Giovenzana HP Series User manual

Strawinskylaan 1105
1077 XX Amsterdam, The Netherlands
HP
EN
instruction manual
MT-HP-EN / 11.10.2021
Rev. 4
PENDANT STATION
IMPORTANT INFORMATION .......................2
TECHNICAL CHARACTERISTICS ................... 3
VERSIONS ......................................5
WIRING ........................................8
Before use, read this booklet carefully to
acquaint yourself with the features of the
product. This booklet is an integral part of
the product and therefore must be kept until
the product is dismissed.
Giovenzana International B.V. reserves the
right to change the features and data shown
in this document at any time and without
notice. This document cannot therefore be
considered a contract with third parties.
HP pendant stations are designed and
manufactured according to IEC international
standard and EN European regulations.
Improper installation or tampering can cause
serious damage to people and property,
therefore installation and maintenance must
be carried out by specialized and authorized
personnel.
The device is not intended for use in
environments with a potentially explosive
atmosphere or in the presence of corrosive
substances and in salt fog.
Ergonomic pendant stations for small hoist:
• Bi-directional, mechanically interlocked
• IP65 double insulation IEC / EN 60529
• Laser engraved symbols comply with
EN60204-1, FEM9.941
• Shock proof and heat resistant
• Single speed or two speed motor
• Direct motor control 1 kW - 1 speed
• HP03 and HP05 available in UL/CSA
requirements
• Contact blocks with spring terminals

2GIOVENZANA INTERNATIONAL B.V. - MT-HP-EN / 11.10.2021 - Rev. 4
IMPORTANT INFORMATION
Symbols
The following symbols are used in this booklet:
Read carefully before use.
Information note.
ATTENTION, the information highlighted by
this symbol is very important.
DANGER, the information highlighted by
this symbol concerns environments with
a potentially explosive atmosphere or the
presence of corrosive substances and salt
fog.
This symbol highlights the recommended
tightening torques to guarantee the degree
of protection of the product and to prevent it
from breaking.
THE INFORMATION SHOWN ON THIS PAGE IS ESSENTIAL FOR THE CORRECT INTERPRETATION OF WHAT HAS
BEEN EXPOSED IN THIS BOOKLET.
ATTENTION
IT IS DANGEROUS TO OPERATE THE
PUSH-BUTTONS AT THE SAME TIME
Tools required (not supplied)
Insert the flathead screwdriver into the opening (a)
and turn it half a turn. Insert the end of the cable into
the opening (b) and remove the screwdriver to lock the
end of the cable. In detail, the mechanical action of the
screwdriver on (c) opens (d) and allows to insert the end
of the cable.
Contact block with spring terminals
ATTENTION
Connectable section to the contact blocks
flexible conductors 1 or 2 0.5 ... 2.5 mm²
18 ... 12 AWG
solid conductors 1 or 2 0.5 ... 2.5 mm²
18 ... 12 AWG
wire peeling length 8 mm
(a)
(c)
(d)
(b)
Phillips screwdriver Flathead screwdriver
Scissors Wrench 33mm
PCF key (to be purchased separately)
Torque screwdriver with its flat and Phillips heads

3GIOVENZANA INTERNATIONAL B.V. - MT-HP-EN / 11.10.2021 - Rev. 4
Compliant to standards IEC / EN60947-5-1
Material ABS V0
Material group II
Pollution class 3
Temperature operating
storage
-25°C ... +70°C
-30°C ... +70°C
Protection class IP65
Cable entry HP03...
HP05... - HP07...
HP08...
spiral cable gland M20
cable gland M25
cable gland M32
Weight HP03...
HP05...
HP07...
HP08...
330 g
450 g
620 g
720 g
Marking
Pendant station technical data
TECHNICAL CHARACTERISTICS
Versions
• HP03 - HP03.D2
• HP05 - HP05.D2 - HP05.D4
• HP07 - HP07.D2 - HP07.D4 - HP07.D6
• HP08 - HP08.D2 - HP08.D4 - HP08.D6
Valid for HP03 and HP05
models only
Only for use with Type S or SJ cord rated 600 V,
75°C min.
Overcurrent protection shall be provided and
sized per the following table:
Conductor AWG Max Protection Ampacity
18 3.5
16 5.0
14 7.5
12 10
The maximum configuration for HP03 shall be as
following:
U V W
L1 L2 L3
22 44 5424 34 12
21 43 5323 33 11
The maximum configuration for HP05 shall be as
following:
• No more than two buttons can be actuated
simultaneously.
• No more than two NO contact block per
operator.

4GIOVENZANA INTERNATIONAL B.V. - MT-HP-EN / 11.10.2021 - Rev. 4
Dimensions
96 88 9088
96 92
235
334
99
285
319
34
335
369
34
96 101
335
369
34
Dimensions in mm
Drawing NOT in scale
HP03
HP07 HP08
HP05

5GIOVENZANA INTERNATIONAL B.V. - MT-HP-EN / 11.10.2021 - Rev. 4
VERSIONS
HP03
HP03.D2
HP05
HP05.D2
Single speed
PCW10 (NO)
green
PCW10 (NO)
green
PCW01 (NC)
red
Single speed
PCW10 (NO)
green
PCW10 (NO)
green
HP05.D4
Double speed
PCW10 (NO)
PCW02 (NO)
green
PCW10 (NO)
PCW02 (NO)
green
Double speed
PCW10 (NO)
PCW02 (NO)
green
PCW10 (NO)
PCW02 (NO)
green

6GIOVENZANA INTERNATIONAL B.V. - MT-HP-EN / 11.10.2021 - Rev. 4
HP07 HP07.D2 HP07.D4 HP07.D6
Single speed
PCW10 (NO)
green
PCW10 (NO)
green
Single speed
PCW10 (NO)
green
PCW10 (NO)
green
Single speed
PCW10 (NO)
green
PCW10 (NO)
green
PCW01 (NC)
red
Double speed
PCW10 (NO)
PCW02 (NO)
green
PCW10 (NO)
PCW02 (NO)
green
Double speed
PCW10 (NO)
PCW02 (NO)
green
PCW10 (NO)
PCW02 (NO)
green
Double speed
PCW10 (NO)
PCW02 (NO)
green
PCW10 (NO)
PCW02 (NO)
green

7GIOVENZANA INTERNATIONAL B.V. - MT-HP-EN / 11.10.2021 - Rev. 4
HP08 HP08.D2 HP08.D4 HP08.D6
Single speed
PCW10 (NO)
green
PCW10 (NO)
green
Single speed
PCW10 (NO)
green
PCW10 (NO)
green
Single speed
PCW10 (NO)
green
PCW10 (NO)
green
PCW01 (NC)
red
PCW10 (NO)
PCW10 (NO)
green
Double speed
PCW10 (NO)
PCW02 (NO)
green
PCW10 (NO)
PCW02 (NO)
green
Double speed
PCW10 (NO)
PCW02 (NO)
green
PCW10 (NO)
PCW02 (NO)
green
Double speed
PCW10 (NO)
PCW02 (NO)
green
PCW10 (NO)
PCW02 (NO)
green

8GIOVENZANA INTERNATIONAL B.V. - MT-HP-EN / 11.10.2021 - Rev. 4
WIRING
1Loosen the screws to remove the bottom of the
pendant station.
ATTENTION
Is shown the wiring of a push-button panel with
only one contact element per key. The procedure is
identical for 2 or 3 contact elements per key.
1
3
2
4
5
HP03...
2Loosen the screws of the cable holder and
insert the cable into
the cable clamp.
4Tighten the cable holder screws.
TIGHTENING
TORQUE
1.2-1.4 N×m
10.6-12.4 lb×in
TIGHTENING TORQUE
0.8-1.0 N×m
7-8.8 lb×in
5Replace the bottom of the pendant station and screw
it in place.
3Wire the contact blocks following the procedure
“Contact block with spring
terminals” on page 2.
ATTENTION
The sections that can be connected to the contact
blocks are shown in the paragraph “Contact block
with spring terminals” on page 2.

9GIOVENZANA INTERNATIONAL B.V. - MT-HP-EN / 11.10.2021 - Rev. 4
ATTENTION
The HP05 pendant station is used in the
illustrations: the operations are the same for the
HP07 pendant station and variants.
HP05... - HP07...
1
(*)
3
2
4
5
6
2Loosen the screws of the cable holder and
insert the cable into
the cable clamp.
3Wire the contact blocks following the procedure
“Contact block with spring
terminals” on page 2.
1Loosen the screws to remove the
bottom of the
pendant station.
4Tighten the cable holder screws.
TIGHTENING
TORQUE
1.2-1.4 N×m
10.6-12.4 lb×in
TIGHTENING TORQUE
0.8-1.0 N×m
7-8.8 lb×in
6Replace the bottom of the pendant station and screw
it in place.
5Tighten the cable clamp
with a 33 mm
wrench.
TIGHTENING
TORQUE
1.2-1.4 N×m
10.6-12.4 lb×in
ATTENTION
The sections that can be
connected to the contact blocks
are shown in the paragraph
“Contact block with spring
terminals” on page 2.
ATTENTION
The screw (*) may not be present on some pendant
stations.

10GIOVENZANA INTERNATIONAL B.V. - MT-HP-EN / 11.10.2021 - Rev. 4
ATTENTION
The HP05 pendant station is used in the
illustrations: the operations are the same for the
HP07 pendant station and variants.
HP08...
1
3
2
4
5
6
2Loosen the screws of the cable holder and
insert the cable into
the cable clamp.
3Wire the contact blocks following the procedure
“Contact block with spring
terminals” on page 2.
1Loosen the screws to remove the
bottom of the
pendant station.
4Tighten the cable holder screws.
TIGHTENING
TORQUE
1.2-1.4 N×m
10.6-12.4 lb×in
TIGHTENING TORQUE
0.8-1.0 N×m
7-8.8 lb×in
6Replace the bottom of the pendant station and screw
it in place.
5Tighten the cable clamp
with a 33 mm
wrench.
TIGHTENING
TORQUE
1.2-1.4 N×m
10.6-12.4 lb×in
ATTENTION
The sections that can be
connected to the contact blocks
are shown in the paragraph
“Contact block with spring
terminals” on page 2.
ATTENTION
The screw (*) may not be present on some pendant
stations.
