Goblin GSV303R-21 User manual

IMPORTANT: RETAIN FOR FUTURE REFERENCE
GSV303R-21 Corded
stick vacuum
User Guide 220-240V~50-60Hz, 450W
ON
OFF

2
About this guide
We’re here to help you get the most from your corded stick
vacuum, so please keep hold of this manual for future use.
THIS PRODUCT WAS DESIGNED AND MANUFACTURED
TO MEET STRICT QUALITY AND SAFETY STANDARDS.
THERE ARE, HOWEVER, SOME OPERATIONAL
PRECAUTIONS YOU SHOULD BE AWARE OF.
1. Read all warnings & instructions in this manual to
ensure you get the best out of your product.
2. Don’t use the stick vac for anything other than
its intended use. The appliance is not suitable for
commercial use. This appliance is only for household
domestic indoor use and car cleaning.
3. Do not use if the stick vac, cord or plug is damaged.
4. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid hazard.
5. Remove all packaging prior to use. Inspect the product
for any damage before use. If damage is found, notify
ASDA to exchange the product.
6. Before connecting the stick vac to the power, check
the voltage shown on the appliance corresponds with
the voltage in your home. If it doesn’t, contact your
local store.
7. Keep the stick vac away from heat sources or direct
sunlight.
8. WARNING: Keep the appliance dry.
9. T o avoid electric shock or injury, never immerse the
stick vac body, cord or plug in liquid or water.
10. Do not handle the appliance with wet hands.
11. Keep away from harsh or abrasive cleaning agents or
solvents.
WARNINGS:

3
12. Ensure you assemble the stick vac correctly before
use.
13. Do not use attachments not recommended by the
manufacturer.
14. Always disconnect the appliance from the power
supply before assembling, disassembling or cleaning.
15. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance.
16. ASDA does not recommend allowing children to
operate this appliance.
17. Cleaning and user maintenance shall not be made by
children without supervision.
18. Only carry the stick vac by the carry handle.
19. DO NOT use the stick vac if it has been dropped,
damaged, left outdoors or dropped into water.
20. Do not pull or carry by the cord, use the cord as a
handle, close a door on the cord, pull the cord around
sharp corners or edges, or expose the cord to heated
surfaces.
21. Ensure fingers and objects are never placed in any part
of the vacuum cleaner. Clothing or hair may become
trapped in the vacuum if used improperly.
22. Keep hair, loose clothing, jewellery, fingers, feet and all
parts of your body away from openings and moving
parts.
23. Keep all air vents clear and free of dust, lint, hair and
anything else that may reduce air flow.
24. Avoid directing the stick vac near naked flames as the
air discharged may extinguish gas fires and pilot lights
or disturb ashes in an open fire.

4
25. DO NOT use the stick vac to suck up large objects or
objects that are likely to damage the vacuum cleaner.
26. DO NOT attempt to vacuum long hair, string, pieces of
cloth etc., as these may clog the vacuum cleaner.
27. DO NOT vacuum hot items e.g. cigarettes, matches,
ashes.
28. DO NOT vacuum fine dust, such as brick dust, plaster
dust etc. This may damage the vacuum cleaner.
29. DO NOT vacuum hard or metal objects, nails, pins etc.
30. DO NOT pick up toxic or flammable materials or use
in the presence of explosive or toxic dust, liquids or
vapour.
31. DO NOT put objects into openings.
32. Use only on dry indoor surfaces.
33. Never use to suck up water or liquids.
34. DO NOT use without all the filters in place or with any
filter blocked.
35. DO NOT use the stick vac to clean animals.
36. Switch the cleaner off before plugging or unplugging
the vacuum cleaner into the mains supply, and when
attaching or removing accessories.
37. T ake extra care when vacuuming stairs.
38. Keep any attachments away from your face and body.
39. This vacuum has a thermal safety device which cuts off
the power when overheated. If this happens, unplug
the vacuum and allow it to cool down completely
before reusing.
40. Wrap the cord loosely around the handle and dust
canister before storing.
41. The appliance shall not be left unattended while it is
connected to the supply mains.
42. Environmental information: If at anytime in the future
you should need to dispose of this product, please
note that, in the UK, waste electrical products/batteries
should not be disposed of with household waste.

5
What’s in the box
• Stick vac main body
• Dust canister
• Filter assembly
• Circular sponge filter
• Extension pole
• Floor head
• Crevice/brush multi-tool
• Wall mount bracket and fixings
• User guide
Features
AUTOMATIC THERMAL CUT OUT
A safety thermostat inside the cleaner protects the motor
from overheating if the airways or filters are clogged. If
the stick vac suddenly stops working during operation,
switch off and unplug immediately. Allow the motor to
cool for an hour, empty the dust canister and thoroughly
clean the filters and airways. Plug in the vacuum again and
switch on. The vacuum should now operate normally.
This is a vacuum cleaner for general purpose, of which
measurement and calculation methods used comply with EN
60312-1 & EU regulation No. 666/2013
Crevice/brush
multi-tool
Circular
sponge filter
Wall mount
bracket
Wall mount
fixings

6
Features
ON
OFF
Carry handle
Power on/o
button
Release clip
Floor head
Extension pole
Mount hook
Dust canister
release button
Power
cord
Plug
Dust canister
Main body

7
Assembling/disassembling
and using the stick vac
Before assembling or disassembling
attachments, ensure the stick vac is
not plugged into the mains supply
and is switched off.
1. Align the top of the extension
pole with the bottom of the stick
vac main body and push up until
the extension pole clicks into
place.
2. Push the other end of the
extension pole into the top of the
floor head. Again it should click
into place.
The stick vac is now assembled,
ready for use.
3. Pop the plug into an electrical
socket and turn the power on.

8
Replacing the attachments
When changing the attachments ensure
the stick vac is switched off.
The floor head and crevice/brush multi-
tool can fit directly onto the main body
for close up vacuuming and low level
dusting and cleaning. For high level
cleaning the crevice/brush multi-tool can
fit on the end of the extension pole.
1. To use the stick vac more as a
handheld vac, remove the extension
pole and replace with the floor head.
Press the release clip on the top of
the extension pole (1) and pull the
extension pole away from the main
body (2).
2. Remove the floor head from the
extension pole in the same way
by pressing the release clip on the
floor head and pulling away the
extension pole.
4. Turn the stick vac on by pushing the
power on/off switch downwards.
5. Move the floor head back and forth
over the surface. Use even strokes.
Don’t press hard; allow the floor head
to suck away the debris.
6. When finished turn off the power on
the vac and to the mains supply.
Note: Lean the stick vac safely against a
wall or surface, or lay the vac down on
the floor when not in use.
1
2

9
3. Align the main body with
the top of the floor head
and push down until it
clicks into place. Turn on
the power.
This set up is useful when
cleaning stairs or sofas.
When finished turn the
power off on the stick vac
and at the mains supply.
Note: Take care when
vacuuming stairs. It is best
to plug in the stick vac at the
bottom of the stairs and work
upwards so the cable isn’t in
the way and doesn’t become a
trip hazard.
4. For low level cleaning
with the crevice/brush
multi-tool, simply slide the
attachment directly onto
the end of the main body.
For high level cleaning,
slide the attachment onto
the end of the extension
pole.
5. To use the brush
attachment on the crevice
tool, pull the top brush
section in the direction of
the arrow until it clicks into
place.
6. To use the crevice tool,
simply push the brush back
to the reverse position.

10
Removing and emptying
the dust canister
Ensure the stick vac is switched off
before emptying the dust canister.
As a tip, it is easier to remove
the dust canister without any
attachments on the vac.
1. Press the dust canister release
button located underneath the
dust canister (1) and pull away
from the main body, keeping the
dust canister fairly upright (2).
2. Pinch either side of the filter
assembly and pull upwards away
from the dust canister. Empty the
debris from the dust canister into
a household bin.
Note: Do not allow the dust canister
to overfill. Don’t exceed the MAX
level marker. Empty regularly.
Everytime you empty the dust
canister, check the filter assembly
and tap gently over the household
bin to remove any excess dust.
3. Replace the filter assembly
into the dust canister. Hook the
channel on the top of the dust
canister with the lug on the main
body (1). Push the dust canister
back towards the main body until
you hear it click into place (2).
2
1
1
2

11
Cleaning the filters
Before starting any cleaning, ensure the
stick vac is not plugged into the mains
supply and is switched off.
1. Remove the dust canister and filter
assembly and empty as shown in the
‘Removing and emptying the dust
canister’ section of this manual.
2. Remove the circular sponge filter
from the filter assembly by pinching
the material tab at the top of the filter
and pulling upwards. Tap the filter
over a household bin to remove any
debris then set aside.
3. Remove any excess dust from the
filter assembly using a soft brush or
a clean paint brush. The filter can
be broken down into three parts.
Hold the top section and twist the
lower section, following the arrow
and wording markings on the filter
assembly that say ‘UNLOCK’.
4. Rinse the dust canister, filter assembly
parts and circular sponge filter under
warm water until the water runs clear
and leave to dry for 24 hours.
5. Once all the parts are thoroughly dry,
reassemble the filter assembly, using
the markings for ‘LOCK’, and place
back into the dust canister. Don’t
forget to put the circular sponge filter
back in the top of the filter assembly.
6. Replace the dust canister to the main
body as shown in the ‘Removing and
emptying the dust canister’ section of
this manual.
1

12
It is important to regularly maintain and clean the filters.
A clogged filter reduces suction power and can shorten the life of
your stick vac.
Below is a recommended guide for how often you should clean
the filters:
Filter Type Recommended cleaning times
Filter assembly
• Shake out debris when you empty the dust canister.
• Rinse under warm water once a month or more often if
required.
Circular
sponge filter
• Shake out debris when you empty the dust canister.
• Occasionally remove any dust/debris as necessary. It
can also be rinsed under warm water once a month.
Clearing a blockage
Ensure the stick vac is not plugged into the mains supply and is
switched off before dismantling the vac.
The stick vac would only become blocked if the dust canister has
exceeded the ‘MAX’ level, the filters are clogged up or a large object
has been sucked up.
1. Check the dust canister and empty if necessary.
2. Check the 2 filters in the unit, remove any debris/dust and wash
if necessary.
3. If the floor head, crevice/brush multi-tool or extension pole were in
use, detach them from the main body and each other and check for
blockages. Remove any blockages.

13
Storing the stick vac
Your stick vac can be stored safely
and securely by hanging from the
wall mount supplied with your
product or by removing all the
attachments and stowing together
in a cupboard. Either way will help
avoid the product falling over and
causing damage.
Always turn off and unplug from the
mains supply before storing.
1. Remove any attachments if the
stick vac was last used with
them on.
2. Wrap the cord over the top of
the handle and underneath the
dust canister.
3. Store the stick vac and
accessories away safely in a
dry place.

14
Storing the stick vac with the wall mount
1. Find a suitable spot in your household
where you’d like to secure your stick vac.
2. Mark the desired screw hole positions on
the wall using a pencil. We recommend
that the stick vac hangs slightly lifted off
the floor.
3. Use the wall mount fixings supplied only
if suitable for your wall type.
4. Screw the wall mount bracket and
fixings to the wall (see illustration for
which way the mount should hang on
the wall).
5. Wrap the cord over the top of the
handle and underneath the dust canister.
6. The stick vac can then be mounted on
the wall mount bracket. The mount hook
can be found on the back on the main
body near the handle.

15
Call
0333 600 7700
Write
ASDA,Leeds LS11 5AD
Customer services information
If you require further information,
spare parts or advice regarding your
product, or if you are experiencing
any problems, please contact
customer services at the telephone
number or address shown opposite.
N.B. When calling or writing please
quote the product site code.
Product name: GSV303R-21 Corded stick vac
Product site code: 15A.09.22.229
Your
28 day
no quibble refund
1 year
guarantee
If you’re not delighted with your product,
simply bring it back within 28 days for a
no quibble refund. Don’t forget to include
all of the product’s original components
(for example remote control, power cable
or stand) and packaging, along with your
receipt or other proof of purchase.
This product is covered by a full 1 year Asda guarantee
from the day you buy it. In the unlikely event that your
product is faulty or you are simply struggling to set it
up, don’t worry - here’s what you should do.
1. First call our Customer Helpline as they may be able
to help you with the problem 2. If the problem can’t
be resolved, you will receive a reference number. 3.
Take the reference number, along with the item, all its
components and your receipt, to your nearest store
for a full refund.

Copyright
© 2020 ASDA Stores Limited.
All other trademarks appearing herein are
the property of their representative owners.
Specifications are subject to change
without notice.
Manufactured for:
ASDA,
Leeds LS11 5AD/ASDA,
Antrim BT41 4GY
Disposal
This symbol on the product or in the
instructions means that your electrical and
electronic equipment should be disposed
at the end of its life separately from your
household waste. There are separate
collection systems for recycling in the UK.
For more information,
please contact the
local authority or
your retailer where
you purchased
the product.
