GL-INET Convexa-B User manual

Convexa-B
(GL-B1300)
USER MANUAL

Page 1 | 3
Table of Contents
1. Getting Started with GL.iNet Convexa-B..........................................................................1
1.1. Power on ................................................................................................1
1.2. Connect..................................................................................................2
(1) Connect via LAN............................................................................................................2
(2) Connect via Wi-Fi..........................................................................................................3
1.3. Access the Web Admin Panel ................................................................3
(1) Language Setting...........................................................................................................4
(2) Admin Password Setting............................................................................................4
(3) Admin Panel.....................................................................................................................5
2. INTERNET......................................................................................................................................6
2.1. Cable......................................................................................................7
(1) DHCP...................................................................................................................................8
(2) Static....................................................................................................................................8
(3) PPPoE.................................................................................................................................9
2.2. Repeater...............................................................................................10
2.3. USB 3G/4G Modem..............................................................................11
Compatible Modems................................................................................................................ 13
2.4. Tethering ..............................................................................................14
3. WIRELESS................................................................................................................................... 15
4. CLIENTS....................................................................................................................................... 17
5. UPGRADE.................................................................................................................................... 17
5.1. Online Upgrade ....................................................................................17
5.2. Upload Firmware ..................................................................................18
(1) Official OpenWrt/LEDE firmware......................................................................... 18
(2) Compile your own firmware................................................................................... 19
5.3. Auto Upgrade .......................................................................................19
6. FIREWALL................................................................................................................................... 19
6.1. Port Forwards.......................................................................................20
6.2. Open Ports on Router...........................................................................21
6.3. DMZ......................................................................................................21
7. VPN................................................................................................................................................. 22
7.1. OpenVPN .............................................................................................22

Page 2 | 3
7.1.1. OpenVPN Client..................................................................................................... 22
7.1.2. OpenVPN Server................................................................................................... 27
7.2. WireGuard............................................................................................30
7.2.1. WireGuard Client.................................................................................................... 30
WireGuard Providers................................................................................................................ 33
7.2.2. WireGuard Server.................................................................................................. 34
7.2.3. Wireguard App Support.........................................................................37
Visit Client’s LAN Subnet .................................................................................37
7.3. VPN Policies.........................................................................................38
7.3.1. Settings....................................................................................................................... 38
7.3.2. Add VPN policy....................................................................................................... 39
7.3.3. Clear DNS cache................................................................................................... 41
8. APPLICATIONS......................................................................................................................... 41
8.1. Plug-ins.................................................................................................41
8.2. Internet Kill Switch................................................................................42
Setup............................................................................................................................................... 43
8.3. File Sharing ..........................................................................................45
8.3.1. Router settings........................................................................................................ 45
8.3.2. Access the storage device................................................................................. 46
8.3.3. Windows..................................................................................................................... 46
8.3.4. Mac OS....................................................................................................................... 51
8.2.5. iOS....................................................................................................................................... 54
8.2.6. Linux............................................................................................................................. 58
8.2.7. ChromeOS or ChromiumOS (Neverware CloudReady and others) 58
Android........................................................................................................................................... 59
8.3. DDNS ...................................................................................................72
8.4. Cloud....................................................................................................79
Introduction................................................................................................................................... 79
Setup............................................................................................................................................... 80
Manage your devices............................................................................................................... 88
Site to Site..................................................................................................................................... 94
Batch Setting.............................................................................................................................103
Template Management.........................................................................................................106
Task List.......................................................................................................................................108

Page 3 | 3
GoodCloud and VPN.............................................................................................................109
Disable..........................................................................................................................................110
8.5. Tor......................................................................................................113
9. MORE SETTINGS..................................................................................................................123
9.1. Admin Password.................................................................................124
9.2. LAN IP................................................................................................124
9.3. Time Zone ..........................................................................................125
9.4. MAC Clone.........................................................................................126
9.5. Custom DNS Server...........................................................................127
9.6. Button Settings...................................................................................128
9.7. Network Mode ....................................................................................129
9.8. Revert Firmware.................................................................................130
9.9. Advanced............................................................................................131
10. Troubleshooting..................................................................................................................132
10.1. LED Indicators....................................................................................132
GL-B1300......................................................................................................133
LED Customization........................................................................................133
10.2. Repair or Reset...................................................................................134
10.3. Debrick via Uboot................................................................................135
10.4. Change WAN to LAN..........................................................................138
10.5. Captive Portal .....................................................................................140
10.6. GL.iNet app.........................................................................................142
10.7. Access Web Panel..............................................................................144
Check connection/router's IP address............................................................................144
Your IP address is incorrect................................................................................................144
Your IP address is correct....................................................................................................144
10.8. Extensible Authentication Protocol (EAP)............................................145
Introduction.................................................................................................................................145
Connect via web panel..........................................................................................................146
Connect via Luci.......................................................................................................................149
10.9. GoodCloud issues...............................................................................151
How to fix if my device show "Deactivated".................................................................151

Page 1 | 152
1. Getting Started with GL.iNet Convexa-B
Model:
GL-B1300
1.1. Power on
Plug the power cable into the power port of the router.

Page 2 | 152
1.2. Connect
You can connect to the router via Ethernet cable or Wi-Fi.
Note: This step only connects your devices to the local area network (LAN) of the
router. You cannot access the Internet currently. In order to connect to the
Internet, please finish the setup procedures below and then follow Internet to set
up an Internet connection.
(1)Connect via LAN
Connect your device to the LAN port of the router via Ethernet cable.

Page 3 | 152
(2)Connect via Wi-Fi
Search for the SSID of the router in your device and input the default password:
goodlife.
Note: The SSID was printed on the bottom label of the router with the following
formats:
•GL-B1300-XXX
•GL-B1300-XXX-5G
1.3. Access the Web Admin Panel
Open a web browser (we recommend Chrome, Firefox) and visit
http://192.168.8.1. You will be directed to the initial setup of the web Admin
Panel.

Page 4 | 152
(1)Language Setting
You need to choose the display language of the Admin Panel. Currently, our
routers support English, 简体中文, 繁體中文, Deutsch, Français, Español and
日本語.
Note: If your browser always redirects to Luci (http://192.168.8.1/cgi-bin/luci), you
can visit: http://192.168.8.1/index.html instead of http://192.168.8.1.
(2)Admin Password Setting
There is no default password for the Admin Panel. You have to set your own
password, which must be at least 5 characters long. Then, click Submit to
proceed.

Page 5 | 152
Note: This password is for this web Admin Panel and the embedded Linux
system. It will not change your Wi-Fi password.
(3)Admin Panel
After the initial setup, you will enter the web Admin Panel of the router. It allows
you to check the status and manage the settings of the router.

Page 6 | 152
2. INTERNET
There are total 4 types of connection method that you can use to access the
Internet: Cable, Repeater, 3G/4G Modem and Tethering.
Click INTERNET to create an Internet connection.

Page 7 | 152
2.1. Cable
Connect the router to the modem or main router via Ethernet cable to access the
Internet.
Before plugging the Ethernet cable into the WAN port of the router, you can click
Use as LAN to set the WAN port as a LAN port. That is useful when you are using
the router as a repeater. As a result, you can have one more LAN port.

Page 8 | 152
Plug the Ethernet cable into the WAN port of the router. The information of your
connection will be shown on the Cable section. DHCP is the default protocol. You
can click Modify to change the protocol.
(1)DHCP
DHCP is the default and most common protocol. It doesn't require any manual
configuration.
(2)Static
Static is required if your Internet Service Provider (ISP) has provided a fixed IP
address for you or you want to configure the network information such as IP
address, Gateway, Netmask manually.
The current settings will be automatically filled once you choose Static. Change it
according to your needs and then click Apply.

Page 9 | 152
(3)PPPoE
PPPoE is required by many Internet Service Providers (ISP). Generally, your ISP
will give you a modem and provide you a username & password that you needed
when you are creating the Internet connection.
Under PPPoE protocol, enter your username and password, then click Apply.

Page 10 | 152
2.2. Repeater
Using Repeater means connecting the router to another existing wireless
network, e.g. when you are using free Wi-Fi in a hotel or cafe.
It works in WISP (Wireless Internet Service Provider) mode by default, which
means that the router will create its own subnet and act as a firewall to protect
you from the public network.
In Repeater section, click Scan to search for the available wireless networks
nearby.
Choose a SSID from the drop-down list and enter its password. You can also
enable the Remember button to save the current chose wireless network.
Finally, click Join.

Page 11 | 152
2.3. USB 3G/4G Modem
You can connect to the Internet using a USB 3G/4G modem. Insert your SIM
card into the USB modem Plug the USB modem into the USB port of the router.
Once it has been detected, the 3G/4G modem section will be activated and you
will be able to set up your USB modem.
Be aware that some modems work in host-less mode, which will be configured
through Tethering but not 3G/4G modem.
Click Auto Setup to create the connection.
You can also click Manual Setup to set up manually.
In General, you can set up by the three basic parameters below. Click Apply to
connect.
•Device: Choose /dev/cdc-wdm0 if your modem supports QMI, otherwise
you need to choose /dev/ttyUSB, which may include several ttyUSB from 0
to 3. You need to choose the correct one based on the modem spec. We
suggest you try ttyUSB0 first.
•Service Type: Indicate the service type of your SIM card.
•APN: Confirm with your SIM card carrier.

Page 12 | 152
More:
•Dial Number: Generally, it is a default value and you don't need to set it
manually. However, if you have this info, please input it.
•Pincode, Username and Password: Generally, these are not necessary for
an unlocked SIM card. However, if you have a locked SIM card, please
consult your service provider.
It is connected when the IP address of your SIM card shows up.

Page 13 | 152
Compatible Modems
Here is a list of supported modems that we had tested before.
Model
3G/4G
Tested
Tested by
Comments*
Quectel EC20-E, EC20-A,
EC20-C
4G
Yes
GL.iNet
Quectel EC25-E, EC25-A,
EC25-V, EC25-C
4G
Yes
GL.iNet
Quectel UC20-E
3G
Yes
GL.iNet
ZTE ME909s-821
4G
Yes
GL.iNet
Huawei E1550
3G
Yes
GL.iNet
Huawei E3276
4G
Yes
GL.iNet
TP-Link MA260
3G
Yes
GL.iNet
ZTE M823
4G
Yes
Arnas
Risqianto
ZTE MF190
3G
Yes
Arnas
Risqianto
Huawei E3372
4G
Yes
anonymous

Page 14 | 152
Pantech UML290VW (Verizon)
4G
Yes
GL.iNet/steven
QMI
Pantech UML295 (Verizon)
4G
Yes
GL.iNet/steven
Host-less
Novatel USB551L (Verizon)
4G
Yes
GL.iNet/steven
QMI
Verizon U620L (Verizon)
4G
Yes
Host-less
*QMI: This modem supports QMI mode. Please choose /dev/cdc-wdm0 in the
Device list.
*Host-less: This modem supports tethering mode, please set up by using
Tethering but not 3G/4G modem.
You can also refer to http://ofmodemsandmen.com/supported.html for a well-
supported modem list.
2.4. Tethering
Using USB cable to share network from your smartphone to the router is called
Tethering. Host-less modem works in Tethering during the setup of the modem
as well.
For host-less modem tethering, plug it into the USB port of the router.
For smartphone tethering, connect it to the USB port of the router and click Trust
to continue when the message pops up in your smartphone.
After plugging in your device, the Tethering section will update and your device
will be shown on the device list. The device name will begin with eth or usb such
as eth2, usb0. Choose your device and click Connect.

Page 15 | 152
3. WIRELESS
In WIRELESS, you can check the current status and change the settings of the
wireless network created by the router. The wireless network can be turned on or
off by switching the ON/OFF button.
Wi-Fi Name (SSID): The name of the Wi-Fi. It is not suggested to use unicode
characters such as Chinese.
Wi-Fi Security: The encryption method of the Wi-Fi.
Wi-Fi Key: The password of the Wi-Fi, which must be at least 6 characters long.
We suggest you to change it when you receive the router.
Hide SSID: Show or hide the SSID.
Channel: The router will not choose the best channel itself. You need to choose
a channel manually. If your router is used as a Wi-Fi repeater, the channel will be
fixed according to the connected wireless network.
Speed: The wireless speed of the router.
TX Power (dBm): It specifies the signal strength. The default value is 20
(Strongest).

Page 16 | 152
Click Modify to change the settings of the wireless network.
