Glas-Col FlexiVap 109A YH-1/YH-1-HF Quick guide

- 1 -
User Instructions
711 HULMAN STREET
PO BOX 2128
TERRE HAUTE, IN 47802
812-235-6167
FAX [phone]
OPERATING AND SAFETY INSTRUCTIONS
For
FlexiVap™ Work Station
109A YH-1/YH-1-HF (24 Pos.)
109A YH-2/YH-2-HF (48 Pos.)
109A YH12 (120V heat block, optional)
109A YH24 (240V heat block, optional)

- 2 -
Knobs to turn
flow on/off for
each position
Metal luer locks
& needles
Optional heat
source for samples
109A YH12 or
109A YH24
Rack & Pinion Drive
Flow Meter
(24 Pos. shown above)

- 3 -
Unpack the FlexiVap work station. The unit comes unassembled so it is not damaged
during shipping.
Take the rack & pinion drive and mount it to the base with the four screws provided.
Place the manifold on the two dowel pins located on the rack & pinion drive and secure it
with the two screws provided.
Next secure the 1/8” tubing from the flowmeter to the manifold as shown in the diagram
below.
Flowmeter
(Rear View)
Manifold
(Top View 24 pos.shown)

- 4 -
Heat Block Info.:
Specifications:
Ambient Temperature: 77°F/25°C +/-5°
Operating Environment: 0 to 90% relative
humidity
32 to 100°F/0 to 37°C
Set-Up:
Place the heat block control onto the two dowel pins located on your
FlexiVap work station base. Plug the power cord from the control into a
grounded outlet. The power switch for the control is located on the front
of the unit. Connect the thermocouple from the heated block to the
control.
Loading the Block:
Position an aluminum insert on the top of your heat block. The unit is now
ready for operation.
Operating the Unit:
Once the power switch is engaged, the block will start heating. To change the
temperature setting:
Press SET. SP text will appear on the display.
Press SET again. The setpoint value is shown on the display.
The value can be modified with the UP and DOWN arrows.
Press SET to enter any new values.
Press SET and DOWN at the same time to quit programming or wait one minute
and the display will automatically exit programming mode.
Maximum temperature of the block is 100oC. The control is factory set and cannot
exceed this maximum temperature limit.
Maintenance:
Glas-Col heaters do not require regularly scheduled maintenance. However, regular
inspection is recommended. Glas-Col heaters should be protected from chemical spillage,
mechanical damage and corrosive atmospheres so far as possible. Contamination,
overheating and general misuse will greatly reduce the life of the block heater.

- 5 -
Spare Parts:
Spare parts for Glas-Col products are generally available from the factory. Consult Glas-
Col for part numbers and pricing.
R80 1010 - Top knobs for air flow
R96 724 –16GA. X 2-3/4” S.S. needles
R66 452 –Silicone tubing
R12 179 –Thermocouple
Catalog Number
Description
Input
Voltage
Max
PSI
Product
Weight
(lbs)
109A YH-4812
Aluminum Insert Block with 48 positions for up to 12
mm vials (Use with large system)
N/A
N/A
3
109A YH-4815
Aluminum Insert Block with 48 positions for 15 mm to
16mm vials (Use with large system)
N/A
N/A
3
109A YH-4828
Aluminum Insert Block with 24 positions for up to
28mm vials(Use with large system)
N/A
N/A
3
109A YH-2412
Aluminum Insert Block with 24 positions for up to
12mm vials (Use with small system)
N/A
N/A
2
109A YH-2416
Aluminum Insert Block with 24 positions for 15mm to
16mm vials (Use with small system)
N/A
N/A
2
109A YH-2428
Aluminum Insert Block with 12 positions for up to
28mm vials (Use with small system)
N/A
N/A
2

- 6 -
Limited Warranty
See the current Glas-Col warranty policy located under the General Sales Policy on the
Glas-Col website at www.glascol.com.
Returns:
Call or fax Customer Service for a Return Goods Authorization (RGA) number before
returning a heating mantle.
Reference the RGA number on the shipping box and on a written description of the
problem.
A 20% restocking charge of the net price is changed for all standard products returned to
stock.
Glas-Col, LLC
711 Hulman Street, P.O. Box 2128, Terre Haute, IN 47802-0128
Phone. [phone], Fax. [phone]
E-mail: [email protected]
Web: www.glascol.com
