Go 1098T User manual

Product Code: 1098T
OWNER’S MANUAL
PRODUCT CODE: 1098T
PORTABLE WORKSHOP HEATER
Product
Code
Waterproof
Class
Voltage
Settings
Self
Re-setting
Thermostat
Dimensions
(mm)
Package
Weight
(kg)
1098T
IPX4
240V~50Hz
25/2000W
90°
285x230x350
4

Product Code: 1098T
Made in China to TQB Brands Pty Ltd specifications Page 2
Visit us at www.tqbbrands.com.au
WARNING
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE
WARNING
The instructions and warnings contained in this manual should be read and understood before
using or operating this equipment. Do not allow anyone to use or operate this equipment until
they have read this manual and have developed a thorough understanding of how this
equipment works. Failure to observe any of the instructions contained in the manual could result
in severe personal injury to the user or bystanders, or cause damage to the equipment and
property. Keep this manual in a convenient and safe place for future reference.
Whilst every effort has been made to ensure accuracy of information contained in this manual,
the TQB Brands Pty Ltd policy of continuous improvement determines the right to make
modifications without prior warning.
CONTENT
WARNING .............................................................................................................................. 2
CONTENT ............................................................................................................................... 2
SAFETY INSTRUCTIONS ........................................................................................................... 3
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE .......................................................... 4
WARRANTY ............................................................................................................................ 7

Product Code: 1098T
Page 3
SAFETY INSTRUCTIONS
SAFETY OPERATING INSTRUCTIONS
Please read the following very carefully as failure to comply may invalidate your guarantee.
When using electrical appliance basic precautions should always be followed including below:
üThe fan heater is not suitable for use outdoors in damp weather, in bathrooms or in
other wet or damp environments.
üPlease note that the fan heater can become very hot and should, therefore, be placed
at a safe distance from flammable objects such as vehicles, toolboxes and similar.
ûDO NOT cover the fan heater.
üThe fan heater must not be located immediately below a wall socket.
ûDO NOT connect the fan heater using an on/off timer or other equipment which can
automatically switch the device on.
ûDO NOT operate the 1098T where flammable liquids or gases are used/stored.
üIf an extension cord is used, it must be as short as possible and always be fully
extended.
ûDO NOT connect other appliances to the same mains socket as the fan heater.
ûDO NOT use this fan heater in the immediate surroundings of a parts washer, shower
or parts cleaning bath.
üIf the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
ûDO NOT leave heater unattended, remove from power.
ûDO NOT place the appliance on uneven surface.
ûDO NOT immerse the machine or power cord in water or other liquid.
ûDO NOT touch the unit if the machine has fallen into water during operation. Remove
the power plug from the socket first.
ûDO NOT operate the 1098T without proper grounding.
ûDO NOT place the device on a soft surface, where the vents could be blocked.
üIn the event of failure/emergency, disconnect the mains supply by removing the plug
from the mains socket.
üWhen servicing, use only TradeQuip identical replacement parts. Use of any other
parts will void the warranty. Ensure the 1098T is disconnected from power before
servicing.
üUse the right product for the job. There are certain applications for which the 1098T
was designed. Do not modify the 1098T and do not use the 1098T for a purpose for
which it was not intended.

Product Code: 1098T
Made in China to TQB Brands Pty Ltd specifications Page 4
Visit us at www.tqbbrands.com.au
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE
1. FEATURES
Depending on the power cord type this fan heater may be used only inside warehouses and
workshops, building sites or greenhouses. It incorporates a thermostat and a self-resetting
thermal cut-out to control the heating elements. The thermostat feels the air temperature
and controls the surrounding temperature. The fan motor is not controlled by thermostat
and it keeps on working when the thermostat cuts off the heating element. The self-
resetting thermal cut-out will switch off the heater to ensure the safety when overheating.
2. ASSEMBLY
Unpacking: after removing the packing material, make sure the product is in perfect
condition and that there are no visible damaged parts. The packaging materials
(Polyethylene bags, polystyrene etc.), must be disposed of in an appropriate refuse
collection container. Recycle cardboard.
3. BEFORE USE
Prior to each use conduct a visual inspection by checking for abnormal conditions, such as
cracked joins and damaged, loose, or missing parts.
When using the heater for the first time, you may notice a slight emission of smoke. This is
quite normal and it stops after a short time. The heating element is made of stainless steel
and during production the element is coated with an oil protection coat. The oil protection
coat may smoke slightly when first heated.

Product Code: 1098T
Page 5
4. OPERATION
1. Position the fan heater so that it stands upright on a firm level surface and at a safe
distance from wet environments and flammable objects.
2. Connect the fan heater to the 240V mains power.
3. Set the thermostat knob to the MAX setting and let the heater operate with full power.
4. The fan heater will switch on when the heating selector is set to one of the power
settings.
5. Once the room reaches the required temperature, the heating element will dim but
the fan will keep rotating. Once the temperature decreases, the heating element will
illuminate once again. The fan heater now starts and stops automatically and thus
keeps the room temperature constant.
6. Before switching off the heater, ensure the thermostat is set to the MIN position and
turn the switch to fan position, let the appliance cool down for two minutes then turn
off the heater and remove the power cord from the mains power outlet.
5. STORAGE
This 1098T should always be stored in a dust free dry location on a level surface.
6. MAINTENANCE
Disconnect power prior to any maintenance.
The 1098T should always be cleaned with a damp sponge and mild detergent, ensuring no
water/detergent enters the internals of the 1098T. Do Not use solvent to clean the heater.
7. SERVICE & REPAIR
Any 1098T found damaged in any way, or found to be worn or operates abnormally should
be removed from service until repaired by an authorised service agent. Owners and / or
operators should be aware that repair of this product may require specialised equipment
and knowledge. Only authorised parts, labels and decals shall be used on this equipment.
Annual inspection of the 1098T is recommended and can be made by an authorised repair
facility to ensure that your equipment is in optimum condition and that the equipment has
the correct decals and safety labels specified by the manufacturer.

Product Code: 1098T
Page 6
TROUBLESHOOTING
Problem
Possible cause
Treatment
The heater does not operate,
even when it is plugged in
and the switch, thermostat
are switched on
The plug is loose, poor
connection
Pull out the plug, check the
connection of the plug and
power outlet. Then connect
again.
No power in socket outlet
Insert the plug in a live
power outlet
The heating element is
glowing
The input voltage is too high
or too low
Use power supply according
to the rating on the label
The air inlet grill is blocked
Keep the heater away from
articles like curtain, plastic
bag, paper and other items
which cover the inlet or
cover on the air inlet
The appliance didn’t heat
up, or only the ventilator
worked
The control switch has not
selected a heating setting
Turn the control switch to
the heat setting
The thermostat operated
Turn the thermostat and
listen if there is open/close
noise. If there is no click and
the thermostat is not
damaged, the heater will
automatic switch on when
the heater cools down
The self-resetting cut-out
operated
Turn the heater off and
inspect the blockage of inlet
or outlet. Disconnect the
plug and wait for 10
minutes for the protection
system to reset before
attempting to restart the
heater.
Abnormal noise
The appliance is not level
Put the heater on a level
surface

Product Code: 1098T
Page 7
WARRANTY
TradeQuip products have been carefully tested and inspected before shipment and are
guaranteed to be free from defective materials and workmanship for a period of 12 months
from the date of purchase except where tools are hired out when the guarantee period is ninety
days from the date of purchase.
Should this piece of equipment develop any fault, please return the complete tool to your
nearest authorised warranty repair agent or contact TQB Brands Pty Ltd Warranty team –
[email protected].
If upon inspection it is found that the fault occurring is due to defective materials or
workmanship, repairs will be carried out free of charge. This guarantee does not apply to normal
wear and tear, nor does it cover any damage caused by misuse, careless or unsafe handling,
alterations, accident, or repairs attempted or made by any personnel other than the authorised
TQB Brands Pty Ltd repair agent.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its
terms are not authorised.
Your TQB Brands Pty Ltd guarantee is not effective unless you can produce upon request a dated
receipt or invoice to verify your proof of purchase within the 12 month period.
Consumer Guarantee
Our goods come with a guarantee that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does not amount to a major
failure.
