Glen GL 3078 User manual

Induction Cooker
GL 3078
User’s Guide
with
Pre-Set Cooking
Functions
• Touch temperature
0
control (60 - 280 C)
• Timer 24 hours
• Auto cut off after 60 seconds
• High quality ceramic glass plate
LARGE
DISPLAY
LED
LED

Elec./Volt.
Down
Timer/Pre.
Function
Up
On/Off
Identify your Induction Cooker
How Induction Cooking Works
•An electric voltage is applied on a conductor spool
beneath the ceramic glass.
•This produces a high-frequency electromagnetic field.
The field penetrates the metal of the ferrous (magnetic-
material) cooking vessel and generates heat.
•The heat generated in the cooking vessel is transferred
to the vessel's contents.
•Nothing outside the vessel is affected by the field. As
soon as the vessel is removed heat generation stops.
Ceramic Glass Plate
Operation &
Display Panel
Operation & Display Panel
Timer
Voltage
Function
Selector
On/Off
Switch

Induction Cooking Advantages
• It is a
• Instant & precise heat control, unlike electric cooking where the elements take time
to heat and cool, resulting in lack of proper control on the dishes being cooked.
• There is no heat wastage as the energy is supplied directly to the cooking vessel
unlike gas or conventional electric cookers where they end up heating your kitchen
and you, instead of heating up the food.
• High safety no open flames, no fire hazards, no gas leakages. The glass top stays
cool that means no burnt fingers or hands.
• Once you take the cookware off the hotplate, the device automatically switches to
standby mode.
• The device detects whether suitable cookware is placed on the hotplate. If this is
not the case, no energy is transmitted.
• As the hotplate is only heated up indirectly via the bottom of the cookware, over
spilling food cannot stick and burn.
powerful cooking medium, just like or even better than gas.
Setting up your Induction Cooker
• Check the device for visible damage.
• Place the device on a stable and level surface.
• Never place the device on a flammable surface (e.g. table cloth, carpet, etc.).
• Do not block the ventilation slots of the device. This may overheat the device. Keep
a minimum distance of 5 to 10 cm from the walls or other items.
• Do not place the induction Cooker next to devices or objects which react
sensitively to magnetic field (e.g. radios, TVs, cassette recorders, etc.).
• Do not place induction Cooker next to open fires, heater or other sources of heat.
• Make sure that the mains connection cable is not damaged or squashed beneath the
device and does not came into contact with sharp edges and / or hot surface.
• The device should be connected to a rolled-out extension cable with a maximum
length of 3m and a cross-section of 2mm. If an intermediate switch is used, it must
be rated at min. 16A.
Using your Induction Cooker
When the device is turned on a beep sound comes on. The cooker is in standby mode.
At this point a red LED glows below the start/stop switch.
The display indication is
Now put the pan on the cooker and press the ON/OFF switch. The display indication
shows ON. Select the appropriate function for your cooking using the function
selector switch. You can choose from a selection of pre-set functions.

Function Power /Temp Setting
HOT POT 1400 W Timer & temperature adjustable setting
STIR FRY 200 °C Timer & temperature adjustable setting
BAR-B-QUE 220 °C Timer & temperature adjustable setting
FRY 200 °C Timer & temperature adjustable setting
SOUP 1600 W Pre set power/temperature, Timer adjustable
RICE 1000 W Pre set power/temperature, Timer adjustable
STEW 1600 W Pre set power/temperature, Timer adjustable
WATER 1800 W Pre set power/temperature, Timer adjustable
MILK 8 Pre set power/temperature, Timer adjustable0 °C
Hot Pot This function is designed to boil water. During heating, you can adjust the
temperature and time as per your requirement. The timer can be adjusted anywhere upto 4
hours. In case of abnormally high heat, the cooker switches to standby mode and starts re-
heating after cooling down.
Stir Fry This is a function designed for cooking of vegetables etc. During cooking the
temperature and time can be adjusted as required.
Bar-b-Que
Fry This is a function designed for frying vegetables etc. During cooking the temperature
and time can be adjusted as required.
Soup Take 4 cups of soup stock in a pan. Select the soup function. After the set time, the
cooker switches to keep warm status.
Stew
Water This function is used for boiling or steaming. Select the water function.
This is the default function and is selected automatically when the cooker is switched ON,
or if no other function is selected.
Note : The results may vary depending on the power supply, quality of ingredients and the
amount of water.
Timer The cooking can be set to a desired time with the help of the timer.
Press the timer button, and adjust the display to set the time with the help of (+) and (-)
buttons.
Once set the display would flash the set time and then begin the countdown. After the set
time elapses the cooker will automatically switch off.
Heat Adjustment The cooker automatically sets to the required temperature in case of
pre-set functions. However it is possible to manually adjust it as per requirement in case of
Hot-Pot, Fry and Stir Fry functions.
0 0
The temperature can be set manually to Ten levels (from 60 C to 280 C) using the (+) and (-)
buttons. The set temperature level is displayed on the digital screen.
Rice Cooking Take a cup of rice, soaked for half an hour. Put the rice along with 2 cups of
water into the pan. Switch on the cooker. Select the rice function. After the stipulated time,
the induction cooker will switch off to keep warm mode.
Milk This function is designed to keep the milk warm. In case you adjust the Power level
please supervise the boiling otherwise the milk may spill over.
0 0
Timer 24 Hours l Temperature Range 60 C to 280 C

Rounded Bottom
Pot
Aluminum
Copper Pot
Bottom Measuring
Less than 12cm
Pot with Stands Ceramic Pot
Glass Pot
Heat-Resistant
Enameled Iron
Pot
Iron or Enameled
Iron Pot
Castiron Pan Iron Pot Deep-Fry Pan Stainless Steel Pot Iron Plate
Error Code Reason Solution
E1 Plate surface temperature Please contact the supplier or go
sensor open to a qualified service centre
E2 IGBT temperature Please contact the supplier or go
sensor mulfunction to a qualified service centre
E3 Abnormal supply voltage; Check power supply. Switch on
voltage too high after power supply is back to normal
E4 Abnormal supply voltage; Please check power supply. Switch on
voltage too low after power supply is back to normal
E5 Plate surface Please wait fo a few
temperature sensor minutes until the unit cools
short-circuited because down and check pot/pan
of empty pot/pan
E6 Fan failure; Air intake/ Please contact the supplier or go to a
exhaust vent blockage. qualified service centre. Clean the vent
after the unit cools down, then restart
E7 Coil panel is not connected Please contact the supplier or go to a
well; circuit malfunction qualified service centre
E8 No pot/pan on the plate. Non Put suitable cooking
-usable pans on the plates utensils on the plates.
Possible Error Messages and their Solution
Suitable and unsuitable cookware for induction cooking
Suitable Cookware
•Pots and pans with magnetic bottom, as stainless steel pots with iron bottom, cast
iron enameled pans.
•Flat-bottom pans and pots with a diameter of 12 to 24 cm with magnetic bottom.
•Max. weight pot and content should not exceed 6 kg.
Unsuitable Cookware
•Pots/pans with a diameter of less than 12 cm.
•Ceramic pots, heat-proof glass.
•Copper pots and pans, aluminium pots and pans.
•Cookware with feet.
•Containers with a curved bottom.

Safety Precautions
•The hotplate surface is made up of temperature-resistant toughened ceramic glass.
However necessary precautions in handling of glass are very important. The
breakage of glass due to any reason is not covered under guarantee.
•In case of damage, even if this concern only a small tear, disconnect the device from
the power supply immediately and contact the customer service.
•We recommend not placing any metal kitchen utensils, cookware or pan lids,
knives or other metal objects on the hotplate. These may heat up when the device is
turned on.
• Place the hot pans in the hob area only. Never place them on the control panel or
the frame.
•Do not place any magnetics objects like credit cards, cassettes etc. on the glass
surface while the device is in operation.
•In order to avoid overheating, do not place any aluminium foil or metal plates on
the device.
• Warning: Please do not put the induction cooker on an iron / steel board, while
operating. Due to electromagnetic reason, the iron / steel board may heat and
damage the bottom of the induction cooker.
• Your Induction Cooker is provided with a cooling fan which keeps the internal
temperature under control. Once the cooking is over the fan is still running so
don't switch off the mains till the time the fan is running.
•Do not insert any objects like wires or tools into the ventilation slots. This may
cause electric shocks.
•Do not touch the hot surface of the ceramic field. Please note the induction hotplate
does not heat up itself during cooking, but the temperature of the cookware heats
up the hotplate!
•Do not heat up any unopened tins on the induction hotplate. A heated tin could
explode; therefore remove the lid under all circumstances beforehand.
•If you do not use the device for an extended period, we recommend you disconnect
it from the electric outlet.
•Never touch the device and the power plug with wet hands.
•Do not connect the device to the same outlet with other devices.
Connect the device to a suitable outlet.
•Never move the device by pulling on the power cable.
•Do not move the induction hotplate during cooking or with hot cookware on
top of it.
•Never use the device when it does not function properly, shows damage or in case it
was dropped.
•Do not leave the device unsupervised during operation. Keep children and other
incompetent persons as well as persons under influence of drugs or alcohol away
from the device.

• Warning: This appliance is not intended for use by persons (including children)
with limited physical, sensory or metal abilities or who lack the necessary
experience and / or skills unless these persons act under the supervision of a person
responsible for their safety or they were instructed by such a person on how to use
the appliance.
•Do not submerge the device in water or other liquids and do not wash it in the
dishwasher.
•Only qualified experts may perform repair and maintenance work on the device
using original replacement and accessory parts. Never attempt to repair the device
yourself!
•Scientific tests have proven that induction hotplates do not pose a risk. However,
persons with a pacemaker should clear with their doctor weather to take care of
some special handling advises.
Cleaning and Maintenance
• Unplug the power prior to cleaning the device. Do not use any caustic
cleaning agents and make sure that no water penetrates the device.
• To protect yourself from electric shock, never immerse the device, its cables
and the plug in water or other liquids.
• Wipe off the ceramic field with a damp cloth or use a mild, non-abrasive soap
solution.
• Wipe off the casing and the operating panel with a soft cloth or a mild detergent.
• Do not use any petrol products as they may damage the plastic parts and the
casing/operating panel.
• Do not use any flammable, acidy or alkaline materials near the device, as this may
reduce the service life of the device and lead to deflagration when the device is
turned on.
• Make sure that the bottom of the cookware does not scrape across the surface of the
ceramic field, although a scratched surface does not impair the use of the device.
• Make sure that the device was properly cleaned before storing it in a dry place.
Specifications
Model No. GL 3078
0 0
Temperature range : 60 to 280 C
Power : 2000 Watt
Connection : 220-240 V AC / 50 Hz
Dimensions I/w/h : 335 mm x 415 mm x 85 mm

DEALER'S STAMP & SIGNATURE
SERIAL NO.
GL 3078
MODEL NO.:
DATE OF PURCHASE
Glen Appliances Pvt. Ltd.
Customer Care & H.O.
I-34, D.L.F. Industrial Area, Phase I, Faridabad-121003, India
Helpline: 0129-2254191
Email: [email protected] www.glenindia.com
WARRANTY
This is fully warranted against any defect arising out of defective
materials or faulty workmanship for a period of one year from the date of purchase.
Should any defect develop in this product, the customer should bring the product to
the nearest authorised service centre, where the company undertakes to get the
product repaired free of charge.
This warranty is not valid if :
• The use and care instructions have not been followed.
• Defects are caused by accident, misuse, abuse or commercial use.
• The repair work is carried out by persons not authorised by the company.
• The serial no. has been deleted, defaced or altered.
• Any modification or alteration of any nature is made in the product.
• Normal wear & tear of the product is not covered under warranty
• The Bill/Cash memo and copy of warranty card is not presented.
• The breakage of glass due to any reason whatsoever is not covered under warranty.
Under no circumstances, whether based on limited warranty or otherwise shall the
company be liable for incidental, special or consequential damages. Use of product
indicates acceptance by you of the aforesaid terms and conditions.
Induction Cooker
