Gigaset E560h User manual

Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / Cover_front.fm / 9/24/19
E560 H
Detailed information on the telephone system:
User guide of your Gigaset telephone
www.gigaset.com/manuals
Documentation relating to your base

Gigaset E560H / US / A31008-M2758-R301-1-3S19 / Cover_front.fm / 9/24/19

Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / overview_HSG.fm / 9/24/19
Template Module, Version 1.3, 11.04.2019
Overview
Availability and operation of the functions
may differ on your telephone.
1
en fr es
Overview
1 Direct dialling key A (p.9)
("SOS key", p. 22)
Illuminated: Emergency function
Flashes: Emergency call started
2 Direct dialling keys B to D (p.9)
3Messagekey(p.18)
5
6
12
13
15
10
4
11
8
7
1
2
9
14
3
Access to the call and message lists;
Flashes: new voice message
4Displaykeys( p. 10)
Various functions, depending on the operating
situation
5 Talk key
Accepting call; selecting displayed number;
opening redial list (press and hold); making an
external call (press briefly)
Flashes: Accepting a call
6 Control key (p.8)
Opening a menu; navigating in menus and
entry fields; accessing functions (depending on
the situation)
7Key1
Call the network mailbox ( p. 21)
8Starkey
Ringers on/off (press and hold) ( p. 29)
Changing number presentation ( p. 17)
9 Torch and signal light (LED)
10 Volume keys
for ringtone, receiver/headset, speaker
Upper key: Setting "extra-loud" during a call
( p. 15)
11 Handsfree key (p.14)
Switch between earpiece and handsfree mode;
accepting call; selecting displayed number;
opening redial list (press and hold); making an
external call (press briefly)
Lights up: handsfree activated
12 End call key, On/Off key
End call; cancel function; go back one menu
level (press briefly); back to idle status (press
and hold); activate/deactivate handset (press
and hold in idle status)
13 Hash key
Keypad lock on/off (press and hold, p. 8);
upper/lower case and digits ( p. 12)
14 Recall key ( p. 13)
Consultation call (flash): press and hold
15 Microphone
Changing the display language: p. 28

Template Module, Version 1.3, 11.04.2019,
Contents
Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / E560HX_IVZ.fm / 9/24/19
2Availability and operation of the functions
may differ on your telephone.
en fr es
Contents
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Using the phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Getting to know your telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Making calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Using the network mailbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Emergency function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Further functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Using the handset as an alarm clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Baby monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
One touch call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Torch/Flashlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Protection against unwanted calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Handset settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Questions and answers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Innovation, Science and Economic Development Canada - Certification . . . . . . . . . . . . . . . . . 33
FCC / ACTA Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Service (Customer Care) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Manufacturer's advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Additional information
Not all functions described in the user guide are available in all countries or from all
network providers.
Regarding the telephone system, if the handset is connected to a Gigaset base:
User guide for your Gigaset telephone
Regarding the telephone system, if the handset is connected to another base:
Documentation regarding your base
You can obtain all Gigaset user guides
in PDF format: www.gigaset.com/manuals

Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / user_guide_operating_steps.fm / 9/24/19
Template Module, Version 1.3, 11.04.2019
Availability and operation of the functions
may differ on your telephone.
3
en fr es
Illustration in the user guide
Keys
Procedures
Example: Switching Auto answer on/off:
¤Menu Settings OK Telephony OK Auto Answer OK ( =on)
Warnings, which, if not heeded, can result in injury to persons or damage to devices.
Important information regarding function and appropriate handling or functions
that could generate costs.
Prerequisite for being able to carry out the following action.
Additional helpful information.
Talk key Handsfree key
End call key to Number / letter keys
/ Control key rim / centre Message key
Recall key Star key
Hash key
OK,Back ... Displaykeys
Step Follow this procedure
¤Menu Press the display key Menu when the handset is in idle status.
The main menu opens.
¤
¤OK
Use the control key to navigate to the entry Settings.
Select OK to confirm. The submenu Settings opens.
¤Telephony
¤OK
Select the Telephony entry using the control key .
Select OK to confirm. The submenu Telephony opens.
¤Auto Answer The function to switch Auto answer on/off appears as the first menu
item.
¤OK Select OK to activate or deactivate.
Function is activated /deactivated .

Template Module, Version 1.3, 11.04.2019,
Safety precautions
Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / security.fm / 9/24/19
4Availability and operation of the functions
may differ on your telephone.
en fr es
Safety precautions
Read the safety precautions and the user guide before use.
The device cannot be used in the event of a power failure. It is also not possible to transmit emer-
gency calls.
If the LAN or Internet connection is down, functions that require an Internet connection are not
available, such as Internet telephony (VoIP), online directories and the Info Center. You are able to
make and receive calls if the phone is connected to an analogue landline.
Emergency numbers cannot be dialled if the keypad/display lock is activated!
Use only rechargeable batteries that correspond to the specification (see list of permitted
batteries www.gigaset.com/service). Never use a conventional (non-rechargeable) battery or
other battery types as this could result in significant health risks and personal injury. Rechargeable
batteries, which are noticeably damaged, must be replaced.
Do not charge the handset in charging unit or base station while the headset is connected.
The handset must not be operated if the battery cover is open.
Do not use the devices in environments with a potential explosion hazard (e.g., paint shops).
The devices are not splashproof. For this reason do not install them in a damp environment such
as bathrooms or shower rooms.
Use only the power adapter indicated on the device.
Whilst charging, the power socket must be easily accessible.
Use only the cables supplied for fixed line and LAN connection and connect these to the intended
ports only.
Remove faulty devices from use or have them repaired by our Service team, as these could inter-
fere with other wireless services. Disconnect the telephone network connector (TNV circuit
connector).
Do not use the device if the display is cracked or broken. Broken glass or plastic can cause injury
to hands and face. Send the device to our Service department to be repaired.
Do not hold the rear of the handset to your ear when it is ringing or when speaker mode is acti-
vated. Otherwise you risk serious and permanent damage to your hearing.
The phone may cause interference in analogue hearing aids (humming or whistling) or cause
them to overload. If you require assistance, please contact the hearing aid supplier.
Keep small cells and batteries, which can be swallowed, out of the reach of children.
Swallowing a battery can lead to burns, perforation of soft tissue and death. Severe burns can
occur within 2 hours of swallowing.
In the case of a swallowed cell or battery, seek medical care immediately.
Using your telephone may affect nearby medical equipment. Be aware of the technical conditions
in your particular environment, e.g., doctor's surgery.
If you use a medical device (e.g., a pacemaker), please contact the device manufacturer. They will
be able to advise you regarding the susceptibility of the device to external sources of high
frequency energy (for the specifications of your Gigaset product see "Technical data").

Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / starting_HSG.fm / 9/24/19
Template Module, Version 1.3, 11.04.2019
Getting started
Availability and operation of the functions
may differ on your telephone.
5
en fr es
Getting started
Contents of the package
•One Gigaset handset Gigaset E560H
•Two batteries
•One battery cover
•One charging cradle
•One user guide
Connecting the charger
Setting up the handset for use
The display is protected by a plastic film. Please remove the protective film!
Inserting the battery and closing the battery cover
The charging cradle is designed for use in enclosed, dry rooms within a temperature
range of +41 °F to +113 °F.
The device's feet do not usually leave any marks on surfaces. However, due to the
multitude of different varnishes and polishes used on furniture, contact marks on the
surfaces cannot be completely ruled out.
Never expose the telephone to heat sources, direct sunlight or other electrical
devices.
Protect your telephone from moisture, dust, corrosive liquids and vapours.
¤Connect the flat plug on the power adapter .
¤Plug the power adapter into the plug socket .
To remove the plug from the charging cradle again:
¤Disconnect the power adapter from the mains power
supply.
¤Press the release button .
¤Pull out the plug .
1
2
3
4
1
2
3
4
Only use a rechargeable battery, as this could otherwise result in significant health
risks and personal injury. For example, the outer casing of the battery could be
destroyed or the battery could explode. The device could also malfunction or be
damaged as a result of using batteries that are not of the recommended type.

Template Module, Version 1.3, 11.04.2019,
Getting started
Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / starting_HSG.fm / 9/24/19
6Availability and operation of the functions
may differ on your telephone.
en fr es
Charging the batteries
¤Charge the batteries fully prior to first use in the
charging cradle.
The batteries are fully charged when the power
icon disappears from the display.
Setting the language
Display language
When using the device for the first time, you are prompted in English for the language required
for the display.
¤. . . Use to select the language required OK
Language for voice prompting and default answer machine
announcement
The default setting is English
¤Menu Enter the digit for the desired language
( = English; = French; = Spanish) OK
Registering the handset
¥Insert the batteries (for
correct +/- direction, see
diagram).
¥Fit the cover from the top .
¥Then press the cover until it
clicks into place .
1
2
To open the battery cover:
¥Push the cover down .
3
1
2
3
Batteries may heat up during charging. This is not dangerous.
After a time, the charge capacity of the battery will decrease for technical reasons.
Registration must be initiated on both the base and on the handset. Both must be
carried out within 60 seconds.

Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / starting_HSG.fm / 9/24/19
Template Module, Version 1.3, 11.04.2019
Getting started
Availability and operation of the functions
may differ on your telephone.
7
en fr es
On the base/router
On the handset
Please register handset flashes on the display.
Registering to a Gigaset base
¤Press the display key Regist. OK . . . an available base is sought . . . if required: enter
system PIN (default setting on Gigaset bases: 0000) OK
Registering to another base
¤. . . Open the menu using the control key Settings OK Registration
OK Register Handset OK . . . an available system is sought . . . if required: enter the
system PIN OK
A handset can be registered to up to four bases.
De-registering the handset
¤Menu Settings OK Registration OK De-register Handset OK
Select handset (the actual handset is indicated with a <) OK . . . enter system PIN,
if required OK . . . confirm de-registration with Yes
Setting the date and time
Set the date/time so that the correct date and time can be assigned to incoming calls, and so that
you can use the alarm.
¤Press the display key below the display Time.The entry field will open.
¤use to enter the month, day and year in 8-digit format,
e. g. for April 1st 2019. OK
To correct errors: Press left or right on the control key in order to swap between fields.
¤Enter the hours and minutes in 4-digit format using the keypad, e.g. for
07:15. Switch between the fields using the control key, if necessary. OK
The display shows Saved. You will hear a confirmation tone.
To revert to idle status: Press and hold the End call key .
On a Gigaset base: ¤Press and hold the Registration/paging key on the base
(approx. 3 seconds).
Other base: ¤Information regarding the registration procedure
Documentation regarding your base

Template Module, Version 1.3, 11.04.2019,
Getting to know your telephone
Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / operating.fm / 9/24/19
8Availability and operation of the functions
may differ on your telephone.
en fr es
Using the phone
Getting to know your telephone
Activating/deactivating the handset
¤Press and hold the end call key (confirmation tone).
Activating/deactivating the keypad lock
The keypad lock prevents any inadvertent use of the phone.
¤In idle status, press and hold the hash key (confirmation tone). The keypad lock is
activated or deactivated. If it is activated, the icon appears in the display.
If the keypad lock is activated, a corresponding message is displayed when you press a key.
The keypad lock deactivates automatically when you receive a call. It is reactivated when the call
is finished.
Control Key
In the description below, the side of the control key (up, down, right, left) that you have to press
in the different operating situations is marked in black, e.g. for "press right on the control
key" or for "press the centre of the control key".
It is not possible to call emergency numbers either when keypad lock is activated.
The SOS key still works even if the keypad lock is activated ( p. 22).
The control key enables you to navigate the menus and input fields, and also to
call up certain functions depending on the situation.
In idle status
Opening the directory
Opening the main menu or
Opening the list of handsets
In submenus, selection and entry fields
Confirming a function
During a conversation
Opening the directory
Muting the microphone
Initiating an internal consultation call

Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / operating.fm / 9/24/19
Template Module, Version 1.3, 11.04.2019
Getting to know your telephone
Availability and operation of the functions
may differ on your telephone.
9
en fr es
Volume keys
During a call, set the volume for the receiver/headset or speaker or in the case of an incoming
call, set the volume of the ringtone (5 levels).
¤Press the volume keys on the right side of the handset:
(louder) / (quieter)
The current setting is permanently saved after approx.
two seconds ( p. 29).
Extra-loud function
¤Press the top volume key until you reach the highest
level.
The extra-loud setting only applies for the duration of the call.
Direct dialling keys A to D
You can store particularly important numbers called frequently under the four Direct dial keys.
You can assign an external number or an internal call to every direct dial key.
To dial these saved numbers, press the relevant direct dialling key to .
You can also assign the emergency function to direct dialling key (p.22).
Assigning a function to direct dialling keys
Prerequisite: The direct dialling key in question has not already been assigned a function.
¤In idle status, press the direct dialling key ( to ) on the handset to which you wish to
assign a function.
Select the relevant function using :
Changing the function of the direct dialling keys
¤Menu Settings OK Direct Dial Keys OK Select direct dialling key
(Ato D)
Volume:
Back OK
•This setting can result in harm to health in persons with a normal hearing ability
and is only intended for persons with a hearing impairment or reduced hearing.
•Disruptive noises on the phone line can be increased.
¤Label with Ext. No. Enter an external phone number directly.
¤Enter the number and press OK.
¤Enter the name and press OK.
¤Label with Internal Call Direct dial to a handset registered to the same base.
If more than one other handset is registered: Select handset OK
¤Label with Call All Int. Direct dial to all handsets registered to the same base.
¤Label with Dir. Number Label the key with a number from the directory. The directory is
opened. Select a number and press OK.

Template Module, Version 1.3, 11.04.2019,
Getting to know your telephone
Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / operating.fm / 9/24/19
10 Availability and operation of the functions
may differ on your telephone.
en fr es
The current labelling is displayed after the key number, e.g.,
You can now change the labelling.
Select a new function using Menu Not all functions may be available, depending on the
current assignment. An entry that is already present must be deleted in advance.
Display keys
The functions of the display keys change depending on the particular operating situation.
Example:
Examples:
Display icons
¤A: <no entry> i.e., the key is not currently labelled.
¤Delete Entry Delete current key labelling.
¤Edit Entry Change phone number and/or name.
Only key : Assign key with emergency function p. 64
Redial Menu
Current display key function
Display keys
1
2
1
2
1
2
Open redial list.
Open main menu/menu for further functions.
Confirm selection or save entry.
Missed calls or messages on the network mailbox ( p. 18).
Delete key: delete character by character/word by word from right to left.
Go back one menu level or cancel operation.
Mute the microphone ( p. 15).
Redial
Menu
OK
Delete
Back
Mute
Action complete Action failed
Information Alarm call
Please wait ... Display up/Down

Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / operating.fm / 9/24/19
Template Module, Version 1.3, 11.04.2019
Getting to know your telephone
Availability and operation of the functions
may differ on your telephone.
11
en fr es
Menu guidance
Your telephone's functions are accessed via a menu consisting of several levels.
Main menu (first menu level)
¤When the handset is in idle status, press the display key Menu to open the main menu.
The functions in the main menu are shown by means of an icon
and the function's name.
Selecting a function:
¤You can scroll between functions using the control key .
The selectable function is shown in the display.
¤Press the display key OK to select the displayed function.
This opens the corresponding submenu and the first entry
is displayed.
If you press the display key Back or briefly press the end call key , the display returns to idle
status.
Sub menu
The functions in the sub menu are indicated by name.
Selecting a function:
¤You can scroll between functions using the control key .
The relevant function is shown in the display.
¤Press the display key OK to select the displayed function.
This opens the corresponding submenu and the first entry
is displayed.
Briefly press the display key Back or the end call key to return to the previous menu level.
Reverting to idle status
From any point in the menu:
¤Press and hold the end call key or
¤Do not press any key: after 2 minutes, the display will auto-
matically revert to idle status.
Settings
Back OK
Display
Back OK
07:15
01.04.2019
Menu

Template Module, Version 1.3, 11.04.2019,
Getting to know your telephone
Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / operating.fm / 9/24/19
12 Availability and operation of the functions
may differ on your telephone.
en fr es
Writing and editing names
The following rules apply when writing names:
•Each key between and is assigned several letters and characters.
•Control the cursor with .
•Characters are inserted at the cursor position.
•Press the display key Delete to delete the character to the left of the cursor.
•The first letter of the name is automatically capitalised and then followed by lower case
letters.
¤Briefly press the key several times in succession to select the required letter/character.
Setting upper/lower case or digits
Repeatedly press the hash key to change the text input mode.
The change of mode is displayed in the middle of the display.
Correcting incorrect entries
You can correct incorrect characters in the input fields by navigating to the incorrect entry using
the control key . You can then:
•Use the display key Delete to delete the character to the left of the cursor,
•Insert characters at the cursor position
•Overwrite the highlighted (flashing) character e.g., when entering time and date.
The characters assigned to the key are shown in a selection line at the bottom left of
the screen. The selected character is highlighted.
1 Writing digits
A Upper case; First letter in capitals, all others in lower case
aLowercase

Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / telephony.fm / 9/24/19
Template Module, Version 1.3, 11.04.2019
Making calls
Availability and operation of the functions
may differ on your telephone.
13
en fr es
Making calls
When the display backlight is switched off, pressing any key will activate the backlight.
Making an external call
External calls are calls to the public telephone network.
¤Enter the number Press the Talk key briefly
or
¤Press the Talk key briefly . . . use to enter the number
Ending call/cancelling selection
¤Press the End call key or place the handset in charging cradle.
Accepting a call
The handset indicates an incoming call in three ways: by ringing, by a display on the screen and
by the flashing talk key . The signal light on the back of the handset flashes if the function
LED Call Signal is activated ( p. 30).
Options for answering a call:
¤Press the Talk key .
¤Press the Handsfree key .
¤Press the display key Accept.
Switching the ringtone off:
¤Press the display key Silence. You can accept the call while it is displayed on the screen.
Accepting a waiting call
If you receive another call while conducting an external call, you will hear the call waiting tone
(short beep). The caller's number or name will appear in the display if phone number iden-
tification is enabled.
¤Press and hold the R key , to accept the call.
If you don’t accept the waiting call, it is added to the missing calls list ( p. 17).
Dialling the phone number:
•with the Direct dial key p. 9
•from the directory p. 19
•from the missed calls list p. 17
•from the redial list p. 16
If the handset is in the base and the Auto Answer function is activated ( p. 28), the
handset will accept a call automatically when you lift it out of the base.
R

Template Module, Version 1.3, 11.04.2019,
Making calls
Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / telephony.fm / 9/24/19
14 Availability and operation of the functions
may differ on your telephone.
en fr es
Calling Line Identification
When you receive a call, the caller's number and/or name is displayed on the screen, if the
following prerequisites are met.
•Your network provider supports CLIP, CLI and CNIP.
•CLI (Calling Line Identification): The caller's number is transmitted.
•CLIP (Calling Line Identification Presentation): The caller's number is displayed.
•CNIP (Calling Name Identification Presentation): The caller's name is displayed.
•You have requested CLIP or CNIP from your network provider.
•The caller has arranged CLI with the network provider.
Call display
When you receive a call, the phone number or, if you have CNIP, the name (town) registered with
your network provider for the caller's number is shown in the display.
If the number of the caller is stored in your directory, the display is
replaced by the corresponding directory entry.
The following is displayed in place of the number:
•Extern. Call, if no number is transmitted.
•Withheld, if the caller has withheld Calling Line Identification.
•Unavailable, if the caller has not arranged Calling Line Identifi-
cation.
Handsfree operation
In handsfree mode, you activate the loudspeaker so that you can hear the caller without having
to hold the handset to your ear. You therefore have both hands free and other people can listen
in on the conversation.
Activating/deactivating handsfree mode
Activating while dialling
Switching between earpiece and handsfree mode
During a call activate or deactivate handsfree mode.
If you wish to place the handset in the charger during a call:
The ringer can be switched off for unknown calls (calls with Calling Line Identification
withheld) ( p. 27).
Inform your caller before you use the handsfree function so that the caller knows a
third party may be listening.
Enter the number and press the handsfree key.
Press the handsfree key.
John
Accept Silence

Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / telephony.fm / 9/24/19
Template Module, Version 1.3, 11.04.2019
Making calls
Availability and operation of the functions
may differ on your telephone.
15
en fr es
¤Press and hold the handsfree key while placing the handset in the charger and for a
further 2 seconds. Otherwise, the call is cancelled.
Muting
You can deactivate your handset’s microphone during a call.
Changing the volume during a call
The volume is changed for the current mode (handsfree mode, receiver).
¤Press the volume keys on the right-hand side of the handset: up : louder / down :
quieter.
This setting is permanently saved ( p. 29).
Extra-loud function: p. 9
Making internal calls
Internal calls are free calls between handsets that you have registered to the same base.
¤(briefly press). Call All is displayed. Select handset from the list (the actual
handset is marked with a <) or Call All (collective choice).
Holding down the key starts a call on all registered handsets immediately.
Accepting an internal call
Your telephone rings and the internal number of the caller (e.g., INT 2) or the assigned name
appears in the display.
¤Press the talk or handsfree key / on the handset to accept the call.
Ending a call
¤Press the end call key on the handset.
Transferring a call to another handset/internal consultation
External call, internal consultation:
¤The list of handsets is opened. If more than two handsets are registered to the base,
select one handset or Call All. or OK.
For instructions on adjusting the handsfree volume p. 29.
Mute Press the display key to mute the handset.
On Press the display key to reactivate the microphone.
Press the control key (right) to activate/deactivate the microphone.
Changing the name of the handset: p. 31

Template Module, Version 1.3, 11.04.2019,
Lists
Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / telephony.fm / 9/24/19
16 Availability and operation of the functions
may differ on your telephone.
en fr es
Transferring an external call: You have two options to transfer the call:
¤Wait until the participant called answers, then hang up:
Press the End call key .
Or:
¤Hang up before the participant answers: Press the End call key .
If the participant called does not answer or does not transfer the call, end the consultation call
with Back.
Accepting a waiting call
If you receive an external call while conducting an internal call, you will hear the call waiting
tone (short beep). The caller's number or name will appear in the display if phone number iden-
tification is enabled.
¤Press the end call key on the handsetto end the internal call.
¤Press the talk key on the handsetto accept the external call.
Lists
Using the redial list
The redial list contains the ten numbers last dialled with the handset (max. 30 digits). If one of
the numbers is in the directory, the corresponding name will be displayed.
Dialling from the redial list
Managing entries in the redial list
The following functions can be selected with :
Network mailbox list
You can use this list to listen to messages on the network mailbox ( p. 21).
Press and hold the Talk key.
Select an entry.
Press the talk key. The number is dialled.
Press and hold the Talk key.
Select an entry.
Menu Press the display key.
¤Use Number
¤Copy to Directory Copy the caller's number to the directory.
¤Delete Entry Delete selected entry.
¤Delete List Delete all entries in the list.

Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / telephony.fm / 9/24/19
Template Module, Version 1.3, 11.04.2019
Lists
Availability and operation of the functions
may differ on your telephone.
17
en fr es
Missed calls list
Prerequisite: CLIP ( p. 14)
Opening the list of missed calls
¤Missed Calls
The list is displayed as follows:
Number of new messages +number of old, read messages.
The last missed call is displayed as the first entry.
¤. . . use to scroll though the list
Example for a list entry:
•Status of entry
Red: New missed call.
White: Entry already read.
The total number of missed calls is shown in brackets.
•Number or name of caller
You can add the number of the caller to the directory ( p. 20).
•Date and time of the call.
Menu functions
Use the Menu display key to select the following options:
Selecting from the list of missed calls
Open list: Missed Calls
Your telephone saves the last 60 missed calls.
OK Press the display key to open the list.
¤Delete Entry Delete selected entry.
¤Copy to Directory Copy the caller's number to the directory.
¤Show Number Display caller's phone number.
¤Delete List Delete all entries in the list.
Select an entry.
Press the talk key. The number is dialled.
Change the number presentation of the stored call.
¤Press the Star key , until the desired format is displayed
•Local call (7-digit number)
•Local call in multiple codes area (10-digit number)
•Long distance call (11-digit number)
Missed Calls:
01+02
Back OK
Missed [55]
. . .1 2 3 4 5 6 7 8 9
28.08. 09:15
Back Menu

Template Module, Version 1.3, 11.04.2019,
Lists
Gigaset E560H / HSG US en / A31008-M2758-R301-1-3S19 / telephony.fm / 9/24/19
18 Availability and operation of the functions
may differ on your telephone.
en fr es
Displaying CNIP information
If you have requested CNIP, you can view the name and town that are registered for this phone
number with your network provider.
Select a list entry.
¤Menu Show Name
If the name and town are not shown, it means that the caller has not requested Calling Line Iden-
tification or that Calling Line Identification has been withheld.
Deleting all entries
Caution! All old and new entries will be deleted.
Open list: Missed Calls
¤Menu Delete List OK
Calling up lists with new messages
Notifications about missed calls and messages on the network mailbox are saved in the mes-
sages list.
If there are messages in a list, use the display key to call up:
•The network mailbox (if your network provider supports this function and the number of the
network mailbox has been entered p. 21)
•The missed calls list
As soon as a new message arrives, an advisory tone will sound. The Message key also
flashes.
Icons for message types and the number of new messages are
shown on the idle display. The number of new entries is
displayed beside the corresponding icon.
Display messages
Answering machine
¤Press the Message key Answ.Mach. OK select the answering machine
(Net AM) OK ...
OK Press the display key to return to the list.
Display the original number of the entry. Use the Star key , to change the
number presentation
Icon New message...
... on the network mailbox
... in the list of Missed Calls
The network mailbox number is dialled (further information p. 21)
07:15
01 05
Menu
