GoECOlife GMC120D User manual

COMMERCIAL
SHREDDER
SERIES
http://www.monomachines.com/
http://www.monomachines.com/
<> <>

http://www.monomachines.com/
http://www.monomachines.com/

Contents
Welcome/Green Features .................................................. 2
Innovative Features .......................................................... 3
GoECOlife™ Commercial Shredder Series
(Features, Warranty & Technical Specifications)
I. 12-Sheet Micro-Cut (GMC120D) .............................. 4
II. 16-Sheet Cross-Cut (GXC160T)................................ 5
III. 18-Sheet Cross-Cut (GXC180T)................................ 6
IV. 20-Sheet Cross-Cut (GXC200T)................................ 7
V. 30-Sheet Strip-Cut (GSC3020T)................................ 8
VI. 16-Sheet Cross-Cut (GXC1620T) .............................. 9
Shredder Diagram........................................................... 10
GoECOlife™ Commercial Shredder Series
GoECOlife™ Commercial Shredder Accessories
VoiceAssist™ & InfoCenter™ Features ........................... 11
Bin Full Indicator & Control Panel Features................... 11
Quick View ........................................................... 12 - 13
Warnings ......................................................................... 14
Installation ...................................................................... 15
Safety Instructions .......................................................... 15
Operation................................................................... 16 - 20
Warranty......................................................................... 21
Return Instructions ......................................................... 21
Registration & Contact Info ............................................. 21
Clear Shredder Bags • Waste Liners.................... 23
Lubricant Sheets .................................................. 24
1
http://www.monomachines.com/
http://www.monomachines.com/

Welcome / Green Features
Thank you for choosing the green option in paper shredding. While
meeting the increasing needs in document shredding and security,
our GoECOlife™ Commercial Shredder series were made with
environmental issues in mind.
Carbon Free ® Certified
This product is carbon neutral. It meets Carbonfund.
org’s Carbon
Free ® Product Certification protocol which
requires third-party life cycle assessment of the product’s
carbon footprint, and carbon reductions in support of
third-party validated renewable energy and reforestation
projects. To learn more, visit www.carbonfund.org/
products.
Energy-Saving Technology
Prevents power drain (phantom load) when your
shredder is not in use. Save energy! Save money!
RoHS Compliant
(Restriction of Hazardous Substances)
Meets RoHS standards that restrict the use of
hazardous substances such as lead, mercury and
RoHS
other heavy metals.
Green Packaging
Recycled (or partially recycled) and biodegradable
materials were used for packaging and printed
materials. No styrofoam, plastic tape or plastic bags
were used to package this product. Fewer trees were
sacrificed to package your shredder!
2
http://www.monomachines.com/
http://www.monomachines.com/

3
Innovative Features
1
2
3
4
VorteX™ Cutting System
Ensures optimal performance.
Technology
Passive, audio troubleshooting
feature with volume control.
InfoCenter™ LCD panel
Displays visual flashing alerts.
Overfeed Prevention Technology
Eliminates paper jams.
.
5
6
7
8
DynamicBin-Full Indicator
Flashing LED meter displays
waste level progressively.
T-Door™ Space-Saving Design
Ergonomically designed doors
for easier basket removal in
tight spaces.
CD/DVD Throat
Separate Waste Bin
Keeps plastic waste out of your
paper waste.
ParticleSweeper™
Waste Leveler
Increases bin capacity by evenly
distributing and leveling shred
particles.
3
8
5 3
6
7
1
4
2
All-Quiet™ Operation
So you don’t disturb those
around you.
http://www.monomachines.com/
http://www.monomachines.com/
3

Commercial Shredder Series
limited limited
2
years 7 years
12-Sheet Micro-Cut GMC120D product cutter
warranty warranty
Innovative Features
I
VorteX
™
Cutting System
•
Technology
•
•
InfoCenter
™
LCD panel
•
Overfeed Prevention Technology
CD/DVD Throat
•
Separate Waste Bin
•
All-Quiet
™
Operation
Recommended Supplies
•
Prolong your shredder life. (Item #GLS24)
clear shredder bags
•
Customized size for this shredder model.
(Item #GBL-0612A)
Technical Specifications
Model ........................................................................................... GMC120D
Cutting Style ................................................................................ Micro-Cut
Shred Size ............................................................... 0.12” x 0.35” (3 x 9mm)
Sheet Capacity ............................................................................... 12 sheets
Shred Speed Max Sheet Capacity.......................... 5.74 ft/min (1.75 m/min)
Intake Throat Width .............................................................8.66” (220mm)
Voltage ........................................................................................ 120V/60Hz
Dimensions (L x W x H).......... 16.14” x 11.7” x 23.62” (410 x 297 x 600mm)
Weight.................................................................................. 33.07 lb (15 kg)
Receptacle Volume .................................................. 6.1 gallons (23.1 liters)
Noise Level (Motor) ........................................................................... 55 dB
4
http://www.monomachines.com/
http://www.monomachines.com/

Commercial Shredder Series
2
years 7 years
limited limited
16-Sheet Cross-Cut GXC160T product cutter
warranty warranty
Innovative Features
VorteX
™
Cutting System
•
Technology
•
•
InfoCenter
™
LCD panel
•
Overfeed Prevention Technology
•
T-Door
™ Space-Saving Design
•
All-Quiet
™
Operation
Recommended Supplies
•
Prolong your shredder life. (Item #GLS24)
clear shredder bags
•
Customized size for this shredder model.
(Item #GBL-1012B)
Technical Specifications
Model ............................................................................................ GXC160T
Cutting Style .................................................................................Cross-Cut
Shred Size ............................................................... 0.16”x1.57” (4 x 40mm)
Sheet Capacity ............................................................................... 16 sheets
Shred Speed Max Sheet Capacity ........................10.01 ft/min (3.05 m/min)
Intake Throat Width .............................................................9.06” (230mm)
Voltage ........................................................................................ 120V/60Hz
Dimensions (L x W x H).............15.35” x 11” x 24.41” (390 x 280 x 620mm)
Weight................................................................................38.58 lb (17.5 kg)
Receptacle Volume ..................................................... 7 gallons (26.5 liters)
Noise Level (Motor) ........................................................................... 60 dB
II
5
http://www.monomachines.com/
http://www.monomachines.com/

Commercial Shredder Series
2
years 7 years
limited limited
18-Sheet Cross-Cut GXC180T product cutter
warranty warranty
Innovative Features
VorteX
™
Cutting System
•
Technology
•
•
InfoCenter
™
LCD panel
•
Overfeed Prevention Technology
•
T-Door
™ Space-Saving Design
•
All-Quiet
™
Operation
Recommended Supplies
•
Prolong your shredder life. (Item #GLS24)
clear shredder bags
•
Customized size for this shredder model.
(Item #GBL-1512C)
Technical Specifications
Model ............................................................................................ GXC180T
Cutting Style .................................................................................Cross-Cut
Shred Size ............................................................... 0.16”x1.57” (4 x 40mm)
Sheet Capacity ............................................................................... 18 sheets
Shred Speed Max Sheet Capacity.............................12 ft/min (3.66 m/min)
Intake Throat Width .............................................................9.06” (230mm)
Voltage ........................................................................................ 120V/60Hz
Dimensions (L x W x H)........ 16.54” x 13.19” x 26.26” (420 x 335 x 667mm)
Weight.................................................................................... 46.3 lb (21 kg)
Receptacle Volume ..................................................10 gallons (37.85 liters)
Noise Level (Motor) ........................................................................... 60 dB
III
6
http://www.monomachines.com/
http://www.monomachines.com/

Commercial Shredder Series
3
years
LIFE
TIME
limited limited
20-Sheet Cross-Cut GXC200T product cutter
warranty warranty
Innovative Features
VorteX
™
Cutting System
•
Technology
•
•
InfoCenter
™
LCD panel
•
Overfeed Prevention Technology
•
Dynamic Bin-Full Indicator
•
T-Door
™ Space-Saving Design
CD/DVD Throat
•
Separate Waste Bin
•
ParticleSweeper
™
Waste Leveler
•
All-Quiet
™
Operation
Recommended Supplies
•
Prolong your shredder life. (Item #GLS24)
clear shredder bags
•
Customized size for this shredder model.
(Item #GBL-2212D)
Technical Specifications
Model ............................................................................................ GXC200T
Cutting Style .................................................................................Cross-Cut
Shred Size ............................................................... 0.16”x1.38” (4 x 35mm)
Sheet Capacity ............................................................................... 20 sheets
Shred Speed Max Sheet Capacity ......................... 12.14 ft/min (3.7 m/min)
Intake Throat Width .............................................................9.45” (240mm)
Voltage ........................................................................................ 120V/60Hz
Dimensions (L x W x H)........ 17.52” x 14.45” x 32.01” (445 x 367 x 813mm)
Weight................................................................................84.22 lb (38.2 kg)
Receptacle Volume ................................................... 15 gallons (56.8 liters)
Noise Level (Motor) ........................................................................... 53 dB
IV
7
http://www.monomachines.com/
http://www.monomachines.com/

Commercial Shredder Series
3
years
LIFE
TIME
limited limited
30-Sheet Strip-Cut GSC3020T product cutter
warranty warranty
Innovative Features
Technology
•
•
InfoCenter
™
LCD panel
•
Overfeed Prevention Technology
•
T-Door
™ Space-Saving Design
CD/DVD Throat
•
Separate Waste Bin
•
All-Quiet
™
Operation
• Solid Steel Cutters
Recommended Supplies
•
Prolong your shredder life. (Item #GLS24)
clear shredder bags
•
Customized size for this shredder model.
(Item #GBL-3212E)
V
Technical Specifications
Model ........................................................................................... GSC3020T
Cutting Style ..................................................................................Strip-Cut
Shred Size ................................................................................ 0.24” (6mm)
Sheet Capacity ............................................................................... 30 sheets
Shred Speed Max Sheet Capacity ......................... 20.67 ft/min (6.3 m/min)
Intake Throat Width ........................................................... 10.43” (265mm)
Voltage ........................................................................................ 120V/60Hz
Dimensions (L x W x H)........ 21.34” x 18.11” x 34.92” (542 x 460 x 887mm)
Weight................................................................................. 95.9 lb (43.5 kg)
Receptacle Volume ..................................................27.2 gallons (103 liters)
Noise Level (Motor) ........................................................................... 53 dB
8
http://www.monomachines.com/
http://www.monomachines.com/
•

VI
Commercial Shredder Series
3
years
LIFE
TIME
limited limited
16-Sheet Cross-Cut GXC1620T product cutter
warranty warranty
Innovative Features
VorteX
™
Cutting System
•
Technology
•
•
InfoCenter
™
LCD panel
•
Overfeed Prevention Technology
•
Dynamic Bin-Full Indicator
•
T-Door
™ Space-Saving Design
CD/DVD Throat
•
Separate Waste Bin
•
ParticleSweeper
™
Waste Leveler
•
All-Quiet
™
Operation
Recommended Supplies
•
Prolong your shredder life. (Item #GLS24)
clear shredder bags
•
Customized size for this shredder model.
(Item #GBL-3212E)
Model .......................................................................................... GXC1620T
Cutting Style .................................................................................Cross-Cut
Shred Size ............................................................... 0.16”x1.38” (4 x 35mm)
Sheet Capacity ............................................................................... 16 sheets
Shred Speed Max Sheet Capacity ......................... 20.67 ft/min (6.3 m/min)
Intake Throat Width ........................................................... 10.43” (265mm)
Voltage ........................................................................................ 120V/60Hz
Dimensions (L x W x H)........ 21.34” x 18.11” x 34.92” (542 x 460 x 887mm)
Weight.................................................................................101.41 lb (46 kg)
Receptacle Volume ..................................................27.2 gallons (103 liters)
Noise Level (Motor) ........................................................................... 53 dB
Technical Specifications
9
http://www.monomachines.com/
http://www.monomachines.com/

Diagram
Dynamic VoiceAssist™ VoiceAssist™ InfoCenter™
CD/DVD
Throat
LCD PanelVolume ControlBin Full
Indicator
Toggle Button
Reverse
Forward
STOP
button
GoECO™
“On” switch
VoiceAssist™
Technology
Dynamic
Bin Full
Indicator
Casters
Control
Panel
Buttons
Paper Feed
Throat
T-Door
Space Saving
Design
10
http://www.monomachines.com/
http://www.monomachines.com/

VoiceAssist™ & InfoCenter™ Features
On/Off
VoiceAssist™
Toggle Button
VoiceAssist™
Volume Control
Button
The VoiceAssist™ feature works in conjunction with the InfoCenter™
display below. To activate, push the “INFO” button and the VoiceAssist™
system will verbally explain the status of the shredder and will help you
troubleshoot the most common problems which may arise during the
operation of the shredder.
InfoCenter™ LCD Panel for
Commercial Shredders
I II III InfoCenter™ LCD Panel for
Commercial Shredders
IV V VI
Bin Full Indicator & Control Panel Features
• The Bin Full Indicator will light
up in different colors to display
the current amount of shredded
waste in the waste bin.
The illustration below shows
each color and the corresponding
waste level.
Available only on Commercial
Shredders: IV VI
Red - Full
Orange - 3/4 Full
Yellow - 1/2 Full
Green - 1/4 Full or less
• The control panel contains the
main operation functions.
Please see the “Operation”
section starting on page 16 for
instructions on these buttons.
Reverse
Forward
STOP
GoECO™
“On” switch
“On” switch
STOP
GoECO™
11
http://www.monomachines.com/
http://www.monomachines.com/
ON FWD Door Open
Reverse Overload
Bin Full Overheat
AUTO 'XX7lI 7Jl
Reverse ~ D
Bin Full IJ~
Door Open I
Overload ~[. J
Overheat ~lllii

Environmentally
Preferable Packaging
...the green option
oss-cut 20-Sheet Cross-cut
GXC200T
30-Sheet Strip-cut
GSC3020T
16-Sheet Cross-cut
GXC1620T
16.0 / 60.6 27.7 / 105.0 27.7 / 105.0
2 years 3 years 3 years 3 years
7 years lifetime lifetime lifetime
#&-",,-
rtification protocol which requires third-party life cycle assessment
lidated renewable energy and reforestation projects. To learn Printed on post consumer waste recycled
paper with soy-based inks.
)'',
Certified CarbonFree®*
Featuring
Cutting System
ParticleSweeper™
Waste Leveler
RoHS
Energy-Saving Technology Meets RoHS standards that
prevents phantom power loss restrict the use of
hazardous substances
12-Sheet Micro-cut 16-Sheet Cross-cut 18-Sheet Cr
GMC120D GXC160T GXC180T
VorteX™ Cutting System
InfoCenter™ LCD Panel
T-Door Space-Saving Design
Dynamic Bin Full Indicator
ParticleSweeper™ Waste Leveler
VoiceAssist™ Troubleshooting
Limited Product Warranty
Bin Size (Gallons/Liters)
Separate CD/DVD Waste Bin
ZeroJam™ Overfeed Prevention
3
3
3
3
3
6.1 / 23.1
3
3
3
3
3
7.0 / 26.5 10.0 / 37.8
2 years 2 years
Limited Cutter Warranty 7 years 7 years
*This product is carbon neutral. It meets Carbonfund.org’s CarbonFree® Product Ce
of the product’s carbon footprint, and carbon reductions in support of third-party va
more, visit www.carbonfund.org/products.
http://www.monomachines.com/
http://www.monomachines.com/

Energy-Saving Technology
prevents phantom power loss Meets RoHS standards that
restrict the use of
hazardous substances
RoHS
12-Sheet Micro-cut
GMC120D
16-Sheet Cross-cut
GXC160T
Cutting System
Featuring
ParticleSweeper™
Waste Leveler
Certified CarbonFree®*
VorteX™Cutting System
InfoCenter™LCD Panel
T-Door Space-Saving Design
Dynamic Bin Full Indicator
ParticleSweeper™Waste Leveler
VoiceAssist™Troubleshooting
Limited Product Warranty
Bin Size (Gallons/Liters)
Separate CD/DVD Waste Bin
ZeroJam™Overfeed Prevention
6.1 / 23.1 7.0 / 26.5
2 years 2 years
Limited Cutter Warranty 7 years 7 years
)''
*This product is carbon neutral. It meets Carbonfund.org’s CarbonFree® Product Ce
of the product’s carbon footprint, and carbon reductions in support of third-party v
more, visit www.carbonfund.org/products.
,#&-",,-
...the green option
Environmentally
Preferable Packaging
Preferable Packaging
18-Sheet Cross-cut 20-Sheet Cross-cut 30-Sheet Strip-cut 16-Sheet Cross-cut
GXC180T GXC200T GSC3020T GXC1620T
3
3
3
3
3
10.0 / 37.8
3
3
3
3
3
3
3
3
16.0 / 60.6
3
3
3
3
3
3
27.7 / 105.0
3
3
3
3
3
3
3
27.7 / 105.0
2 years 3 years 3 years 3 years
7 years lifetime lifetime lifetime
rtification protocol which requires third-party life cycle assessment
alidated renewable energy and reforestation projects. To learn Printed on post consumer waste recycled
paper with soy-based inks.
http://www.monomachines.com/
http://www.monomachines.com/

WARNINGS !!
CAUTION: KEEP THIS DEVICE AWAY FROM CHILDREN AND
PETS! Place the paper shredder in an area less accessible to children.
DO NOT PLACE FINGERS TOO CLOSE TO THE FEED SLOT AS
SERIOUS INJURY MAY OCCUR. Paper shredders can pull children’s
fingers into the shredder mechanism.
AVOID GETTING LOOSE CLOTHING OR JEWELRY NEAR THE
FEED SLOT.
AVOID GETTING HAIR NEAR THE FEED SLOT.
NEVER spray any aerosol-based products in or around the shredder.
NEVER dispose of flammable chemicals, or materials that have
come into contact with flammable chemicals (for example, nail polish,
acetone, gasoline) in the shredder basket. NEVER use any petroleum
based or flammable oils or lubricants in or around the machine, as
some oils can combust causing serious injury. Lubricants specifically
designed for shredders are acceptable.
NEVER place the shredder near water or any heat source.
Avoid direct contact with water.
DO NOT SHRED PAPERS WITH PAPER CLIPS ON THEM.
Please take out any paper clips from paper before shredding.
STOP USE IMMEDIATELY IF:
1. The shredder blades become wadded up with paper.
2. The shredder motor makes loud and/or irregular noises
during operation.
3. The shredder blades or paper guides become bent or
compromised in any way.
Continuing to operate your shredder with any of the above
conditions present could be potentially dangerous.
14
http://www.monomachines.com/
http://www.monomachines.com/

Installation
• Refer to set-up instructions printed on carton box for proper assembly.
• Only operate this product from the type of power source indicated on the
marking label. If you are not sure of the type of power available, consult
an electrician.
• Make sure the electrical outlet is easily accessible from the shredder.
• Shredder must be operated only in upright position.
• To make sure the shredder has proper ventilation, place it a minimum
distance of 5cm from the wall or furniture.
Safety Instructions
1. Read and follow all instructions before use. Save these instructions for later use.
2. Always turn off and unplug the machine before moving, servicing,
cleaning, or anything other than normal operation. Serious injury may
result. Clean shredder with a damp cloth, using a mild soap and water
solution.
3. Do not use abrasives or petroleum-based cleaners.
4. Place this product as close as possible to power source for quick and easy
unplugging.
5. Turn off the power switch before removing waste bin. It is advisable to
disconnect the power cord before opening the shredder.
6. This product should never be placed near a radiator or other heat source.
7. Do not allow anything to rest on the power cord. Do not place the power
cord where people may walk on the it.
8. If an extension cord is used with this product, make sure the total of the
ampere (amps) ratings on the products plugged into the extension cord do
not exceed the extension cord’s ampere rating.
9. Do not attempt to service this product yourself, as in opening or removing
covers may expose you to risks of getting injured. Also, doing this will
void the warranty of the shredder.
10. Unplug this product and contact technical support when:
• The power cord or plug is damaged or frayed.
• Liquid has been spilled on the product.
• The product has been exposed to rain.
• The product does not operate normally even when the operating
instructions are followed.
• The product has been dropped, or the casing has been damaged.
11. This shredder should be operated only with an operator in attendance.
12. Regularly empty the waste bin so that the waste output is not impeded.
13. This machine can shred normal paper, credit cards, CDs and DVDs.
However, you should shred only one of these items at a time to avoid
causing an overload.
15
http://www.monomachines.com/
http://www.monomachines.com/

Operation
Please read operating instructions before putting shredder into operation.
TO POWER ON:
1. Connect the power cord to any standard 120V AC, 60Hz outlet.
2. Toggle the power switch to the ON position.
FOR NORMAL OPERATION:
3. Press the green power saving switch to turn ON
the shredder. It will clean the paper/run automatically for
2 seconds. Depending on the model of the shredder,
the LCD will display either “ON” or “AUTO”. The
“GoECOlife” logo will light on and the shredder is
then in AUTO status. (The “GoECOlife” logo does
not light up on the GMC120D model.)
the shredder. It will clean the paper/run automatically for
AUTO
ON
or
I II III
For Commercial Shredders:
For Commercial Shredders:
IV V VI
4. Feed up to the maximum allowed sheets of paper for shredding into the
paper feeding throat.
5. When you press the ”INFO” button, it will speak from 1st voice
assistance to the last one (Auto / Reverse / bin full / door open / overload
/ overheat). It will skip to the next message each time you press the
“INFO” a button until the last message. Press the “speaker” shape
button to adjust the volume.
16
http://www.monomachines.com/
http://www.monomachines.com/

Operation (cont’d)
TO PUT INTO REVERSE MODE:
6. Press the “R” button on the control panel.
•
will move in reverse to push out the paper sheets.
• Depending on the model of the
shredder, the LCD display will look
like the diagram shown.
• For assistance in the VoiceAssist™
mode, press the button “INFO” and
the voice assistance will tell you
which mode you are in.
• To deactivate the VoiceAssist™ mode, or
press the button “INFO” again.
The shredder is now in Reverse mode, and the motor
Reverse
I II III
For Commercial Shredders:
Reverse
For Commercial Shredders:
IV V VI
TO PUT INTO FORWARD MODE:
7. Press the “F” button on the control panel.
• The shredder is now in forward mode,
and the motor will move forward to shred paper.
• Depending on the model of the
shredder, the LCD display will look FWD
like the diagram shown.
For Commercial Shredders:
I II III
or
For Commercial Shredders:
IV VIV
17
http://www.monomachines.com/
http://www.monomachines.com/

Operation (cont’d)
TO PUT BACK INTO AUTO MODE:
8. Press the green GoECO™ button on the control panel.
• The shredder is now in AUTO mode, and when
you insert papers into the paper throat, the shredder
will start automatically.
• Depending on the model of the
shredder, the LCD display will look
like the diagram shown.
• For assistance in the VoiceAssist™
mode, press the button, “INFO”,
and the VoiceAssist™ function will
announce the problem and solution. or
• To deactivate the VoiceAssist™ mode, AUTO
press the button “INFO” again.
FOR PAPER JAMS:
9. If you insert more than the maximum number of paper sheets allowed
and jamming occurs, the machine will automatically go into reverse to
push out the jammed papers.
• Depending on the model of the
shredder, the LCD display will look
like the diagram shown.
Overload
• The Red LED light underneath the button
For Commercial Shredders:
“INFO” will flash to warn the user.
• Press the button, “INFO”, and the
I II III
or
VoiceAssist™ function will announce the
problem and solution.
• To deactivate the VoiceAssist™ mode,
press the button “INFO” again.
ON FWD
I II III
For Commercial Shredders:
For Commercial Shredders:
IV VVI
Overload
For Commercial Shredders:
IV V VI
18
http://www.monomachines.com/
http://www.monomachines.com/
