . . . . . . . . . 32
System settings . . . . . . . . . . . . . . . . . . 33
Restoring the default settings . . . . . 33
Appendix . . . . . . . . . . . . . . . . . . . . . . . . 34
Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Contact with liquid . . . . . . . . . . . . . . . . . . . . 34
Questions and answers . . . . . . . . . . . . . . . . . 34
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Authorisation . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Customer Service & Assistance . . . . . . . . . . 36
Manufacturer warranty
(Middle East) . . . . . . . . . . . . . . . . . . . . . 38
Service Centres (Midde East) . . . . . . . . . . . . 40
Menu of the handset . . . . . . . . . . . . . 42
Menu of the base station . . . . . . . . . . 44
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

8
Safety precautions
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / security.fm / 7/14/11
Version 4, 16.09.2005
Safety precautions
Warning
Be sure to read this user guide and the safety precautions in detail before using your tele-
phone. Explain their content and the potential hazards associated with using the telephone
to your children.
Use only the power adapter supplied, as indicated on the underside of the base.
Use only rechargeable batteries that correspond to the specification provided
(see page 35), as this could otherwise result in significant health risks and personal
injury. Do not charge the handset in the charger or base while the headset is con-
nected.
Using your telephone may affect nearby medical equipment. Be aware of the tech-
nical conditions in your particular environment e.g., doctor's surgery.
Do not hold the rear of the handset to your ear when it is ringing or when handsfree
mode is activated. This may cause serious and permanent damage to your hearing.
Your Gigaset is compatible with the majority of digital hearing aids on the market.
However, perfect function with all hearing aids cannot be guaranteed.
The handset may cause interference in analogue hearing aids. If you require assis-
tance, please contact the hearing aid supplier.
Do not install the base or charger in bathrooms or shower rooms. The base and
charger are not splashproof.
Do not use your phone in environments with a potential explosion hazard (e.g., paint
shops).
If you give your phone to a third party, make sure you also give them the user guide.
Remove faulty bases from use or have them repaired by our Service, as these could
interfere with other wireless services.
!
$
ƒ

9
Safety precautions
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / security.fm / 7/14/11
Version 4, 16.09.2005
Batteries should not be disposed of in general household waste. Observe the local
waste disposal regulations, details of which can be obtained from your local author-
ity.
All electrical and electronic products should be disposed of separately from the
municipal waste stream via designated collection facilities appointed by the govern-
ment or the local authorities.
This crossed-out wheeled bin symbol on the product means the product is covered
by the European Directive 2002/96/EC.
The correct disposal and separate collection of your old appliance will help prevent
potential negative consequences for the environment and human health. It is a pre-
condition for reuse and recycling of used electrical and electronic equipment.
For more detailed information about disposal of your old appliance, please contact
your local council refuse centre or the original supplier of the product.
Please note
uNot all of the functions described in this user guide are available in all countries.
uThe device cannot be used in the event of a power failure. It is also not possible to trans-
mit emergency calls.
uEmergency numbers cannot be dialed if the keypad lock is activated!

10
Notes on the operating instructions
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / notes-on-instructions.fm / 7/14/11
Version 4, 16.09.2005
Notes on the operating
instructions
This section explains the meaning of certain
symbols and typographical conventions
used in this user guide.
Symbols used
On / Off (example)
Select one of the two menu
functions specified.
~Enter digits or letters.
§Back§ The display keys' current func-
tions are shown in reverse and
are highlighted in the lower dis-
play line. Press the display key
below to launch the function.
qPress the top or the bottom of
the control key: scroll up or
down.
c/ Q/ *etc.
Press the corresponding key of
the handset.
Example: menu input
In the user guide, the steps you need to per-
form are shown in abbreviated form. This is
illustrated below using "Changing the dis-
play language" as an example.
What you need to do is explained in the box.
§Menu§ ¢Settings ¢Handset
¢Language ¢Italian / Français /
English
¤With the handset in idle status, press the
right display key to open the main menu.
¤Select Settings using the control key q
– press the control key at the top or bot-
tom.
¤Press the §OK§ display key to confirm the
function Settings.
The Settings submenu is displayed.
¤Press the bottom of the control key s
repeatedly until Handset is selected.
¤Press the §OK§ display key to confirm the
function.
The Handset submenu is displayed.
¤Press the bottom of the control key s
repeatedly until Language is selected.
¤Press the §OK§ display key to confirm the
function.
The Language submenu is displayed.
¤Select the language you want using the
control key q– press the control key at
the top or bottom.
¤Press the §OK§ display key to confirm the
selected language.
The language is now changed for all text.

11
Gigaset C285 – more than just a telephone
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / starting.fm / 7/14/11
Version 4, 16.09.2005
Gigaset C285 – more than
just a telephone
Your phone not only lets you store up to 250
phone numbers (page 18), it can do a whole
lot more:
uPhone directly using the base station:
Your base station has the same keys as
your handset. So nearly all functions you
usually use on the handset are also avai-
lable directly on the base station.
uUse two telephone lines with only one
telephone.
uMake conference calls with two external
parties (page 30).
uView missed calls on your phone
(page 19).
uECO DECT uses a power supply with low
power consumption. Your handset
reduces the transmission power depend-
ing on its distance from the base station
(close-up range).
Headset socket
Which headsets are compatible?
0845 367 0812 (local call cost charge)
or contact us at
www.gigaset.com/customercare for infor-
mation.
Have fun using your new phone!
First Steps
Package contents
uOne base station Gigaset C285
uTwo telephone line cords
uOne AC adapter for the base station (with
yellow marked plug)
uOne User Guide
uOne Gigaset C28H handsets with battery
cover
uTwo batteries
uOne belt clip
Included with each additional handset:
uOne Gigaset C28H handset with battery
cover
uOne Gigaset charging cradle
uOne AC adapter for the charging cradle
(with black marked plug)
uTwo batteries
uOne belt clip
Installing the base station
The base station is designed for use in dry
rooms in a temperature range of +5°C to
+45°C.
Set the base station at a central point in the
building.
Please note:
uNever expose the phone to heat sources,
direct sunlight, or other electrical appli-
ances.
uProtect your phone from moisture, dust,
corrosive liquids, and vapors.
Note:
The transmission power of the base station is
lowered to its minimum level when the handset
is placed in the base station and only one hand-
set is registered on the base station.
Caution:
Do not charge the handset in the charging cradle
or base station while the headset is connected.

12
First Steps
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / starting.fm / 7/14/11
Version 4, 16.09.2005
Range and reception indicator
Range:
uUp to 300 m outdoors
uUp to 50 m indoors
Reception indicator:
The display shows if the handset is linked to
the base station:
uÄis on: handset is linked to the base sta-
tion.
uÄflashes: no reception; handset is out of
range or not registered.
Connecting the base station
¤First connect the yellow marked plug pin
to the base station's socket (yellow
marked) and then the AC adapter to the
AC outlet (see below).
¤Afterwards connect the phone jacks as
shown below.
1 230 V power adapter
2Backofthebasestation
3 Phone jacks with telephone line cords
To connect your base station with the phone
jack: For each line use either the telephone line
cord or telephone line cord with adapter
which fits into your telephone jack.
Please note
uThe power adapter must always be con-
nected, as the phone will not operate
without an electrical supply.
uYour answering machine is set to give a
standard announcement.
Setting up the handset for
use
All supplied handsets are already registered
to the base station by factory settings.
Carry out the following steps for each hand-
set.
Inserting the batteries
¤Open the battery cover.
¤Insert the batteries according to the cor-
rect polarity (see diagram).
The polarity is indicated in/on the battery
compartment.
¤Close the cover, and press the top so that
it clicks into place.
1
2
3
TEL LINE 1
TEL LINE 2
Caution:
Use only rechargeable Nickel-metal hydride
(NiMH) AAA batteries. Never use a conventional
(non-rechargeable) battery or other battery
types as this could result in significant health
risks and personal injury. For example, the batter-
ies could explode. The phone could also malfunc-
tion or be damaged as a result of using batteries
that are not of the recommended type.
Note:
If attached, remove the belt clip before opening
the battery cover.

13
First Steps
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / starting.fm / 7/14/11
Version 4, 16.09.2005
Attaching the belt clip
There are notches on the sides of the hand-
set for attaching the belt clip, nearly at the
same height as the handset earpiece.
¤Press the belt clip onto the back of the
handset so that the protrusions on the
belt clip engage the notches.
For multiple handsets:
Connecting charger
¤First connect the black marked plug pin
to the charger's socket (black marked)
and then the AC adapter to the AC outlet.
Placing the handset in the base
station
¤Place the handset in the base station or
charger with the handset's display facing
outwards.
Charging the batteries for the first
time
¤To charge the batteries, leave the handset
in the base station or charging cradle
continuously for ten hours.
The alternately flashing battery icons =U
on the upper right side of the display screen
indicate that the batteries are being
charged.
For questions and troubleshooting,
seepage34.
Setting the date and time
You should set the date and time, for exam-
ple, to ensure the correct time of incoming
calls is recorded.
Time and date can be set on the handset or
on the base station.
To change the time and date, open the input
field using:
§Menu§ ¢s¢Settings ¢Date/Time
¢Set Date/Time
~Enter the time and date using 10
digits, for example, Q M
1 5 1 5Q 1
1Q for January 15, 2010,
07:15.
To correct an incorrect entry,
overwrite the character by typ-
ing the correct one.
§OK§ Press the display key to save
changes.
You can change the date and time format:
§Menu§ ¢s¢Settings ¢Date/Time
¢Set Format
¤Choose between 12- and 24-hour time
formats:
s¢Time Format ¢12 Hours / 24 Hours
¤Choose between day/month and month/
day date formats:
s¢Date Format ¢DD.MM or MM.DD
Note:
– If the handset has turned itself off because its
batteries are empty, and you then place the
handset into the base station, it will turn on
automatically.
– Only place the handset into the base station
or charging cradle specifically intended for it.
– During handset operation, the battery icon
eindicates the charge status of the batter-
ies (page 3).
– The batteries may feel warm when they are
charging. This is not dangerous.
Note:
Date and time settings apply to base station and
all registered handsets.
Date and time format settings apply only to your
own handset or to the base station. You must set
date and time format at each device separately.

14
Making calls
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / starting.fm / 7/14/11
Version 4, 16.09.2005
Selecting the line settings
For each handset and the base station, you
can set how your telephone will use the two
telephone lines:
Auto All incoming calls will ring. For
outgoing calls, your phone will
use whichever line is currently
free.
Line 1 / Line 2
For incoming and outgoing
calls, your phone will always use
the selected line.
If you have selected Line 1 or Line 2, you can
still answer or make a call on the free line by
using the Cor hkeys.
Selecting line settings for a handset
On the handset:
§Menu§ ¢s¢Settings ¢Handset
¢Line Setting
Auto / Line 1 / Line 2
Select entry and press §OK§.
Selecting line settings for the base
station
On the base station:
§Menu§ ¢s¢Settings ¢Base
¢Line Setting
Auto / Line 1 / Line 2
Select entry and press §OK§.
Display in idle status
Once the phone is registered and the time
set, the idle display looks as shown here
(example). The symbol Õshown in the dis-
play’s header indicates that the answering
machine is turned on.
Your phone is now ready to use.
Making calls
Making an external call
External calls are calls using the outside tele-
phone network.
~c Enter the number and press the
Talk key c or Handsfree key
d.
Or:
c~ Briefly press the Talk key cor
Handsfree key d, and then
enter the number.
To cancel the dialing operation, press the
End Call key a.
Depending on the line settings of the used
handset/base station (see page 14), the tele-
phone selects the line. You can use the line
keys Cor hinstead of the cor d
key to select the line for this call.
You are shown the duration of the call while
the call is in progress.
Ending a call
aPress the End Call key.
Answering a call
The handset indicates an incoming call in
three ways: by ringing, by a display on the
screen, and by the flashing Talk key c.
The base station indicates an incoming call
in three ways: by ringing, by a display on the
screen, and by the flashing line key Cor
h.
ÄÕ e
INT 1
31.01. 9:45
§§§§Menu§§§§
Ê
Ë
Note:
Dialing using the directory (page 18) or Calls list
(page 19) saves time re-entering numbers.

15
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / telefony.fm / 7/14/11
Version 4, 16.09.2005
You can accept the call by:
¤Pressing the Talk key c.
¤Pressing the line key Cor h.
¤Pressing the Handsfree key d.
Depending on the line settings of the used
handset/base station (see page 14), the tele-
phone reacts differently:
uIf you have selected Auto, you can use
the Talk key c or Handsfree key d
for calls on both lines.
uIf you have selected Line 1 or Line 2, you
can only answer calls on the selected line
with the Talk key c or Handsfree key
d. For calls on the other line, you must
use the Ckey or hkey to answer the
call.
If the handset is in the base station or
charger and the Auto Answer function is
activated (page 31), the call will be answered
automatically when you lift the handset
from the base station or charger. Lifting the
handset from the base station or charger in
this case has the same effect as pressing the
Talk key c.
You can press the §Quiet§ display key to mute
the ring tone of your handset without
answering the call. The other registered
handsets and the base station keep ringing.
You can answer the call as long the call is dis-
played on the screen.
Caller ID
Caller ID (CID) is an optional subscription ser-
vice provided by your telephone service pro-
vider. This feature supplies incoming caller
identification information that will be dis-
played on your handset and the base sta-
tion.
Call display with Caller ID/Name
If the number of the caller is stored with a
name in the directory, on the display you will
see both number and name.
Depending on the information that Gigaset
C285 receives from the network of your pro-
vider it is also possible that the phone num-
ber is shown twice on the display (on both
lines), if the name is not available (for exam-
ple in the phone book).
This behaviour changes depending on the
network provider.
The following is displayed in place of the
number:
uExternal Call, if no number is transmitted,
or the caller has not subscribed to Caller
ID.
uWithheld, if the caller has withheld Caller
ID.
Handsfree operation
You can activate the speakerphone at any
time to provide handsfree operation during
a call.
Activating/deactivating handsfree
Activating while dialing
~d Enter the number and press the
Handsfree key.
¤You should inform your caller before you
use the handsfree function so that the
caller knows someone else may be listen-
ing.
Switching between the earpiece and
the handsfree mode
dPress the Handsfree key.
During a call and when listening to the
answering machine, turn handsfree on or
off.
For how to adjust the volume, see page 31.
Note:
If two calls are ringing simultaneously on the two
lines, your telephone display will switch from one
line to the other every 3 seconds.
¥Use the Ckey or hkey to answer the
call.

16
Operating the telephone
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / telefony.fm / 7/14/11
Version 4, 16.09.2005
Operating the telephone
Most of the keys are the same on the hand-
set and on the base station, so that, with few
exceptions, you can operate the base station
the same way as the handset.
Activating/deactivating the
handset
aPress and hold the End Call key
to turn the handset on/off.
Activating/deactivating the
keypad lock of the handset
#Press and hold the pound key.
Keypad Locked appears in the display when
the keypad lock is activated.
The keypad lock is deactivated automati-
cally if someone calls you. It is re-activated
when the call is finished.
Control key
In the description below, the top or bottom
of the Control key (up, down), which you
must press depending on the operating
situation, is marked in black, for example, t
for "press up on the Control key".
The Control key has different functions:
When the handset is in idle status
sOpen the directory
tOpen Calls list (page 19)
In input fields
You can use the Control key to move the cur-
sor backwards tor sforwards.
In the main menu, lists and submenus
t/ sScroll up/down line by line.
At the bottom/top of a menu or a list:
A feedback tone signals that the menu/list
has wrapped around automatically (the first/
last entry is selected in the display).
When the handset is off the hook or
when the answering machine is
playing
t/ sIncrease/decrease volume
Display keys
The function of the display keys changes
depending on the particular operating situ-
ation. Example:
1 The display keys' current functions are shown
on the bottom display line.
2Displaykeys
The most important display symbols are:
§§§§§Menu§§§§ Open the main menu (in idle
mode) or the context-depen-
dent menu.
§§§§§Back§§§§ Go back one menu level.
§§§§§§§OK§§§§§§§ Confirm your choice or save
edited characters.
§§§§Clear§§§§§ Clear key: deletes one character
at a time from right to left (press
briefly), or deletes all characters
(hold).
Control key
§§§§§Back§§§§§ U§§§§Menu§§§§§ 1
2

17
Operating the telephone
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / telefony.fm / 7/14/11
Version 4, 16.09.2005
Returning to idle status
You can return to idle status from anywhere
in the menu as follows:
¤Press the End Call key a.
Or:
¤Do not press any key: after 2 minutes, the
display will automatically return to idle
status.
Changes that you have not confirmed or
saved by pressing §OK§ will not be saved.
An example of the display in idle status is
shown on page 14.
Menu guidance
Your phone's functions are accessed using a
menu that has a number of levels.
Main menu (first menu level)
¤Press the display key §Menu§ with the hand-
set in idle status to open the main menu.
The main menu functions are shown on the
screen in a list.
To access a function, open the correspond-
ing submenu (next menu level):
¤Navigate to the function using the con-
trol key q. Pressing the display key §OK§.
Submenus
The functions in the submenus are displayed
as lists.
To access a function:
¤Scroll to the function with the control key
qand press §OK§.
Pressing the §Back§ display key returns you to
the previous menu level. acancels the
operation.
Writing, editing, and
correcting entries
Correcting incorrect entries
You can correct incorrect characters in the
text by navigating to the incorrect entry
using the control key. You can then:
uPress §§§§Clear§§§§§ to delete the character to
the left of the cursor.
uInsert characters by typing.
Entering and editing names
The following rules apply when creating an
entry:
uControl the cursor with q.
uPress the pound key #to switch
between uppercase and lowercase.
Entering special characters
You can enter special characters using the
Qor 1key.
Q.0,/:;"’!?*+-%\^~|
1SPACE1@_#=<>
()&$[]{}

18
Using the directory and lists
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / direct_charges.fm / 7/14/11
Version 4, 16.09.2005
Using the directory
and lists
The options are:
uDirectory
uLast Number Redial list
uCalls list
You can store a maximum of 250 entries in
the directory. Each entry must consist of a
name and a number.
The directory is stored in the base station
and is shared by all registered handsets.
Directory
In the directory, you can store phone num-
bers and the names associated with them.
¤With the handset in idle status, open the
directory by pressing the skey.
Length of entries
Number: max. 24 digits
Name: max. 16 characters
Saving a number in the directory
Quickly storing a number starting
from the idle status
The handset is in the idle status:
~Enter the number and press
§Save§.
~Enter the name and press §OK§.
~Correct the number, if neces-
sary, and press §OK§.
Storing a number starting from the
directory
s¢§Menu§ ¢New Entry
~Enter the name and press §OK§.
~Enter the number and press §OK§.
You can use the Clear key to delete one char-
acter at a time from right to left (press
briefly) or all characters (press and hold).
Entering and editing names
The following rules apply when creating an
entry:
uTo enter a letter press the corresponding
numeric key as often as necessary.
uUse tsto move the cursor to the left or
right.
uCharacters are inserted after the cursor.
uPress the pound key #, before entering
the letter, to switch between uppercase
and lowercase.
Entering special characters see page 17.
Selecting a directory entry
sOpen the directory.
You have the following options:
uUse qto scroll to the entry until the
desired name is selected.
uEnter the first character of the name, or
scroll to the entry with s, if necessary.
Dialing with the directory
s¢q(Select entry)
c/ dPress the Talk key or the Hands-
free key.
The number is dialed.
You can press the Cor hkey instead, if
you want to specify which line to use.
Managing entries in the directory
s ¢q(Select entry)
Viewing an entry
§Menu§ ¢View
The entry is displayed.
Go back with §Back§.
Editing entries
§Menu§ ¢Edit Entry
~Edit the name and press §OK§.
~Edit the number and press §OK§.
You can use the Clear key to delete one char-
acter at a time from right to left (press
briefly) or all characters (press and hold).

19
Using the directory and lists
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / direct_charges.fm / 7/14/11
Version 4, 16.09.2005
Deleting entries
§Menu§ ¢Delete
Delete the displayed entry.
Or:
§Menu§ ¢Delete List
¤Confirm question Delete? by pressing
§OK§.
All entries in your directory will be deleted.
Adding a displayed number to the
directory
Numbers that appear in a list, such as the
Calls list or the Last Number Redial list can be
added to the directory. If you have Caller ID
and the name is transmitted, the first
16 characters of the transmitted name are
copied to the name line.
A number is displayed:
§Menu§ ¢Copy To Dir.
¤Complete the entry as described in the
section "Saving a number in the direc-
tory" (see page 18).
Last number redial list
The Last Number Redial list contains the 50
numbers last dialed with the handset (max.
32 digits). If a number has been dialed sev-
eral times, only the last try is shown in the
list.
Last number redial
kPress the key.
qSelect the entry.
c/ dPress the Talk key or the Hands-
free key.
The number is dialed.
You can press the Cor hkey instead, if
you want to specify which line to use.
Managing entries in the Last
Number Redial list
kPress the key.
qSelect the entry.
§Menu§ Open menu.
The following functions can be selected with
q:
View
In the list long numbers are shown abbre-
viated. Select View to show the whole
number.
Copy To Dir.
Copy an entry to the directory (page 19)
Delete (as in the directory, page 19)
Delete List (as in the directory, page 19)
Calls list
Requirement: Caller ID Presentation (CIP,
seepage15)
The numbers of the last 100 incoming calls
are stored.
The Óicon is shown on the display of the
idle status when incoming calls are stored in
the Calls list. The Ó icon flashes if new
missed calls are in the Calls list.
New missed calls and the number of the calls
are shown for the corresponding line on the
display of the idle status, e.g.:
L1:01 L2: 01.
¤With the handset in the idle status, open
the Calls list by pressing the tkey.
Dialing with the Calls list
t¢q(Select entry)
c/ dPress the Talk key or the Hands-
free key.
The number is dialed.
You can press the Cor hkey instead, if
you want to specify which line to use.

20
Operating the answering machine
Gigaset C285 / MEA-en / A31008-M1931-A601-1-UZ19 / direct_charges.fm / 7/14/11
Version 4, 16.09.2005
Viewing an entry
t¢q(Select entry)
§Menu§ ¢View
The entry is displayed.
c/ dPress the Talk key or the Hands-
free key.
The number is dialed.
Or:
§Back§ Press display key to go back.
List entry
New messages are at the top. A list entry
contains the following information:
uList type (in header)
uStatus of entry (new entries are marked
with a star (*) in the header)
uName of caller, if name is transmitted or
stored in directory
Caller's phone number, if only the num-
ber is transmitted
External Call, if no number is transmitted
or the caller has not subscribed to Caller
ID
Withheld, if the caller has withheld Caller
ID
You can add the number of the caller to
the directory (page 19).
uDate and time of call (if set, page 13)
uLine: Êor Ëbehind the text shows
whether the call has come in on Line 1 or
Line 2.
You can manage the entries in the same way
as the entries of the Last Number Redial list
(see page 19).
Operating the answering
machine
You can use the answering machine for both
lines or only for one line, depending on your
needs.
You can operate the base station's answer-
ing machine using the handset, using the
keypad of the base station (page 5), or using
remote operation (from another phone/cell
phone).
Announcement mode
You can use the answering machine in two
different modes.
uIn Answer & Rec. mode, the caller hears
your announcement and can then leavea
message.
uIn Answer Only mode, the caller hears
your announcement but cannot leave a
message.
Operation using the base
station keys
You can use the base station keys for the
most commonly used functions of your
answering machine. For more information,
seepage5.
Status of the answering machine
The LED in the Start/Stop key and the sym-
bols in the display of the base station indi-
cate the status of the answering machine.
The LED in the respective Start/Stop key ø
or ù
uIs on when playing messages on the
respective line.
uFlashes slowly when there is at least one
new message on the answering machine
for the respective line.
uFlashes rapidly when the message mem-
ory for the respective line is full.
