gofanco USBCharge7PW User manual

1
7-Port USB Charging Station
User's Guide
G4-0004B
®

2
Introduction
The gofanco 7-Port Charging Station can charge up to
7 USB-powered devices simultaneously
and keep them organized.
Congratulationsforowningagofancoproduct.Ourproducts
aim to meet all your connectivity needs wherever you go.
Have fun with our products!
Please read this manual carefully before first use.
If you need more information about our products, please
visit www.gofanco.com.
For technical support, please email us at support@gofanco.
com.
For drivers/manuals download, please go to http:// www.
gofanco.com/download.

3
Features & Specifications
Port 7 USB Charging Ports
Input AC 100~240V / 50-60Hz, 1.5A
USB Output 2.4A (Max.) / per port
Total: DC 5V / 13A (Total output capacity)
Power DC 19V / 3.42A, 64.98W (Max.)
Each Interval Space 0.75"
Size 7.48" (W) x 2.63" (H) x 5.51" (D)
Weight 13.4oz
Operating Temperature 32F ~ 104F
Storage Temperature -4F ~ 185F
Package Contents
• 7-Port USB Charging Station - Black/White
• Power adapter & AC power cord
• User's Guide

4
USB charging port
Power jack
On/off button
Figure 1: 7-Port USB Charging Station
•On /Off button: Press to turn on/off the charging
station.
•USB charging ports (x7): Connect devices here to charge.
•Power jack: Connect the power adapter here.
Power Jack's Specifications:
Product Layout
L
ID
OD

5
Installation
1. Insert the power plug into the charging station's power
jack.
2. Plug the AC power adapter into a reliable 100V-240V
wall outlet.
3. Verify the green LED on the power adapter is lit to ensure
it's receiving power.
Figure 2: Power Adapter & AC Power Cord
Table 1: Power Plug Specifications
Outside
diamet-
er (OD)
Inside
diameter
(ID)
Plug
length
(L)
Negative / Positive
5.5(mm) 2.5(mm) 12(mm)
*Center pin for positive voltage and
the outer shield for negative voltage

6
Figure 4
Anti-Slip pad
Anti-Slip pad
Figure 3
Anti-slip pad
Anti-slip pad
5. PresstheOn/Offbutton to power onthe charging station.
The power button should be lit with a blue LED.
6. Plug in your devices via their USB charging cables.

7
FAQ & Solutions
If the charger station isn't functioning properly:
• Check that the charger station is plugged into a
functioning wall socket.
• Check that the green LED on the power adapter is lit to
ensure that it is receiving power.
• Check that the USB cord is firmly inserted into both the
charger station and your USB device.
• Check that the total wattage for all connected USB
devices is under 65W.
• Check that the power of the charger is on.
Safety Notice
• Check that the wall outlet you are using is within the
AC 100 - 240V range
• Do not place the charger on heated seats or against
other heat sources
• Do not attempt to replace any part of the charger on
your own
• Do not expose the charger to liquids or excessive
heat
• Do not use any corrosive cleaning substances on the
charger
• Keep out of reach from children

®
Thank you for choosing gofanco
www.gofanco.com
