GivEnergy WE Series User manual

The WiFi dongle can be powered up on the
USB port on the underside of the inverter,
or another USB supply if the inverter
is not yet powered up.
WiFi dongle serial
numbers start
with W
WiFi has a
reset button
4G has a
SIM card slot
You can tell the difference by removing
the blue rubber cap at the base of the
device and taking a look inside.
USB Dongles come in 2 varieties, WiFi and 4G.
S/N: W 0000X000
Insert the dongle into the USB port
on the underside of the GivEnergy Hybrid
Inverter.
IMPORTANT! Please ensure the dongle is
screwed into the bottom of the
inverter on both sides.
Setting up your WiFi Dongle
Solid light
Connected
Flashing light
Connecting

Select your WiFi
network from the
list.
Click Apply.
Click Refresh if
your network
doesn’t appear
(see troubleshooting
for more support).
RSSI (signal strength) should be at least
50% for a reliable signal.
A WiFi booster/extender may be required
if signal strength is <50% (see diagram).
5 6
78
1 2 3
4
Select AP Interface
Setting.
Select WPA2-PSK
from the drop down
menu in Security
Mode.
Click Apply.
Note: If desired
network does
not appear, you
can manually
enter it here.
Enter the
customer’s WiFi
password.
Click Apply.
Access your WiFi settings.
Select the WiFi network
that matches the dongle
serial number.
Click Connect when
it is visible (ensure
Connect automatically
is ticked).
Select
Mode Selection.
Select
STA mode.
Click Apply.
Connecting to the dongle
Connecting to your WiFi network
Select ModeConnecting to the dongle
Re-securing your network
Select Device
Management.
Select Restart.
9Restart Dongle
Open your
web browser
(preferably Google
Chrome).
Type 10.10.100.254
into the address bar.
When prompted
enter:
Username: admin
Password: admin
Select
STA Interface
Setting.
Click the
Search button.
WE / WF Serial Number Dongles
Choose a password
(inverter serial no.
is recommended).
Click Apply.

Select your WiFi
network from the
list.
Click OK.
Click Refresh if
your network
doesn’t appear
(see troubleshooting
for more support).
RSSI (signal strength) should be at least
50% for a reliable signal.
A WiFi booster/extender may be required
if signal strength is <50% (see diagram).
Select Restart.
5 6
78
1 2 3
4
Select AP setting.
Select WPA2-PSK
from the drop down
menu in Select
Channel.
Choose a password
(inverter serial no. is
recommended).
Click Save.
Note: If desired
network does
not appear, you
can manually
enter it here.
Enter the
customer’s WiFi
password.
Click Save.
Access your WiFi settings.
Select the WiFi network
that matches the dongle
serial number.
Click Connect when
it is visible (ensure
Connect automatically
is ticked).
Select Work Mode.
Select
STA mode.
Click Save.
Connecting to the dongle
Connecting to your WiFi network
Select ModeConnecting to the dongle
Re-securing your network Restart Dongle
Open your
web browser
(preferably Google
Chrome).
Type 10.10.100.254
into the address bar.
When prompted
enter:
Username: admin
Password: admin
Select STA Setting.
Click the
Scan button.
Solid light
Connected
Flashing light
Connecting
WZ Serial Number Dongles

Adding a WiFi extender
Position the WiFi Repeater approximately midway between the Router and the
Inverter.
When installing the
Inverter and the router
is situated on the other
end of the building. A
WiFi repeater may be
needed for a good
connection between
the GivEnergy Dongle
and the Internet router
need to communicate.
GivEnergy
Dongle
GivEnergy
Dongle
Router
Dead
Zone
Router
Troubleshooting
Only one device can be connected to the dongle at any one time. If multiple
devices are connected, it may disconnect you from the dongle.
The SSID of the WiFi extender should be a different name from the customer’s
main network (i.e. add _EXT to the end).
You can manually write in a networks SSID in the Network Name box if it
does not show in the list of available WiFi networks.
The USB plug on the dongle has 4 pins, the two outer pins are power and are
longer, the two inner pins are data and are shorter - make sure the dongle is
screwed into the inverter.
When entering a password, remember that passwords are case sensitive.
If you cannot find the customer’s WiFi network, try restarting the customer’s
Internet Router.
WE and WF serial number dongles are 2.4 gHz, WZ serial number dongles
are 2.4gHz and 5gHz.
If you require further support, please contact us
01377 252 874
If you can’t connect to the dongle as the W###### network is password
protected - try your Inverter serial number, if not RESET THE DONGLE. This
can be done by pressing the small button under the cover on the bottom of
the dongle.
Signal strength (RSSI) should be at least 50% for a reliable connection. A WiFi
extender may be required if signal strength is lower than 50%.
Ensure the dongles W###### WiFi network is password protected in the AP
Settings page.
When installing the
Inverter into an
outbuilding, such as a
garage, the signal may
not be strong enough
to reach the
dongle.
