GILMAN gemini GAP5B User manual

1
MODEL NO.: GAP5B
3W
Personal Ionic HEPA
ltration Air Purier
個人負離子HEPA過濾
空氣淨化機
A GILMAN GROUP BRAND

2
Please read and retain for future reference.
SAFETY INSTRUCTION - GENERAL
SAFETY INSTRUCTION - ELECTRICITY AND HEAT
• Use this appliance solely in accordance with these instructions.
• This appliance is for household use only, not for commercial purpose.
• Remove all packaging material from the appliance before use.
• This appliance shall not be used by children of 0 to 8-year old.
• This appliance can be used by children older than 8-year old and persons with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge, but only if they have been given supervision or instruction concerning use
of the appliance in safe way and understand the hazards involved.
• Children should be supervised to ensure that they do not play with the appliance.
• Cleaning and maintenance must not be done by children.
• Have any repairs carried out solely by a qualied electrician. Never try to repair
the appliance yourself.
• Do not handle the plug or appliance with wet hands.
• Do not immerse the main body in water.
• Children shall not play with the appliance.
• Do not leave the appliance unattended when connected to the mains supply.
• Only use the attachments/accessories supplied with the product.
• Ensure the appliance is in placed on a horizontal, even and stable surface.
• Verify that the mains voltage is the same as that indicated on the rating plate on
the appliance before use.
• Never use the extention cord as power connection.
• Make sure that the appliance, the USB cable do not make contact with water.
• Make sure that the appliance, the USB cable do not make contact with hot surface,
such as a hot hob or naked ame.
• Check the appliance’s USB cable regularly to make sure it is not damaged.
• Do not use the appliance if the USB cable is damaged. If the USB cable is damaged
in order to avoid any hazards.
• Never use the appliance in the vicinity of ammable material.

3
SAFETY INSTRUCTION – DURING OPERATION
• Do not pick up the appliance if falls into water. Remove the plug from the socket
immediately. Do not use the appliance again.
• Never immerse the appliance, the power cord or the plug in water or any liquid.
• Do not move the appliance while its switched on.
• Do not use the liquids, such as water or ammable solvents to clean the product,
please use a soft cloth to clean when product not in running.
• Please keep air circulation and do not cover detect air quality sensor, air inlet and
outlet when the product is running.
• Please close the car and room window when product running to improve the purication,
and please adjust to lowest air-conditioning power when you turn on the air-conditioner.
• To keep safety, please DO NOT open the product top cover when it is running.
• Please install the purier rmly on the car cup holder, and prohibit to place it on the
car dashboard to avoid any accidents.
• For your safety, DO NOT adjust the product when driving.
• Do not use other type power adapters, keep use the original accessories which
accompany with the package.
• Please refer to “Cleaning and Maintenance” section to clean the appliance.

4
1. The purication wind speed indication
1a.Primary purication (low speed )
1b.Rapid purication (medium speed )
1c.High-efciency purication (high speed )
1d.Automastic mode
2. Temperature indicator
3. Humidity indicator
4. Air quality indicator (blue/ yellow/ red)
5. On/ Off / Purication wind speeds button
(LOW–MED–HIGH, Automatic mode
can not be selected manually)
6. Current room temperature display
7. Current room humidity display
PRODUCT OVERVIEW
LED Display Screen
7
Filter
(Pre-lter, HEPA lter & Activated carbon lter)
1a 1c1b 1d
4 5
3
7
2
6
1. Gradient LED lights (Decoration purpose)
(Red/ yellow/ blue/ green/ white/
orange/ purple)
2. Air outlet
3. Main body
4. LED touch panel & display screen
5. Air inlet
6. Detect air quality sensor
7. USB cable (1.5 metre)
6

5
HOW TO USE
• Connect the power source (5V) to the product with the provided USB cable.
• Automastic mode on touch panel:
Connect to the power source, the product will turn on automatically and enters into
the automatic mode if there is no input operation by user in 2 seconds. The On/ Off/
Purication wind speeds button remains blue at the beginning. The appliance will
detect automatically based on detect air quality sensor to adjust suitable purication
wind speeds (LOW–MED–HIGH) around 2 minutes.
Blue light-> Good air quality
Yellow light-> Poor air quality
Red light -> Bad air quality
If good air quality, the purication speed starts at LOW. ( LOW & AUTO )
If poor air quality, the purication speed starts at MED. (MED & AUTO )
If bad air quality, the purication speed starts at HIGH. (HIGH & AUTO )
*This automatic mode cannot select on touch panel by manual. The purier will de-
fect the air quality when connect to the power supply under this mode.
• Manually Mode on touch panel:
Connect to the power source, touch the On/ Off / Purication wind speed button to
adjust the 3 purication speeds.
Touch once: Turn on Primary purication (low speed )
Touch twice: Turn on Rapid purication (medium speed )
Touch three times: Turn on High-efcient purication (high speed ), as a cycle
Press it and hold about 3 seconds, product will turn-off.
• How to turn on and off the gradient LED lights:
When connect the power source, the decoration LED lights will be automatically
turned on. When touching the On/ Off / Purication wind speeds button around 2
seconds, the lights will turn off. Need restart the appliance to turn on the LED lights
again.

6
FILTER REPLACEMENT
In order to keep the best purify performance, we suggest it is better to replace the lter
after 3-5 months of use. If need to replace lter, the On/ Off/ Purication wind speeds
button will automatically warning as red light icker 3 times and 3 “Dee” sounds during
operation. After replace lter, press and hold the On/ Off/ Purication wind speeds
button for 8 seconds to start resetting till the green light icker will start, then it will
reset and start to work normally.
Shutdown the power rst, then rotate the bottom casing of the machine at clockwise
direction, and then loosen naturally after turning to the position (Fig.1). Take out the
lter in the middle, and then replace in a new one (Fig.2). Rotate the base at counter-
clockwise direction and twist it into place (Fig.3).
Fig.1 Fig.2 Fig.3
lter
Rotate the bottom
casing of the machine
clockwise
Rotate the bottom
casing of the machine
counter-clockwise
bottom casing

7
CLEANING AND MAINTENANCE
TROUBLESHOOTING
PRODUCT SPECIFICATIONS
• Do not use the liquids, such as water or ammable solvents to clean the product,
unplug and please use a soft cloth to clean.
• Keep the product at a cool and dry place.
Model no.: GAP5B
Voltage / Current: DC5V 1A
Power: 3W
Accessory: 1.5 M USB cable
Product dimensions: Ø72 (diameter) × 180 (H) mm
Problem Cause Solution
Purier not works
Did not press On / Off button Press On / Off button
Abnormal supply voltage,
over/under voltage protection
Check if the supply
voltage is 5V
Power source is disconnected
or loose the USB cable
Connect the USB cable
/ switch on the power
source again
The On/ Off/ Purication
wind speeds button
warning as red
light icker 3 times
and 3 “Dee” sounds
Need to replace lter Refer to the
“FILTER
REPLACEMENT” on P.6

8
安全指引 - 一般安全
安全指引 - 電子和熱能產品
- 請按照這些說明事項, 使用本產品。
- 本產品僅供家用，不作商業用途。
- 使用前，請將所有包裝材料拆除。
- 0至8歲的兒童不應使用本產品。
- 超過8歲的兒童可使用本產品，但請勿由肢體不健全、感覺或精神上有障礙或缺乏
相關經驗和知識的人使用，除非有負責他們安全的人對他們使用本產品進行監督或
指導。
- 請務必看顧好兒童，以確保他們不玩耍本產品。
- 兒童不應清潔或維修本產品。
-
當需進行任何維修，必須由專業維修人員進行維修。永遠不要嘗試自己修理本產品。
- 手濕時不可以接觸電源插頭或本機。
- 主機不可以浸入水中。
- 兒童不可以把玩本機。
- 本機開著後不可以無人監管。
- 只使用隨機附送的配件。
閱讀下列說明事項並請妥善保管，以供日後參考。
- 請把本產品放置在平穩的表面上使用。
- 使用相符的電源和電壓，以防止觸電。
- 永不可使用延長電線插座於本機上。
- 確保本產品、USB電源線不與水接觸。
- 確保本產品、USB電源線不接觸發熱表面，如明火。
- 定期檢查本產品的USB電源線以確保其沒有損壞。
- 如果USB電源線損壞，請勿使用其產品，以避免出現任何危險。
- 切勿在易燃材料附近使用本產品。

9
安全指引 - 操作期間
- 如果本產品落入水中，立即從牆身插槽中拔下插頭，並且不要再次使用本產品。
- 切勿將本產品、USB電源線或插頭浸入水中或其他液體中。
- 當本產品運作時，請勿隨意移動本產品。
- 切勿用液體清洗或潑灑本產品，如水、清洗劑或易燃溶劑等，如需清潔，請將電源斷
開，使用柔軟抹布擦拭。
-
請保持本產品周圍空氣暢通無阻，切勿覆蓋本產品的檢測空氣質量傳感器及出入風口。
- 為提高淨化效果，使用本產品時請將車及房間的窗子關閉，如有打開空調，請將空調風力
調到最小。
- 為了您的安全 ， 切勿在通電情況下打開機器頂蓋。
- 請將淨化器牢固的安裝到車上，切勿隨意擺放到前方中控臺上，以免造成意外事故。
- 為了您的安全，切勿在駕車時調節本產品，如需調節請先停車。
- 切勿使用不同規格的電源適配器，請使用本產品附帶的配件進行安裝。
- 清潔本產品 時請參閱“清潔和保養”部份。

10
部件示意圖
1. 風速指示燈
1a.從左到右為初級凈化 (低速 )
1b.快凈化 (中速 )
1c.高效凈化 (高速 )
1d.自動模式
2. 溫度指示燈
3. 濕度指示燈
4. 空氣質量指示燈 (藍/ 黃/ 紅 )
5. 開/ 關/ 淨化空氣風速鍵 (低 - 中 - 高)
6. 現時室內溫度顯示
7. 現時室內濕度顯示
LED 顯示屏
過濾網
(前置過濾網、HEPA高效過濾網及活性炭過濾網)
1a 1c1b 1d
4 5
3
7
2
6
7
6
6
1. 裝飾的漸變LED燈
(紅/ 黃/ 藍/ 綠/ 白/ 橙/ 紫色持續變色)
2. 出風口
3. 主機
4. ＬＥＤ輕觸顯示屏
5. 進風口
6. 檢測空氣質量傳感器
7. USB充電線 (1.5米)

11
如何使用
- 將USB電源輸出插頭插到本機上，再將USB插到 5V 電源位置。
自動感應空氣質量模式 (頂部面板)：
- 連接電源，若於2秒內沒有任何操作指示，空氣淨化器會進入自動感應空氣質量模
式，最初開／關／淨化空氣風速鍵 默認為藍色，自動探測約2分鐘後，本機會根據
室內空氣質量程度自動調整3檔淨化空氣速度（低－中－高）。
藍色（空氣品質優）
黃色（空氣品質較差）
紅色（空氣品質最差）
若空氣品質優，會自行於低工作風速運作。（低速 及自動 ）
若空氣品質較差，會自行於中工作風速運作。（中速 及自動 ）
若空氣品質最差，會自行於高工作風速運作。（高速 及自動 ）
*自動感應空氣質量模式不供自行於輕觸顯屏上調校。本機會於開機後自動感應空氣質
量而操作。
手動模式 (頂部面板)：
連接電源，可按頂部開/ 關/ 淨化空氣風速鍵 調節風速，
第一次按 為初級淨化 (低速 ) ;
第二次按 為快速淨化 (中速 ) ;
第三次按 為高速淨化 (高速 )，依次循環。
長按三秒，產品自動關閉
裝飾用的漸變 LED燈的開啟和關閉
當連接電源時，彩色漸變燈自動漸變亮起，當長按開/ 關/ 淨化空氣風速鍵 約2秒的時
候，彩色漸變燈關閉。若需再開啟彩色漸變燈，需要重新開啟本機。

12
更換高效過濾網
為維持最佳淨化性能，本機工作運轉3-5個月後，根據過濾網的污染程度，產品在運作
時會自動提示進行更換過濾網，開/ 關/ 淨化空氣風速鍵 紅色顯示燈閃爍3次，會發
出“滴”3聲，此時需要更換過濾網，更換完成後，長按8秒開/ 關/ 淨化空氣風速鍵
開始，顯示綠色閃爍後，本機重啟開始進入正常工作狀態。
更換高效過濾網的方法：
將本產品先關機，
然後順時針方向旋轉本機底部外殼，轉到位後便可鬆開（如圖 1）
將中間的高效過濾網取出，然後放入新的過濾網（如圖 2）
再逆時針旋轉底部外殼，扭到位便可（如圖 3）
圖 1 圖 2 圖 3
底部外殼
順時針旋轉
逆時針旋轉
底部外殼
底部外殼
主機 主機
高效
過濾網

13
清潔及保養
產品規格
疑難排除
- 切勿用液體清洗或潑灑本機，如水、清洗劑或易燃溶劑等，如需清潔，請請拔掉電源
線，使用柔軟抹布擦拭。
- 將本產品放在陰涼乾燥的地方。
型號：GAP5B
電源：DC5V 1A
功率：３瓦
配件：1.5米 USB電源線
產品尺寸：72 (直徑) x 180 (高) 毫米
問題 原因 解決方法
本機無法開啟
沒有按開 / 關鍵 按下開 / 關鍵
異常過高或過低電壓 確認5V電源是否可靠連接
主電源關上或USB插
座鬆開
重新插入主電源插座或檢查
USB電線是否鬆開
開/ 關/ 淨化空氣風
速鍵 紅色顯示燈
閃爍3次，會發出“
滴”3聲
需更換過濾網 參考“更換高效過濾網”
(第12頁)

14

15

16
太平家庭電器
