GLITZHOME Patio Gray Aluminum Sectional User manual

Assembly Instruction
Outdoor Patio Gray
Aluminum Sectional

1
PRE-ASSEMBLY PREPARATION
WARNING! DO NOT LET CHILDREN PLAY IN OR AROUND THE UNIT DUE TO THE POSSIBLE RISK OF FINGER ENTRAPMENT
•Please read through this instrucon before beginning assembly.
•Two adults assembly is recommended.
•Clear out the space for assembly and lay out all parts base on parts List, extra room will allow you to easily
determine if all the pieces are present.
•Save all packing materials unl assembly is complete to avoid accidentally discarding smaller parts or hardware.
•Keep small parts and pieces away from children unl fully assembly.
•Do not fully ghten the bolts unl all have been inserted and hand ghtened.
•
•
Please check for any loose screws and ghten them before use.
If there is any queson, please contact us first, we will quickly solve any doubt for you.
HARDWARE LIST
Wrench (P)Long Bolts (M)
M6 X 35mm
Gasket (O)Washers (N)
M6 X 20mm
Short Bolts (L)
M6 X 20mm
Qty: 96 Qty: 24 Qty: 120 Qty: 12 Qty: 1
PANEL AND FITTINGS IDENTIFICATION
Left Seater Sofa with
Side Table Panel (A1)
Table Top (E)
Qty: 1
Qty: 1
Seater Sofa with Side
Table and Armless
Sofa Seat Cushion (J)
Qty: 4
Corner Sofa Seat
Cushion (K)
Qty: 1
Right Seater Sofa with
Side Table Panel (A2)
Qty: 1 Qty: 3 Qty: 6 Qty: 20
Seater Sofa Panel (B) Back Panel (C) Sofa Legs (D)
Seater Sofa with Side
Table and Armless
Sofa Back Cushion (G)
Qty: 4
Qty: 4 Qty: 1 Qty: 1
Corner Sofa Back
Cushion (H)
Corner Sofa Back
Cushion (I)
Table Legs (F)

2
Step 2
Step 1
Aach 4 Sofa Legs (D) to Le Seater Sofa with Side Table Panel (A1) by using 16 Short Bolts (L)
and 16 Washers (N).
NOTE: From step 1 to step 2 is for both Seater Sofa with Side Table assembly.
Please find Panel A1, C and Sofa Leg D firstly.
Aach Back Panel (C) to Le Seater Sofa with Side Table Panel (A1) by using 2 Gaskets (O),
4 Long Bolts (M) and 4 Washers (N).
D
M
C
N
O
A1
L
N
Connect Tape (Q)
Qty: 12

3
Step 3
Repeat above Step 1 and 2 to assemble Right Seater Sofa with Side Table.
Step 4
Aach 4 Sofa Legs (D) to Seater Sofa Panel (B) by using 16 Short Bolts (L) and 16 Washers (N).
NOTE: From step 4 to step 5 is for Armless Seater Sofa assembly.
Please find Panel B, C and Sofa Leg D firstly.
N
L
B
D

4
M
Step 5
Aach Back Panel (C) to Armless Seater Sofa Panel (B) by using 2 Gaskets (O), 4 Long Bolts (M)
and 4 Washers (N).
C
N
O
Step 6
Aach 4 Sofa Legs (D) to Seater Sofa Panel (B) by using 16 Short Bolts (L) and 16 Washers (N).
NOTE: From step 6 to step 8 is for Corner Seater Sofa assembly.
Please find Panel B, C and Sofa Leg D firstly.
L
N
B
D

5
Step 7
Aach Back Panel (C) to Seater Sofa (B) by using 2 Gaskets (O), 4 Long Bolts (M) and
4 Washers (N).
Step 8 Repeat Step 7 to assemble the other Back Panel.
M
C
N
O
MC
N
O

6
Step 10
Connect Seater Sofa with Side Table and Armless Sofa and Coner Sofa by using 8 Connect
Tapes (Q).
Step 9
Aach 4 Table Legs (F) to Table Top (E) by using 16 Short Bolts (L) and 16 Washers (N).
NOTE: Step 9 is for Coffee Table assembly. Please find Table Top E, and Table Leg F firstly.
Armless
Sofa
Armless
Sofa
Corner Sofa
Seater Sofa with
Side Table
Table
N
F
E
L
Seater Sofa with
Side Table
Q

7
Step 11 Put on the Back Cushion (G & H & I) and Seat Cushion (J & K). Please make sure all bolts are
properly ghtened before use.
