GLUCKSTEIN ELEMENTS ANDERS 38706-HBC User manual

THANK YOU
USE AND CARE GUIDE
ANDERS 56-INCH INDOOR LED CEILING FAN
HOMEDEPOT.CA
Item #1001591931
Model #38706-HBC
create quality products designed to enhance your home. Visit us online to see our full line of products available for your
home improvement needs. Thank you for choosing Gluckstein Elements!
We appreciate the trust and confidence you have placed in Gluckstein Elements through the purchase of this ceiling fan. We strive to continually

2
Table of Contents ................................................................ 2
Safety Information............................................................... 2
Warranty ............................................................................... 3
Pre-Installation .................................................................... 3
Installation............................................................................ 6
Assembly............................................................................ 7
Operation ........................................................................... 13
Care and Cleaning.............................................................13
Troubleshooting................................................................. 14
To reduce the risk of electric shock, ensure the electricity has
been turned off at the circuit breaker or fuse box before you
begin.
All wiring must be in accordance with the National Electrical
Code ANSI/NFPA 70 and local electrical codes. Electrical
electrician.
The outlet box and support structure must be securely mounted
and capable of reliably supporting 15.9 kg (35 lbs). Use only UL-
listedoutlet boxes marked “Acceptable for Fan Support of 15.9 kg
Do not operate the reversing switch while the fan blades are in
motion. You must turn the fan off and stop the blades before
you reverse the blade direction.
Do not place objects in the path of the blades.
Safety Information
Table of Contents
READ AND SAVE THESE INSTRUCTIONS.
installation should be performed bya qualified licensed
IC Statement ...................................................................... 14
WARNING: To reduce the risk of personal injury, do not
WARNING:
WARNING: To avoid possible electrical shock,
turn the electricity off at the main fuse box before
wiring. If you feel you do not have enough electrical
wiring knowledge or experience, contact a licensed
electrician.
CAUTION: To reduce the risk of personal injury,
use only the screws provided with the outlet box.
CAUTION: To avoid personal injury or damage to the fan
and other items, use caution when working around or
cleaning the fan.
bend the blade brackets when installing the brackets,
balancing the blades, or cleaning the fan. Do not insert
foreign objects in between rotating fan blades.
To reduce the risk of fire, electric shock
or personal injury, mount to an outlet box marked
“acceptable for fan support of 15.9 kg (35 lbs) or less”
and use screws provided with the outlet box.
Thefan must bemounted with a minimumCAUTION:
of 7 ft. (2.1m) of clearance from the trailing edge of the
blades to the floor.
After making electrical connections, spliced conductors
should be turned upward and pushed carefully up into the
outlet box. The wires should be spread apart with the
grounded conductor and the equipment-grounding conductor
on one side of the outlet box and ungrounded conductor on
the other side of the outlet box.
All set screws must be checked and retightened where
necessary before installation.
Changes or modifications not expresslyCAUTION:
approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
WARNING:
shock, do not use this fan with any solid-state speed
control device.
To reduce the risk of fire or electric
WARNING:
fan must be installed with an isolating wall control/
switch.
To reduce the risk of electric shock, this
□
□
□
□
□
□
□
(35 lbs) or less”.

3
Pre-Installation
Warranty
TOOLS REQUIRED
NOTE: These are approximate measures. They do not
include the amps and wattage used by the light kit.
Phillips
screwdriver
Flat head
screwdriver
Adjustable
wrench
Electrical
tape
Wire
cutter
Step ladder
Contact the Customer Service Team visit WWW.HOMEDEPOT.CA
We warrant the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of a lifetime
after the date of purchase by the original purchaser. We warrant that the light kit to be free from defects in workmanship and material at the time of
shipment from the factory for a period of five years after the date of purchase by the original purchaser. We also warrant that all other fan parts,
excluding any glass or acrylic blades, to be free from defects in workmanship and material at the time of shipment from the factory for a period of
two years after the date of purchase by the original purchaser. We agree to correct such defects without charge or at our option replace with a
comparable or superior model if the product is returned. To obtain warranty service, you must present a copy of the receipt as proof of purchase. All
costs of removing and reinstalling the product are your responsibility. Damage to any part such as by accident, misuse, improper installation, or by
affixing any accessories, is not covered by this warranty. Because of varying climatic conditions, this warranty does not cover any changes in brass
finish, including rusting, pitting, corroding, tarnishing or peeling. Brass finishes of this type give their longest useful life when protected from varying
weather conditions. A certain amount of “wobble” is normal and should not be considered a defect. Servicing performed by unauthorized persons
shall render the warranty invalid. There is no other express warranty. We hereby disclaim any and all warranties, including but not limited to those
of merchantability and fitness for a particular purpose to the extent permitted by law. The duration of any implied warranty which cannot be
disclaimed is limited to the time period as specified in the express warranty. Some provinces do not allow limitation on how long an implied warranty
lasts, so the above limitation may not apply to you. The retailer shall not be liable for incidental, consequential, or special damages arising out of or in
connection with product use or performance except as may otherwise be accorded by law. Some provinces do not allow the exclusion of incidental or
consequential damages, so the above exclusion or limitation may not apply to you. This warranty gives specific legal rights, and you may also have
other rights which vary from province to province. This warranty supersedes all prior warranties. Shipping costs for any return of the product as part
of a claim on the warranty must be paid by the customer.
SPECIFICATIONS
722.90
213.27
158.88
2559.09
4753.87
5314.56
Size Speed Volts CFM
Fan Power
Consumption
(Without Lights)
WATT
(Higher Is Better)
CFM/WATT
Net
Weight
Gross
Weight Cubic Feet
56 in.
Low
120
33.45
2.28 cu. ft.
Medium 22.29
High
3.54
13.95 lbs
(6.33 kgs)
17.37 lbs
(7.87 kgs)
HOMEDEPOT.CA

4
Pre-Installation (continued)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
AA
BB
CC
DD
EE
Blade screw
Canopy screw (preassembled) 2
Wire nuts
13
3
1
13
1
Hitch pin (preassembled)
Fiber washer
2
FF
II
Set screw (preassembled)
AA
BB
EE
FF
GG
CC
DD
Part Description Quantity
Lock pin (preassembled)
HH
II
HH
Metal washer
GG
Wood screw 2
2
LL
JJ
2
Remote control holder screws
LL
6
Mounting screws (preassembled)
JJ
KK
3
Lamp shade screws (preassembled)
KK

5
PACKAGE CONTENTS
D
E
Hanger ball (preassembled)
Downrod (preassembled)
1
1
A
B
C
4
1
1
Fan blade
Mounting bracket
Canopy
Fan motor assembly
Remote control
1
J
1
G
B
F
E
D
C
A
I
Part Description Quantity Part Description Quantity
Pre-Installation (continued)
G
I
1
Remote control holder
J
K
L
Lamp shade
K
F 1Coupling cover
1
1
Battery CR2032
L
H
HDecorative canopy bottom cover 1
HOMEDEPOT.CA

6
Installation
MOUNTING OPTIONS
WARNING:
personal injury, mounttooutletbox marked “acceptable
for fan support of 15.9 Kg (35 lbs) or less” using the
screwsprovided with theoutlet box. An outlet box
not beacceptable for fan support and may need to be
If your ceiling fan does not have an existing UL-listed mounting
box, then install one using the following instructions:
□Disconnect the power by removing the fuses or turning off
the circuit breakers.
□Secure the outlet box directly to the building structure.
Use the appropriate fasteners and materials. The outlet box
and its bracing must be able to fully support the weight
of the moving fan (at least 15.9 kg). Do not use a plastic
outlet box.
The illustrations below show three different ways to mount the
outlet box.
If the canopy touches the downrod, then remove the decorative canopy
bottom cover, and turn the canopy 180° before attaching the canopy to
the mounting plate.
you may need an installation hanger bar as shown above.
NOTE: You may need a longer downrod to maintain
proper blade clearance when installing on a steep, sloped
ceiling. The maximum angle allowable is 23° away from
horizontal.
Outlet Box
Outlet Box
Recessed
Outlet
Box
Provide Strong
Support
Ceiling
Mounting
Plate
Outlet Box
Hanger Bar
To reduce the risk of fire, electric shock, or
commonly used for the support of lighting fixtures may
replaced. If in doubt, consult a qualified electrician.
To hang your fan where there is an existing fixture but no ceiling joist,

7
Assembly - Hanging the Fan
Attaching the mounting bracket to
the electrical box
1
Attaching the fan blades
2Remove six mounting screws (JJ) from the top plate located
on the motor yoke. Lift the top plate and set it aside.
Attach the fan blades (A) to the fan motor assembly (G)
using the blade screws (BB) and fiber washers (CC).
Tighten the blade screws (BB) securely.
Repeat these steps for the remaining blades (A).
Reattach the top plate to the motor yoke and install it
by aligning the key slot holes on the motor yoke using
previously removed mounting screws (JJ).
□
□
□
□
JJ
BB
CC
G
A
□Secure the mounting bracket (B) to the ceiling outlet box
with the screws and washers provided with your outlet
box.
W ARNING:
To reduce the risk of fire, electric shock
or personal injury, mount to outlet box marked
“acceptable for fan support of 15.9 kg (35 lbs) or less”
and use the screws provided with the outlet box.
B
HOMEDEPOT.CA

Assembling the fan
3
□
□
□
CAUTION:
To ensure wobble-free operation and to avoid
Loosen the set screws (GG) in the downrod coupler until the inside
of the channel is clear of the screw tip.
Remove the hitch pin (EE) and lock pin (FF) from the downrod (E).
C
E
F
G
GG
FF
EE
8
Assembly - Hanging the Fan (continued)
Hanging the fan
□Lift the fan motor assembly (G) into position, and place the
hanger ball (D) into the mounting bracket (B). Rotate the fan
motor assembly (H) until the check groove drops into the
registration slot and seats firmly. The downrod (E) should not
rotate if this is done correctly.
4
G
damage to the fan, the downrod (E) and the set screw
(GG) must be completely tightened.
Slip the coupling cover (F), and canopy (C) onto the downrod (E).
Carefully feed the fan wires and safety cable up through the
downrod (E). Thread the downrod (E) into the fan motor assembly (G)
coupling. Line up the holes and replace the lock pin (FF) and the
hitch pin (EE). Tighten the set screws (GG).
B
NOTE: The half ball (D) on the end of the support rod (E) is
grooved down one side. This keyway fits over the small keyway
pin on the inside of the mounting bracket (B) and keeps the
ceiling fan from spinning on the mounting bracket (B).
D
E

9
Assembly - Hanging the Fan (continued)
Making the electrical connections
5
WARNING:
Follow the steps below to connect the fan to your house supply
wires. Secure the wire nuts (DD) supplied with your fan by
wrapping the connections with electrical tape.
the electricity is turned off at the circuit breaker or main
fuse box before wiring.
To avoid possible electrical shock, ensure
□
□
□
□
□
WARNING:
including the ground, and that no bare wire is visible at
the wire nuts, except for the ground wire.
Check to see that all connections are tight,
ATTENTION: This steel cable is a protection device to
prevent people being hurt in case the fixture drops
accidentally. It must be securely installed.
□
□
WhiteGreen Black
1
B
HH
II
Put the end of the cable through the holes of the crimping column
and form a small loop of suitable size. Then tighten the crimping
screws to lock the cable. Use a wood screw (HH) with a metal
washer (II) through the cable loop and secure it at the ceiling.
Connect the black (hot) wire from the ceiling to the
black wire from the fan motor assembly (G).
Connect the white (neutral) wire from the ceiling to
the white wire from the fan motor assembly (G).
If your outlet box (1) has a ground wire (green or bare
copper), connect it to the fan ground wires; otherwise,
connect the hanging ball (D) ground wire to the
mounting bracket (B).
Secure the wire connection with a plastic wire nut
(DD) provided with the electrical hardware.
After connecting the wires, spread them apart so that
the green and white wires are on one side of the
outlet box (1) and the black wires are on the other side.
Carefully tuck the wire connections up into the outlet
box (1).
DD (x3)
D
G
HOMEDEPOT.CA

10
Assembly - Hanging the Fan (continued)
Mounting the fan
6
WARNING: When using the standard ball/downrod mounting, the
tab in the ring at the bottom of the mounting bracket must rest in
the groove of the hanger ball. Failure to properly seat the tab in
the groove could cause damage to the wiring.
B
AA
C
Installing the lamp shade
7
□Attach the lamp shade (I) onto the fan motor assembly (G)
using the lamp shade screws (KK).
KK
□Align the locking slot of the ceiling canopy (C) with the canopy
screw (AA) in the mounting bracket (B). Push up to engage the
slot and turn clockwise to lock in place. Install the canopy
screw (AA) previously removed. Tighten the canopy
screws (AA).
□Attach the decorative canopy bottom cover (H) onto the
canopy (C) and turn it clockwise to lock in the canopy (C).
□Loosen the canopy screw (AA) located in the “L-shaped”
slots.
I
G
□Remove the canopy screw (AA) in the round hole.
H

11
K
J
J
Operation
WARNING: Do not short-circuit, disassemble, heat up,
connect improperly, or dispose of used batteries in fire. Do
not recharge or mix batteries with used or other battery
types. Immediately remove used batteries.
WARNING: a) The cells shall be disposed of properly,
including keeping them away from children; and
b) Even used cells may cause injury.
NOTE: After the AC power is on, do not press any other button
on the remote control before pressing the (ON/OFF) button.
Doing so will cause the procedure to fail.
Should you desire to use another remote control (J) unit with your
new fan, install one using the steps below:
Turn the main power source off to begin the learning process.
□
Return the power to the unit.
□
Within 30 seconds of turning the fan’s AC power ON, press and
hold the button for 5-15 seconds to enter the learning function.
A beeping sound is emitted when pairing is complete (a beep is
also emitted when a signal has been sent from the transmitter).
If there is anything unusual, please turn off the power supply for
60-120 seconds and then turn it back on. Once it's on, refer to the
step above to complete the learning process.
□
Remove the screw from the battery cover, and then install a CR2032 battery (L)
into the remote control (J). To prevent damage to the remote control, remove
the battery if not used for long periods of time.
WARNING: Chemical Burn Hazard. Keep batteries away
from children. This product contains a lithium button/coin
cell battery. If a new or used lithium button/coin cell battery
is swallowed or enters the body, it can cause severe
internal burns and can lead to death in as little as 2 hours.
Always completely secure the battery compartment. If the
battery compartment does not close securely, stop using the
product, remove the batteries, and keep it away from
children. If you think batteries might have been swallowed
or placed inside any part of the body, seek immediate
medical attention.
REMOTE CONTROL OPERATING INSTRUCTIONS
LEARNING PROCESS
HOMEDEPOT.CA

12
Operation (continued)
1. Fan button. Press and release the button to turn the fan off.
2. Speed functions
3. Comfort breeze
Pressing the button will activate the Comfort Breeze mode. Alternates through speeds 1-6.
button, increases the fan speed.
Press and hold the button for 5-15 seconds to enter the learning function.
□
Pressing and releasing the button one time will increase the speed of the fan.
□
button, decreases the fan speed.
Pressing and releasing the button one time will decrease the speed of the fan.
□
Fan off. The fan memory function will store the current setting for the next time the fan is in use.
□
NOTE: If you are currently using Comfort Breeze mode, pressing the button will cancel Comfort Breeze mode and resume normal fan operation.
NOTE: You must turn the fan on prior to using the timer function.
NOTE: On start up, your ceiling fan will oscillate back and forth. This is NORMAL OPERATION for a DC ceiling fan as it goes through its
calibration cycle. The fan is NOT DEFECTIVE.
1 speed 2 speed 3 speed 4 speed 5 speed 6 speed
J
LED LIGHT
(Counterclockwise Direction) A downward air flow creates a
cooling effect. This allows you to set your air conditioner on a
higher setting without affecting your comfort.
(Clockwise Direction) An upward air flow moves warm air off the
ceiling. This allows you to set your heating unit on a lower setting
without affecting your comfort.
4. Timer (2H, 4H, 8H)
7. Fan reverse button (Must be pushed when the fan is in operation).
Pressing the (2H/4H/8H) button will automatically turn fan off
after 2, 4 or 8 hours.
□
□
□
5. Color temperature
Pressing the button twice changes the color temperature.
□
6. Dimmer
Pressing the button increases and decreases brightness.
□

13
Care and Cleaning
□Becauseof thefan’s natural movement, some connections may become loose. Check the support connections, brackets, and blade
attachments twice a year. Make sure they are secure. Itisnot necessary to remove the fan from the ceiling.
□Clean your fan periodically to help maintain its new appearance over the years. Do not use water when cleaning, as thiscould damage
plating is sealed with a lacquer to minimize discoloration or tarnishing.
□You can applya light coatoffurniture polish to the wood for additional protection and enhanced beauty. Cover small scratches with a
light application ofshoe polish.
□You donotneed tooil your fan. The motor has permanently lubricated, sealed ball bearings.
WARNING: Make sure the power is off before cleaning
your fan.
the motor or wood, or possibly cause an electrical shock. Use only a soft brush or lint-free cloth to avoid scratching the finish. The
□Always unplug the fan before cleaning, disassembly or servicing.
Operation (continued)
K
LL
□Install the wall plug onto the wall, then attach the remote control
holder (K) with the two remote control holder mounting screws (LL).
INSTALLING THE REMOTE CONTROL HOLDER
HOMEDEPOT.CA

14
IC Statement
This device contains license-exempt transmitter(s)/receiver(s) that comply with lnnovation, Science and Economic Development Canada’s
license-exempt RSS(s). Operation is subject to the following two conditions:
□ This device may not cause interference.
□ This device must accept any interference, including interference that may cause undesired operation of the device.
Troubleshooting
Problem Solution
The fan will not start. □Check the main and branch circuit fuses or breakers.
□Check the line wire connections to the fan and switch wire connections in the switch housing.
The fan is noisy. □Ensure all motor housing screws are snug.
□Ensure the screws that attach the fan blade bracket to the motor hub are tight.
□Ensure the wire nut connections are not rattling against each other or the interior wall of the switch housing.
□Allow a 24-hour “breaking in” period. Most noises associated with a new fan disappear during this time.
□If you are using the ceiling fan light kit, ensure the screws securing the glassware are tight. Check that the light
bulbs are also secure.
□Make sure there is a short distance from the ceiling to the canopy. It should not touch the ceiling.
□Make sure your ceiling box is secure and rubber isolator pads are used between the mounting bracket and outlet
box.
The fan wobbles. □Check that all blade and blade arm screws are secure.
□
The fan moves
backwards and
forwards when turned
on.
This is normal start-up procedure for DC motor fans. The partial movement during start-up is the result of the DC
motor aligning the internal magnetic poles for proper motor operation. This design saves electricity and allows
the fan to operate more quietly than standard AC motor fans.
□
Most fan wobble problems are caused when blade levels are unequal. Check this level by selecting a point on
the ceiling above the tip of one of the blades. Measure from a point on the center of the blade to the point on the
ceiling. Rotate the fan until the next blade is positioned for measurement, and measure from the same point on
each blade to the ceiling. Any measurement deviation should be within 1/8 in. Run the fan for ten minutes. If the
fan continues to wobble, please contact Customer Service. A balancing kit will be sent to you at no charge.
Check the battery in the remote control.
Ensure you are in the normal range of 10-17 feet.
□
□

Retain this manual for future use.
HOMEDEPOT.CA
