Global Cache Flex Link Serial Cable User manual

Flex Link Serial Cable
Quick Start
Global Caché is lessening our carbon
footprint by reducing our paper
output. For complete documentation
and tutorials, visit:
www.globalcache.com/docs
Getting Started. Once the iTach Flex is
connected to the network by either an Eth-
ernet cable or WiFi, plug the Flex Link
RS232 or RS485 Serial cable into the Flex
Link Port.
To congure Serial cable functionality, right
click on the unit entry in iHelp* and select
Congure. To access the set up pages manu-
ally, type in the unit’s IP address. A web
browser will display the conguration pages.
On the Flex Link Cable page, select Serial
in the dropdown menu to congure the set-
tings as desired.
Flex Link 485 Serial Cable. e RS485
setting includes Baud Rate, Duplex, Parity,
Data Bits, and Stop Bits. Duplex is unique
to RS485 cables . It should be set to Full for
Flex Link Serial Cable
Quick Start
Global Caché is lessening our carbon
footprint by reducing our paper
output. For complete documentation
and tutorials, visit:
www.globalcache.com/docs
Getting Started. Once the iTach Flex is
connected to the network by either an Eth-
ernet cable or WiFi, plug the Flex Link
RS232 or RS485 Serial cable into the Flex
Link Port.
To congure Serial cable functionality, right
click on the unit entry in iHelp* and select
Congure. To access the set up pages manu-
ally, type in the unit’s IP address. A web
browser will display the conguration pages.
On the Flex Link Cable page, select Serial
in the dropdown menu to congure the set-
tings as desired.
Flex Link 485 Serial Cable. e RS485
setting includes Baud Rate, Duplex, Parity,
Data Bits, and Stop Bits. Duplex is unique
to RS485 cables . It should be set to Full for
Flex Link Serial Cable
Quick Start
Global Caché is lessening our carbon
footprint by reducing our paper
output. For complete documentation
and tutorials, visit:
www.globalcache.com/docs
Getting Started. Once the iTach Flex is
connected to the network by either an Eth-
ernet cable or WiFi, plug the Flex Link
RS232 or RS485 Serial cable into the Flex
Link Port.
To congure Serial cable functionality, right
click on the unit entry in iHelp* and select
Congure. To access the set up pages manu-
ally, type in the unit’s IP address. A web
browser will display the conguration pages.
On the Flex Link Cable page, select Serial
in the dropdown menu to congure the set-
tings as desired.
Flex Link 485 Serial Cable. e RS485
setting includes Baud Rate, Duplex, Parity,
Data Bits, and Stop Bits. Duplex is unique
to RS485 cables . It should be set to Full for

Global Caché, Inc.
160 East California Street
PO Box 1659
Jacksonville, Oregon 97530
Phone [phone] - Fax [phone]
www.globalcache.com - [email protected]
Copyright ©2016 Global Caché, Inc. All rights reserved.
PN: 022213-03 ver.4 Information subject to change without notice.
Global Caché
Global Caché, Inc.
160 East California Street
PO Box 1659
Jacksonville, Oregon 97530
Phone [phone] - Fax [phone]
www.globalcache.com - [e-mail]
Copyright ©2016 Global Caché, Inc. All rights reserved.
PN: 022213-03 ver.4 Information subject to change without notice.
Global Caché
4 signal RS485 and Half for 2 signal RS485.
Flex Link 232 Serial Cable. e RS232 set-
ting includes Baud Rate, Flow Control, Parity,
Data Bits, Stop Bits, and Gender.
e gender of a Flex Link Serial cable can be
changed using the included gender changer.
e setting should be set to True if the gender
changer is used or False if it is not used. If a
null modem cable is desired then the Gender
Changer setting should be inverted. Once selec-
tion is made click Save Conguration to apply
the new settings.
Disconnecting the Serial cable from the Flex
Link Port will reset all open TCP sockets and
reinitialize the Serial cable. All connections
must be reestablished after unplugging the cable
from the port.
Troubleshooting. See the iTach Flex Quick
Starts or visit our website for more information
on conguring Flex devices.
*To download the iHelp application visit
www.globalcache.com/downloads. Run iHelp
on a Windows PC that is connected to your
network.
This device complies with Part 15 of FCC rules and with
ICES-003 of Industry Canada. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference
Made in the U.S.A.
