0.3-1.2s 0.3-1.5s 0.3-1.2s
DE300
300Ws
76
DE200
200Ws
76
DE400
400Ws
76
Buzz Function
The sound button (7) is used to decide whether there is sound reminder for ready flash after
recharging. When the buzz indicator (12) is on, it means buzz function is working; if it is off, the
buzz function is shut down. A “BI” sound will be heard when it's fully charged.
Memory Function
The device is equipped with memory function for the panel setting. It will help remember the
panel setting 3 seconds after you set it. When starting up the flash next time, the panel setting
will be the same as that before powering it off.
Wireless Control Function
The flash unit is built in with a Wireless Control Port (17) so that you can wirelessly control the
on-and-off of your flash, modeling lamp and buzzer, as well as adjust the flash output level, etc.
To control the flash wirelessly, you need a Godox FT series remote control set (on-camera and
on-flash), which is sold separately. Insert its receive end into the Wireless Control Port (17) on
the flash and insert the transmit end into the camera hot shoe. Settings made on the hotshoe-
mounted transmit and receive ends will be wirelessly communicated to the flash. Then you can
press the camera shutter-release button to trigger the flash. You can also hold the transmit end
at hand to control your flash.
For full instructions on the use of FT series remote control, see its user manual.
Tube Replacement
Shut down the power and remove the power cord before replacing the flash tube and wear
insulated gloves. Then, loosen the iron wire on the tube, keep a balanced hold on the two feet
of the flash tube and pull out the old tube gently. Take down the feet casing from the old tube
and put it on the new one. Hold two feet of the new tube, and target directly towards the two
copper outlets, then push them slightly in. Twine the iron wire on the stainless steel sheet to fix
the flash tube.
TECHNICAL DATA
MAINTENANCE
Shut down the device immediately when it works abnormally and find out the reason.
Avoid sudden impacts and the lamp should be dedusted regularly.
It is normal for the lamp to be warm when in use. Avoid continuous flashes if unnecessary.
Maintenance of the flash must be performed by our authorized maintenance department which can provide
original accessories. The flash-tube and the modeling lamp are user-replaceable. Replacement tubes and
lamps can be obtained from the manufacturer.
This product, except consumables e.g. flash tube and modeling lamp, is supported with a one-year warranty.
Unauthorized service will void the warranty.
If the product had failures or was wetted, do not use it until it is repaired by professionals.
Disconnect the power when cleaning the flash or when changing the flash tube / modeling lamp.
Changes made to the specifications or designs may not be reflected in this manual.
Approx.1.5kg
Flash diameter Φ12.5cm,
height of flash with handle
25cm, length of flash with
modeling lamp 35cm
Flash diameter Φ12.5cm, height of flash with
handle 25cm, length of flash with modeling
lamp 30cm
Approx.1.8kg
- 14 -- 13 -
Approx. 1.6kg
Net Weight
Dimension
5600±200K
AC110V-120V~60Hz or AC220V-240V~50Hz
OFF, 5.0~7.0(1/16~1/1)
150W
Sync cord, Test button, Slave triggering, Wireless control port
1/2000~1/800s
5V
5V/200mA (only for Godox receiver)
AC220V-240V~50Hz: 5A
AC110V-120V~60Hz: 8A
Model
Max Power (WS)
Guide Number(m ISO 100)
Color Temperature
Operating Voltage
Power Output Control
Modeling Lamp (W)
Recycle Time
Triggering Method
Flash Duration
Parameters Output from
the Sync Cord Jack
Parameters Output from
the USB Port
Fuse
