Glensound Dante AOIP2M Installation guide

6 BROOKS PLACE, MAIDSTONE, KENT, ME141HE. ENGLAND. TEL: [phone]
Visit our website at www.glensound.com FAX: [phone]
AOIP2M
2 Channel Dante Microphone Preamplifier
PRODUCT DETAILS

Page 2of 21
Glensound Electronics Ltd
Thank you for choosing a new Glensound product.
All rights reserved.
Information contained in this manual is subject to change without notice, if in
doubt please contact us for the latest product information.
If you need any help with your product then we can be contacted at:
Glensound Electronics Ltd
1 –6 Brooks Place
Maidstone
Kent
ME14 1HE
United Kingdom
Telephone: [phone]
Fax: [phone]
EMAIL ADDRESSES
General and Technical enquires: [e-mail]
Sales enquires: [e-mail]

Page 3of 21
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions
2) Keep these instructions
3) Heed all warnings
4) Follow all instructions
5) Do not use this apparatus near water
6) Clean only with a dry cloth
7) Do not block any ventilation openings. Install in accordance with manufacturer’s
instructions
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat
9) Do not defeat the safety purpose of the polarized or grounding type plug. A
polarized plug has 2 blades with one wider than the other. A grounding type plug
has 2 blades and third grounding prong. The wider blade or the 3rd prong are
provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet
10) Protect the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles and the point where they exit from the apparatus
11) Only use attachments/ accessories specified/ supplied by the
manufacturer
12) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/ apparatus combination to avoid
injury from tip over
13) Unplug this apparatus during lightning storms or when unused for long periods of
time
14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped
15) Do not attempt to modify this product. Doing so could result in personal injury and/
or product failure
This symbol is intended to warn that
dangerous voltages within the product are
present and constitute a risk of electric
shock.
This symbol is intended to highlight that
there are important operating &
maintenance instructions in the literature
accompanying this unit.

Page 4of 21
PRODUCT WARRANTY
All equipment is fully tested before dispatch and carefully designed to
provide you with trouble free use for many years.
We have a policy of supporting products for as long as possible and
guarantee to be able to support your product for a minimum of 10 years.
For a period of one year after the goods have been despatched the Company
will guarantee the goods against any defect developing after proper use
providing such defects arise solely from faulty materials or workmanship and
that the Customer shall return the goods to the Company’s works or their
local dealer.
All non-wear parts are guaranteed for 2 years after despatch and any defect
developing after proper use from faulty materials or workmanship will be
repaired under this warranty providing the Customer returns the goods to
the Company's works or their local dealer.

Page 5of 21
EU DECLARATION OF CONFORMITY
AOIP2M
2 Channel Dante Microphone Preamplifier
This declaration of conformity is issued under the sole responsibility of the
manufacturer.
This equipment is manufactured by Glensound Electronics Ltd of Brooks
Place Maidstone Kent ME14 1HE is marked and conforms to the
following Union harmonisation legislation:
Emissions: BS EN55032:2015
Immunity: BS EN55035:2017
Signed for and on behalf of Glensound Electronics Ltd.
Marc Wilson, Managing Director
Maidstone, Kent, England
Date: 02/09/2022

Page 6of 21
RoHS DIRECTIVE
RoHS 2 Directive 2011/65/EU restricts the use of the hazardous substances
listed below in electrical and electronic equipment.
This product conforms to the above directive and for these purposes, the
maximum concentration values of the restricted substances by weight in
homogenous materials are:
Lead
0.1%
Mercury
0.1%
Hexavalent Chromium
0.1%
Polybrominated Biphenyls
0.1%
Polybrominated Diphenyl
Ethers
0.1%
Cadmium
0.01%

Page 7of 21
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT
REGULATIONS 2006 (WEEE)
Glensound Electronics Ltd is registered for business to business sales of
WEEE in the UK our registration number is:
WEE/JJ0074UR

Page 8of 21
GLENSOUND AOIP2M
Handbook Contents
Description Issue 1.0 02/09/22 Page No.
Contents
IMPORTANT SAFETY INSTRUCTIONS ..............................................................................3
PRODUCT WARRANTY ......................................................................................................4
....................................................................................................................................5
RoHS DIRECTIVE.................................................................................................................6
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE)....7
Handbook Contents ..........................................................................................................8
Overview.............................................................................................................................9
AOIP2M Front Panel Layout ...........................................................................................10
Power LED...................................................................................................................................................10
Input Gain control....................................................................................................................................10
Mic activity..................................................................................................................................................10
Phantom power switch .........................................................................................................................10
Phantom power indicator ....................................................................................................................10
AOIP2M Rear Panel Layout.............................................................................................11
Microphone inputs..................................................................................................................................11
DC Power Input jack ...............................................................................................................................11
USB connector...........................................................................................................................................11
Network RJ45 etherCON .......................................................................................................................11
Audio Block Diagram ......................................................................................................12
Connecting The AOIP2M To A Dante Network.............................................................13
Getting Dante Controller ......................................................................................................................13
Connecting AOIP2M device to the network .................................................................................13
Audio Over IP Network ..........................................................................................................................13
Running Dante Controller ....................................................................................................................14
Dante Controller TIP ...............................................................................................................................14
Device not showing up in Dante Controller .................................................................................15
AES67 Mode .....................................................................................................................16
Turning On AES67 Mode.......................................................................................................................16
Sending AES67 Audio ............................................................................................................................16
Receiving AES67 Audio..........................................................................................................................17
AES67 Restrictions ...................................................................................................................................18
Updating The Dante firmware .......................................................................................19
Updating the device ...............................................................................................................................19
Wiring Information..........................................................................................................21

Page 9of 21
Overview
The Glensound AOIP2M is an analogue to digital converter with high quality
Microphone Preamplifiers designed to connect microphones to a Dante® audio
network.
Dante® network audio is a common protocol for distributing high quality linear audio
over standard IP networks and it is widely used by many audio equipment
manufacturers. The AOIP2M Dante® audio interface is compatible with all Dante® audio
interfaces across all manufacturers. Further details of Dante® network audio can be
found at www.audinate.com
Intended for live on-air broadcast applications, the AOIP2M is built into a rugged
lightweight aluminium chassis with anaodised and laser etched panels. Holes suitable
for temporarily attaching the unit with cable ties to hold it in place are provided for
ease of installation.
AES67 is supported by the Audinate’s Ultimo chipset and can be easily turned on/off
via Dante® controller.
Sample frequencies from 44.1 to 96kHz are supported by the unit when connected to a
Dante® network and 48kHz is supported when in AES67 mode.

Page 10 of 21
AOIP2M Front Panel Layout
Power LED
Power LED for power indication.
Input Gain control
Potentiometer for controlling microphone input gain.
Mic activity
Post-pot mic activity LEDs for monitoring Microphone level.
Phantom power switch
Press and hold for a few seconds to toggle +48V phantom power on for the selected
Mic channel.
Phantom power indicator
LED to indicate if +48V phantom power is on or off. Illuminates red.
Power LED
Mic activity
Input Gain
control
Phantom power indicator
Phantom power switch
