GOEBEL GO-520 User manual

OPERATION MANUAL
HAND RIVET NUT &RIVET BOLT/STUD TOOL
With Auto-Open Design
TM
& Detachable Easy-Turn Unit
TM
MODEL GO-520 / GO-520-UN
Industrial & Heavy Duty
●
●
●
This Illustrated Operation Manual includes the FEATURES, SPECIFICATIONS, PARTS LIST,
OPERATION INSTRUCTIONS, MAINTENANCE and TROUBLESHOOTING.
Before operating this TOOL, please MUST read this Illustrated OPERATION MANUAL carefully to
ensure Safe, Correct and Satisfactory Operation.
GO-520 / GO-520-UN can be also served as the RIVET BOLT/STUD TOOL with the Optional
THREADED SOCKETS on request.
GOEBEL 2018
c
PATENTS USA US 9,162,278 B2 GERMANY 20 2014 102 094.2 TAIWAN I 551371
中囯 实用新型专利 ZL 2013 2 0300246.1 WORLDWIDE PATENTS PENDING

1)
2)
*3)
RIVET NUTS/THREADED INSERTS Materials: Aluminum, Steel, Stainless Steel/Inox ISO
Metric Thread Size: M4X0.7, M5x0.8, M6x1.0, M8x1.25, M10x1.5. Or UN Inch Thread Size:
8-32, 10-24, 10-32, 1/4-20, 5/16-18, 3/8-16.
RIVET NUTS/THREADED INSERTS Materials: Aluminum, Steel ISO Metric Thread Size:
M12X1.75. Or UN Inch Thread Size: 1/2-13.
RIVET BOLTS/STUDS Materials: Aluminum, Steel, Stainless Steel/Inox ISO Metric Thread
Size: M5x0.8, M6x1.0, M8x1.25. Or UN Inch Thread Size: 10-24, 10-32, 1/4-20, 5/16-18.
* GO-520 / GO-520-UN can fasten RIVET BOLTS/STUDS with the optional THREADED SOCKETS
on request.
... RIVET NUT TOOL is designed to fasten RIVET NUTS with the THREADED MANDRELS,
from M5x0.8 UP TO M12X1.75 or from 10-24/10-32 UP TO 1/2-13, firmly and to build up enough
Female Threads securely in the thin base metals and pipes with weldless, tapping-free and
one-side work in order to fasten with Bolts.
is also designed to set RIVET BOLTS/STUDS with the optional THREADED SOCKETS,
from M5x0.8 UP TO M8x1.25 or from 10-24/10-32 up to 5/16-18, firmly and to build up enough
Male Threads securely on the thin base metals and pipes with weldless and one-side work in
order to fasten with Nuts.
is equipped with a Detachable Easy-Turn Unit Design™, just turn the ROTATING KNOB
to drive the THREADED MANDREL or THREADED SOCKET to engage with and release from
RIVET NUT or RIVET BOLT/STUD easily.
is equipped with Innovative Auto-Open Design™ for convenient operation, and Innovative
Detachable Easy-Turn Unit for easy replacement of Easy-Turn Unit.
is equipped with an innovative FIXING-HOLES DEVICE™, simply inserts the
FIXING-HOLE PIN not only to solve the headache problem of RIVET NUT stuck on the working
THREADED MANDREL or RIVET BOLT/STUD stuck in the working THREADED SOCKET that
might happen when engaging with or fastening RIVET NUT or RIVET BOLT/STUD, but also to
assist THREADED MANDREL or THREADED SOCKET to mount to or dismount from the TOOL
easily just with a single SERVICE WRENCH.
GO-520 / GO-520-UN Standard Parts:
GO-520 / GO-520-UN Optional Parts:
GO-520 / GO-520-UN Working Capacity:
A. FEATURES
B. SPECIFICATIONS
2
GO-520 / GO-520-UN Tool Dimensions and Net Weight:
Dimensions(Closed type): L 530 x W 150 mm, L 20-7/8˝ x W 5-7/8˝. Net Weight: 1.83 kg, 4.03 lb.
1)
2)
3)
THREADED MANDRELS:
ISO Metric Thread Size: M5x0.8, M6x1.0, M8x1.25, M10x1.5, M12x1.75: 1 pc of each. Or UN
Inch Thread Size: 10-24, 10-32, 1/4-20, 5/16-18, 3/8-16, 1/2-13: 1 pc of each.
NOSEPIECES:
ISO Metric Size: M5, M6, M8, M10, M12: 1 pc of each. Or UN Inch Size: #10, 1/4, 5/16, 3/8,
1/2: 1 pc of each.
NOSEPIECE LOCK NUT, SERVICE WRENCH, SMALL RULE, FIXING-HOLE PIN, PIN
RETAINER, PARTS PLASTIC BOX, TRAY & STEEL CARRY CASE or PLASTIC CARRY
CASE, OPERATION MANUAL: 1 pc of each.
1)
2)
THREADED MANDRELS: M4x0.7 or 8-32.
THREADED SOCKETS (To fasten RIVET BOLTS/STUDS):
ISO Metric Thread Size: M5x0.8, M6x1.0, M8x1.25. Or UN Inch Thread Size: 10-24, 10-32,
1/4-20, 5/16-18.
GO-520 / GO-520 UN
...
...
...
...
Industrial
& Heavy Duty
HAND RIVET NUT TOOL
With Auto-Open Design
TM
& Detachable Easy-Turn Unit
TM
Model GO-520/GO520-UN

Industrial
& Heavy Duty
HAND RIVET NUT TOOL
With Auto-Open Design
TM
& Detachable Easy-Turn Unit
TM
3
1) means Wearing Parts or Possible Missing Parts.
2) Threaded Mandrels are for setting Rivet Nuts.
Optional Threaded Sockets are for setting Rivet Bolts/Studs.
3) Each Nosepiece can set same size of Rivet Nut and Rivet Bolt/Stud.
For example, GO-520-06M6 Nosepiece can set both M6 Rivet Nut and M6 Rivet Bolt/stud.
4) Ordering example: GO-520-04M8125, M8x1.25 Threaded Mandrel, 10 pcs.
REMARKS:
C. PARTS LIST
PATENTS & WORLDWIDE PATENT PENDING
0 0.2 0.4 INCH
0 5
10
MM
A
E
KO
RTS
ORTS-RE
V
O !
E
K
M
MH
C
N
I
0
1
5
0
4
.
0
2
.
0
TE
S
TON
OD
0
Model GO-520/GO520-UN
1
2
3
4-M407
4-M508
4-M610
4-M8125
4-M1015
4-M12175
4-832
4-1024
4-1032
4-1420
4-51618
4-3816
4-1213
5-M508
5-M610
5-M8125
5-1024
5-1032
5-1420
5-51618
6-M4
6-M5
6-M6
6-M8
6-M10
6-M12
GO-520-01
GO-520-02
GO-520-03
GO-520-04M407
GO-520-04M508
GO-520-04M610
GO-520-04M8125
GO-520-04M1015
GO-520-04M12175
GO-520-04832
GO-520-041024
GO-520-041032
GO-520-041420
GO-520-0451618
GO-520-043816
GO-520-041213
GO-520-05M508
GO-520-05M610
GO-520-05M8125
GO-520-051024
GO-520-051032
GO-520-051420
GO-520-0551618
GO-520-06M4
GO-520-06M5
GO-520-06M6
GO-520-06M8
GO-520-06M10
GO-520-06M12
Front Body
Rear Body Assembly
Easy-Turn Unit, Complete Set
Threaded Mandrel, M4x0.7 (Option)
Threaded Mandrel, M5x0.8
Threaded Mandrel, M6x1.0
Threaded Mandrel, M8x1.25
Threaded Mandrel, M10x1.5
Threaded Mandrel, M12x1.75
Threaded Mandrel, 8-32 (Option)
Threaded Mandrel, 10-24
Threaded Mandrel, 10-32
Threaded Mandrel, 1/4-20
Threaded Mandrel, 5/16-18
Threaded Mandrel, 3/8-16
Threaded Mandrel,1/2-13
Threaded Socket, M5x0.8 (Option)
Threaded Socket, M6x1.0 (Option)
Threaded Socket, M8x1.25 (Option)
Threaded Socket, 10-24 (Option)
Threaded Socket, 10-32 (Option)
Threaded Socket, 1/4-20 (Option)
Threaded Socket, 5/16-18 (Option)
Nosepiece, for M4 (Option)
Nosepiece, for M5
Nosepiece, for M6
Nosepiece, for M8
Nosepiece, for M10
Nosepiece, for M12
No. Part No. Part Name
6-8
6-10
6-14
6-516
6-38
6-12
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23-A
24
25
26
27
GO-520-0608
GO-520-0610
GO-520-0614
GO-520-06516
GO-520-0638
GO-520-0612
GO-520-07
GO-520-08
GO-520-09
GO-520-10
GO-520-11
GO-520-12
GO-520-13
GO-520-14
GO-520-15
GO-520-16
GO-520-17
GO-520-18
GO-520-19
GO-520-20
GO-520-21
GO-520-22
GO-520-23A
GO-520-24
GO-520-25
GO-520-26
GO-520-27
Nosepiece, for #8 (Option)
Nosepiece, for #10
Nosepiece, for 1/4˝
Nosepiece, for 5/16˝
Nosepiece, for 3/8˝
Nosepiece, for 1/2˝
Nosepiece Lock Nut
Head
Handle
Grip
Pin, L329
Snap Ring
Bolt, L252
Washer, 12x6
Arm
Joint
Washer, 10x5
Nylon Nut, M5
Service Wrench
Small Rule
Fixing-Hole Pin
Pin Retainer
Stroke Indicator,
Metric & Inch Sizes
Stroke Indicator, Inch Size
Parts Plastic Box
Steel Carry Case (Not Shown)
Tray (Not Shown)
Plastic Carry Case (Not Shown)
No. Part No. Part Name
23-MA GO-520-23MA
3A GO-520-03A Quick-Drill Unit, Complete Set (Option)

Industrial
& Heavy Duty
HAND RIVET NUT TOOL
With Auto-Open Design
TM
& Detachable Easy-Turn Unit
TM
D. MAIN PARTS NAME
4
NOSEPIECE
FIXING-HOLES
OF HEAD
MANDREL SEAT,
*LEFT-HANDED
FEMALE THREAD
FRONT BODY
NOSEPIECE LOCK NUT
HEAD
THREADED MANDREL
LONG FIXING-HOLE
OF MANDREL SEAT
MANDREL SEAT,
*LEFT-HANDED
FEMALE THREAD
FIXING-HOLE PIN
PIN RETAINER
THREADED
MANDREL
Upper Thread To
Engage With RIVET
NUT Thread
Lower *LEFT-HANDED
MALE THREAD
Loose Fasten
THREADED MANDREL
NOSEPIECE LOCK NUT
Detachable EASY-TURN UNIT
REAR BODY
FRONT BODY
STROKE INDICATOR
HANDLE
GRIP
FIXING-HOLES OF HEAD
NOSEPIECE
HEAD
STROKE ADJUSTER
HANDLE
GRIP
STROKE
OVER-STROKE !
MM INCH
10
5
0
0.4
0.2
DO NOT SET
0
Model GO-520/GO520-UN
The Detachable EASY-TURN
UNIT (3) can be easily
exchanged with the
Detachable QUICK-DRILL
UNIT (3A) by a Wrench.
NOTE

STROKE
ADJUSTER
STROKE
OVER-STROKE !
MM INCH
10
5
0
0.4
0.2
DO NOT SET
0
STROKE
OVER-STROKE !
MM INCH
10
5
0
0.4
0.2
DO NOT SET
0
STROKE
OVER-STROKE !
MM INCH
10
5
0
0.4
0.2
DO NOT SET
0
E. HOW TO CHANGE THREADED MANDREL AND NOSEPIECE
FIXING-HOLE PINPIN RETAINER
NOSEPIECE
